1. Introduction
1.1 What is LIG16 Indoor LoRaWAN Gateway
The LIG16 is an open source LoRaWAN Pico Gateway. It lets you bridge LoRa wireless network to
an IP network via WiFi, Ethernet network. The LoRa wireless allows users to send data and reach
extremely long ranges at low data-rates.
The LIG16 supports Semtech packet forwarder and LoRaWAN Station connection, it is fully
compatible with LoRaWAN protocol. It includes a SX1302 LoRa concentrator, which is the new
generation baseband LoRa chip for gateway with lower current consumption and higher amount
of traffic than preceding devices.
LIG16 has pre-configured standard LoRaWAN frequency bands to use for different countries.
User can also customize the frequency bands to use in their own LoRaWAN network.
LIG16 can communicate with ABP LoRaWAN end node without LoRaWAN server. System
integrator can use it to integrate with their existing IoT Service without set up own LoRaWAN
server or use 3rd party LoRaWAN service.
LIG16 supports auto-provision for mass deployment and long term maintain. System integrator
can easily change the configure remotely.

www.dragino.com
LIG16 Indoor LoRaWAN Gateway User Manual 6 / 46

www.dragino.com
LIG16 Indoor LoRaWAN Gateway User Manual 7 / 46
1.2 Specifications
Hardware System:
Linux Part:
➢400Mhz ar9331 processor
➢64MB RAM
➢16MB Flash
Interface:
➢10M/100M RJ45 Ports x 1
➢WiFi : 802.11 b/g/n
➢LoRaWAN Wireless
➢Power Input: USB Type C. 5V , 2A
➢USB 2.0 host connector x 1
➢SX1302 + 2 x SX1250
WiFi Spec:
➢IEEE 802.11 b/g/n
➢Frequency Band: 2.4 ~ 2.462GHz
➢Tx power:
✓11n tx power : mcs7/15: 11db mcs0 : 17db
✓11b tx power: 18db
✓11g 54M tx power: 12db
✓11g 6M tx power: 18db
➢Wifi Sensitivity
✓11g 54M : -71dbm
✓11n 20M : -67dbm
LoRa Spec:
➢70 dB CW interferer rejection at 1 MHz offset
➢Up to -141 dBm sensitivity with SX1250 Tx/Rx front-end
➢125 kHz LoRa reception with:
8 x 8 channels LoRa® packet detectors
8 x SF5-SF12 LoRa® demodulators
8 x SF5-SF10 LoRa® demodulators
➢125 /250 / 500 kHz LoRa® demodulator
Power Consumption:
➢Max: 5v, 410mA

www.dragino.com
LIG16 Indoor LoRaWAN Gateway User Manual 8 / 46
1.3 Features
✓Open-Source Linux system
✓Managed by Web GUI, SSH via LAN or WiFi
✓LoRaWAN Gateway
✓Auto-Provision
1.4 Hardware System Structure
1.5 LIG16 Applications

www.dragino.com
LIG16 Indoor LoRaWAN Gateway User Manual 9 / 46
1.6 LED Indicators
LIG16 has totally 6 LEDs:
➢Power LED : This YELLOW LED will be solid on if the device is properly powered.
➢HEART LED : This GREEN LED will be solid on if there is LoRaWAN connection.
➢SYS LED :This LED will show different colors on different state:
✓ON: device have Internet connection.
✓BLINKING: a) Device has internet connection but no LoRaWAN Connection. or b)
Device is in booting stage, in this stage, it will BLINKING for several seconds.
✓OFF: device doesn’t have Internet connection.
➢TRIANGLE LED : No Function.
➢ETH LED : This LED shows the ETH interface physical connection status.
➢WiFi LED : This LED shows the WiFi interface connection status.
