PRODUCT
INSTALLATION MANUAL
SLIM FENDERS
2020+ JEEP WRANGLER JT
FDGL-07
TOOLS REQUIRED SKILL LEVEL TIME REQUIRED
- Trim Clip Tool
- 4, 5mm Allen Bit
- 4mm “L” Shaped Allen Tool
- 10, 12, 13mm Wrench
- Angle Grinder or Cutting Tool of Choice
- Spray Paint
- Zip Ties (Optional)
Before you install this kit — Read and understand all
instructions, warnings, cautions, and notes contained in
this installation instruction guide. Consult your vehicle
owner’s manual for proper disconnection of electrical and
lifting of vehicle if required for installation of this product.
This install may require some technical skills and
knowledge of basic mechanical work. If you do not feel that
you are capable of performing this install please take this
product to a trained professional.
After reading this guide please contact us with any
questions or concerns before installing product.
Customer Service: 855-680-9595
DV8 Offroad is not responsible for any bodily injury or harm to you
or your vehicle as a result of an improper install.
Proper installation of this kit required knowledge of the factory
recommended procedures for removal and installation of original
equipment components. We recommend that the factory shop manual
and any special tools needed to service your vehicle be on hand during
the installation. Installation of this kit without proper knowledge of the
factory recommended procedures may affect the performance of these
components and the safety of the vehicle
• Always wear eye protection when operating power tools
Inspect all contents of this package to make sure product is not damaged
and all installation hardware has been included. If parts are missing from
kit, please be prepared to provide the following information
1. Name of purchase location
2. Bar Code on side of box
3. Date above bar code
4. Date inside box cover
- Novice/Intermediate
- 1 (you) to 2 persons
Little skill level required, you can
easily install it by yourself however,
additional help will be useful.
- 2.5 Hours
Time to install this should only
take about two and a half hours.
WARNINGS/CAUTIONS BEFORE STARTING INSTALLATION
855-680-9595
NEED HELP?

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 1 | Use a 10mm socket to
remove the bolts along the top and at the
front of the inner fender.
Use a trim clip tool to remove the clips on
interior of the inner fender.
Use a trim clip tool to remove the clips
running along the outside lip, securing
the inner fender to the vehicle.
Remove inner fender by pulling down,
then out.
Note: Pictured are un-install and installation of
the passenger side fender.
FRONT UNINSTALL

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 2 | Unplug the turn signal
indicator by pulling the red release tab
out and pulling.
STEP 3 | Use a 10mm socket to
remove the bolt securing the fender to the
vehicle.
Then, remove the fender by pulling away
from the vehicle to release the clips.
Be sure to pull “straight” away from the
vehicle to avoid breaking clips.
Clips will not be re-used, breaking one or
two is normal and nothing to worry about.
STEP 4 | Use a trim clip tool to
remove the factory clips along the fender.
Repeat process for the other side.

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 5 | Use a 8mm socket to
remove the bolts located along the
interior of the inner fender.
Then, use a trim clip tool to remove the
clips located in each corner of the fender.
REAR UNINSTALL

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 6 | Remove the fender are
by pulling the front section towards the
front of the vehicle, and the rear section
towards the rear.
Then pull the fender directly “away” from
the vehicle, to release the remaining clips.
On the JT, you should be able to reach
around and squeeze the clips to remove if
needed.
STEP 7 | Use a trim clip tool to
remove the clips along the edge of the
fender that remained in the vehicle.
Repeat process for the other side.
