DV8 OFFROAD CCBR-01 User manual

6400 SYCAMORE CANYON BLVD.
RIVERSIDE, CALIFORNIA 92507
855-680-9595
WWW.DV8OFFROAD.COM
PRODUCT
INSTALLATION MANUAL
CENTER CONSOLE AND BRIDGE
2021+ FORD BRONCO
CCBR-01
TOOLS REQUIRED SKILL LEVEL TIME REQUIRED
-4mm Allen Bit
-Drill
-11/32” Drill Bit
-10mm wrench
Before you install this kit — Read and understand all
instructions, warnings, cautions, and notes contained in
this installation instruction guide. Consult your vehicle
owner’s manual for proper disconnection of electrical and
lifting of vehicle if required for installation of this product.
This install may require some technical skills and
knowledge of basic mechanical work. If you do not feel that
you are capable of performing this install please take this
product to a trained professional.
After reading this guide please contact us with any
questions or concerns before installing product.
Customer Service: 855-680-9595
DV8 Offroad is not responsible for any bodily injury or harm to you
or your vehicle as a result of an improper install.
Proper installation of this kit required knowledge of the factory
recommended procedures for removal and installation of original
equipment components. We recommend that the factory shop manual
and any special tools needed to service your vehicle be on hand during
the installation. Installation of this kit without proper knowledge of the
factory recommended procedures may affect the performance of these
components and the safety of the vehicle
• Always wear eye protection when operating power tools
Inspect all contents of this package to make sure product is not damaged
and all installation hardware has been included. If parts are missing from
kit, please be prepared to provide the following information
1. Name of purchase location
2. Bar Code on side of box
3. Date above bar code
4. Date inside box cover
- Novice/Intermediate
- 1 (you) to 2 persons
Little skill level required, you can
easily install it by yourself however,
additional help will be useful
- 2 Hours
Time to install this should only
take about two hours.
WARNINGS/CAUTIONS BEFORE STARTING INSTALLATION
855-680-9595
NEED HELP?

Place the driverside mount up to the center
console. The top of the mount will line up
with the top of the plastic.
With the mount aligned, mark the holes on
the mounting tabs.
INSTALLATION MANUAL
NEED HELP? 855-680-9595
-(14) M6x15 Allen Head
-(14) M6 Flat Washers
-(6) M6 Split Washers
-(8) M6 Serrated Nuts
HARDWARE INCLUDED
Begin by unpacking all items and
inspecting for missing pieces or damage. If
you have any concerns, please contact the
company the product was purchased from.
STEP 1
STEP 2

Repeat steps 1-4 with the passenger side
mount. The top of the mount will align with
the center console trim and grab bar handle.
Align the driver side mount with the mount-
ing holes and press the M6x15 hardware
into the drilled out holes, to loosely hold
the mount in place. Pull back on the center
console trim from the bottom to t the M6
nuts into place.
Thread the nut onto the m6 bolt two or three
threads only, secure with a 4mm allen bit
while applying pressure with your hand un-
der the center console until the nut “catch-
es” and tightens.
Repeat this process for the other three bolts
until the driver side mount is secure.
Use a 11/32” drill bit to drill out the marked
mounting positions.
Drill accurately and carefully to avoid scuff-
ing the trim unnecessarily.
INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 4
STEP 3
STEP 5

Double check tment and all hardware is
secure. Congratulations, you are nished
with the install of the Bronco Center Console
and Bridge.
Slide the bridge into place over the grab bar
handle as shown. Align the bridge with the
handle and the dash, and secure using a
4mm allen bit and provided M6 hardware.
INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 6
STEP 7
