DV8 OFFROAD SRGX-02 User manual

6400 SYCAMORE CANYON BLVD.
RIVERSIDE, CALIFORNIA 92507
855-680-9595
WWW.DV8OFFROAD.COM
PRODUCT
INSTALLATION MANUAL
SLIDER RAILS
03-09 Lexus GX470
SRGX-02
TOOLS REQUIRED SKILL LEVEL TIME REQUIRED
- 18mm, 13mm wrenches
- Safety Glasses
Before you install this kit — Read and understand all
instructions, warnings, cautions, and notes contained in
this installation instruction guide. Consult your vehicle
owner’s manual for proper disconnection of electrical and
lifting of vehicle if required for installation of this product.
This install may require some technical skills and
knowledge of basic mechanical work. If you do not feel that
you are capable of performing this install please take this
product to a trained professional.
After reading this guide please contact us with any
questions or concerns before installing product.
Customer Service: 855-680-9595
DV8 Offroad is not responsible for any bodily injury or harm to you
or your vehicle as a result of an improper install.
Proper installation of this kit required knowledge of the factory
recommended procedures for removal and installation of original
equipment components. We recommend that the factory shop manual
and any special tools needed to service your vehicle be on hand during
the installation. Installation of this kit without proper knowledge of the
factory recommended procedures may affect the performance of these
components and the safety of the vehicle
• Always wear eye protection when operating power tools
Inspect all contents of this package to make sure product is not damaged
and all installation hardware has been included. If parts are missing from
kit, please be prepared to provide the following information
1. Name of purchase location
2. Bar Code on side of box
3. Date above bar code
4. Date inside box cover
- Novice/Intermediate
- 2 persons
Little skill level required, additional
help is required.
- 3 Hour
Time to install this should only
take about three hours.
WARNINGS/CAUTIONS BEFORE STARTING INSTALLATION
855-680-9595
NEED HELP?

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 1 | Install the slide rails center
nut plate in-between the fuel tanks skid
plate and frame rail.
Be sure the nut plate is centered and the
M12 nuts can are aligned with the large
square and circle holes in the frame rail.
Begin by unpacking all items and inspecting
for missing pieces or damage. If you have any
concerns, please contact the company the
product was purchased from. Extra hardware
may be included with the product.
(3) M12x120 Bolts
(3) M12x105 Bolts
(2) M12x140 Bolts
(8) M12 Split Washers
(11) M12 Flat Washers
(2) M8x25 Bolts
(2) M8 Spring Washers
(2) M8 Washers
(6) M6x25 Bolts
(6) M6 Flat Washers
(6)M6 Nutserts
HARDWARE INCLUDED

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 2 | With assistance, loosely
secure the slider rails to the frame using
provided M12x140 hex bolts using a 18mm
wrench.
Start with the front bracket.
STEP 3 | Loosely attach the slider
rails center mount to the frame using the
provide M12x105 hex bolts using a 18mm
wrench.

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 4 | Install the rear slider mount
nut plate with handle behind the frame
rail.
STEP 5 | Loosely secure the rear
slider mount using a M12x105 hex bolt
into the nut plate with handle using a
18mm wrench.
STEP 6 | Make any minor up/down
and front/rear adjustments.
Use a M8x25 Hex bolt and 13mm wrench
to secure any up/down adjustment made.

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 7 | Use a 18mm wrench to
secure all M12 hardware.
STEP 8 | Check clearance of all
hardware.

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 9 | Loosely secure the front
slider rail mount to the frame using a
M12x140 hex bolt,square nut plate and
18mm wrench.
STEP 10 | Loosely secure the slider
rail center mount to the frame using
provided M12x120 hex bolts, square nut
plate and 18mm wrench.
STEP 11 | Loosely secure the rear
slider rail mount to the frame using a
M12x120 hex bolt, square nut plate and
18mm wrench.

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 12 | Make any minor up/down
or front/rear adjustments. Use a M8x25
hex bolt and 13mm wrench to secure any
up/down adjustments made.
STEP 13 | Secure all M12 hardware
STEP 14 | Double check all hardware
is secure.
Congratulations, you are nished
installing the DV8 03-09 Lexus GX470
slider rails/ SRGX-02.
