DV8 OFFROAD MPGX-02 User manual

6400 SYCAMORE CANYON BLVD.
RIVERSIDE, CALIFORNIA 92507
855-680-9595
WWW.DV8OFFROAD.COM
PRODUCT
INSTALLATION MANUAL
GX460 REAR INTERIOR
MOLLE PANEL
2010-2022 LEXUS GX460
MPGX-02
TOOLS REQUIRED SKILL LEVEL TIME REQUIRED
-Ratchet
-10mm Wrench
-10mm Socket
-4mm Allen Bit
-Trim Clip Removal Tool
Before you install this kit — Read and understand all
instructions, warnings, cautions, and notes contained in
this installation instruction guide. Consult your vehicle
owner’s manual for proper disconnection of electrical and
lifting of vehicle if required for installation of this product.
This install may require some technical skills and
knowledge of basic mechanical work. If you do not feel that
you are capable of performing this install please take this
product to a trained professional.
After reading this guide please contact us with any
questions or concerns before installing product.
Customer Service: 855-680-9595
DV8 Offroad is not responsible for any bodily injury or harm to you
or your vehicle as a result of an improper install.
Proper installation of this kit required knowledge of the factory
recommended procedures for removal and installation of original
equipment components. We recommend that the factory shop manual
and any special tools needed to service your vehicle be on hand during
the installation. Installation of this kit without proper knowledge of the
factory recommended procedures may affect the performance of these
components and the safety of the vehicle
• Always wear eye protection when operating power tools
Inspect all contents of this package to make sure product is not damaged
and all installation hardware has been included. If parts are missing from
kit, please be prepared to provide the following information
1. Name of purchase location
2. Bar Code on side of box
3. Date above bar code
4. Date inside box cover
- Novice/Intermediate
- 1 (you) to 2 persons
Little skill level required, you can
easily install it by yourself, however
additional help will be useful
- 2 Hour
Time to install this should only
take about two hours.
WARNINGS/CAUTIONS BEFORE STARTING INSTALLATION
855-680-9595
NEED HELP?

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 1 | These instructions are for the
passenger side of the vehicle.
Install the larger “L” shaped bracket on
the side of the molle panel that does not
show the DV8 logo. Loosely secure using
provided M6x16 hardware with a 10mm
wrench and 4mm allen bit.
Tip: M6x16 is the second shortest hardware in
the kit. The shortest will be used near the end of
the install.
Begin by unpacking all items and
inspecting for missing pieces or damage.
If you have any concens, please contact the
company the product was purhcased from.
Extra hardware may be included.
- (2) M6x25 Allen Head
-(18) M6x16 Allen Head
-(2) M6x12 Allen Head
-(44) M6 Flat Washers
-(18) M6 Nylon Lock Nuts
HARDWARE INCLUDED
BACKSIDE OFBACKSIDE OF
LOGOLOGO

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 2 | Install the lower brackets
on the side that does not show the DV8
logo. Loosely secure using provided M6x16
hardware with a 10mm wrench and 4mm
allen bit. Notice the rubber bumpers
orientation in relation to the DV8 logo.
STEP 3 | Install the smaller “L”
brackets onto the upper bracket and
secure using provided M6x16 hardware
with a 4mm allen bit and 10mm wrench.
Note: The bend shown in the circles
should face towards the logo side.
RUBBER
BUMPER
LOGO

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 4 | The aluminum spacer has
two places to insert hardware. Identify
the deeper side and secure the provided
threaded post using a 4mm Allen bit.
Tip: You may choose to use a
small amount of superglue or
locktite for increased strength.
STEP 5 | Moving to the vehicle, undo
the clips for the grab bar handles located
above the rear window and remove the
hardware using a 10mm socket. Save the
hardware for later use.

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 6 | Remove the plastic trim
cover located under the rear window
using a trim clip removal tool. Remove the
hardware using a 10mm socket.
Insert the spacer using the threaded post
from step 4.
STEP 7 | Loosely secure the molle
panel into place using a 10mm socket and
the factory hardware.

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 8 | Secure the bottom of the
molle panel to the spacer using the
provided M6x12 (shortest) hardware and a
4mm allen bit.
Finish securing the top of the molle panel
using a 10mm socket.
STEP 9 | Finish securing the bottom
and lower brackets to the molle panel.
Repeat steps 1-9 for the driver side of the
vehicle.

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 10 | Double check tment and
all hardware is secure. Congratulations,
you are nished with the install of the
GX460 Rear Interior Molle Panels!
