DV8 OFFROAD CMJL-01 User manual

6400 SYCAMORE CANYON BLVD.
RIVERSIDE, CALIFORNIA 92507
855-680-9595
WWW.DV8OFFROAD.COM
PRODUCT
INSTALLATION MANUAL
AIR COMPRESSOR MOUNT
2018+/2020+ JL/JT WRANGLER/GLADIATOR
CMJL-01
TOOLS REQUIRED SKILL LEVEL TIME REQUIRED
- 4mm Allen Bit
- 10mm Wrench
- 10mm Socket
- Trim Clip Tool
- Zipties (Optional)
Before you install this kit — Read and understand all
instructions, warnings, cautions, and notes contained in
this installation instruction guide. Consult your vehicle
owner’s manual for proper disconnection of electrical and
lifting of vehicle if required for installation of this product.
This install may require some technical skills and
knowledge of basic mechanical work. If you do not feel that
you are capable of performing this install please take this
product to a trained professional.
After reading this guide please contact us with any
questions or concerns before installing product.
Customer Service: 855-680-9595
DV8 Offroad is not responsible for any bodily injury or harm to you
or your vehicle as a result of an improper install.
Proper installation of this kit required knowledge of the factory
recommended procedures for removal and installation of original
equipment components. We recommend that the factory shop manual
and any special tools needed to service your vehicle be on hand during
the installation. Installation of this kit without proper knowledge of the
factory recommended procedures may affect the performance of these
components and the safety of the vehicle
• Always wear eye protection when operating power tools
Inspect all contents of this package to make sure product is not damaged
and all installation hardware has been included. If parts are missing from
kit, please be prepared to provide the following information
1. Name of purchase location
2. Bar Code on side of box
3. Date above bar code
4. Date inside box cover
- Novice/Intermediate
- 1 (you) to 2 persons
Little skill level required, you can
easily install it by yourself however,
additional help will be useful.
- 1.5 Hour
Time to install this should only
take about an hour and a half.
WARNINGS/CAUTIONS BEFORE STARTING INSTALLATION
855-680-9595
NEED HELP?

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 1 | Use a trim clip tool to
remove the clips on interior of the inner
fender.
Use a trim clip tool to remove the clips
running along the outside, securing the
inner fender to the vehicle.
Use a 10mm socket to remove the bolts
along the top and at the front of the inner
fender.
Remove inner fender by pulling down,
then out
Note: CMJL-01 is not compatible with factory
inner fenders. If you are running aftermarket
inner fenders, they will be installed after com-
pleting this installation.
UNINSTALL DRIVER SIDE INNER
FENDER

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 2 | Remove the plastic clips
securing the wiring harness to this
bracket. These holes will be utilized to
mount the compressor bracket.
STEP 3 | Prior to installing the
compressor on the mount, prepare the
compressor for installation. Needs may
differ depending on your application.
For our installation, we are using the
quick disconnect hose system on an
ARB Dual Air Compressor, which we
installed on the compressor before
mounting the compressor on the
bracket..
Install the compressor on the mount
using the hardware provided with the
compressor.
Begin by unpacking all items and inspecting
for missing pieces or damage. If you have any
concerns, please contact the company the
product was purchased from. Extra hardware
may be included with the product.
(7) M6x20 Allen
(7) M6 Lock Washers
(14) M6 Flat Washers
(7) M6 Nuts
HARDWARE INCLUDED

INSTALLATION MANUAL
NEED HELP? 855-680-9595
STEP 4 | We recommend connecting
the wire harness provided by ARB prior
to installation and feeding the wiring
up through the engine bay. Connecting
this harness after installation may be
difcult.
Install the mount on the vehicle using
a 4mm allen bit and 10mm wrench and
provided M6 hardware.
Refer to the manufacturers instructions
for wiring your air compressor.
STEP 5 | Congrats! You are nished
with the install of the 2018+/2020+ JL/
JT Wrangler/Gladiator.
