E2S Minialarm IS-MA1-R User manual

_______________________________________________________________________________________________________________________________
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH [email protected] Tel: +44 (0)20 8743 8880
www.e2s.com Fax: +44 (0)20 8740 4200
Document No. IS 5001 Issue H 03-01-2020 Sheet 1 of 6
INSTRUCTION MANUAL
IS-mA1 Minialarm
Intrinsically Safe Round Sounder
1) Introduction
The IS-mA1 minialarm is an ATEX and IECEx certified
intrinsically safe sounder which produces a loud warning
signal in a hazardous area. Forty-nine first stage alarm
sounds can be selected by internal switches and each one
can be externally changed to a second or third stage alarm
sound. The sounder may be used in all gas groups IIA IIB
and IIC.
2) Description
Fig 1 shows a simplified block diagram of an IS-mA1
minialarm sounder. The device operates immediately power
is applied to the + and – terminals which are duplicated to
allow a second sounder to be connected in parallel, or for an
end of line monitoring resistor to be installed. The output tone
is defined by the positions of the six internal switches and this
tone can be changed to a second or third stage alarm tone by
connecting terminals S2 or S3 to 0V. The tone generator is
crystal controlled to ensure that when two sounders
connected to the same power supply are started at the same
time the output tones remain synchronised.
3) Supply Voltage
The IS-mA1 minialarm sounder has been designed to
operate in a hazardous area from a 24V dc supply via 28V
93mA resistive ATEX and IECEx certified Zener Barriers or
Galvanic Isolators. The sounders may be tested or used in
safe areas without a Zener Barrier or Galvanic Isolator, but at
supply voltages above 16V the internal current limit will
function and therefore it is recommended that they are not
operated continuously with a direct supply greater than 16V.
Tone Generator
Tone Selection Switches
Volume Control
IS-mA1 Sounder
_
_
S2
S3
+
+
Fig 1 Simplified block diagram
4) Intrinsic Safety Certification
4.1 ATEX certificate
The IS-mA1 minialarm sounder complies with the following
standards:-
EN IEC 60079-0:2018
EN60079-11:2012
IEC60079-26:2014
The EC-Type Examination Certificate SIRA 05ATEX2084X
has been issued by the Notified Body Sira. This confirms
compliance with the European ATEX Directive 94/9/EC for
Group II, Category 1G equipment. The sounder carries the
Community Mark and subject to local codes of practice, may
be installed in any of the EEA member countries. This
instruction sheet describes installations which conform to
EN60079:Part14:2008 Electrical Installation in Hazardous
Areas. When designing systems for installation outside the
UK, the local Code of Practice should be consulted.
1) The certification marking is as follows:
e
2S
european safety systems ltd. London W3 7QH UK
WARNING:
TO AVOID A POSSIBLE ELECTROSTATIC
CHARGE ONLY CLEAN WITH A DAMP CLOTH
IS-mA1 Sounder
II 1G Ex ia IIC T4 Ga (-40ºC <=Ta<= +60°C)
2813
SIRA 05ATEX2084X
Year / Serial No. 09 / 1MA000001
Ui = 28V Ii = 93mA Pi = 660mW Ci = 0 Li = 0
Terminal + w.r.t. Terminal -
Ui = 28V Ii = 0mA
Terminals S2&S3 w.r.t. Terminal -
www.e2s.com
0786-CPD-20338
EN54-3
Type B
VdS
2) The equipment may be used in zones 0, 1 and 2
with flammable gases and vapours with apparatus
groups IIA, IIB & IIC and with temperature classes
T1, T2, T3 and T4.
The IS-mA1 sounder is CE marked for
compliance with the European
Explosive Atmospheres Directive
2014/34/EU and the European EMC
Directive 2014/30/EU
II 1G Ex ia IIC T4 Ga (-40ºC <= Ta <= +60ºC)

_______________________________________________________________________________________________________________________________
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH [email protected] Tel: +44 (0)20 8743 8880
www.e2s.com Fax: +44 (0)20 8740 4200
Document No. IS 5001 Issue H 03-01-2020 Sheet 2 of 6
3) The equipment is only certified for use in ambient
temperatures in the range -40oC to +60oC and
should not be used outside this range.
4) The certificate number has an ‘X’ suffix, which
indicates that the certificate contains one of more
special conditions for safe use. Those installing or
inspecting the equipment should refer to this section
of the certificate.
5) The equipment has not been assessed as a safety-
related device (as referred to by Directive 94/9/EC
Annex II, clause 1.5).
6) Installation of this equipment shall be carried out by
suitably-trained personnel in accordance with the
applicable code of practice.
7) Repair of this equipment shall only be carried out by
the manufacturer or in accordance with the
applicable code of practice.
8) The certification of this equipment relies on the
following materials used in its construction:
Enclosure: ABS Plastic
If the equipment is likely to come into contact with
aggressive substances, then it is the responsibility of
the user to take suitable precautions that prevent it
from being adversely affected, thus ensuring that the
type of protection is not compromised.
“Aggressive substances” - e.g. acidic liquids or
gases that may attack metals, or solvents that may
affect polymeric materials.
“Suitable precautions” - e.g. regular checks as part
of routine inspections or establishing from the
material’s data sheet that it is resistant to specific
chemicals.
SPECIAL CONDITIONS FOR SAFE USE (as stated in the
EC Type Examination Certificate SIRA 05ATEX2084X)
Conditions for IS-mAl Sounder
The equipment has an ingress protection rating of IP65.
However, if it has been supplied without cable entry devices,
then the user shall ensure that the devices that are fitted will
provide an ingress protection that is appropriate to the
environment in which it is installed i.e. IP20 or better. If only
one of the two cable entries are used, then the unused entry
'knockout' shall be left intact or fitted with a blanking device
that ensures ingress protection appropriate to the
environment in which it is installed i.e. IP20 or better.
The total capacitance connected to terminals + wrt - (i.e. the
capacitance of the cable plus any other capacitance) shall
not exceed 83nF.
The enclosure is non-conducting and may generate an
ignition-capable level of electrostatic charges under certain
extreme conditions. The user should ensure that the
equipment is not installed in a location where it may be
subjected to external conditions that might cause a build-up
of electrostatic charges on non-conducting surfaces,
additionally, cleaning of the equipment should be done only
with a damp cloth.
The equipment shall only be supplied via Terminals + w.r.t.
Terminals - from a barrier having a maximum open circuit
voltage Uo that is < 28V and a maximum short circuit current
Io that is < 93mA, where Io is resistively limited. The barrier
shall be ATEX certified by a notified body.
4.2 Zones, Gas Groups and Temperature Classification
The IS-mA1 minialarm sounder has been certified Ex ia IIC
T4. When connected to an approved system it may be
installed in:
Zone 0 explosive gas air mixture
continuously present.
Zone 1 explosive gas air mixture likely to occur in
normal operation.
Zone 2 explosive gas air mixture not likely to occur,
and if it does, it will only exist for a short time.
Be used with gases in groups:
Group A propane
Group B ethylene
Group C hydrogen
Having a temperature classification of:
T1 450ºC
T2 300ºC
T3 200ºC
T4 135ºC
4.3 Terminals + and -
Power is supplied to the sounder via the + and – terminals
which have the following input safety parameters:
Ui = 28V
Ii = 93mA
Pi = 660mW
Ci = 0 Li = 0
The IS-mA1 sounder may be powered from an ATEX certified
Zener barrier or galvanic isolator which have output
parameters equal to or less than 28V, 93mA and 660mW,
where Io is resistively limited. The cable parameters stated
on the selected Zener barrier or galvanic isolator certificate
must be observed.
Up to three IS-mA1 sounders can be connected in parallel
and powered from a common barrier or isolator. Connecting
two sounders in parallel will reduce the output from each by
about 3dB. Three sounders should only be powered from a
common supply when the maximum supply voltage is
available.
4.4 Terminals S2 and S3
When terminals S2 or S3 are connected to 0V (- terminal) the
sounder output tone changes to the second or third stage
alarm respectively. The input safety parameters for these
terminals are:
Ui = 28V
Ii = 0mA
Because the permitted input current is zero, these terminals
may only be connected to a diode return barrier, an
intrinsically safe relay or a galvanic isolator, all of which must
have been certified by an EC Notified Body. Only diode return
barriers with a voltage drop of less than 0.9V may be used.
Alternatively, these terminals may be connected directly to a
mechanically activated switch within the hazardous area.

_______________________________________________________________________________________________________________________________
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH [email protected] Tel: +44 (0)20 8743 8880
www.e2s.com Fax: +44 (0)20 8740 4200
Document No. IS 5001 Issue H 03-01-2020 Sheet 3 of 6
Tone Selection – To select the required first stage tone set the tone switches 1 to 6 (see
Fig 2) to the tone setting shown in the table below. The table also shows which 2nd and 3rd
stage tones are available for use with the selected first stage tone if more than one tone
output stage is required.
Tone
Number
Tone Description
Switch
Settings
1 2 3 4 5 6
Second
Stage
Alarm
Third
Stage
alarm
Tone 1
Tone 2
Tone 3
Tone 4
Tone 5
Tone 6
Tone 7
Tone 8
Tone 9
Tone 10
Tone 11
Tone 12
Tone 13
Tone 14
Tone 15
Tone 16
Tone 17
Tone 18
Tone 19
Tone 20
Tone 21
Tone 22
Tone 23
Tone 24
Tone 25
Tone 26
Tone 27
Tone 28
Tone 29
Tone 30
Tone 31
Tone 32
Tone 33
Tone 34
Tone 35
Tone 36
Tone 37
Tone 38
Tone 39
Tone 40
Tone 41
Tone 42
Tone 43
Tone 44
Tone 45
Tone 46
Tone 47
Tone 48
Tone 49
Continuous 340Hz
Alternating 800/1000Hz @ 0.25s intervals
Slow whoop 500/1200Hz @ 0.3Hz with 0.5s gap repeated
Sweeping 500/1000Hz @ 1Hz
Continuous 2400Hz
Sweeping 2400/2900Hz @ 7Hz
Sweeping 2400/2900Hz @ 1Hz
Siren 500/1200/500Hz @ 0.3Hz
Sawtooth 1200/500Hz @ 1Hz - D.I.N.
Alternating 2400/2900Hz @ 2Hz
Intermittent 1000Hz @ 1Hz
Alternating 800/1000Hz @ 0.875Hz
Intermittent 2400Hz @ 1Hz
Intermittent 800Hz 0.25s ON, 1s OFF
Continuous 800Hz
Intermittent 660Hz 150Ns ON, 150ms OFF
Alternating 544Hz (100ms) / 440Hz (400ms) – NFS 32-001
Intermittent 660Hz 1.8s ON, 1.8s OFF
Sweep 1400Hz to1600Hz up 1s 1600Hz to 1400Hz down 0.5s
Continuous 660Hz
Alternating 554/440Hz @ 1Hz
Intermittent 544Hz @ 0.875Hz
Intermittent 800Hz @ 2Hz
Sweeping 800/1000Hz @ 50Hz
Sweeping 2400/2900Hz @ 50Hz
Simulated bell
Continuous 554Hz
Continuous 440Hz
Sweeping 800/1000Hz @ 7Hz
Continuous 300Hz
Sweeping 660/1200 @ 1Hz
Two Tone Chime
Intermittent 745Hz
Alternating 1000/2000Hz @ 0.5s – Singapore
420Hz @ 0.625s - Australian Alert
500-1200Hz 3.75s / 0.25s - Australian Evacuate
Continuous 1000Hz
Continuous 2000Hz
Intermittent 800Hz 0.25s ON 1s OFF
Alternating 544Hz (100ms) / 440Hz (400ms) – NFS 32-001
Motor Siren – Slow rise to 1200Hz
Motor Siren – Slow rise to 800Hz
Continuous 1200Hz
Motor Siren – Slow rise to 2400Hz
Intermittent 1000Hz 1s ON, 1s OFF
Sawtooth 1200/500Hz @ 1Hz - D.I.N. (PFEER P.T.A.P)
Intermittent 1000Hz 1s ON, 1s OFF – PFEER General Alarm
420Hz @ 0.625s - Australian Alert
500-1200Hz 3.75s / 0.25s - Australian Evacuate
0 0 0 0 0 0
1 0 0 0 0 0
0 1 0 0 0 0
1 1 0 0 0 0
0 0 1 0 0 0
1 0 1 0 0 0
0 1 1 0 0 0
1 1 1 0 0 0
0 0 0 1 0 0
1 0 0 1 0 0
0 1 0 1 0 0
1 1 0 1 0 0
0 0 1 1 0 0
1 0 1 1 0 0
0 1 1 1 0 0
1 1 1 1 0 0
0 0 0 0 1 0
1 0 0 0 1 0
0 1 0 0 1 0
1 1 0 0 1 0
0 0 1 0 1 0
1 0 1 0 1 0
0 1 1 0 1 0
1 1 1 0 1 0
0 0 0 1 1 0
1 0 0 1 1 0
0 1 0 1 1 0
1 1 0 1 1 0
0 0 1 1 1 0
1 0 1 1 1 0
0 1 1 1 1 0
1 1 1 1 1 0
0 0 0 0 0 1
1 0 0 0 0 1
0 1 0 0 0 1
1 1 0 0 0 1
0 0 1 0 0 1
1 0 1 0 0 1
0 1 1 0 0 1
1 1 1 0 0 1
0 0 0 1 0 1
1 0 0 1 0 1
0 1 0 1 0 1
1 1 0 1 0 1
0 0 1 1 0 1
1 0 1 1 0 1
0 1 1 1 0 1
1 1 1 1 0 1
0 0 0 0 1 1
Tone 2
Tone 17
Tone 2
Tone 6
Tone 3
Tone 7
Tone 10
Tone 2
Tone 15
Tone 7
Tone 2
Tone 4
Tone 15
Tone 4
Tone 2
Tone 18
Tone 2
Tone 2
Tone 2
Tone 2
Tone 2
Tone 2
Tone 6
Tone 29
Tone 29
Tone 2
Tone 26
Tone 2
Tone 7
Tone 2
Tone 26
Tone 26
Tone 2
Tone 38
Tone 36
Tone 35
Tone 9
Tone 34
Tone 23
Tone 31
Tone 2
Tone 2
Tone 2
Tone 2
Tone 38
Tone 47
Tone 46
Tone 49
Tone 26
Tone 5
Tone 5
Tone 5
Tone 5
Tone 20
Tone 5
Tone 5
Tone 5
Tone 2
Tone 5
Tone 5
Tone 5
Tone 5
Tone 5
Tone 5
Tone 5
Tone 27
Tone 5
Tone 5
Tone 5
Tone 5
Tone 5
Tone 5
Tone 5
Tone 5
Tone 15
Tone 5
Tone 5
Tone 5
Tone 5
Tone 5
Tone 15
Tone 5
Tone 45
Tone 5
Tone 5
Tone 45
Tone 45
Tone 17
Tone 27
Tone 5
Tone 5
Tone 5
Tone 5
Tone 34
Tone 37
Tone 37
Tone 5
Tone 37

_______________________________________________________________________________________________________________________________
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH [email protected] Tel: +44 (0)20 8743 8880
www.e2s.com Fax: +44 (0)20 8740 4200
Document No. IS 5001 Issue H 03-01-2020 Sheet 4 of 6
1 2 3 4 5 6
+ + - - S2 S3
IS-mA1 Sounder
Tone Setting
Switches 1-6
Volume Control
Input Terminals
'O' Ring Seal
Fig 2 Location of field terminals and controls.
4.5 Other intrinsic safety certifications
Please contact European Safety Systems Ltd. for details of
non-European intrinsic safety approvals.
5) Installation
IS-mA1 minialarm sounders should only be installed by
trained competent personnel.
5.1 Mounting
The IS-mA1 minialarm sounder may be secured to any flat
surface by inserting two mounting screws through the back of
the round base (see figure 3). The enclosure provides IP65
protection and is suitable for installation in exterior locations
provided that the area around the two mounting screws
through the back of the base moulding has been sealed and
that suitable cable glands with the required IP rating have
been used.
5.2 Installation procedure
a. Unscrew the sounder unit security screw and remove
the sounder section from the base by turning it anti-
clockwise. Ensure that the ‘O’ ring seal remains in
place.
b. Remove the required 20mm knockout section(s)
depending on system wiring and mount the base to a
flat surface by inserting two screws through the back
of the base.
c. Fit the required number of 20mm cable glands or
conduit entries into the base and connect the field
wiring to the appropriate sounder terminals as shown
in section 6 and fig 2 of this manual. The power supply
terminals + and - are duplicated so that sounders may
be connected in parallel, or an end of line monitoring
resistor may be fitted.
d. Select the required output tone by positioning the six
switches as shown in Table 1 and Fig 2.
e. Apply power to the sounder and adjust the internal
volume control to provide the required sound level.
f. Check that the ‘O’ ring seal is correctly located on the
sounder section (see Fig. 2) and insert the sounder
section into the base. Push it fully home and turn it
clockwise to align the mouldings before tightening the
security screw.
Fit mounting screws
through base 20mm knockouts
Fig 3 Mounting Sounder Base.
6) Electrical System Design For Installation In
Hazardous Areas Using Zener Barriers
6.1 Single stage alarm
If the control switch is in the positive supply, or the power
supply is being turned on and off, only a single channel Zener
barrier is required as shown in Fig 4. This circuit may also be
used if the sounder is being controlled by a mechanically
activated switch on the hazardous area side of the barrier.
Safe Area
Hazardous Area
+
-
IS-mA1
Sounder
0V
+
Power
Supply
Barrier
On/Off
28V 93mA
Positive
Fig 4 Single stage alarm using single channel barrier.
If the control switch must be in the negative supply, the circuit
shown in Fig 5 may be used. Any diode return barrier certified
Ex ia by a EC Notified Body may be used, providing its
voltage drop is less than 0.9V.
Safe Area
Hazardous Area
-
IS-mA1
Sounder
+
0V
+
Power
Supply
Diode Return
Barrier
Barrier
On/Off
28V 93mA
Positive
Fig 5 Single stage alarm using two channel barrier.

_______________________________________________________________________________________________________________________________
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH [email protected] Tel: +44 (0)20 8743 8880
www.e2s.com Fax: +44 (0)20 8740 4200
Document No. IS 5001 Issue H 03-01-2020 Sheet 5 of 6
6.2 Multi-stage alarm
Connecting terminal S2 to 0V activates the second stage
alarm, and similarly terminal S3 for the third stage alarm. Fig
6 shows how the diode return barriers may be used. If only
two stages of alarm are required the third stage barrier
should be omitted, the 28V 93mA barrier and the single diode
return channel may then be contained in one package.
Power
Supply
+
0V
Barrier
+
-
28V 93mA
Positive
Hazardous Area Safe Area
Diode Return
Barrier 2nd Stage
On/Off
Diode Return
Barrier 3rd Stage
S2
S3
IS-mA1
Sounder
Fig 6 Multi stage alarm using Zener barriers.
7) Electrical System Design For Installation In
Hazardous Areas Using Galvanic Isolators
Galvanic isolators do not require a high integrity earth
connection. For small systems where a high integrity earth is
not already available, the use of galvanic isolators often
reduces the overall installation cost and simplifies design.
7.1 Single stage alarm
The IS-mA1 minialarm sounder may be powered by any
galvanic isolator having output parameters within the limits
specified in section 4.3, which has been certified Ex ia by an
EC Notified Body. The sounder may be controlled by turning
the galvanic isolator on and off, or by a mechanically
activated switch on the hazardous area side of the isolator.
Safe Area
Hazardous Area
IS-mA1
Sounder
+
--
+
Galvanic
Isolator
Power
Fig 7 Single stage alarm using galvanic isolator.
7.2 Multi stage alarm
The IS-mA1 sounder second and third stages may be
activated by using Galvanically Isolated Relays that have
output parameters within the limits specified in section 4.4.
which have been certified Ex ia by an EC Notified Body.
+
Hazardous Area Safe Area
-Power
Galvanic Isolator
Galvanic Isolated Relay
Power
S2
-
-
IS-mA1
Sounder
+
Fig 8 Multi stage alarm using galvanic isolated relays
8) Cable Parameters
The maximum permitted cable parameters are as specified
on the certificate of the Zener barrier or galvanic isolator that
has been selected for the installation. Normally the limits are
not restrictive, but care should be taken not to exceed a
capacitive limit of 83nF for installations when very long cables
are used.
9) Volume Control
The output level of the IS-mA1 sounder can be set by
adjusting the volume control potentiometer (see Fig 2).
10) Maintenance
The sounder should be regularly inspected to ensure that it
has not been damaged. Frequency of inspection depends
upon environmental conditions, but initially we recommend
that this should be done annually.
No attempt should be made to repair a faulty ISmA1
sounder. Suspect sounders must be returned to
European Safety Systems Ltd. or to your local agent for
repair.
11) Guarantee
Sounders that fail within the guarantee period should be
returned to European safety Systems Ltd. It is helpful if a
brief description of the fault symptoms is provided.
12) Customer Comments
European Safety Systems Ltd. is always pleased to receive
comments from customers about our products and services.
All communications are acknowledged and whenever
possible, suggestions are implemented.

_______________________________________________________________________________________________________________________________
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH [email protected] Tel: +44 (0)20 8743 8880
www.e2s.com Fax: +44 (0)20 8740 4200
Document No. IS 5001 Issue H 03-01-2020 Sheet 6 of 6
IECEx Approval
The IS-mA1 Sounder has also been approved to the IECEx
scheme.
The installation requirements for IS-mA1 sounders approved
to the IECEx scheme are the same as the installation
requirements for IS-mA1 sounders approved to the ATEX
directive.
Certificate No. IECEx SIR 06.0045X
Marking: Ex ia IIC T4 Ga (Ta = -40ºC to +60ºC)
Standards: IEC 60079-0:2017
IEC 60079-11:2011
IEC 60079-26:2014-10
CONDITIONS OF CERTIFICATION (as stated on the IECEx
Certificate of Conformity IECEx SIR 06.0045X)
The equipment has an ingress protection rating of
IP65. However, if it has been supplied without a
cable entry device, then the user shall ensure that
the devices that are fitted will provide an ingress
protection that is appropriate to the environment in
which it is installed i.e. IP20 on better. If only one of
the two cable entries are used, then the unused
entry ‘knockout’ shall be left intact or fitted with a
blanking device that ensues ingress protection
appropriate to the environment in which it is installed
i.e. IP20 or better.
The total capacitance connected to terminals + w.r.t.
terminals - (i.e. the capacitance of the cable plus
any other capacitance) shall not exceed 83nF.
The enclosure is non-conducting and may generate
an ignition-capable level of electrosatic charges
under certain extreme conditions. The user should
ensure that the equipment is not installed in a
location where it may be subjected to external
conditions that might cause a build-up of
electrostatic charges on non-conducting surfaces,
additionally, cleaning of the equipment should be
done only with a damp cloth.
The equipment shall only be supplied via terminal +
w.r.t. terminal - from a barrier having a maximum
open circuit voltage Uo that is < 28V and a
maximum short circuit current Io that is < 93mA,
where Io is resistively limited.
The IS-mA1 sounders are marked with the certification
requirements for the ATEX and IECEx and approvals.
e
2S
european safety systems ltd. London W3 7QH UK
WARNING:
TO AVOID A POSSIBLE ELECTROSTATIC
CHARGE ONLY CLEAN WITH A DAMP CLOTH
IS-mA1 Sounder
II 1G Ex ia IIC T4 Ga (-40ºC <=Ta<= +60°C)
2813
SIRA 05ATEX2084X
Year / Serial No. 09 / 1MA000001
Ui = 28V Ii = 93mA Pi = 660mW Ci = 0 Li = 0
Terminal + w.r.t. Terminal -
Ui = 28V Ii = 0mA
Terminals S2&S3 w.r.t. Terminal -
www.e2s.com
IECEx SIR 06.0045X
0786-CPD-20338
EN54-3
Type B
VdS
FM Approval
The IS-mA1 Sounder has also been FM Listed.
Marking: IS Class I, Zone 0, AEx ia IIC T4
IS Class I, Division 1, Groups A, B, C, D
See the Control Drawings D 5035 Sheets 1 and 2 for
installation details and entity parameters.
WARNINGS:
IS-mA1 Sounder
To prevent ignition of flammable or combustible
atmospheres, disconnect power before servicing
Substitution of components may impair safety
FM
APPROVED
IS Class l, Division 1, Groups A, B, C, D
IS Class I, Zone 0, AEx ia IIC T4 (-40ºC <=Ta<= +60°C)
e
2S
european safety systems ltd.
London W3 7QH UK
Control Drawing D 5035
www.e2s.com
Year / Serial No. 09 / 1MA000001
TO AVOID A POSSIBLE ELECTROSTATIC
CHARGE ONLY CLEAN WITH A DAMP CLOTH
CPD Directive 89/106/EEC
The IS-mA1 Sounder is compliant with the
requirements of the Construction Products Directive
89/106/EEC.
EN54-3 Type B IP65
Voltage Range 18 – 28V DC via a safety barrier
(see sections 6 and 7).
Tone
Description
2 800/1000Hz @ 0.25 Seconds Alternating
3 500/1200Hz @ 0.3Hz 0.5 Sec Gap Slow Whoop
9 1200/500Hz @ 1Hz DIN
15 800Hz Continuous
16 660Hz 150mS ON 150ms OFF
17 554Hz (100mS) / 440Hz (400mS) NF S 32-001
The tones listed have been tested to EN54-3 and are
compliant with the Construction Products Directive
89/106/EEC.
EN54-3 Test data document D5073

slangisgninraw
:etaD
:nwarD
:eussI.dppA :etaD
.dtLsmetsySytefaSnaeporuE esuoHsserpmI daoRllesnaM notcA HQ73WnodnoL
2fo1teehS5305D gwd.a5305D
SRM
70-10-01
SRM
A
S2
noitacoL)deifissalC(suodrazaH D,C,B,AspuorG,1noisiviD,IssalC CII,BII,AIIspuorG,0enoZ,I
ssalC
rednuoS1Am-SI 4TCIIaixEA,0enoZ,Issal
CSI
(04 C Ta 06 )C
:sretemaraPytitnE
slanimreT .t.r.w
UiV82=
IiAm39=
PiWm066=
Ci0=
Li0=
-.t.r.w3S&2SslanimreT
UiV82=
Ii0= 0=iC V8.61=oU Am3.7=oI Wm13=oP
noitacoLdeifissalcnU
edoiDreneZtnuhS-sutarappAdetaicossA :sretemaraPytitnEhtiwreirraB
UoV82
IoAm39
PoWm066
CoC elbac)01etonees(
LoL elbac
reirraBnruteRedoiD-sutarappAdetaicossA :sretemaraPytitnEhtiw
UoV82
Io0=
CoC elbac
reirraBnruteRedoiD-sutarappAdetaicossA :sretemaraPytitnEhtiw
UoV82
Io0=
CoC elbac
+
-
2S
3S
.lavorppaMFroirptuohtiwgniwardotnoisiveroN.1
.devo
rppaMFebtsumsutarappadetaicossaehT.2
t
sumgniwardnoitallatsnis'rerutcafunamsutarappadetaicossaehT.3 .tnempiuqesihtgnillatsninehwde
wollofeb
10.60.21PRASI/ISNAhtiwecnadroccaniebdluohsnoitallatsnI.4 )deifissalC(suodrazaHrofs
metsySefaSyllacisnirtnIfonoitallatsnI" .)07APFN/ISNA(edoClacirtcelElanoitaN
ehtdna"snoitacoL
htraeehtdnadnuorgefasyllacisnirtniehtneewtebecnatsiserehT.5 .mho1ehtsselebtsumdnuorg
re
irraBedoiDreneZtnuhSehT.6ylevitsiser,devorppaMFaebtsum lauqero,nahtsselsretemarapgnivah
reirrablenn
ahcelgnis,detimil rofelbapacnoitingi-nonsituptuoehthcihwrofdna,detouqesoht,ot .esufopuorGdnaenoZronoisiviD,ssalCeht
fognitarnoitcetorpssergninasaherusolcnerednuoS1A
m-SIehT.7 citsalprocilla
temnehtsecivedyrtneelbactuohtiwdeilppusfI.
56PI deriuqerehtedivor
ptahtdettifebllahs,sbuhtiudnocro,sdnalgelbac .noitcetorplatnemnorivne
,serehpsomtaelbitsubmo
croelbammalffonoitingitneverpoT.8 .gnicivreserofebrewoptcennocsid
.ytefasriapmiyamstnenopm
ocfonoitutitsbuS.9
,rednuosehtfo-/+slanimretotdetcennocecnaticapaclatotehT.01 C.e.i elbac .Fn38deecxetonllahs,ecnaticapacrehtoynasulp
:setoN
citamotuatonsisnoitcennoctiudnocneewteb
gnidnoB-NOITUAC .noitallatsnisihtfotrapsadedivorpebtsumdna
si3Sdna2Sslanimretrednuosne
ewtebecnaraelcehT-NOITUAC .mm6nahtssel
.oNgniwarD .feRretupmoC
rednuoS1Am-SI edoidreneztnuhsrofgniwarDlortnoC .reirrabnruteredoid/reirrab
eltiT
60-40-12
GNIWARDELUDEHCS
dettimrepnoitacifidomoN ehtotecnerefertuohtiw "ydoBdeifitoN"

sla
ngisgninraw
:etaD
:nwarD
:eussI.dppA :etaD
.dt
LsmetsySytefaSnaeporuE esuoHsserpmI daoRllesnaM notcA HQ73WnodnoL
60-40-12
SRM
70-10-01
SRM
A
S2
noitacoL)deifissalC(suodrazaH D,C,B,AspuorG,1noisiviD,IssalC CII,BII,AIIspuorG,0enoZ,I
ssalC
noitacoLdeifissalcnU
detalosIyllacinavlaG-sutarappAdetaicossA :sretemaraPytitnEhtiwylppuS
UoV82
IoAm39
PoWm066
CoC )9etonees(elbac
LoL elbac
detalosIyllacinavlaG-sutarappAdetaicossA :sretemaraPytitnEhtiwyaleR
Uo0=
Io0= )01etoNeeS(
detalosIyllacinavlaG-sutarappAdetaicossA :sretemaraPytitnEhtiwyaleR
Uo0=
Io0= )01etoNeeS(
+
-
.lavorppaMFroirptuohtiwgniwardotnoisiveroN.1
.devorppaMFebtsumsutarappadetaicossaehT.2
t
sumgniwardnoitallatsnis'rerutcafunamsutarappadetaicossaehT.3 .tnempiuqesihtgnillatsninehwde
wollofeb
10.60.21PRASI/ISNAhtiwecnadroccaniebdluohsnoitallatsnI.4 )deifissalC(suodrazaHrofs
metsySefaSyllacisnirtnIfonoitallatsnI" .)07APFN/ISNA(edoClacirtcelElanoitaNehtdna"snoitacoL
,devorppaMFaebtsumylppuSdetalosIyllacinavlaGehT.5 ,nahtsselsretemarapgnivahylppuslennahc
elgnis,detimilylevitsiser noitingi-nonsituptuoehthcihwrofdna,detouqesoht,otlauqero .esuf
opuorGdnaenoZronoisiviD,ssalCehtrof
elbapac
fognitarnoitcetorpssergninasaherusol
cneredn
uoS1Am-SIehT.6 citsalprocillatemnehtsecivedyrtneelbactuohtiwdeilppusfI.56PI deriuqereht
edivorptahtdettifebllahs,sbuhtiudnocro,sdnalgelbac .noit
cetorplatnemnorivne
,serehpsomtaelbitsubmocroelbammalffonoitingitneverpoT.7 .gnicivreserofebrewoptcennocsid
.ytefasriapmiyamst
nenopmocfonoitutitsbuS.8
.e.i,rednuosehtfo-/+slanimretotdetcennocecnaticapaclatotehT.9
Celbac .Fn38deecxetonllahs,ecnaticapacrehtoynasulp
CehT.01 elbac Ldna elbac yllacinavlagehtgnitcennocselbacehtfo ,nahtsselebllahs-/3Sdna-/2Sslanimretrednuosotsyale
rdetalosi Ceht,otlauqero elbac Ldna elbac ehtgnitcennocelbacehtfo .-/+slanimretrednuosotylppusdet
alosiyllacinavlag
:setoN
citamotuaton
sisnoitcennoctiudnocneewtebgnidnoB-NOITUAC .noitallatsnisihtfotrapsadedivorpebtsumdna
si
3Sdna2SslanimretrednuosneewtebecnaraelcehT-NOITUAC .mm6nahtssel
2S
-
3S
-
rednuoS1Am-SI yllacinavlagrofgniwarDlortnoC yalerdetalosi/ylppus
detalosi .noitallatsni 2fo2teehS5305D gwd.b5305D
.oN
gniwarD .feRretupmoC
eltiT
rednuoS1Am-SI 4TCIIaixEA,0enoZ,IssalCSI
(04 C Ta 06 )C
:sretemaraPytitnE
slanimreT .t.r.w
UiV82=
IiAm39=
PiWm066=
Ci0=
Li0=
-.t.r.w3S&2SslanimreT
UiV82=
Ii0= 0=iC V8.61=oU Am3.7=oI Wm13=oP
GNIWARDELUDEHCS
dettimrepnoitacifidomoN ehtotecnerefertuohtiw "ydoBdeifitoN"
This manual suits for next models
1
Table of contents
Other E2S Marine Equipment manuals

E2S
E2S AlertAlight AL121H User manual

E2S
E2S D1xS2FDC024-A User manual

E2S
E2S SONF1DC024 X Y Series User manual

E2S
E2S A100 AlertAlarm User manual

E2S
E2S E2xS1R User manual

E2S
E2S IS-mA1M User manual

E2S
E2S BExH120D User manual

E2S
E2S AlertAlight AL105N Series User manual

E2S
E2S STExC1 User manual

E2S
E2S D105 AlertAlarm User manual
