Enabling Devices Cheap Talk 4 Square Direct User manual

For Technical Support:
Call our Technical Service Department
Monday through Friday, 9 a.m. to 5 p.m. (EST)
1-800-832-8697
[email protected]
Cheap Talk 4 Square Direct #1392
USER’S GUIDE
50 Broadway
Hawthorne, NY 10532
Tel. [phone] / Fax [phone]
Toll Free 800.832.8697
www.enablingdevices.com

Assists in language development and it's easy to use!
Our popular Cheap Talk communicators are light-weight, portable,
user-friendly and economical. They enable the user to “speak” pre-
recorded messages. Use them to provide communication and
cognitive support to enhance and develop expressive and receptive
language skills. Messages can be up to 5 seconds each and can be
recorded and re-recorded as often as you wish. Size: 8" x 8" x 3".
Requires 4 AA Batteries.
Operation:
1. Carefully turn over unit to reveal battery compartment. Observing
polarity, install four AA Alkaline batteries (e.g. Duracell or
Energizer Brand) only (Not included) into the holder. Do not use
rechargeable or any non alkaline type batteries as they will not
work in this device.
2. The microphone and red “RECORD” button are located on the
back panel of the unit. To record, depress and hold the “RECORD”
button, then depress one of the 4 colored squares and speak into
the microphone. Release both buttons once recording is over.
Playback your message by pressing and releasing the same
square used to record. Each of the remaining buttons can be
“programmed” in the same manner. (The unit will retain recorded
information indefinitely, even if the battery is disconnected.
Previously stored information will be erased only when new
recording is performed.)
3. Playback volume can be adjusted using the control provided on
the back panel of the unit, next to the “RECORD” button.
4. Turn the unit off by rotating the “VOLUME” control knob located
on the back of the unit counterclockwise until you hear an audible
“click”.
5. There is pre-made icon template in the Mayer-Johnson’s
Board-Maker Program sold separately or you can purchase
our PRINT IT! ICON MAKER item No.4069
Important Notes:
The memory of this unit is capable of holding up to 20 seconds of
speech information total. This memory is divided into four equal
segments 5 seconds each
Troubleshooting:
If the unit fails to operate or operates incorrectly, the following
steps should be performed:
Action: Make sure there are no obstacles between the colored
square buttons and the housing unit.
Action: Remove the batteries for 20 seconds to reset the unit. If the
unit still does not work correctly after the batteries are re-installed,
replace the batteries with new alkaline batteries (E.G Duracell or
Energizer Brand).
Action: Do not use rechargeable batteries.
Care of Unit:
The Cheap Talk can be wiped clean with any mild household multi-
purpose cleaner and disinfectant. We recommend Simple Green,
which is a non toxic biodegradable all-purpose cleaner.
Do not submerge the unit, as it will damage the contents and the
electrical components.
Do not use abrasive cleaners, as they will scratch the surface of the
unit.
Rev 10/9/17
