EOS EOS Selection User manual

IPx4
Made in Germany
EOS Selection
Print-no.: 2902 5136 / 03.22
Technical changes reserved
EN Installation and Operating Instructions
Sauna heater

2EN
Manufacturer
EOS Saunatechnik GmbH
Schneiderstriesch 1
D-35759 Driedorf, Germany
Tel.: [phone]
Fax: [phone]
Web: www.eos-sauna.com
Original installation instructions EN
Copyright for these installation instructions remains with EOS Saunatechnik GmbH.
Copyright as per DIN ISO 16016:
The copying and distribution of this document, as well as the use and communication of its con-
tents without express authorisation, are not permitted. Compensation will be claimed in the event
of infringements.
All rights reserved with regard to patent claims or submission of design or utility patent.
Documentation
Documentation

3
EN
Deutsch
Contents
Documentation ..........................................................................................................................................2
General safety instructions..........................................................................................................................4
Safety levels ...................................................................................................................................................4
Mounting and electrical installation.....................................................................................................5
Operator instruction...................................................................................................................................8
Standards and regulations.......................................................................................................................9
Identification ................................................................................................................................................... 10
Requirements for operation, Nameplate .........................................................................................10
Scope of delivery, Technical data........................................................................................................11
Accessories (optional).............................................................................................................................11
Intended use...............................................................................................................................................12
Installation........................................................................................................................................................ 13
Specifications for the cabin................................................................................................................... 13
Installation site...........................................................................................................................................13
Minimum clearances ............................................................................................................................... 14
Mounting example................................................................................................................................... 14
Air inlets and outlets................................................................................................................................ 15
Adjusting the feet.....................................................................................................................................17
Connections...................................................................................................................................................... 18
General instructions for electrical installation ...............................................................................18
Connections................................................................................................................................................ 18
Connection example for 400V 3N ~...................................................................................................19
Internal wiring............................................................................................................................................20
Connection example for 230V 1N ~...................................................................................................21
Heating time limitation .......................................................................................................................... 22
Commissioning ............................................................................................................................................... 24
Filling stones............................................................................................................................................... 24
Starting the heater................................................................................................................................... 24
Commissioning by remote control .................................................................................................... 24
Water splash ...............................................................................................................................................25
Maintenance.....................................................................................................................................................26
Cleaning the heater ................................................................................................................................. 26
Replacing sauna stones.......................................................................................................................... 26
Replacing the tubular heating elements.............................................. ........................................... 27
Troubleshooting........................................................................................................................................ 28
General terms and conditions of service............................................................................................28
Disposal.............................................................................................................................................................. 31
Service Adress ................................................................................................................................................. 32

4EN
General safety instructions
General safety instructions
Safety instructions and important operating instructions are classied. Please familiarise
yourself with the following terms and symbols:
WARNING
Warning
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION
Caution
Indicates a hazardous situation which, if not avoided, could result in minor or moderate in-
jury.
NOTICE
Notice
Indicates a hazardous situation which, if not avoided, will result in damage to the unit.
Safety levels

5
EN
General safety instructions
Mounting and electrical installation
These installation instructions are intended for qualified personnel familiar with
the laws and regulations applicable to electrical installations at the installation
site.Observethe followinggeneral safetyinstructionsduring mounting,configu-
ration and commissioning of the product.
Risk to life and limb and risk of re
Risk to life and limb from electric shock and re in the event of improper or faulty electrical
connection. This risk also applies following completion of the installation work.
• The electrical installation of the heater, relay boxes and other electrical systems or equip-
ment with a xed mains connection must only be performed by a trained electrician from
an authorised electrical company.
• Ensurecompliancewith the applicablestandardsand regulationsfor electricalinstallation.
• The system must be disconnected and removed entirely from the mains supply before
commencing installation and repair work.
• The housing cover must only be removed by a specialist.
Fire hazard from overheating
Insucient ventilation can lead to device overheating and re.
• Install the air inlet and outlet in the cabin.
• Observe the cabin manufacturer‘s safety and installation instructions.
Risk of re due to sauna stones
It is possible for hot stones or stone pieces to fall out of the rock store.
• The sauna heater may not be placed on a oor made of easily ammable material (e.g.
laminate or synthetic ooring). Ceramic tiles are recommended as a ooring option.

6EN
General safety instructions
Risk of burns from hot glass
Glass surfaces in the cabin become hot while the sauna is in operation.
• When installing the cabin, ensure that the touchable glass surfaces on the outside of the
cabin may reach a maximum temperature of 76°C. Appropriate protection may need to be
installed if required.
Risk of burns from hot unit
During operation, the sauna heater may become hot and, if touched, could cause burns.
• Maintain a safe distance.
Sauna cabin and heater
The sauna cabin must be constructed with proper material and built in a professional man-
ner, and the heater must be suited for the cabin.
• Sauna heaters and control units may only be used in sauna cabins made of suitable, low-
resin and untreated material (e.g. Nordic spruce).
• Multiple heaters may be installed in one sauna if the heater output can properly supply the
cabin volume. In this case, depending on the position, an additional safety temperature
limiter must be installed for each additional heater.
• The sauna heater is not designed to be installed or set up in an alcove or under a bench or
sloping roof unless the sauna heater is specically designed and approved for this type of
installation.
• Receptacles may not be installed inside the sauna cabin.
• Each sauna cabin must have air inlets and outlets.The air inlets and outlets may be instal-
led below or behind the sauna heater, approx. 5 to 10 cm above the oor. The minimum
dimensions of the air inlets and outlets can be found here: Technical data, Air inlets and
outlets
• The exhaust openings are always installed in the lower part of the wall diagonal to the
sauna heater. The supply and exhaust openings must not be closed. Please observe the
instructions provided by your sauna cabin manufacturer.
• Use one of the control units listed below to check and control the sauna heater. This con-
trol unit is xed to a suitable location on the cabin‘s external wall, and the corresponding

7
EN
General safety instructions
sensor housings according to the installation instructions that accompany the control units
inside the sauna cabin.
• The cabin lighting must be safe for sauna cabin use and installed in such a way that it can
be used safely in a sauna cabin. Ensure that the heater is installed in compliance with the
standards and legal norms valid in your country.
• The cabin door must open outward and must not have a lock that cannot be opened in the
case of failure.We recommend magnetic or spring locks.

8EN
General safety instructions
Der Betreiber der Sauna-Kabine muss bei der Inbetriebnahme über die folgenden allgemei-
nen Sicherheitshinweise unterrichtet werden. Dem Betreiber muss die Gebrauchsanweisung
ausgehändigt werden.
Risk of electric shock
A risk to life and limb from electric shock and re arises in the event of improper repair work.
This risk also applies after work is completed..
• The housing cover must only be removed by a specialist.
• Repairs and installations must only be performed by a trained specialist.
• The system must be disconnected and removed entirely from the mains supply before
commencing repair work.
• Use only original spare parts from the manufacturer.
Fire hazard
Objects placed on the heater can easily be ignited and cause res.
• Do not place objects on the heater.
• Fill the rock store as directed.
• Inspect the sauna cabin prior to each commissioning.
• If you switch on the heater using pre-set timers or a remote control, attach a protective
cover to the heater or install a suitable safety device.
Health risks
Spending time in a sauna cabin can lead to serious health risks or even death for persons
with health impairments.
• Persons with health impairments who spend time in a sauna must consult a doctor before
entering a sauna cabin.
Operator instruction

9
EN
General safety instructions
Damage to health
Excessive time spent in a heated sauna cabin can lead to overheating of the body (hyper-
thermia), which may cause serious health problems and even death. Hyperthermia occurs
when the core temperature of the body exceeds the norm by a few degrees. Symptoms of
hyperthermia include fever, dizziness, lethargy, sleepiness, and fainting. Side eects of hy-
perthermia include perception disorders, inability to recognize the need to leave the room,
inability to identify imminent danger, harm to the foetus in the case of pregnant women,
inability to physically leave the room and unconsciousness.
Alcohol, drugs, and medications increase the risk of hyperthermia..
• Do not exceed the maximum recommended time in the sauna.
• Leave the sauna cabin if your body responds abnormally to the heat or if you do not feel
well.
• Avoid alcohol, drugs, and medications when you are using the sauna.
Operating the unit
This unit should not be used by children or persons with reduced mental capacity or limited
physical or sensory abilities. Children must not play with the unit. Cleaning and user mainte-
nance must not be performed by children.
• Children must be supervised to ensure they do not play with the unit.
Standards and regulations
For an overview of the standards that were observed during design and construction of
the sauna heaters, please refer to the individual product‘s technical data sheet that can be
downloaded from www.eos-sauna.com.

10 EN
Identification
Elektro-Saunaofen
Type EOS Selection
Art. Nr. SEF XXXX 00
400V 3N ~ 50 Hz XX kW
Made in Germany 00002S-No. 30.20
EOS SAUNATECHNIK GmbH, Schneiderstriesch 1, 35759 Driedorf
IPX4
Identification
EOS Selection is an electrically heated Finnish sauna heater available in a variety of output
capacities.
Requirements for operation
The heater must be operated together with one control unit. They are not included in the scope
of delivery.
Nameplate
AName
BModel
CItem number
DElectrical connection
ECountry of origin
FManufacturer
GHeater output
HManufacturing date
ISerial number
A
B
C
D
E
F
G H I

11
EN
Identification
Technical data
Scope of delivery
The contents are as follows:
• 1 Sauna heater
• 1 Rear side cover panel
• 1 Assembly and operating instruction
Electrical connection 400V 3N ~ 50 Hz
Power output 7,5 kW 9,0 kW 10,5 kW 12,0 kW
For sauna cabin size 7 - 10 m³ 9 - 14 m³ 11 - 15 m³ 14 - 18 m³
Min. size air inlet and air outlet 35 x 5 cm 35 x 6 cm 35 x 6 cm 35 x 7 cm
Weight, excl. stones / packaging 28 kg
Dimensions H x W x D 75 x 42 x 42 cm
Stone llung approx. 35-40 kg (stones are optionally available)
Power extension required (LSG unit) no EmoTec LSG 09R
Suitable sauna control units EOS Econ-series, Compac-series, EmoTec -series,
EmoStyle-series, EmoTouch-series
Leakage current max. 0,75 mA per kW heating power
Intended use Sauna heater for private and commercial sauna cabins
Fuse control unit in A 3 x 16 A
Fuse LSG in A 3 x 16 A
Connection cable main - control unit 5 x 2,5 mm²
Connection cable main- LSG 5 x 2,5 mm²
Connection control unit - heater 5 x 1,5 mm²
Connection LSG - heater 5 x 1,5 mm²
Connection control unit - LSG 4 x 1,5 mm²
All cross sections of a line are minimum diameters in mm² (Copper line)
Accessories (optional):
Sauna stones, approx. 25 kg ..................................................................... Item no. 94.7337
Sauna stones, Quartz white, approx. 15 kg........................................ Item no. 94.6878
Heater guard brackets................................................................................ Item no. 94.7501
Heater guard, 3 parts, Abachi / Walnut............................................... Item no. 94.7502 / 7503
Heater guard back side, Abachi / Walnut .......................................... Item no. 94.7504 / 7505

12 EN
Identification
Intended use
This sauna heater is intended solely for the purpose of heating sauna cabins, together with a suit-
able control unit.
EOS Selection is a oor-standing sauna heater that is suitable for private and commercially used
cabins.
The heater is not suitable for outdoor use !
It must be operated only inside buildings and may not be exposed to environmental
conditions such as extreme humidity and moisture or the possible formation of conden-
sation or corrosive substances in the ambient air, as well as other weather conditions.
Any use beyond this is considered improper use. Proper use also includes compliance with operat-
ing, maintenance and servicing requirements.
The manufacturer is not responsible for unauthorised modications and damages resulting from
these modications; the person modifying the equipment alone shall bear the associated risk.
Foreseeable misuse
The following are considered instances of foreseeable misuse:
• The unit is operated without knowledge of or compliance with the safety instructions.
• Operating, service and maintenance requirements are not observed.
• The unit is operated by children or persons with reduced mental capacity or by persons who
have not been thoroughly instructed in its use.
General instructions
• Please note that an optimal sauna climate can be achieved only if the cabin with its air inlets and
outlets, the sauna heater, and the control unit are synchronized.
• Observe the specications and information provided by your sauna retailer.
• The sauna heaters heat the sauna cabin with heated convection air.
• resh air is drawn in through the air inlet. It is warmed and rises (convection) and is then cir-
culated in the cabin. Some of the used air is pushed out of the cabin through the cabin‘s air
outlet. This creates a typical sauna climate in which temperatures of approx. 110°C are achieved
directly below the ceiling. These temperatures drop to approx. 30–40°C in the cabin along the
oor. Therefore, it is not unusual that if the temperature sensor above the heater reads 110°C,
the thermometer that is mounted approx. 20–25 cm below the cabin ceiling on the sauna wall
reads only 85°C. When the max. temperature is set for the area around the upper recliner bench,
the bathing temperature is typically between 80°C and 90°C.
• Please note that the highest temperatures in the cabin are always above the sauna heater and
that is where the temperature sensor and safety temperature limiter should be mounted ac-
cording to the installation instructions for the control units.
• The rst time the cabin is heated, you may notice a slight odour resulting from the evaporation
of consumables used in the manufacturing processes. Air out your cabin once it has been heat-
ed and before using the sauna.

13
EN
Installation
Installation
Installation site
• Inner ceiling height of at least 190 cm
• Distance between heater and cabin wall at least 4 cm
• Distance between heater and bench or other ammable materials at least 4 cm
• The required heater power depends on the sauna size and construction. Heater power must suit
the sauna size. See the chapter„Technical Data“.
This chapter describes how to install the sauna heater. Prior to the installation, air inlets and outlets
must be installed in the sauna. It may be necessary to mount additional fans in the inlets/outlets.
All protective lms must be removed from the heater.
NOTICE
Damage due to incorrect mounting location
The heater is not suitable for outdoor use!
• The heater must be operated only inside buildings and may not be exposed to environ-
mental conditions such as extreme humidity and moisture or the possible formation of
condensation or corrosive substances in the ambient air, as well as other weather condi-
tions.
• The heater is not designed to be installed in a niche, under a bench or a sloping roof.
Specications for the sauna cabin
The sauna cabin must be planned and installed according to specications before the sauna heat-
er is installed.
The oor on which the sauna heater stands must be level.
In general, it should be noted that the sauna heater must not be placed on a oor made of easi-
ly ammable material (laminate, ooring made of plastic material, etc.). Ceramic tiles are recom-
mended as a ooring option.
Electrical lines
All electrical installations laid inside the cabin must be heat-resistant silicone cables and must be
suitable for temperatures of at least 170°C.
All lines must be routed in such a way that they are well-protected, e.g. in a cable duct.
If single-core lines are used as connecting cables, they must be protected by a exible metal hose
connected to the protective conductor.

14 EN
Installation
4 cm42 cm
4 cm
4 cm
42 cm
4 cm
• The minimum height of the sauna cabin must be 190 cm on the inside. (Fig. 1).
cabin wall
stove guard
Fig. 1
Fig. 2
min. 190 cm
75+1 cm
4 cm
42 cm
4 cm
cabin ceiling
• Make sure that the horizontal distance between the heater and cabin wall is at least 4 cm (Fig. 2).
• The safety gap between the heater and the safety guard rail, sauna bench or other ammable
materials must be at least 4 cm. The top of the safety guard rail should be approx. at the same
height as the front of the heater.
Minimum clearances
ventilation in the
lower area required
Installation example
The heater safety guard rail is not part of the delivery and must be ordered as an option or provid-
ed by the sauna cabin builder.

15
EN
Installation
Air inlets and outlets
Fire hazard from overheating
The heater can overheat if the air supply is insucient. Risk of death due to sauna re.
• Ensurethattheairinletsandoutlets providesucientventilation.Installa fan if necessary.
• Sauna may be only switched on after all air inlets and outlets have been opened.
WARNING
Air inlets and outlets must be installed in the sauna cabin to ensure a sucient air circulation and
to prevent the heater from overheating.
The required size of the air inlets and outlets depends on the heater power, see Technical data.
Connection cable
The heater connects via a connection cable to the sauna control unit, and if above certain power
also to the additional power extension unit. The heat-resistant silicone cable is sensitive to me-
chanical damages and be appopriately protected during installation. For this purpose use a cable
duct or a protective pipe from the installation site of the heater up to the control unit. The radius
for laying the cable around a corner should be at least 100 mm (R100).
See the connection diagram for details.
Temperature sensor
The main temperature sensor with the safety overheating limiter must be installed at the place
with the highest expected temperature, which normally means directly above the heater.
The temperature sensor with the overheating limiter fuse is not included in the scope of delivery.
Refer to the separate installation instruction of the sauna control unit for installation details.
If the heating process takes too long time, the common reason is the insucient fresh air supply to
the heater. Sauna should have the air exchange rate of at least 5 volumes per hour.
If, although the air inlet/outlet are properly sized, the heater still lacks the fresh air supply, a fan
(mechanical ventilation) should be installed at the air supply side outside the sauna cabin.
Depending on the location of the heater, the air inlet needs to be installed behind or below the
heater.

16 EN
Installation
1
3
1.1
3.1
2
• Connects the cable(s) as per connection diagram. The connection diagram is among others at-
tached on the inside of the terminal box cover.
• The terminal box is placed behind the external cover panel:
Undo 2 screws (1.1) at the top cover (1) and lift it. Lift the cover panel (2) and pull it out.
Undo 2 xation screws (3.1) at the terminal cover (3).
Connections
Fig. 3
Press out the pre-punched holes for
cable glad installation
• Connect the cable(s) to the control unit and, if installed, to the power extension unit. Make sure
to observe the local regulations and applicable safety norms.

17
EN
Installation
1 cm
3 cm
Adjusting the feet
Adjustable foot Ø 25
(1 cm height by default)
Fig. 4
After the heater has been placed at its nal position ensure that it stands stable and level, using
the 4 adjustable feet which you can adjust in height individually by rotating them clockwise or
anticlockwise.

18 EN
Connections
General instructions for electrical installation
Ensure that electrical installation is performed in compliance with the standards and legal norms
valid in your country.
If a residual current device (RCD) is installed, ensure that there are no other electrical consumers
not belonging to the sauna system which are fused via this RCD.
If the sauna heater has not been used for an extended period of time, the heater may draw mois-
ture from the ambient air, which, in rare cases, could lead to the RCD to be tripped.This is a physical
process and not a fault on the part of the manufacturer.
In this case, the heater must be heated by a technician under supervision which will bypass the
RCD function. Once the moisture has escaped from the heating elements after approx. 10 minutes,
the RCD can be integrated again in the electric circuit.
If the sauna heater will not be used for an extended period of time, we recommend that you switch
on the heater every 6 weeks so that the heating elements do not accumulate moisture. If, during
commissioning, the RCD is triggered, the electrical installation must be checked again
The electrician is responsible for properly connecting the heaters; thus, the manufacturer does not
assume liability.
Connections
The sauna control unit, the output controller, and the heater must be connected as shown in the
circuit diagrams.
Please observe the installation and operating instructions for the control units and output con-
trollers.
Connections

19
EN
Connections
LSG
5 5
5
4
5
4
Saunasteuergerät
Control unit
Boîtier de commande
Пульт управления
Saunaofen
Sauna heater
Poêle de sauna
Печь для сауны
Leistungsschaltgerät
Power extension unit
Extension de puissance
Блок расширения мощности
Netz / Mains / Réseau / Сеть
10,5 - 12,0 kW
Caution! Always make certain to include neutral conductor N clamp!
400 V 3N ~
L1 L2 L3 N W V U N
Saunasteuergerät / Control unit /
Boîtier de commande / Пульт управления
Netz / Mains / Réseau / Сеть
3x16A
N U V W N U V W
1 1 1 1
LSG
Contactor box
S1 N
400 V 3N ~
Netz / Mains / Réseau / Сеть
Saunaofen / Sauna heater
Poêle de sauna / Печь для сауны
WVU N VS1 L1 L2 L3N N
Sensor/
Limiter
Connection example for 400V 3N ~
7,5 - 9,0 kW (*10,5 kW)
4
Saunasteuergerät
Control unit
Boîtier de commande
Пульт управления
Saunaofen
Sauna heater
Poêle de sauna
Печь для сауны
5
5
Netz / Mains / Réseau / Сеть
400 V 3N ~
L1 L2 L3 N W V U N
U V W N N
PE
(Gr)
N
X Y Z
3x16A
Saunasteuergerät / Control unit /
Boîtier de commande / Пульт управления
Saunaofen / Sauna heater
Poêle de sauna / Печь для сауны
max. 9 kW
Sensor/
Limiter

20 EN
Connections
Internal wiring
U V W U V W
NN
1 1 1 1
bl
sw
sw
bl
mind. 5 x 1,5 mm² mind. 5 x 1,5 mm²
2000W 2000W 2000W 2000W 2000W 2000W
12 kW = 6x 2000 W
6 kW
zum LSG
power unit
6 kW
zum SSG
control unit
12,0 kW
U V W U V W
NN
1 1 1 1
bl
sw
sw
bl
mind. 5 x 1,5 mm² mind. 5 x 1,5 mm²
1500W 2000W 1500W 2000W 1500W 2000W
10,5 kW =3x 1500W + 3x 2000 W
6 kW
zum LSG
power unit
4,5 kW
zum SSG
control unit
1500W 1500W 1500W 1500W 1500W 1500W
U V W
NNN
bl sw
9 kW
zum SSG
control unit
mind. 5 x 1,5 mm²
9 kW = 6x 1500W
9,0 kW
1500W 1500W 1500W 1500W 1500W
U V W
bl
7,5 kW
zum SSG
control unit
mind. 5 x 1,5 mm²
7,5 kW = 5x 1500W
sw
NNN
7,5 kW
U V W U V W
NN
bl
sw
mind. 5 x 2,5 mm²
1500W 2000W 1500W 2000W 1500W 2000W
10,5 kW =3x 1500W + 3x 2000W
10,5 kW
zum LSG
control unit
10,5 kW Twin-circuit connection 10,5 kW Single-circuit connection
Attention!
Make sure to observe the connection plan in the terminal box of the heater.
SSG - sauna control unit,
LSG - power extension unit
