evertz 7825DSK2-LG-HD User manual

7825DSK2-LG-HD & 7825DSK2-LG-3G
Logo Inserters
Instruction Manual
© Copyright 2006 - 2017
EVERTZ MICROSYSTEMS LTD.
5288 John Lucas Drive,
Burlington, Ontario, Canada
L7L 5Z9
Phone: [phone]
Sales Fax: [phone]
Tech Support Phone: [phone]
Tech Support Fax: [phone]
Internet: Sales: [e-mail]
Tech Support: [email protected]
Web Page: http://www.evertz.com
Version 2.0, May 2017
The material contained in this manual consists of information that is the property of Evertz Microsystems and is
intended solely for the use of purchasers of the 7825DSK2-LG Series Logo Inserter and Downstream Keyer.
Evertz Microsystems expressly prohibits the use of this manual for any purpose other than the operation of the
device.
All rights reserved. No part of this publication may be reproduced without the express written permission of Evertz
Microsystems Ltd. Copies of this guide can be ordered from your Evertz products dealer or from Evertz
Microsystems.

This page left intentionally blank

7800 Multiframe Manual
7825DSK2-LG(-HD)(-3G) 3G/HD/SD Dual Downstream Keyer
Revision 2.0
IMPORTANT SAFETY INSTRUCTIONS
The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of uninsulated “Dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (Servicing) instructions
in the literature accompanying the product.
•Read these instructions
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water
•Clean only with dry cloth.
•Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
•Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
•Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than other. A grounding-type plug has two blades and a third
grounding prong. The wide blade or the third prong is provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
•Only use attachments/accessories specified by the manufacturer
•Unplug this apparatus during lightning storms or when unused for long periods of time.
•Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has been dropped.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC – SHOCK
, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE
WARNING
DO NOT EXPOSE THIS EQUIPMENT TO DRIPPING OR SPLASHING AND ENSURE THAT NO
OBJECTS FILLED WITH LIQUIDS ARE PLACED ON THE EQUIPMENT
WARNING
TO COMPLETELY DISCONNECT THIS EQUIPMENT FROM THE AC MAINS
, DISCONNECT THE
POWER SUPPLY CORD PLUG FROM THE AC RECEPTACLE
WARNING
THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL REMAIN READILY OPERABLE

7800 Multiframe Manual
7825DSK2-LG(-HD)(-3G) 3G/HD/SD Dual Downstream Keyer
Revision 2.0
INFORMATION TO USERS IN EUROPE
NOTE
CISPR 22 CLASS A DIGITAL DEVICE OR PERIPHERAL
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to the European Union EMC directive. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
INFORMATION TO USERS IN THE U.S.A.
NOTE
FCC CLASS A DIGITAL DEVICE OR PERIPHERAL
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
WARNING
Changes or Modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s
authority to operate the equipment.
Use of unshielded plugs or cables may cause radiation interference. Properly shielded interface
cables with the shield connected to the chassis ground of the device must be used.

7800 Multiframe Manual
7825DSK2-LG(-HD)(-3G) 3G/HD/SD Dual Downstream Keyer
Revision 2.0
REVISION HISTORY
REVISION DESCRIPTION DATE
1.0 Original Version Oct 2008
1.1 Updated VistaLINK section May 2009
1.2 Table 2-3 Updated: Comm B Pin Out Corrected Feb 2010
1.2.1 Added note on CF Jun 2010
1.3 Updated pin information throughout section 2 May 2011
1.4 Added -3G information. Added Status Indicators section July 2011
1.5 Removed references to Desktop Control Panel August 2011
1.5.1 Added EAN Alert notes to “EAS over TCP/IP” section Dec 2011
1.6 Updates made throughout section 5. Jan 2012
2.0 Full manual update May 2017
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof
nor for the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning
performance of Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The
only warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order
confirmation form.

7800 Multiframe Manual
7825DSK2-LG(-HD)(-3G) 3G/HD/SD Dual Downstream Keyer
Revision 2.0
TABLE OF CONTENTS
1. OVERVIEW................................................................................................................................1-1
1.1. SUMMARY ........................................................................................................................1-1
1.2. HOW TO USE THIS MANUAL...........................................................................................1-2
1.3. DEFINITIONS....................................................................................................................1-3
2. INSTALLATION .........................................................................................................................2-1
2.1. REAR PANEL OVERVIEW................................................................................................2-1
2.1.1. Video Connections .................................................................................................2-1
2.1.2. Reference Video Connections................................................................................2-2
2.1.3. Serial I/O Connections ...........................................................................................2-2
2.1.3.1. Serial Port Pin Out Definitions..................................................................2-4
2.1.4. GPI/O Connections ................................................................................................2-4
2.1.5. Ethernet Network Connections...............................................................................2-5
2.2. MOUNTING.......................................................................................................................2-5
2.3. POWER REQUIREMENTS................................................................................................2-6
2.4. CONNECTING THE REMOTE CONTROL PANEL ...........................................................2-6
2.5. CONNECTING THE VIDEO...............................................................................................2-7
2.5.1. Video Inputs...........................................................................................................2-7
2.5.2. Video Outputs ........................................................................................................2-7
2.5.3. Genlock Reference ................................................................................................2-7
2.6. CONNECTING THE LINEAR TIME CODE........................................................................2-8
2.7. CONNECTING TO AN ETHERNET NETWORK................................................................2-8
2.8. CONNECTING THE GENERAL PURPOSE INPUTS AND OUTPUTS..............................2-9
2.9. CONNECTING THE OPTIONAL TEMPERATURE PROBE ............................................2-13
2.10. MODULE CONFIGURATION ..........................................................................................2-14
2.11. CONFIGURING THE MODULE USING THE MODULE SERIAL PORT..........................2-14
2.11.1. Network Configuration..........................................................................................2-15
2.12. HOW TO INCORPORATE A ROUTER............................................................................2-17
2.12.1. Using a Xenon Router..........................................................................................2-17
2.12.2. Using a X1200 Series Router...............................................................................2-17
3. STATUS INDICATORS ..............................................................................................................3-1
4. HOW TO OPERATE THE DOWNSTREAM KEYER USING VISTALINK®PRO........................4-1
4.1. WHAT IS VISTALINK®?....................................................................................................4-1
4.2. VIDEO TAB .......................................................................................................................4-2
4.2.1. Video Standard ......................................................................................................4-2
4.2.2. Reference Type......................................................................................................4-3
4.2.3. Horizontal Output Offset.........................................................................................4-3

7800 Multiframe Manual
7825DSK2-LG(-HD)(-3G) 3G/HD/SD Dual Downstream Keyer
Revision 2.0
4.2.4. Vertical Output Offset.............................................................................................4-3
4.2.5. Video Mandatory Input ...........................................................................................4-3
4.3. TIME TAB..........................................................................................................................4-4
4.3.1. Displaying Real Time Clock....................................................................................4-5
4.3.2. Displaying the Universal Time Clock Time .............................................................4-5
4.3.3. Displaying the Local Time ......................................................................................4-5
4.3.4. Displaying the Local Date.......................................................................................4-5
4.3.5. Displaying the Universal Date.................................................................................4-5
4.3.6. Displaying the Real Time Date...............................................................................4-5
4.3.7. Enabling Daylight Saving Time Compensation.......................................................4-6
4.3.8. Selecting Whether the Time Code Input is UTC or Local Time ..............................4-6
4.3.9. Setting the LTC Date Format..................................................................................4-6
4.3.10. LTC Presence Detection Enabled ..........................................................................4-6
4.3.11. Synchronizing the Real Time Clock to the UTC Time.............................................4-7
4.3.12. Setting the Time Zone Offset .................................................................................4-7
4.3.13. Up Down Timer ......................................................................................................4-7
4.3.13.1.Setting the Up Down Timer......................................................................4-7
4.4. NETWORK TAB ................................................................................................................4-8
4.4.1. Network IP Address................................................................................................4-8
4.4.2. Sub Net Mask.........................................................................................................4-8
4.4.3. Gateway.................................................................................................................4-8
4.4.4. MAC Address.........................................................................................................4-8
4.5. GENERAL TAB .................................................................................................................4-8
4.5.1. Firmware Version ...................................................................................................4-9
4.5.1.1. Monitoring the Build Number....................................................................4-9
4.5.1.2. Enabling Reboot ......................................................................................4-9
4.5.2. Port Entry...............................................................................................................4-9
4.5.3. General ................................................................................................................4-11
4.5.3.1. Automation Debug and M2100 Debug Functions...................................4-11
4.5.4. Controls................................................................................................................4-11
4.5.4.1. Monitoring the Genlock Status...............................................................4-11
4.5.4.2. Setting the Router Enable......................................................................4-11
4.5.4.3. Configuring the Router Select................................................................4-11
4.5.5. MCP Controls.......................................................................................................4-12
4.6. DSK TAB.........................................................................................................................4-12
4.6.1.1. Setting the Key Type..............................................................................4-12
4.6.1.2. Setting the Key Gain..............................................................................4-13
4.6.1.3. Setting the Key Offset............................................................................4-13
4.6.1.4. Setting the Key Threshold......................................................................4-13
4.6.1.5. Setting the Auto Key Enable ..................................................................4-13
4.7. MATTE TAB ....................................................................................................................4-13
4.7.1. Matte Parameters.................................................................................................4-14
4.7.1.1. Setting the Matte Enable Function .........................................................4-14
4.7.2. Setting a User Defined Matte Aspect Ratio ..........................................................4-14
4.7.2.1. Setting the Matte Top.............................................................................4-14
4.7.2.2. Setting the Matte Bottom .......................................................................4-14
4.7.3. Setting the Matte Aspect Ratio.............................................................................4-15

7800 Multiframe Manual
7825DSK2-LG(-HD)(-3G) 3G/HD/SD Dual Downstream Keyer
Revision 2.0
4.8. GPI/GPO CONTROL TAB...............................................................................................4-15
4.8.1. Configuring the GPO Outputs ..............................................................................4-16
4.8.2. Configuring the GPI Inputs...................................................................................4-17
4.8.2.1. Target Logo...........................................................................................4-17
4.8.2.2. Configuring the Perform Transition Function..........................................4-17
4.8.2.3. Configuring the Load Preset Function....................................................4-18
4.8.2.4. Configuring the Action............................................................................4-18
4.8.2.5. Configuring the Logo Function...............................................................4-18
4.9. TEMPERATURE TAB......................................................................................................4-19
4.9.1. Setting the Temperature Format ..........................................................................4-19
4.9.2. Setting the Temperature Source ..........................................................................4-19
4.9.3. Setting the Static Temperature.............................................................................4-20
4.9.4. Temperature Read Loss.......................................................................................4-20
4.10. TRANSITION TAB...........................................................................................................4-20
4.10.1. Setting the Transition Type ..................................................................................4-20
4.10.2. Setting the Transition Rate...................................................................................4-21
4.10.3. Setting the Transition Swap Mode........................................................................4-21
4.10.4. Pausing a Transition.............................................................................................4-21
4.10.5. Setting Program Bus Change...............................................................................4-22
4.11. EAS TAB .........................................................................................................................4-22
4.11.1. EAS over TCP/IP..................................................................................................4-22
4.11.1.1.Setting the EAS Vertical Position...........................................................4-23
4.11.1.2.Setting the EAS Font .............................................................................4-23
4.11.1.3.Setting the EAS Height..........................................................................4-23
4.11.1.4.Setting the EAS Rate.............................................................................4-23
4.11.2. EAS Colour Settings.............................................................................................4-23
4.12. PRESETS TAB................................................................................................................4-24
4.13. MEDIA TAB.....................................................................................................................4-25
4.13.1. General Control....................................................................................................4-25
4.13.1.1.Setting the Control Bypass.....................................................................4-25
4.13.2. Preview Channel..................................................................................................4-25
4.13.2.1.Setting the Video Input...........................................................................4-25
4.13.2.2.Setting the DSK Layer ...........................................................................4-26
4.13.2.3.Setting the Logo Layer...........................................................................4-26
4.13.2.4.Setting the DSK 2 Layer ........................................................................4-26
4.13.3. Program Control...................................................................................................4-26
4.13.3.1.Setting the Video Input...........................................................................4-26
4.13.3.2.Setting the DSK Layer ...........................................................................4-26
4.13.3.3.Setting the Logo Layer...........................................................................4-26
4.13.3.4.Setting the DSK Layer 2 ........................................................................4-26
4.13.4. Voice Over Control...............................................................................................4-26
4.13.5. Transition Control.................................................................................................4-27
4.13.6. Command Status .................................................................................................4-27
4.13.7. Media All Out........................................................................................................4-27
4.13.8. Static Logo Configuration Settings.......................................................................4-27
4.13.8.1.Setting the Logo Horizontal Position......................................................4-28
4.13.8.2.Setting the Logo Vertical Position ..........................................................4-28
4.13.8.3.Setting the Logo Transparency (Gain)...................................................4-28
4.13.8.4.Setting the Logo Fade In Duration .........................................................4-28

7800 Multiframe Manual
7825DSK2-LG(-HD)(-3G) 3G/HD/SD Dual Downstream Keyer
Revision 2.0
4.13.8.5.Setting the Logo Display Time (Hold).....................................................4-29
4.13.8.6.Setting the Logo Fade Out Duration.......................................................4-29
4.13.8.7.Setting the Up Down Timer....................................................................4-29
4.13.9. Crawl Logo Configuration Settings.......................................................................4-29
4.13.9.1.Setting the Crawl Logo Horizontal Position ............................................4-30
4.13.9.2.Setting the Crawl Logo Vertical Position ................................................4-30
4.13.9.3.Setting the Crawl Logo Transparency (Gain).........................................4-30
4.13.9.4.Setting the Crawl Logo Fade In Duration ...............................................4-31
4.13.9.5.Setting the Crawl Logo Display Time (Hold)...........................................4-31
4.13.9.6.Setting the Crawl Logo Fade Out Duration.............................................4-31
4.13.9.7.Setting the Up Down Timer....................................................................4-31
4.13.9.8.Setting the Crawl Rate...........................................................................4-31
4.13.9.9.Setting the Crawl Repeats Count...........................................................4-31
4.13.9.10. Setting the Crawl Pause Frequency....................................................4-31
4.13.9.11. Setting the Crawl BG Opacity..............................................................4-31
4.13.9.12. Setting the Font Height........................................................................4-32
4.13.9.13. Setting the Font Name ........................................................................4-32
4.13.10. Setting the Crawl Logo Colours..........................................................................4-32
4.13.10.1. Setting the Crawl Outline Opacity........................................................4-33
4.13.10.2. Setting the Logo Layer........................................................................4-33
4.13.10.3. Logo Quick In/Fade Out Effect............................................................4-33
4.13.11. Selecting a Logo or Media Item and Issuing a Fade/Cue/Fade Out...................4-33
4.13.12. Audio Clip Configuration Settings.......................................................................4-34
4.13.13. Setting the Audio Clip Repeat Count..................................................................4-34
4.14. AUDIO CONTROL TAB...................................................................................................4-35
4.14.1. Parameters...........................................................................................................4-35
4.14.2. Settings................................................................................................................4-36
4.14.3. Wav File Playout ..................................................................................................4-38
5. HOW TO OPERATE THE DOWNSTREAM KEYER USING THE REMOTE
CONTROL PANEL.....................................................................................................................5-1
5.1. AN OVERVIEW OF KEY AND DISPLAY FUNCTIONS.....................................................5-1
5.1.1. Preview Bus Button Group .....................................................................................5-1
5.1.2. Program Bus Button Group....................................................................................5-2
5.1.3. The Function Button Group....................................................................................5-3
5.1.4. Setup Button Group................................................................................................5-4
5.1.5. Control Panel Status Indicators..............................................................................5-4
5.1.5.1. Preview Bus Status Indicators..................................................................5-4
5.1.5.2. Program Bus Status Indicators ................................................................5-4
5.1.5.3. Function Status Indicators........................................................................5-5
5.1.6. Electronics Unit Status Indicators...........................................................................5-5
5.1.7. Front Panel Display Functions................................................................................5-5
5.2. OVERVIEW OF FRONT REMOTE CONTROL PANEL OPERATION ...............................5-6
5.2.1. Displaying Logos....................................................................................................5-6

7800 Multiframe Manual
7825DSK2-LG(-HD)(-3G) 3G/HD/SD Dual Downstream Keyer
Revision 2.0
5.3. AN OVERVIEW OF THE SETUP MENU SYSTEM............................................................5-6
5.4. NAVIGATING THE SETUP MENU ....................................................................................5-6
5.5. FRONT PANEL SETUP MENU – MAIN MENU.................................................................5-8
5.6. GENERAL CONFIGURATION ITEMS...............................................................................5-9
5.6.1. Selecting the Video Standard...............................................................................5-10
5.6.2. Setting the Video Output Timing With Respect To Reference..............................5-11
5.6.3. Configuring the Real Time Clock..........................................................................5-12
5.6.3.1. Displaying the Local Time......................................................................5-12
5.6.3.2. Displaying the UTC Time.......................................................................5-12
5.6.3.3. Setting the Real Time Clock ..................................................................5-12
5.6.3.4. Setting the Time Zone Offset.................................................................5-13
5.6.3.5. Enabling Daylight Saving Time Compensation.......................................5-13
5.6.3.6. Selecting Whether the Time Code input is UTC or Local Time..............5-14
5.6.3.7. Synchronizing the Real Time Clock to the UTC Time ............................5-14
5.6.3.8. Displaying the Local Date ......................................................................5-14
5.6.3.9. Displaying the UTC Date........................................................................5-14
5.6.3.10.Setting the Real Time Date....................................................................5-14
5.6.3.11.Setting the LTC Date Format.................................................................5-15
5.6.4. Setting Up the Network Addresses.......................................................................5-15
5.6.4.1. Setting Up the IP Address......................................................................5-15
5.6.4.2. Setting Up the Sub Net Mask.................................................................5-15
5.6.4.3. Setting Up the Gateway.........................................................................5-16
5.6.4.4. Displaying the Ethernet Hardware Address............................................5-16
5.6.4.5. Setting Up the Primary and Secondary Servers.....................................5-16
5.6.4.6. Setting Up the MCP IP Address.............................................................5-16
5.6.5. Displaying SNMP Trap Destination.......................................................................5-16
5.6.6. Displaying AFD Logo Trigger ...............................................................................5-17
5.6.7. Setting the Serial Protocol for COM Ports D and E ..............................................5-17
5.6.8. Setting the Genlock Status...................................................................................5-18
5.6.9. Protecting Line 21 Captions .................................................................................5-19
5.6.10. Setting the Up Down Timer ..................................................................................5-19
5.6.11. Auto Proto Debug Functions ................................................................................5-20
5.7. FILE MANAGEMENT CONFIGURATION ITEMS............................................................5-21
5.7.1. Selecting the Source Media..................................................................................5-21
5.7.2. Selecting the Media File Name.............................................................................5-21
5.7.3. Selecting the Destination Media...........................................................................5-22
5.7.4. Deleting a File ......................................................................................................5-22
5.7.5. Erasing all the Files from a Media Disk ................................................................5-22
5.8. MATTE CONFIGURATION ITEMS..................................................................................5-22
5.8.1. Turning the Matte On and Off...............................................................................5-23
5.8.2. Setting the Matte Aspect Ratio.............................................................................5-23
5.8.3. Setting a User Defined Matte Aspect Ratio ..........................................................5-23
5.9. DOWNSTREAM KEYER CONFIGURATION ITEMS.......................................................5-24
5.9.1. Setting the Downstream Key Type.......................................................................5-24
5.9.2. Setting the Downstream Key Object Transparency..............................................5-24
5.9.3. Setting the Downstream Key Object Offset ..........................................................5-25
5.9.4. Setting the Downstream Self Key Threshold........................................................5-25
5.9.5. Allowing Automation to Control the Media Layer..................................................5-25

7800 Multiframe Manual
7825DSK2-LG(-HD)(-3G) 3G/HD/SD Dual Downstream Keyer
Revision 2.0
5.10. TRANSITION CONFIGURATION ITEMS.........................................................................5-25
5.10.1. Setting the Transition Type...................................................................................5-26
5.10.2. Setting the Transition Rate...................................................................................5-26
5.10.3. Setting the Transition Swap Mode........................................................................5-27
5.10.4. Pausing a Transition.............................................................................................5-27
5.10.5. Setting Program Bus Change...............................................................................5-27
5.11. PRESET CONFIGURATION ITEMS................................................................................5-27
5.11.1. Configuring the GPI Inputs...................................................................................5-28
5.11.1.1.Selecting One of the GPI Inputs to Configure........................................5-29
5.11.1.2.Configuring the GPI Actions...................................................................5-29
5.11.2. Configuring the GPO Outputs...............................................................................5-31
5.11.3. Recalling a User Preset........................................................................................5-32
5.11.4. Storing a User Preset...........................................................................................5-32
5.11.5. Exporting a User Preset .......................................................................................5-32
5.11.6. Selecting the Source of the Preset Settings .........................................................5-32
5.12. SELECTING THE AUDIO OVER TRANS SETTINGS .....................................................5-33
5.13. TEMPERATURE CONFIGURATION ITEMS ...................................................................5-33
5.13.1. Setting the Temperature Source ..........................................................................5-33
5.13.2. Setting the Temperature Format ..........................................................................5-34
5.13.3. Setting the Static Temperature.............................................................................5-34
5.13.4. Temperature Read Loss.......................................................................................5-34
5.14. EAS CONFIGURATION ITEMS (+E OPTIONED UNITS ONLY) .....................................5-35
5.14.1. TCP/IP .................................................................................................................5-35
5.14.2. Setting the Vertical Position of EAS Crawl Display...............................................5-36
5.14.3. Setting the Font used for the EAS Crawl Display..................................................5-36
5.14.4. Setting the Font Size for the EAS Crawl Display ..................................................5-36
5.14.5. Setting the Crawl Rate for the EAS Crawl Display................................................5-36
5.14.6. Setting the Colours for the EAS Crawl Display.....................................................5-37
5.15. MEDIA CONFIGURATION ITEMS...................................................................................5-38
5.15.1. Setting the Logo Horizontal Position.....................................................................5-39
5.15.2. Setting the Logo Vertical Position.........................................................................5-39
5.15.3. Setting the Logo Transparency ............................................................................5-39
5.15.4. Setting the Logo Fade In Duration........................................................................5-39
5.15.5. Setting the Logo Display Time..............................................................................5-40
5.15.6. Setting the Logo Fade Out Duration.....................................................................5-40
5.15.7. Setting the Up Down Timer ..................................................................................5-40
5.15.8. Crawl Logo Configuration Items (Crawl Optioned Units Only) ..............................5-40
5.15.8.1.Setting the Crawl Logo Horizontal Crawl Rate .......................................5-40
5.15.8.2.Setting the Crawl Logo Repeat Count....................................................5-41
5.15.8.3.Setting the Crawl Logo Pause Time between Repeats ..........................5-41
5.15.8.4.Setting the Crawl Logo Text Font Size...................................................5-41
5.15.8.5.Setting the Crawl Logo Text Font...........................................................5-41
5.15.8.6.Setting the Crawl Logo Transparency....................................................5-41
5.15.8.7.Setting the Crawl Logo Colours..............................................................5-42
5.15.9. Audio Clip Configuration Items.............................................................................5-42
5.15.9.1.Setting the Audio Clip Repeat Count......................................................5-42
5.15.9.2.Audio Clip Configuration ........................................................................5-42

7800 Multiframe Manual
7825DSK2-LG(-HD)(-3G) 3G/HD/SD Dual Downstream Keyer
Revision 2.0
6. PLAYLIST COMMANDS............................................................................................................6-1
7. HTML AUDIO SETUP PAGE .....................................................................................................7-1
7.1. HTML SETUP PAGE.........................................................................................................7-1
7.1.1. Main Index Page ....................................................................................................7-1
7.1.2. WAV File Playout ...................................................................................................7-4
7.1.3. METAR Setup Page...............................................................................................7-5
7.1.4. Set Time Page .......................................................................................................7-6
7.1.5. SNMP Trap Dest Page...........................................................................................7-7
7.1.6. Proxy Setup Page ..................................................................................................7-8
7.1.7. Reboot Page..........................................................................................................7-9
8. TECHNICAL DESCRIPTION......................................................................................................8-1
8.1. SPECIFICATIONS.............................................................................................................8-1
8.1.1. Serial Digital Video Input........................................................................................8-1
8.1.2. Serial Digital Video Outputs....................................................................................8-1
8.1.3. Video Reference ....................................................................................................8-1
8.1.4. LTC Reader (on breakout cable)............................................................................8-1
8.1.5. Control (on breakout cable)....................................................................................8-1
8.1.6. General Purpose Inputs and Outputs.....................................................................8-2
8.1.7. Electrical.................................................................................................................8-2
8.1.8. Physical..................................................................................................................8-2
9. UPGRADING THE FIRMWARE .................................................................................................9-1
9.1. OVERVIEW .......................................................................................................................9-1
9.2. FIRMWARE UPGRADE VIA OVERTURE APPLICATION (RECOMMENDED
PROCEDURE) ..................................................................................................................9-2
9.3. FIRMWARE UPGRADE VIA TERMINAL PROGRAM .......................................................9-3
9.3.1. Step 1: Transferring the File to the CF ...................................................................9-3
9.3.1.1. Method 1: Using Overture 2.....................................................................9-3
9.3.1.2. Method 2: Copy Using a CF Reader ........................................................9-4
9.3.2. Step 2: Serial Upgrade Procedure..........................................................................9-4
9.3.2.1. Terminal Program Setup..........................................................................9-5
9.3.2.2. Initiating Firmware Upgrade Mode from the Terminal Program................9-5
9.3.2.3. Uploading the New Firmware...................................................................9-6
9.3.2.4. Completing the Upgrade..........................................................................9-7
10. APPENDIX A............................................................................................................................10-1
10.1. GPI SCRIPTING..............................................................................................................10-1
10.1.1. Scripting Object Syntax........................................................................................10-3
10.1.2. Scenario Samples SAP Programming..................................................................10-6
10.1.3. Bring Up a Trouble Slide Called “trouble”.............................................................10-7
11. INDEX ......................................................................................................................................11-1

7800 Multiframe Manual
7825DSK2-LG(-HD)(-3G) 3G/HD/SD Dual Downstream Keyer
Revision 2.0
Figures
Figure 1-1: 7825DSK2-LG-HD Block Diagram ............................................................................................. 1-2
Figure 2-1: 7825DSK2-LG-HD & 7825DSK2-LG-3G Rear Panels............................................................... 2-1
Figure 2-2: Keyer GPIO Opto Isolator Circuitry........................................................................................... 2-10
Figure 2-3: Powering the General Purpose Input Opto-Isolators from the Unit.......................................... 2-11
Figure 2-4: Powering the General Purpose Input Opto-Isolators from an External Power Supply............. 2-11
Figure 2-5: Powering the General Purpose Output Opto-Isolators from the Unit....................................... 2-12
Figure 2-6: Powering the General Purpose Output Opto-Isolators from an External Power Supply.......... 2-12
Figure 2-7: Tera Term – Main Menu.......................................................................................................... 2-15
Figure 2-8: Tera Term – Network Configuration........................................................................................ 2-16
Figure 3-1: Status LED Locations................................................................................................................. 3-1
Figure 4-1: Video Window............................................................................................................................. 4-2
Figure 4-2: Video Mandatory Input Parameters............................................................................................ 4-4
Figure 4-3: Time Window.............................................................................................................................. 4-4
Figure 4-4: Network Window ........................................................................................................................ 4-8
Figure 4-5: General Window......................................................................................................................... 4-9
Figure 4-6: DSK Window ............................................................................................................................ 4-12
Figure 4-7: Matte Window........................................................................................................................... 4-13
Figure 4-8: GPI/GPO Control Window........................................................................................................ 4-15
Figure 4-9: Temperature Window............................................................................................................... 4-19
Figure 4-10: Transition Window.................................................................................................................. 4-20
Figure 4-11: Wipe Pattern Angles............................................................................................................... 4-21
Figure 4-12: EAS Window........................................................................................................................... 4-22
Figure 4-13: Presets Window ..................................................................................................................... 4-24
Figure 4-14: Media Window........................................................................................................................ 4-25
Figure 4-15: Voice Over Control Options.................................................................................................... 4-26
Figure 4-16: Static Logo Configuration Settings......................................................................................... 4-28
Figure 4-17: Crawl Logo Configuration Settings......................................................................................... 4-30
Figure 4-18: “Choose a Colour” Dialog Box................................................................................................ 4-32
Figure 4-19: Issuing a In/Out/Cued............................................................................................................. 4-33
Figure 4-20: Command Status Table.......................................................................................................... 4-34
Figure 4-21: Audio Clip Configuration Settings........................................................................................... 4-34
Figure 4-22: Audio Control Tab................................................................................................................... 4-35
Figure 5-1: 7825DSK2-LG(-HD)(-3G) – Front Remote Control Panel Layout .............................................. 5-1
Figure 5-2: 7825DSK2-LG(-HD)(-3G) – Back Remote Control Panel Layout............................................... 5-1
Figure 5-3: Overview of the Setup Menu System ......................................................................................... 5-7
Figure 7-1: Main Index Page......................................................................................................................... 7-1
Figure 7-2: HTML Audio Setup Page............................................................................................................ 7-2
Figure 7-3: Metar Setup Page....................................................................................................................... 7-5
Figure 9-1: Upgrading via Overture .............................................................................................................. 9-2
Figure 9-2: Transferring File in Overture....................................................................................................... 9-4
Figure 9-3: 7700FC Boot Monitor ................................................................................................................. 9-6
Figure 9-4: Second Stage Boot Loader ........................................................................................................ 9-6
Figure 9-5: Main Menu.................................................................................................................................. 9-7

7800 Multiframe Manual
7825DSK2-LG(-HD)(-3G) 3G/HD/SD Dual Downstream Keyer
Revision 2.0
Tables
Table 2-1: Remote Panel Port Pin Definitions ...............................................................................................2-2
Table 2-2: Serial Port C and D – RS422 Pin Definitions................................................................................2-3
Table 2-3: Serial Port Pin Definitions.............................................................................................................2-4
Table 2-4: GPI/O Connector Pin Definitions..................................................................................................2-5
Table 2-5: Serial Port C and D RS232 Pin Definitions...................................................................................2-5
Table 2-6: Remote Control Panel Extender Cable ........................................................................................2-6
Table 2-7: Video Input Formats.....................................................................................................................2-7
Table 2-8: Standard RJ45 Wiring Colour Codes...........................................................................................2-8
Table 2-9: GPIO Maximum Ratings.............................................................................................................2-13
Table 2-10: Temperature Probe Extender Cable ........................................................................................2-13
Table 5-1: Top Level of the General Setup Menu..........................................................................................5-9
Table 5-2: Top Level of the Manage Files Setup Menu...............................................................................5-21
Table 5-3: Top Level of the Matte Setup Menu ...........................................................................................5-22
Table 5-4: Top Level of the DSK Setup Menu.............................................................................................5-24
Table 5-5: Top Level of the Transition Setup Menu.....................................................................................5-25
Table 5-6: Top Level of the Preset Setup Menu..........................................................................................5-28
Table 5-7: Top Level of the EAS Setup Menu.............................................................................................5-35
Table 5-8: Top Level of the Media Setup Menu...........................................................................................5-38

7800 Multiframe Manual
7825DSK2-LG(-HD)(-3G) 3G/HD/SD Dual Downstream Keyer
OVERVIEW Revision 2.0
CHAPTER 1
TABLE OF CONTENTS
1. OVERVIEW................................................................................................................................1-1
1.1. SUMMARY ........................................................................................................................1-1
1.2. HOW TO USE THIS MANUAL...........................................................................................1-2
1.3. DEFINITIONS....................................................................................................................1-3

7800 Multiframe Manual
7825DSK2-LG(-HD)(-3G) 3G/HD/SD Dual Downstream Keyer
Revision 2.0 OVERVIEW
This page left intentionally blank

7800 Multiframe Manual
7825DSK2-LG(-HD)(-3G) 3G/HD/SD Dual Downstream Keyer
OVERVIEW Revision 2.0 Page 1-1
1. OVERVIEW
1.1. SUMMARY
The 7825DSK2-LG-HD and 7825DSK2-LG-3G Dual Downstream Keyer and Logo Inserter are
complete packages that will insert simultaneous static or animated logos over a full bandwidth SDI
program video signal.
The 7825DSK2-LG-HD and 7825DSK2-LG-3G have been designed to manage and store multiple
logo objects. Logos are stored in non-volatile Flash memory and may be downloaded to the hardware
via Ethernet FTP using the overture™ software. Both models have two sets of key and fill inputs to
allow for external keyer sources. In addition to the support for two external keyers, up to 16 static or
animated logos can be keyed simultaneously with independent fade control for each logo. The size of
each logo is variable and ranges from 1/25th to full screen. The position of the logo, fade rates, and
animation rates are also user controllable. They come with 1GB of playout cache and 2GB of compact
flash storage.
The onboard preview allows you to cue your logos for position and content verification prior to going
"On Air". The optional features of the 7825DSK2-LG-HD and 7825DSK2-LG-3G are an air
temperature probe and a crawl option which provides the ability to insert crawls with static content.
The 7825DSK2-LG-HD and 7825DSK2-LG-3G are VistaLINK®capable, offering remote monitoring,
control and configuration capabilities via Simple Network Management Protocol (SNMP). This product
feature offers another solution to manage operations including signal monitoring and module
configuration from SNMP-enabled control systems (Manager or NMS) locally or remotely.
Features
•Two downstream keyers with full preview
•Supports 525i/59.94, 625i/50, 720p/50, 720p/59.94, 1080p/60, 1080p/50, 1080i/50, and
1080i/59.94 video formats
•Full 12-bit linear keyer with video fade-in and fade-out processing
•Stores and inserts up to 16 static or animated logos with independent control of logo position,
transparency and offset. Independent controls of fade in and fade out for static logos
•Download logos from a standard PC using Ethernet using overture™ software
•1GB of available playout cache; 2GB of compact flash storage
•LTC input for analog or digital 'Breakfast Clock' logos
•16 channel embedded audio support
•Video input bypass relays for power failure bypass protection
•Multiple control interface options including GPI, RS-232 automation control
•Optional crawl support for static crawls
•Optional temperature probe for temperature logos
•Optional playout cache and compact flash upgrades
Network Management
•Built in VistaLINK® support for remote monitoring and control via SNMP (using VistaLINK® PRO)
•The 7825DSK2-LG-HD and 7825DSK2-LG-3G modules do not require a 7700FC VistaLINK®
Frame Controller. A direct Ethernet connection to the network for VistaLINK® operations must be
provided by the user

7800 Multiframe Manual
7825DSK2-LG(-HD)(-3G) 3G/HD/SD Dual Downstream Keyer
Page 1-2 Revision 2.0 OVERVIEW
EAS Option
•Emergency alert crawls
•Interfaces to TFT, DAS, DEC and SAGE EAS decoders (over IP)
•Maximum number of static logos reduced to 15
Background
Program
Output
Preview
Output
Output
Timing
Generator
S/P
S/P
Ref In
Fill
Logo
Storage
S/P
S/PKey
Fill
3G/HD/SD
Input B
3G/HD/SD
Input A
P/S
Cable
Driver
Bypass
Relay
Protected
P/S
Cable
Driver
S/P
S/PKey
Fill
Fill
Control GPO Status
GPI Control
1
2
Video
Status
VistaLINK®
Interface
Ethernet
1 GB
Serial
Comms
Chroma/Luma
Processor & Filter
12-bit
Linear
Mixer
Chroma/Luma
Processor & Filter
Auto
Synchronizing
Unit
Figure 1-1: 7825DSK2-LG-HD Block Diagram
1.2. HOW TO USE THIS MANUAL
This manual is organized into 9 main chapters: Overview, Installation, Status Indicators, VistaLINK®
PRO Front Panel Operation, Remote Control Panel Operation, Playlist Commands, HTML Audio
Setup, Technical Description, and Upgrading the Firmware. The overview section contains a brief
overview of the 7825DSK2-LG-HD operations, technical features and a glossary to define concepts
and terms used throughout the remainder of the manual. We highly recommend taking the time to
become familiar with the terms and concepts described here before proceeding further into the manual.
Chapter 2 provides a detailed description of the rear panel connectors, and how the 7825DSK2-LG-HD
should be connected into your system.
Chapter 3 provides information on the Status Indicators.
Chapter 4 describes how to operate the 7825DSK2-LG-HD using VistaLINK® PRO.
Chapter 5 describes how to operate the 7825DSK2-LG-HD using the Front Panel Controls or
Rackmount Remote Control Panel. This chapter also includes information on the Setup Menu system.
Chapter 6 provides information on playlist commands.

7800 Multiframe Manual
7825DSK2-LG(-HD)(-3G) 3G/HD/SD Dual Downstream Keyer
OVERVIEW Revision 2.0 Page 1-3
Chapter 7 provides an overview of the HTML setup page.
Chapter 8 provides technical information such as the specifications.
Chapter 9 describes how to upgrade the firmware in the 7825DSK2-LG-HD.
1.3. DEFINITIONS
4:2:2: The sampling ratio used in the HDTV digital video signal. For every 4 samples of luminance
there are 2 samples each of R-Y (Red minus Luminance) and B-Y (Blue minus Luminance).
16x9: A widescreen television format such as HDTV in which the aspect ratio of the screen is 16
units wide by 9 high as opposed to the 4x3 of normal TV.
AES/EBU:(Sometimes abbreviated as AES) Refers to the digital audio standard (AES3-1992) set by
the Audio Engineering Society and European Broadcast Union and used by most forms of
digital audio from CDs to professional digital video.
Aspect Ratio:The ratio of width to height in a picture. Theatre screens generally have an aspect ratio
of 1.85 to 1, widescreen TV (16x9) is 1.77 to 1, and normal TV (4x3) is 1.33 to 1.
CCIR (International Radio Consultative Committee): An international standards committee. (This
organization is now known as ITU.)
CCIR-601: See ITU-R601.
Cliff effect: (also referred to as the ‘digital cliff’) This is a phenomenon found in digital video systems
that describes the sudden deterioration of picture quality when due to excessive bit errors,
often caused by excessive cable lengths. The digital signal will be perfect even though one
of its signal parameters is approaching or passing the specified limits. At a given moment
however, the parameter will reach a point where the data can no longer be interpreted
correctly, and the picture will be totally unrecognisable.
Component analog: The non-encoded output of a camera, video tape recorder, etc., consisting of the
three primary colour signals: red, green, and blue (RGB) that together convey all necessary
picture information. In some component video formats these three components have been
translated into a luminance signal and two colour difference signals, for example Y, B-Y, R-
Y.
Component digital: A digital representation of a component analog signal set, most often Y, B-Y, R-
Y. The encoding parameters are specified by ITU-R709 for HDTV signals. SMPTE 274M
and SMPTE 296M specify the parallel interface.
Composite analog: An encoded video signal such as NTSC or PAL video that includes horizontal
and vertical synchronising information.
Composite digital: A digitally encoded video signal, such as NTSC or PAL video that includes
horizontal and vertical synchronising information.

Items of special note are indicated with a double box like this.

7800 Multiframe Manual
7825DSK2-LG(-HD)(-3G) 3G/HD/SD Dual Downstream Keyer
Page 1-4 Revision 2.0 OVERVIEW
D1: A component digital video recording format that uses data conforming to the ITU-R601
standard. Records on 19 mm magnetic tape. (Often used incorrectly to refer to component
digital video.)
D2: A composite digital video recording format that uses data conforming to SMPTE 244M.
Records on 19 mm magnetic tape. (Often used incorrectly to refer to composite digital
video.)
D3: A composite digital video recording format that uses data conforming to SMPTE 244M.
Records on 1/2" magnetic tape.
D5: A component digital video recording format that uses data conforming to the ITU-R601
standard. Records on 1/2" magnetic tape.
Drop frame: In NTSC systems, where the frame rate is 29.97002618 frames per second, the drop
frame mode permits time of day indexing of the frame numbers by dropping certain frame
numbers. Specifically frames 0, and 1 at the beginning of each minute except minutes
0,10,20,30,40, & 50, are omitted, to compensate for an approximate timing error of 108
frames (3 seconds 18 frames) per hour. A flag bit is set in the time code to signal when the
drop frame mode is in effect.
DVS/168: A standard for carrying EAS notifications over TCP/IP. Crawl text (.txt) and sound (.wav)
files are copied via FTP, then activated by a notification over a custom TCP/IP port.
EAS: Emergency Alert System, a national warning system employed in the U.S.
EBU (European Broadcasting Union): An organisation of European broadcasters that among
other activities provides technical recommendations for the 625/50 line television systems.
Embedded audio: Digital audio is multiplexed onto a serial digital video data stream.
ITU: The United Nations regulatory body governing all forms of communications. ITU-R
(previously CCIR) regulates the radio frequency spectrum, while ITU-T (previously CCITT)
deals with the telecommunications standards.
ITU-R601: An international standard for standard definition component digital television from which was
derived SMPTE 125M and EBU 3246-E standards. ITU-R601 defines the sampling
systems, matrix values and filter characteristics for Y, B-Y, R-Y and RGB component digital
television signals.
Letterbox: Placing a wide screen image on a conventional TV by placing black bands at the top
and bottom of the screen.
Linear time code: (Also known as Longitudinal Time Code) A digital code used for timing and
control purposes on videotape and associated audio tape machines. It is recorded on a
linear track with audio characteristics and is referred to as LTC. Each 80 bit code word is
associated with one television frame, and consists of 26 time bits, 6 flag bits, 32 user bits
and 16 sync bits. This time code may run at 24, 25 or 30 frames per second depending on
the video format. See also SMPTE 12M
LTC: See Linear Time Code
