1. SETUP FOR INSTALLATION OF QMC-DCP ADJUSTABLE RACK MOUNTS
The QMC-DCP-RP is an accessory kit for the QMC Desktop Control Panel (QMC-DCP). The QMC-
DCP-RP accessory kit allows the user to adjust the angle of the QMC-DCP when it is installed in a desk
or rack.
1.1. GETTING STARTED
The QMC-DCP-RP accessory kit comes with the following pieces of equipment:
Part Description Evertz Part # Quantity
A QMC DCP Top Guide Rotation Lock - Right Side QMC-DCP-MC-8 1
B QMC DCP Top Guide Rotation Lock - Left Side EQMC-DCP-MC-9 1
C QMC DCP Bottom Guide Rotation EQMC-DCP-MC-7 2
D 3 x 25mm Pan Head Screw HMMM3X25PANZC 8
E M5 Lockwasher HWASHER-M5LOCK 2
F 5 x 10mm Pan Head Screw HM5X10MM-PANPHIL 2
Table 1-1: Parts List
Figure 1-1: Parts in the QMC-DCP-RP Accessory Kit
"If items are missing from the QMC-DCP-RP accessory kit, please contact Evertz
Service department at 1-905-335-7570 or [email protected].

Installation Guide for the QMC-DCP-RP
Page 2 Revision 1.0
2. REMOVING PROTECTIVE COVERS
The QMC-DCP is shipped with protective covering on the mounting braces. These covers can be
removed by unscrewing the screws, as shown in Figure 2-1. This step is repeated for both the right
and left side of the QMC-DCP. (See Figure 2-2 and Figure 2-3)
Figure 2-1: Protective Cover on QMC-DCP
Figure 2-2: Remove the Protective Covering from the Right Side

Installation Guide for the QMC-DCP-RP
Revision 1.0 Page 3
Figure 2-3: Remove the Protective Covering from the Left Side
Figure 2-4 shows the QMC-DCP with both protective covers removed.
Figure 2-4: Protective Cover removed from the QMC-DCP

Installation Guide for the QMC-DCP-RP
Page 4 Revision 1.0
3. INSTALLING THE ADJUSTABLE MOUNTS
The QMC-DCP-RP accessory kit has two major parts: The Top Guides (right and left) and the Bottom
Guides. The right and left Top Guides are fastened on the QMC-DCP panel itself and the Bottom
Guides are fastened to the mounting 19” wide rack on the desk or in the equipment room.
3.1. STEP 1: INSTALLING THE TOP GUIDES TO THE RIGHT AND LEFT SIDE
Place Top Guide Rotation Lock – Right Side (PART A) onto the mounting bracket on the right side of
the QMC-DCP. (See Figure 3-1)
Figure 3-1: Attaching the Top Guide Rotation Lock – Right Side
Using four 3x25mm Pan Screws (Part D), secure the Top Guide Rotation Lock to the QMC-DCP as
shown in Figure 3-2.

Installation Guide for the QMC-DCP-RP
Revision 1.0 Page 5
Figure 3-2: Securing the Top Guide Rotation Lock – Right Side
Repeat the process for attaching the Top Guide Rotation Lock – Left Side to the mounting bracket on
the left side of the QMC-DCP panel, as shown in Figure 3-3 and Figure 3-4.
Figure 3-3: Attaching the Top Guide Rotation Lock – Left Side

Installation Guide for the QMC-DCP-RP
Page 6 Revision 1.0
Figure 3-4: Securing the Top Guide Rotation Lock – Right Side
3.2. STEP 2: INSTALLING THE BOTTOM GUIDES
The Bottom Guides (Part C – see Figure 3-5) are fastened to the rack or desktop rack that the QMC-
DCP is being fitted in. There are two Bottom Guides provided in the QMC-DCP-RP. These parts are
bi-directional, therefore, no right or left designation is required. The Bottom Guides are fastened to the
rack through the mounting holes shown in Figure 3-5.
"
The screws used to fasten the Bottom Guides to the rack or desktop rack ARE NOT
INCLUDED in the QMC-DCP-RP Accessory kit. The user MUST provide this
hardware.

Installation Guide for the QMC-DCP-RP
Revision 1.0 Page 7
Figure 3-5: Bottom Guide with mounting holes
When installing the Bottom Guide to the rack, the user should be aware that the Bottom Guide attaches
to the Top Guide with Rotation Lock, as shown in Figure 3-6 and Figure 3-7. Therefore, care MUST be
taken when centering the Bottom Guide in the rack. This step is repeated for both the right and left side
of the rack or desktop rack.
Figure 3-6: Bottom Guide position in respect to Top Guide (not installed)

Installation Guide for the QMC-DCP-RP
Page 8 Revision 1.0
Figure 3-7: Bottom Guide position in respect to Top Guide (installed)
3.3. STEP 3: COMPLETING THE ASSEMBLY
For the final step of the assembly, the user can adjust the angle of the panel using the pin connector
shown in Figure 3-8. Once the desired angle is achieved, the user fixes this angle by tightening the
Lock Screw (Part E), shown in Figure 3-8.
Figure 3-8: Adjusting and securing the angle
