evertz 7800EMR-HYDRA2 User manual

7800EMR-HYDRA2
User Manual
© Copyright 2020
EVERTZ MICROSYSTEMS LTD.
5288 John Lucas Drive
Burlington, Ontario
Canada L7L 5Z9
Phone: [phone]
Sales: [e-mail] Fax: [phone]
Tech Support: [e-mail] Fax: [phone]
Web Page: http://www.evertz.com
Version 1.0, April 2020
The material contained in this manual consists of information that is the property of Evertz Microsystems and is intended solely for the use of
purchasers of the 7800EMR-HYDRA2 product. Evertz Microsystems expressly prohibits the use of this manual for any purpose other than the
operation of the 7800EMR-HYDRA2 product. Due to on going research and development, features and specifications in this manual are subject to
change without notice.
All rights reserved. No part of this publication may be reproduced without the express written permission of Evertz Microsystems Ltd. Copies of
this manual can be ordered from your Evertz dealer or from Evertz Microsystems.

This page left intentionally blank

IMPORTANT SAFETY INSTRUCTIONS
The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of uninsulated “Dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (Servicing) instructions
in the literature accompanying the product.
•Read these instructions
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water
•Clean only with dry cloth.
•Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
•Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
•Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than other. A grounding-type plug has two blades and a third grounding prong.
The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
•Only use attachments/accessories specified by the manufacturer
•Unplug this apparatus during lightning storms or when unused for long periods of time.
•Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
•
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC –
SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE
WARNING
DO NOT EXPOSE THIS EQUIPMENT TO DRIPPING OR SPLASHING AND ENSURE THAT NO
OBJECTS FILLED WITH LIQUIDS ARE PLACED ON THE EQUIPMENT
WARNING
TO
COMPLETELY DISCONNECT THIS EQUIPMENT FROM THE AC MAINS, DISCONNECT THE
POWER SUPPLY CORD PLUG FROM THE AC RECEPTACLE
WARNING
THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL REMAIN READILY OPERABLE

INFORMATION TO USERS IN EUROPE
NOTE
CISPR 22 CLASS A DIGITAL DEVICE OR PERIPHERAL
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to the European Union EMC directive. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
INFORMATION TO USERS IN THE U.S.A.
NOTE
FCC CLASS A DIGITAL DEVICE OR PERIPHERAL
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
WARNING
Changes or Modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s
authority to operate the equipment.
Use of unshielded plugs or cables may cause radiation interference. Properly shielded interface cables
with the shield connected to the chassis ground of the device must be used.
EN60065
Safety
EN504192 2005
Waste electrical products should not be
disposed of with household waste. Contact
your Local Authority for recycling advice
EN55103-1: 1996
Emission
EN55103-2: 1996
Immunity

7800EMR-HYDRA2
User Manual
Revision 1.0 Page-i
REVISION HISTORY
REVISION DESCRIPTION DATE
1.0
First Release
Apr 2020
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor
for the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning
performance of Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The
only warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order
confirmation form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no
warranty is granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or
order confirmation. Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If
you encounter an error, please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make
changes in equipment design or specifications.

7800EMR-HYDRA2
User Manual
Page-ii Revision 1.0
ii
This page left intentionally blank

7800EMR-HYDRA2
User Manual
Revision 1.0 Page-iii
TABLE OF CONTENTS
1. OVERVIEW ...................................................................................................................................1
2. SPECIFICATION ...........................................................................................................................3
2.1. ORDERING INFORMATION.................................................................................................3
2.1.1. Rear Plate Suffix........................................................................................................3
2.1.2. Enclosures.................................................................................................................3
2.1.3. Ordering Options .......................................................................................................3
3. INSTALLATION.............................................................................................................................5
3.1. INSTALLATION OF 7800EMR-HYDRA2 ON 7800FR FRAME ............................................5
3.2. FRONT CARD EDGE CONTROLS AND LEDS....................................................................7
4. SERIAL CONFIGURATION...........................................................................................................9
4.1. NETWORK CONFIGURATION.............................................................................................9
4.2. AUDIO CONFIGURATION....................................................................................................9
4.3. HID ADDRESS ...................................................................................................................10
4.4. SFP SETUP ........................................................................................................................11
4.5. PUSHING NAMES FROM MAGNUM .................................................................................11
5. VISTALINK®PRO CONFIGURATION.........................................................................................17
6. UPDATING VLPRO SERVER JAR FILE.....................................................................................19
7. UPGRADING THE FIRMWARE ON 7800EMR-HYDRA2 THROUGH FTP .................................21

7800EMR-HYDRA2
User Manual
Page-iv Revision 1.0
iv
FIGURES
Figure 1-1 : 7800EMR-HYDRA2 Block Diagram.............................................................................................. 2
Figure 1-2 : 7800EMR-HYDRA2 Top View ...................................................................................................... 2
Figure 3-1 : 7800EMR-HYDRA2 Rear Panel ................................................................................................... 5
Figure 3-2 : Illustration of 7800EMR-HYDRA2 card in 7800 Frame ................................................................ 6
Figure 3-3: 7800EMR-HYDRA2 Card Edge ..................................................................................................... 7
Figure 4-1 : Network Configuration .................................................................................................................. 9
Figure 4-2 : Audio Configuration ...................................................................................................................... 9
Figure 4-3 : H2M Module................................................................................................................................ 10
Figure 4-4 : HID Address................................................................................................................................ 10
Figure 4-5 : SFP Status .................................................................................................................................. 11
Figure 4-6 : Carlec Setup ............................................................................................................................... 12
Figure 4-7 : Calrec Webpage ......................................................................................................................... 13
Figure 4-8 : Hydra2 Card SFP........................................................................................................................ 13
Figure 4-9 : Patching ...................................................................................................................................... 14
Figure 4-10 : MAGNUM Interfaces................................................................................................................. 15
Figure 6-1 : VistaLINK®PRO Server.............................................................................................................. 19
Figure 6-2 : VistaLink®PRO – Applying JAR Updates................................................................................... 20
Figure 6-3 : VistaLink®PRO – Restart You Alarm Server.............................................................................. 20
Figure 7-1 : Run Window for FTP Access ...................................................................................................... 21
Figure 7-2 : Sample FTP Upgrade Window ................................................................................................... 22
TABLES
Table 3-1: Description of 7800EMR-HYDRA2 Card Edges ............................................................................. 7

7800EMR-HYDRA2
User Manual
Revision 1.0 Page-1
1. OVERVIEW
The 7800EMR-HYDRA2 interface module provides 7800EMR existing and new EMR audio systems
the ability to integrate directly to Calrec Hydra2* audio systems, by means of a seamless bidirectional
translation between Evertz TDM and Calrec Hydra2. Featuring primary and secondary Hydra2 paths
that are capable of 512 bidirectional audio channels (at 48kHz), primary and secondary TDM paths
all are monitored and provide an automatic failover mechanism, in addition there is a licensable
feature to allow for name transfer, from a Magnum Unified Control System to the Calrec Hydra 2
system for the appropriate audio labels.
The 7800EMR–HYDRA2 interface module just makes sense, it simplifies system wiring, configuration
and overall management of the audio signals, monitoring and name transfers, not to mention it
provides path redundancy as well as saving rack and module slots space. When we compare this to
a traditional or equivalent system one would require multiple MADI lines to interlink the systems via
numerous MADI conversion boxes on both ends, which to a key point do not have an inherently
incorporated path redundancy as seen with Hydra2/TDM Audio paths, and then names would be
handled in a separate protocol translator card with additional complicated configuration required.
Features & Benefits
•Compact 2 Slot design
•512 mono channels
•Main and Redundant paths with auto fail over or dual path
•Reference Via Frame or external connection
•High Availability, 24/7 Design
•Full modular design
•Hot swappable
•Passive I/O rear plate
•Redundant Frame power supply
•Comprehensive system monitoring bus
•VistaLINK® PRO SNMP monitoring of I/O modules
•Supports Backwards compatibility to 7700FR
* Hyrda2 is a Trade Mark of Calrec Audio Ltd.

7800EMR-HYDRA2
User Manual
Page-2 Revision 1.0
Figure 1-1 : 7800EMR-HYDRA2 Block Diagram
Figure 1-2 : 7800EMR-HYDRA2 Top View

7800EMR-HYDRA2
User Manual
Revision 1.0 Page-3
2. SPECIFICATION
2.1. ORDERING INFORMATION
7800EMR–HYDRA2 TDM to Hydra2 bi–directional interface module ** Calrec Hydra2
Daughter Card to be purchased from Calrec
2.1.1. Rear Plate Suffix
+3RU 3RU Rear Plate for use with 7700FR-C or 7800FR Multiframe
2.1.2. Enclosures
350FR 3RU Portable Multiframe which holds up to 7 single slot modules
7800FR 3RU Multiframe which holds up to 15 single slot modules
7801FR 1RU Multiframe which holds up to 4 single or 2 dual slot
2.1.3. Ordering Options
+NAMES License to enable name transfer from the MAGNUM Unifi ed
control system to the Calrec Hydra 2 system

7800EMR-HYDRA2
User Manual
Page-4 Revision 1.0
This page left intentionally blank

7800EMR-HYDRA2
User Manual
Revision 1.0 Page-5
3. INSTALLATION
Before handling the card, it is important to minimize the potential effects of static electricity. It is
therefore recommended that an ESD strap to be worn.
7800EMR-HYDRA2 module must have minimum 1 slot vacant in the frame. Each rear plate can house
one 7800EMR-HYDRA2 module.
3.1. Installation of 7800EMR-HYDRA2 on 7800FR Frame
Step 1: Install the 7800EMR-HYDRA2 rear plate to the 7800 Frame with screws provided and make
sure the orientation of the card as is shown in Figure 3-1.
Figure 3-1 : 7800EMR-HYDRA2 Rear Panel

7800EMR-HYDRA2
User Manual
Page-6 Revision 1.0
Step 2: Insert the 7800EMR-HYDRA2 card in the 7800 Frame and make sure the orientation of the
card will be as is shown in Figure 3-2.
Figure 3-2 : Illustration of 7800EMR-HYDRA2 card in 7800 Frame

7800EMR-HYDRA2
User Manual
Revision 1.0 Page-7
3.2. FRONT CARD EDGE CONTROLS AND LEDS
The 7800EMR-HYDRA2 front card edges have some key controls and indicators that can help in the
installation and debugging processes. Figure 3-3 shows the card edges and Table 3-1 describe the
expected behaviour of each component. When applied relevant signal to the card, the following card
edge LED’s should light up.
Figure 3-3: 7800EMR-HYDRA2 Card Edge
Component
Description
TDM Present LEDs
LD8 Green
TDM input 1,TDM signal present
LD2 Green
TDM input 2,TDM signal present
Reference LED
LD6 Green
Video PLL Status is locked
LD6 Red
Video PLL Status is unlocked
Ethernet Speed LED
LD11 Green or Off
Depending on speed
Ethernet Activity LED
LD12 Flashes Green
Activity
Rotary Switch
Switches the display to view firmware version, IP address and
Table 3-1: Description of 7800EMR-HYDRA2 Card Edges

7800EMR-HYDRA2
User Manual
Page-8 Revision 1.0
This page left intentionally blank

7800EMR-HYDRA2
User Manual
Revision 1.0 Page-9
4. SERIAL CONFIGURATION
4.1. NETWORK CONFIGURATION
This section allows the user to configure the IP address, Netmask address, Gateway, Broad cast
address and DHCP mode.
Figure 4-1 : Network Configuration
4.2. AUDIO CONFIGURATION
This section allows the user to configure and view Audio settings. To view the audio input packets and
audio input status, Go to options 1) Video Audio Input Packets Table and option 2) View Audio Input
Status Table
Figure 4-2 : Audio Configuration

7800EMR-HYDRA2
User Manual
Page-10 Revision 1.0
4.3. HID ADDRESS
This section allows the user to check the HID address of H2M module. Go the menu (3) Audio
Configuration, then (4) Hydra Module Options, then (10) Send HID request to Hydra module.
HID address is used to communicate with the Calrec.
If H2M module not plugged in to the Hydra2 card, there will be no communication between Calrec and
Hydra2 card. HID should not be detected.
Figure 4-3 : H2M Module
Figure 4-4 : HID Address

7800EMR-HYDRA2
User Manual
Revision 1.0 Page-11
4.4. SFP SETUP
This should detect the SFP and report back with a Vendor name (Avago, for instance).
Go to option 6) Show SFP setup -> 1) Show SFP status,
Figure 4-5 : SFP Status
4.5. PUSHING NAMES FROM MAGNUM

Note: +Names Option Available for Mono mode only

7800EMR-HYDRA2
User Manual
Page-12 Revision 1.0
Setting up Calrec’s Test Rack
Secondary SFP should configured same as Primary SFP only difference will be control and router SFP
location (Use Secondary SFP location)
1. Calrec rack IP address is set to 192.1.1.0, to change this please refer to Calrec’s initial setup for
Evertz document or the label on top of the chassis. Set your test pc’s 2nd network adaptor IP
address to 192.1.134.0 and Netmask 255.255.0.0 and MAC address to 000D07FF8600 (also called
the locally administered address).
2. Insert the two Eoptolink Copper SFP’s provided, one into the CONTROL card’s Surface port 1 or 2
and the other into any of the ROUTER card’s Hydra2 ports. Also plug a PAL/NTSC video reference
into Video 2 Sync input on the central RESET card – see picture below.
CAUTION: Do not hot plug SFPs into the Calrec Rack
Figure 4-6 : Carlec Setup
3. Plug the Control CAT5 cable into the test pc’s 2nd network connection and power cycle the Calrec
Rack. Wait 30 seconds until Active and Module OK leds both on for CONTROL and ROUTER cards.
Confirm that you can ping 192.1.1.0.
Open Chrome and type in the following URL http://192.1.1.0:8080 This will be up the login screen for
Calrec’s H2O interface. Log in with the following:
Username = admin
Password = admin1
Once logged in you should see the following tabs below:
