Exaco Tulip House User manual

Louvre Assembly Instruction
For the louvre assembly you will need 1 top cill, 1 bottom
cill, 2 side jambs(one with handle), 4 self tapping screws,
4 crop head bolts and nuts and glass blades or polycar-
bonate blades (including 4 alu.clips and 2 PVC anti-dust
strip).
2. Installation of louvre to the structure
＊ The louvre is fitted after the unit is assembled fully and during glazing.
＊ The louvre is fitted to the vertical glazing bar/wall or corner bar utilizing either 4 unoccupied bolts previ-
ously inserted, or the 4 crop head bolts supplied with the louvre kit.
＊ The louvre is fitted from inside the structure with the angle jams fitting around the vertical greenhouse
bars concerned.
＊ The louvre handle is on the inside of the greenhouse and is fitted to the right of the louvre ( as viewed
from the inside)
＊ First you should locate where to fit the louvre, To determine the height, place the relevant piece of poly-
carbonate panel below the louvre position. this position will vary .
＊ Then you should cut polycarbonate panel, If you want to fit the louvre in the middle of of polycarbonate
panel, then cut size 456mm (remove middle part size 456mm) and remain both ends. If you want to fit
louvre at the end of panel, then cut 475mm size from PC panel end (remove end part).
Procedure：
1. Installation of Louvre frame
＊ Place top cill into position on side jamb of louvre and secure with self tapping screws.
＊ Do same on the other top corner.
＊ Do same with bottom cill.
＊ Please note that the handle is on the right hand side. The diagrams are viewed from inside.
＊ You attach the louvre to the frame during the glazing of the greenhouse.
475
456

PCPanel573x97x4mm
Alu.Cover Strip
Alu.Cover Strip
Instead
＊ Put the PVC anti-dust strip p6 on the end of cutted & remained panel
p6
p6
＊ Offer the louvre frame to the bolts, add a nut to each bolt and fingertip tighten.
＊ Put the Alu.clip on the top and bottom cill first
＊ Slide the louvre frame to the top of the pane of polycarbonate so that the bottom cill of the louvre rests on
the polycarbonate panel.
＊ Tighten all nuts
Louvre frame installation is now complete.
3. Glazing the louvre
The louvre must be glazing after it has been installed to the
structure
＊ Open the louvre using the handle
＊ Slide each individual blade of polycarbonate panel be-
tween the jams into the aluminium holders
＊ The glass(polycarbonate) will come to rest in the holder
at the bottom of the jams.
Note:
For Polycarbonate------The polycarbonate blades are
supplied with an aluminium cover strip which serves to re-
inforce and protect the insulating flutes-simply fit them to
either side of the glazing.
For Toughened Glass------The louvre blades for the toughened glass model have specially rounded edges
and, therefore, can be fitted directly into the louvre.
456 x 610
