Festo CPX-FB39 Operating and installation instructions

Electronics
description
Network protocol
Sercos III
8028633
1504NH
[8028639]
Bus node CPX-FB39
Terminal CPX

Bus node CPX-FB39
2 Festo – P.BE-CPX-FB39-EN – 1504NH – English
Translation of the original instructions
P.BE-CPX-FB39-EN
CODESYS®, SERCOS®, SPEEDCON®are registered trademarks of the respective trademark owners in
certain countries.
Identification of hazards and instructions on how to prevent them:
Warning
Hazards that can cause death or serious injuries.
Caution
Hazards that can cause minor injuries or serious material damage.
Other symbols:
Note
Material damage or loss of function.
Recommendations, tips, references to other documentation.
Essential or useful accessories.
Information on environmentally sound usage.
Text designations:
 Activities that may be carried out in any order.
1. Activities that should be carried out in the order stated.
– General lists.

Bus node CPX-FB39
Festo – P.BE-CPX-FB39-EN – 1504NH – English 3
Table of Contents – Bus node CPX-FB39
1 Safety and requirements for product use 7......................................
1.1 Safety 7..................................................................
1.1.1 General safety instructions 7.........................................
1.1.2 Use for intended purpose 7...........................................
1.2 Requirements for product use 8...............................................
1.2.1 Technical requirements 9............................................
1.2.2 Qualification of the specialized personnel (requirements for the personnel) 9...
1.2.3 Range of application and certifications 9................................
1.2.4 Quoted guidelines and standards 9....................................
2 Installation 10..............................................................
2.1 General instructions on installation 10...........................................
2.2 Electrical connections and indicators 11..........................................
2.3 Mounting and dismantling 12..................................................
2.3.1 Mounting 12.......................................................
2.3.2 Dismantling 12.....................................................
2.3.3 Complying with degree of protection IP65/IP67 13.........................
2.4 Settings of the DIL switches on the bus node 14...................................
2.4.1 Removing and attaching the DIL switch cover 14...........................
2.4.2 Arrangement of the DIL switches 14.....................................
2.4.3 Setting the DIL switches 15...........................................
2.4.4 Setting the operating mode 15.........................................
2.4.5 Setting of the diagnostic mode (remote I/O) 16...........................
2.4.6 Setting of the I/O mode (remote controller) 17............................
2.4.7 Set the Sercos address 18............................................
2.5 Connecting to the network 19..................................................
2.5.1 General notes about Sercos networks 19.................................
2.5.2 Overview of connection technology and network plugs 19...................
2.5.3 Cable specification 20................................................
2.5.4 Network connections 20..............................................
2.5.5 Setting the IP address 21.............................................
2.5.6 Webserver function 22...............................................
2.6 Power supply 23.............................................................
3 Commissioning 24...........................................................
3.1 General points about Sercos III 24..............................................
3.2 Depiction of the CPX system on the Sercos-device model 25..........................
3.3 Device description 25........................................................

Bus node CPX-FB39
4 Festo – P.BE-CPX-FB39-EN – 1504NH – English
3.4 Address assignment 26.......................................................
3.4.1 Bus node 27........................................................
3.4.2 Digital modules 28..................................................
3.4.3 Analogue modules 31................................................
3.4.4 Technology modules 32...............................................
3.4.5 Determination of the address assignment 34..............................
3.5 Addressing 35..............................................................
3.5.1 Basic rules for addressing 35..........................................
3.5.2 Example 1: CPX terminal with electronic modules VMPA1 and VMPA2 36........
3.5.3 Example 2: CPX terminal with electrical interface (CP interface) 37............
3.5.4 Example 3: CPX terminal with analogue module and pneumatic interface 38.....
3.5.5 Address assignment after extension/conversion 39........................
3.6 Incorporation in the host system 40.............................................
3.6.1 Codesys control software 40...........................................
3.6.2 Installing device description files (SDDML files) 40.........................
3.6.3 Inserting field bus 42.................................................
3.6.4 Insert bus node 44..................................................
3.6.5 Inserting other modules 47............................................
3.6.6 I/O assignment 48...................................................
3.6.7 Changing parameters in Codesys 49.....................................
3.7 Parameterisation 50.........................................................
3.7.1 Introduction to parameterisation 50.....................................
3.7.2 Prerequisite for parameterization 51....................................
3.7.3 Methods of parameterisation 51.......................................
3.7.4 Parameterisation via the Festo Maintenance Tool (CPX-FMT) software 52.......
3.7.5 Parameterization with the control device (CPX-MMI) 52.....................
3.7.6 Parameterization via Sercos III 52......................................
4 Diagnostics and error handling 53..............................................
4.1 Summary of diagnostics options 53.............................................
4.2 Diagnostics via LED displays 54.................................................
4.2.1 Standard operating status 55..........................................
4.2.2 CPX-specific LEDs 55.................................................
4.2.3 Network-specific LEDs 57.............................................
4.3 Diagnostics via status bits 59..................................................
4.4 Diagnostics via the I/O diagnostics interface 60....................................
4.5 Diagnostics via Sercos III 61...................................................
4.5.1 Basic diagnostic functions 61..........................................
4.5.2 I/O diagnostics 61...................................................
4.5.3 I/O diagnostics with Festo-specific extensions 62..........................
4.6 Error handling 63............................................................

Bus node CPX-FB39
Festo – P.BE-CPX-FB39-EN – 1504NH – English 5
A Technical appendix 64........................................................
A.1 Technical data 64............................................................
A.2 List of abbreviations 65.......................................................
B Identification Numbers (IDNs) 67...............................................
B.1 Sercos Communication Profile (SCP) 67..........................................
B.1.1 Function Group - SCP Identification 67...................................
B.1.2 Function Group - Timing 67............................................
B.1.3 Function Group - Telegram Setup 67.....................................
B.1.4 Function Group - Control 68...........................................
B.1.5 Function Group - Bus Diagnosis 68......................................
B.1.6 Function Group - Connection 69........................................
B.1.7 Function Group - NRT 69..............................................
B.2 Generic Device Profile (GDP) 70................................................
B.2.1 Function Group - Diagnosis 70.........................................
B.2.2 Function Group - Administration 70.....................................
B.2.3 Function Group - Identification 71......................................
B.2.4 Function Group - Time 71.............................................
B.3 Function Specific Profile IO (FSP IO) 72...........................................
B.3.1 Function Group - Generic I/O 72........................................
B.3.2 Function Group - Bus Coupler 72.......................................
B.3.3 Manufacturer-specific extensions to the Function Specific Profile IO (FSP IO) 73..
B.4 Overview of the supported classes 74...........................................
B.4.1 Supported classes of the Sercos Communication Profile (SCP) 74.............
B.4.2 Supported classes of the Generic Device Profile (GDP) 74...................
C Diagnostic messages 75......................................................
C.1 Depiction of CPX diagnostic classes on Sercos diagnostic classes 75...................
C.2 Depiction of CPX diagnostic messages on Sercos status codes 75.....................
Index 79........................................................................

Bus node CPX-FB39
6 Festo – P.BE-CPX-FB39-EN – 1504NH – English
Instructions on this documentation
This description contains specific information about the installation, commissioning and diagnostics of
the CPX bus node for Sercos III as well as specific information about Sercos III relating to the paramet
erization, commissioning, programming and diagnostics of a CPX terminal in a Sercos III network.
You will find further information about Sercos III on the Internet:
èwww.sercos.org
General basic information about the mode of operation, mounting, installation and commissioning of
CPX terminals can be found in the CPX system description (èP.BE-CPX-SYS-…).
Information about additional CPX modules can be found in the description for the respective module.
An overview of the structure of user documentation for the CPX terminal can be found in
the CPX system description (èP.BE-CPX-SYS-…).
Service
Please consult your regional Festo contact if you have any technical problems.

1 Safety and requirements for product use
Festo – P.BE-CPX-FB39-EN – 1504NH – English 7
1 Safety and requirements for product use
1.1 Safety
1.1.1 General safety instructions
 The general safety information in the corresponding chapters must be observed.
Special safety and danger warnings are written directly before the action instruction.
Please Note
Damage to the product from incorrect handling.
 Switch off the supply voltage before mounting and installation work. Switch on sup
ply voltage only when mounting and installation work are completely finished.
 Never unplug or plug in a product when powered!
 Observe the handling specifications for electrostatically sensitive devices.
1.1.2 Use for intended purpose
The module described in this document, used in conjunction with a CPX terminal, makes it possible to
connect up as a participant on a Sercos III network.
The module is intended for use in an industrial environment. Outside of industrial environments, e.g. in
commercial and mixed-residential areas, actions to suppress interference may have to be taken.
The module is intended exclusively for use in CPX terminals from Festo for installation in machines or
automated systems and may be used only in the following ways:
– In perfect technical condition
– in original status without unauthorised modifications, except for the adaptations described in this
documentation
– within the limits of the product defined through the technical data (èA.1 Technical data).

1 Safety and requirements for product use
8 Festo – P.BE-CPX-FB39-EN – 1504NH – English
Warning
Electrical voltage
Injury caused by electric shock, damage to machine and to system
 For the electrical power supply, use only PELV circuits in accordance with
IEC 60204-1 (Protective Extra-Low Voltage, PELV).
 Observe the general requirements of IEC 60204-1 for PELV circuits.
 Use only voltage sources which guarantee reliable electrical isolation of the operat
ing and load voltage in accordance with IEC 60204-1.
 Always connect all circuits for operating and load voltage supply UEL/SEN, UVAL and
UOUT.
Through the use of PELV circuits, protection against electric shock (protection against direct and indir
ect contact) is ensured in accordance with IEC 60204-1.
 Note the information about the power supply and about the applicable grounding
measures provided in the CPX system description (èP.BE-CPX-SYS-…).
Please Note
In the event of damage caused by unauthorised manipulation or other than intended
use, the guarantee is invalidated and the manufacturer is not liable for damages.
1.2 Requirements for product use
 Make this documentation available to the design engineer, installer and personnel responsible for
commissioning the machine or system in which this product is used.
 Make sure that the specifications of the documentation are always complied with. Consider also the
documentation for other components and modules (e.g. CPX system description, P.BE-CPX-SYS-…).
 Take into consideration the legal regulations applicable for the location as well as:
– Regulations and standards
– Regulations of the testing organisations and insurers
– national specifications.

1 Safety and requirements for product use
Festo – P.BE-CPX-FB39-EN – 1504NH – English 9
1.2.1 Technical requirements
General conditions for the correct and safe use of the product, which must be observed at all times:
 Comply with the connection and ambient conditions specified in the technical data of the product
(èAppendix A.1) and for all connected components.
Only compliance with the limit values or load limits permits operation of the product in accordance
with the relevant safety regulations.
 Observe the notes and warnings in this documentation.
1.2.2 Qualification of the specialized personnel (requirements for the personnel)
This description is directed exclusively to technicians trained in control and automation technology,
who are experienced in:
– the installation, commissioning, programming and diagnosis of programmable controllers (PLCs)
and field bus systems
– the applicable regulations for operating safety-engineered systems
– the applicable regulations for accident prevention and industrial safety
– the documentation for the product.
1.2.3 Range of application and certifications
Standards and test values, which the product complies with and fulfils, can be found in the “Technical
data” section (èAppendix A.1). The product-relevant EU directives can be found in the declaration of
conformity.
Certificates and declaration of conformity on this product can be found at www.festo.com.
1.2.4 Quoted guidelines and standards
Issue status
ANSI/TIA-568-B.1-3:2003-02 IEC 61076-2:2011-06
IEC 60204-SER:2013-04 IEEE 802.3:2012
IEC 60204-1:2009-02 ISO/IEC 11801:2008-09
IEC 60529:2001-02
Tab. 1.1

2 Installation
10 Festo – P.BE-CPX-FB39-EN – 1504NH – English
2 Installation
2.1 General instructions on installation
Warning
Uncontrolled movement of the actuators, loose tubing, undefined switching states of
the electronics
Injury caused by moving parts, damage to machine and to system
Before mounting and installation work:
 Switch off the power supply
 Switch off the compressed air supply
 Vent the pneumatics.
Caution
The CPX bus node contains electrostatically sensitive devices.
 Therefore, do not touch any components.
 Observe the handling specifications for electrostatically sensitive devices.
They will help you avoid damage to the electronics.
Please Note
Ensuring degree of protection IP65/IP67
 Use cover caps or dummy plugs to seal unused connections
(è2.3.3 Complying with degree of protection IP65/IP67).

2 Installation
Festo – P.BE-CPX-FB39-EN – 1504NH – English 11
2.2 Electrical connections and indicators
The following connections and displays are located on the bus node:
1Network status and CPX-specific LEDs
2Network connection X11)
3Network connection X21)
4DIL switch cover
5Service interface2) for the control device
(CPX-MMI) or the Festo Maintenance Tool
software (CPX-FMT)
1
2
3
4
5
1) Connection bush M12, D-coded, 4-pin
2) Connection bush M12, A-coded, 5-pin
Fig. 2.1

2 Installation
12 Festo – P.BE-CPX-FB39-EN – 1504NH – English
2.3 Mounting and dismantling
Warning
Electrical voltage
Injury caused by electric shock, damage to machine and to system
 Switch supply power off before assembly work.
2.3.1 Mounting
Please Note
Material damage due to incorrect mounting
 Select screws that are suitable for the material of the interlinking block:
– plastic: thread-cutting tapping screws
– metal: screws with metric thread.
When ordering an individual module, all the screws required are enclosed.
1. Check seal and sealing surface. Replace
damaged parts.
2. Push the module carefully and without tilting
into the interlinking block up to the stop.
3. Turn the screws into the existing thread.
4. Tighten the screws in diagonally opposite
sequence. Tightening torque: 0.9 … 1.1 Nm.
1Screws
2Module
3Interlinking block
2
3
1
Fig. 2.2
Please Note
In the Remote I/O operating mode, the bus node must be placed as the first module
(slot 0) to the far left of the CPX terminal.
2.3.2 Dismantling
1. Unscrew screws.
2. Pull the module without tilting out of the interlinking block.

2 Installation
Festo – P.BE-CPX-FB39-EN – 1504NH – English 13
2.3.3 Complying with degree of protection IP65/IP67
 Use connection technology with type of protection IP65/IP67 (èwww.festo.com/catalogue,
examples in Tab. 2.1).
 Use cover caps to seal unused connections.
connection Connection technology Cover cap
Network connection Plug connector NECU-M-S-D12G4-C2-ET ISK-M122)
Service interface Connecting cable KV-M12-M12-…1)
1) Connecting cable for operator unit (CPX-MMI)
2) Included in the scope of delivery
Tab. 2.1

2 Installation
14 Festo – P.BE-CPX-FB39-EN – 1504NH – English
2.4 Settings of the DIL switches on the bus node
In order to set the bus node, you must first remove the cover for the DIL switches.
Caution
The CPX bus node contains electrostatically sensitive devices.
 Therefore, do not touch any components.
 Observe the handling specifications for electrostatically sensitive devices.
They will help you avoid damage to the electronics.
2.4.1 Removing and attaching the DIL switch cover
 Use an appropriate tool to remove or attach the DIL switch cover.
Please Note
Observe the following notes when removing or attaching the DIL switch cover:
 Disconnect the power supply before removing the cover.
 Make sure that the seal is seated correctly when attaching the cover!
 Tighten the two mounting screws with a max. torque of 0.4 Nm.
2.4.2 Arrangement of the DIL switches
There are 3 DIL switches available for configuring the bus node. These are located under the DIL switch
cover (è2.4.1 Removing and attaching the DIL switch cover).
1DIL switch 1:
– operating mode “remote I/O”
– operating mode “remote controller”
2DIL switch 2:1)
– diagnostics mode (remote I/O)
– I/O mode (remote controller)
3DIL switch 3:
– Sercos address (1 … 255)
12
3
1) The function is dependent on the set operating mode (èDIL switch 1)
Fig. 2.3

2 Installation
Festo – P.BE-CPX-FB39-EN – 1504NH – English 15
2.4.3 Setting the DIL switches
1. Switch supply power off.
2. Remove DIL switch cover (è2.4.1).
3. Perform required settings (è2.4.4 … 2.4.7).
4. Reinstall DIL switch cover (è2.4.1).
Please Note
Parameterisation via DIL switch settings is taken over only when the power supply is
switched on.
2.4.4 Setting the operating mode
With the DIL switch element 1.1 on DIL switch 1 the operating mode of the bus node is set.
Operating mode Setting DIL switch 1
Remote I/O operating mode
All functions of the CPX terminal are controlled directly by the
Sercos controller or by a superordinate PLC/IPC. The bus node
takes charge of connection to the Sercos III network.
1.1: OFF
(factory setting)
Remote Controller operating mode
An FEC or CEC integrated into the CPX terminal controls all
functions of the CPX terminal, i.e. the FEC or CEC undertakes the
I/O control. The bus node takes charge of connection to the
Sercos III network.
1.1: ON
Tab. 2.2
Please Note
Setting of the operating mode via DIL switch 1 has priority over all other settings.
The switch element 1.2 of DIL switch 1 is reserved and without function.

2 Installation
16 Festo – P.BE-CPX-FB39-EN – 1504NH – English
2.4.5 Setting of the diagnostic mode (remote I/O)
The diagnostic mode is available only in the remote I/O operating mode.
Diagnostic mode (remote I/O operating mode) Setting DIL switch 2
I/O diagnostics interface and status bits are switched off 2.1 OFF
2.2 OFF
(factory setting)
I/O diagnostics interface is switched on1) 2.1 ON
2.2 OFF
Status bits are switched on2) 2.1 OFF
2.2 ON
Reserved 2.1 ON
2.2 ON
1) The I/O diagnostic interface occupies an additional 16 input and 16 output bits
2) The status bits occupy an additional 16 input bits
Tab. 2.3
Please Note
The diagnostics mode reduces the available address space.
 When planning your CPX terminal, consider that the number of input and output bits
available for communication is reduced with usage of the diagnostic mode.
Subsequent activation of the diagnostics mode requires a reconfiguration.
 Observe that the CPX-internal I/O image can be displaced during subsequent activa
tion of the diagnostics mode.
 In this case, repeat the network configuration.

2 Installation
Festo – P.BE-CPX-FB39-EN – 1504NH – English 17
2.4.6 Setting of the I/O mode (remote controller)
The I/O mode is available only in the remote controller operating mode.
Number of I/O bytes (Remote Controller operating mode) Setting DIL switch 2
8 byte I/8 byte O for communication of the bus node with the
CPX-FEC or CPX-CEC.
2.1 OFF
2.2 OFF
(factory setting)
Reserved 2.1 ON
2.2 OFF
16 byte I/16 byte O for communication of the bus node with the
CPX-FEC or CPX-CEC.
2.1 OFF
2.2 ON
Reserved 2.1 ON
2.2 ON
Tab. 2.4

2 Installation
18 Festo – P.BE-CPX-FB39-EN – 1504NH – English
2.4.7 Set the Sercos address
DIL switch elements 3.1 to 3.8 are used for setting the binary coding of the Sercos address.
If all switch elements of DIL switch 3 are in the OFF setting, the Sercos address can
altered dynamically by write accesses to parameter S-0-1040.
Sercos address Setting DIL switch 3
Permitted addresses:
– 1 … 255 (via DIL switches)
– 0 … 511 (dynamically via S-0-1040)1)
Factory reset:
– 0 (DIL switch)
– 254 (dynamic)
12 34 56 78
3.8: 27128
3.7: 2664
3.6: 2532
3.5: 2416
3.4: 238
3.3: 224
3.2: 212
3.1: 201
1) Only with dynamic address issue (all switch elements in the OFF setting)
Tab. 2.5
Address 05 Address 38 Address 55 Address 106 Address 239
1234 5678
+
–
–
–
+
–
Address:
–
5
1
4
–
1234 5678
+
–
–
–
–
+
Address:
+
38
32
4
2
–
1234 5678
+
–
+
–
+
+
Address:
+
55
32
4
2
–
16
1
1234 5678
–
+
–
+
–
+
Address:
+
106
64
32
8
2
–
1234 5678
+
+
–
+
+
+
Address:
+
+
239
128
64
32
8
4
2
1
Tab. 2.6

2 Installation
Festo – P.BE-CPX-FB39-EN – 1504NH – English 19
2.5 Connecting to the network
2.5.1 General notes about Sercos networks
Please Note
A Sercos network must always be structured as as ring or line topology.
For this reason, the use of hubs or switches is not permitted.
Please Note
Connecting a PC to the Sercos network (e.g. to use the bus node with the CPX-FMT soft
ware).
– With line topology:
 Connect the PC to the free port of the Sercos slave.
– With ring topology:
 Use a network tap suitable for Sercos.
Please Note
Sub-assemblies with Ethernet interfaces should only be operated in networks if all con
nected network components are supplied by PELV circuits or integrated power circuits
with equivalent protection.
Installation guidelines
Installation guidelines can be sourced from the Sercos user organization
(èhttp://www.sercos.org).
2.5.2 Overview of connection technology and network plugs
Note
Faulty installation and high transmission rates may cause data transmission errors as a
result of signal reflections and attenuations.
 Note wiring specification (èTab. 2.8).
Transmission errors can be caused by:
– faulty screened connection
– branches
– transmission over distances which are too long
– unsuitable cables.
Connection technology Network connectors
2 x M12 bush, D-coded, 4-pin, in accordance with
IEC 61076-2, SPEEDCON compatible
Plug connector NECU-M-S-D12G4-C2-ET
Tab. 2.7

2 Installation
20 Festo – P.BE-CPX-FB39-EN – 1504NH – English
2.5.3 Cable specification
 Use sheathed Industrial Ethernet wiring of category Cat 5 or higher.
The bus node supports the “crossover detection” function (Auto-MDI/MDI-X).
To connect the bus node to the network or to a PC, this means you can choose between
patch cables or crossover cables.
The circuitry for network connections X1 and X2 is adapted automatically.
CPX-FB39 Cable specification
Cable type Industrial Ethernet cable, screened
Transmission class Category Cat 5
Cable diameter 6 … 8 mm
Wire cross section 0.14 … 0.75 mm², AWG 221)
Connection length Maximum 100 m2)
1) Required for maximum connection length between the network participants
2) corresponding to specification for Ethernet networks, based on ISO/IEC 11801, ANSI/TIA/EIA-568
Tab. 2.8
Please Note
When mounting the CPX terminal on a moving part of a machine.
 Use network wiring with tension relief.
 Note corresponding stipulations of IEC 60204.
2.5.4 Network connections
There are two 4-pin, D-coded M12 sockets on the bus node for the network connection. The sockets are
compatible with SPEEDCON plugs.
Socket1)
M12, 4-pin Pin
Connection [X1] Connection [X2]
Signal Explanation Signal Explanation
1
2
3
4
TX+
RX+
TX–
RX–
Transmitted data +
Received data +
Transmitted data –
Received data –
RX+
TX+
RX–
TX–
Received data +
Transmitted data +
Received data –
Transmitted data –
1) Functional earth is accomplished via the housing.
Tab. 2.9
Functional earth
Please Note
The shielded connection for both network connections is linked by RC element to the
ground potential of the CPX terminal.
 Connect the ground connection of left-hand terminal plate in a low-current and
low-impedance manner to the ground potential (èCPX system description
P.BE-CPX-SYS-…).
