Festo MPA-ASI-VI User manual

Manual
pneumatics MPA-S
Valve terminal with
MPA-S pneumatics
Type:
MPA-FB-...
MPA-CPI-...
MPA-MPM-... and
MPA-ASI-...
Manual
534 241
en 1108e
[750 435]
MPA-S Valve Terminal

Contents and general instructions
I
Festo P.BE-MPA-EN en 1108e
Original de.......................................
Edition en 1108e..................................
Designation P.BE-MPA-EN...........................
Order no. 534 241.................................
© (Festo AG & Co. KG, D-73726 Esslingen, Germany, 2011)
Internet: http://www.festo.com
E-Mail: [e-mail]
The reproduction, distribution and utilization of this
document as well as the comunication of its contents to
others without express authorization is prohibited.
Offenders will be held liable for the payment of damages.
All rights reserved in the event of the grant of a patent,
utility module or design.

Contents and general instructions
II Festo P.BE-MPA-EN en 1108e

Contents and general instructions
III
Festo P.BE-MPA-EN en 1108e
Contents
Intended use VII..........................................................
Range of application and certifications VII.....................................
Target group VIII..........................................................
Service VIII...............................................................
Instructions on this manual IX..............................................
Important user instructions X..............................................
1. Summary of components 1-1........................................
1.1 The MPA-S valve terminal 1-3........................................
1.2 Overview of variants 1-4.............................................
1.2.1 Electrical variants 1-4.......................................
1.3 Valve terminal design 1-8............................................
1.4 Description of components 1-9.......................................
1.4.1 Sizes 1-14..................................................
1.4.2 Valves 1-14.................................................
1.4.3 Pressure sensor plate 1-17....................................
1.4.4 Pneumatic supply plate 1-18..................................
1.4.5 Electrical supply plate 1-18....................................
1.4.6 Pressure zone separation 1-18.................................
1.4.7 Vertical stacking 1-23........................................
1.5 Operation and connection elements 1-33................................
1.5.1 Manual override (MO) 1-34....................................
1.6 Display components 1-37.............................................
1.6.1 Pressure sensor plate 1-39....................................
1.6.2 Proportional-pressure regulator 1-40............................
1.6.3 Proportional-pressure regulator with LCD display 1-41.............

Contents and general instructions
IV Festo P.BE-MPA-EN en 1108e
2. Fitting 2-1........................................................
2.1 General instructions on mounting and dismounting 2-3...................
2.2 Mounting variants 2-4..............................................
2.2.1 Mounting/dismounting on H-rails 2-5..........................
2.2.2 Mounting/dismounting on walls 2-9...........................
2.2.3 Standard fastening points of the valve terminal 2-10...............
2.2.4 Additional fastening of the valve terminal 2-11....................
2.3 Mounting/removing the inscription label holder 2-13......................
3. Installation 3-1...................................................
3.1 Compressed air preparation 3-3......................................
3.1.1 Operation with unlubricated compressed air 3-3.................
3.1.2 Operation with lubricated compressed air 3-4....................
3.2 General instructions on installation 3-6................................
3.3 Connecting the MPA-S valve terminal 3-8...............................
3.3.1 Pilot control (pilot air supply) 3-8..............................
3.3.2 MPA-S valve terminal with pressure zone separation 3-10...........
3.3.3 Operation of the MPA-S valve terminal with
reversible pressure regulators 3-12.............................
3.3.4 Setting the pressure regulating valve 3-12.......................
3.3.5 Controller with rigid threaded connection (MPA1) 3-16.............
3.3.6 Vacuum/low pressure operation 3-16...........................
3.3.7 Connecting the pneumatic lines 3-19............................
3.4 Installing the tubing 3-22.............................................
3.4.1 Common pneumatic lines 3-24.................................
3.4.2 Connecting the electric cables 3-25.............................
3.5 Address assignment of the valves 3-30..................................
3.5.1 MPA-S valve terminal with CPX terminal 3-30.....................
3.5.2 MPA-S valve terminal with CPI module or AS-Interface 3-32..........
3.5.3 MPA-S valve terminal with multi-pin plug connection 3-32...........

Contents and general instructions
V
Festo P.BE-MPA-EN en 1108e
4. Commissioning 4-1................................................
4.1 General instructions 4-3.............................................
4.1.1 Before commissioning 4-3....................................
4.1.2 Pressure build-up in the overall supply 4-4......................
4.2 Manual override (MO) 4-6...........................................
4.3 Checking the valves and the valve/actuator combination 4-8...............
4.4 Fitting/removing the manual override caps (optional) 4-13.................
4.5 LED display of the valves 4-15.........................................
4.6 Commissioning instructions for the proportional pressure regulator 4-18......
4.7 Fault finding 4-20...................................................
4.7.1 Impairment of function 4-20...................................
4.7.2 Operating states of the pneumatic system 4-22...................
5. Maintenance and conversion 5-1.....................................
5.1 General instructions 5-3.............................................
5.2 Dismantling the MPA-S valve terminal 5-4..............................
5.3 Maintenance of the MPA-S valve terminal 5-5...........................
5.3.1 Cleaning the flat plate silencer 5-5.............................
5.3.2 Replace the flat plate silencer or the exhaust plate 5-6............
5.3.3 Replacing valves or blanking plates 5-6.........................
5.3.4 Replace the proportional pressure regulator 5-9.................
5.3.5 Replacing electronics modules 5-10.............................
5.3.6 Replacing the sub-base, supply plate or MPA-S end plate 5-18.......
5.3.7 Replacing the interlinking boards 5-21...........................
5.4 Converting the MPA-S valve terminal 5-25...............................
5.4.1 Conversion to internal or external pilot air supply 5-25.............
5.4.2 Converting the MPA-S valve terminal to different pressure zones 5-30.
5.4.3 Adding valve positions 5-34...................................
5.4.4 Adding an electrical supply plate (only for MPA-S valve terminal
with CPX terminal or CPI interface) 5-38..........................
5.4.5 Adding a pressure sensor plate 5-40............................
5.4.6 Adding a proportional pressure regulator 5-41....................

Contents and general instructions
VI Festo P.BE-MPA-EN en 1108e
A. Technical appendix A-1.............................................
A.1 Technical data A-3..................................................
A.1.1 Product key A-20............................................
A.2 Festo accessories A-20...............................................
B. Supplementary component summary B-1..............................
B.1 Overview of valve position components B-3.............................
B.2 Separating the MPA-S valve terminal from the CPX terminal B-13............
C. Index C-1.........................................................

Contents and general instructions
VII
Festo P.BE-MPA-EN en 1108e
Intended use
The MPA-S valve terminals documented in this manual are
intended for installation into a machine or automated system.
The user must at all times observe the safety regulations
specified in this manual as well as the instructions concerning
the designated use of the relevant MPA-S valve terminal. The
MPA-S valve terminals may only be used as follows:
– as intended in an industrial environment
– in original status without unauthorised modifications.
Only the conversions or modifications described in the
documentation accompanying the product are permitted.
– in perfect technical condition.
When commercially available components, such as actuators,
are connected, the specified limits for pressures,
temperatures, electrical data, torques etc. must be
maintained. Comply with the regulations of the trade
associations and the German Technical Control Board (TÜV)
and the VDE conditions or relevant national regulations.
Range of application and certifications
The product fulfils the requirements of the EU directives and
is marked with the CE marking symbol.
Standards and test values, which the product observes and
fulfils, can be found in the section “Technical data”.
The product-relevant EU directives can be found in the
declaration of conformance.

Contents and general instructions
VIII Festo P.BE-MPA-EN en 1108e
Certain product configurations have been certified by the
Underwriters Laboratories Inc. (UL) for the USA and Canada.
These configurations are marked as follows:
UL Recognized Component Mark for Canada and the United
States
Only for connection to an NEC Class 2 supply.
Raccorder Uniquement a un circuit de Classe 2.
Note
Observe the following if the UL requirements are to be
complied with in your application:
– Rules for observing the UL certification can be found in
the separate UL-specific documentation. The relevant
technical specifications listed there also apply here.
– The technical data in this documentation may show
values deviating from this.
Target group
This manual is directed exclusively toward technicians trained
in control and automation technology.
Service
Please consult your local Festo repair service if you have any
technical problems.

Contents and general instructions
IX
Festo P.BE-MPA-EN en 1108e
Instructions on this manual
This manual contains specific information on the mounting,
installation, commissioning, servicing and modification of the
MPA-S valve terminal. It deals only with the pneumatic
components.
Information on the electrical/electronic components can be
found for:
–MPA-SwithCPXterminal:
in the description on the respective CPX module.
An overview is provided in the system description of your
CPX terminal, in the “Descriptions of the CPX terminal”
table.
– MPA-S with multi-pin plug connection, CPI interface,
AS interface:
in the respective package insert

Contents and general instructions
XFesto P.BE-MPA-EN en 1108e
Important user instructions
Danger categories
This manual contains instructions on the possible dangers
which can occur if the product is not used correctly.
These instructions are marked (Warning, Caution, etc),
printed on a shaded background and marked additionally
with a pictogram. A distinction is made between the following
danger warnings:
Warning
... means that failure to observe this instruction may result
in serious personal injury or damage to property.
Caution
... means that failure to observe this instruction may result
in personal injury or damage to property.
Note
... means that failure to observe this instruction may result
in damage to property.
The following pictogram marks passages in the text which
describe activities with electrostatically sensitive devices:
Electrostatic sensitive devices: inappropriate handling can
result in damage to components.

Contents and general instructions
XI
Festo P.BE-MPA-EN en 1108e
Identification of specific information
The following pictograms designate texts that contain special
information.
Pictograms
Information:
Recommendations, tips and references to other sources of
information.
Accessories:
Information on necessary or useful accessories for the Festo
product.
Antipollution:
Information on environment-friendly use of Festo products.
Text designations
•Bullet points indicate activities that may be carried out in
any order.
1. Numerals denote activities which must be carried out in
the numerical order specified.
– Arrowheads indicate general lists.

Contents and general instructions
XII Festo P.BE-MPA-EN en 1108e
The following product-specific terms and abbreviations are
used in this manual:
Term/abbreviation Meaning
Basic components Component (pneumatic interface, multiple connector plate, pneumatic
sub-base or pneumatic supply plate) on which further components
(exhaust plates, flat plate silencers, pressure regulators, valves or
blanking plates) are mounted.
Components Common term for pneumatic interface, multiple connector plate,
exhaust plate, flat plate silencer, pneumatic sub-base or pneumatic
supply plate, electric supply plate, pressure sensor plate, proportional
pressure regulator, end plate, pressure regulator plate, valve and
blanking plate.
Cover plate Plate without valve function for sealing unused valve positions on
sub-bases.
CPX modules Common term for the various modules which can be incorporated into
aCPXterminal
CPX terminal Modular electrical terminal
Electrical interface Common term for pneumatic interface, CPI interface, multi-pin plug
connection plate and AS interface.
Electrical supply plate Plate for additional supply of the valves with load voltage.
Electronics module Module in the sub-base with an LED and solenoid coil management
End plate Extreme right-hand plate:
– with/without pneumatic supply ports
– holes for H-rail and wall mounting
Extreme left-hand plate:
–oftheCPXterminal
– of the valve terminal with multi-pin plug connection
– with holes for H-rail and wall mounting
Exhaust plate Plate for ducted exhaust with connection (3/5)
I/O Input/output modules
MO Manual override
MPA1 or MPA2 Size of the valves: MPA1 = 10 mm, MPA2 = 20 mm.

Contents and general instructions
XIII
Festo P.BE-MPA-EN en 1108e
Term/abbreviation Meaning
MPA-S valve terminal Modular Performance Anschlussplatten (sub-base) Size-optimized
valve terminal (type 32) with multi-pin plug connection, AS interface,
CPX terminal or CPI interface.
MPA-S valve terminal with
multi-pin plug connection
type MPA...-MPM-...
VariantoftheMPA-Svalveterminalwith Sub-D plug. All solenoid coils
are connected centrally via the Sub-D plug. The electrical interlinking
is modular, i.e. every sub-base has its own circuit board.
Multi-pin plug connection Connection with modular electric linking type MPA...-MPM-...
Pneumatic interface The pneumatic interface is the interface between the modular
electrical periphery of the CPX terminal and the pneumatic MPA-S.
Pneumatic module Module consisting of pneumatic sub-base, electronic module, valves
or cover plates
Pneumatic supply plate Plate for additional supply of compressed air to the valves, e.g. with
several pressure zones.
Separating seal Special seals for forming pressure zones.
Sub-base Plate for mounting monostable, impulse or mid-position valves, with
working lines (2) and (4).
– size MPA1 (type MPAS...4) with 4 valve locations
– size MPA2 (type MPAS...2) with 2 valve locations
Tubing connection Connecting the pneumatic supply lines (tubing) to the MPA-S valve
terminal
Valve Monostable, bistable or mid-position valves
Tab. 0/1: Product-specific terms and abbreviations

Contents and general instructions
XIV Festo P.BE-MPA-EN en 1108e

Summary of components
1-1Festo P.BE-MPA-EN en 1108e
Chapter 1
Summary of components

1. Summary of components
1-2 Festo P.BE-MPA-EN en 1108e
Contents
1. Summary of components 1-1........................................
1.1 The MPA-S valve terminal 1-3........................................
1.2 Overview of variants 1-4.............................................
1.2.1 Electrical variants 1-4.......................................
1.3 Valve terminal design 1-8............................................
1.4 Description of components 1-9.......................................
1.4.1 Sizes 1-14..................................................
1.4.2 Valves 1-14.................................................
1.4.3 Pressure sensor plate 1-17....................................
1.4.4 Pneumatic supply plate 1-18..................................
1.4.5 Electrical supply plate 1-18....................................
1.4.6 Pressure zone separation 1-18.................................
1.4.7 Vertical stacking 1-23........................................
1.5 Operation and connection elements 1-33................................
1.5.1 Manual override (MO) 1-34....................................
1.6 Display components 1-37.............................................
1.6.1 Pressure sensor plate 1-39....................................
1.6.2 Proportional-pressure regulator 1-40............................
1.6.3 Proportional-pressure regulator with LCD display 1-41.............

1. Summary of components
1-3
Festo P.BE-MPA-EN en 1108e
1.1 The MPA-S valve terminal
Festo supports your automation tasks at machine level with
theMPA-Svalveterminal.Themodularstructureofthe
MPA-S valve terminal enables you to match this valve
terminal optimally to your machine or system.
The valve terminal pneumatics establish the following
connections:
– Common ducts for supply and exhaust air
– Electric signals from all solenoid coils
Working lines (2) and (4) are provided for each valve position
on the individual pneumatic modules. The valves are supplied
with compressed air (operating pressure and pilot pressure)
via the common channels and connections in the basic
components. The exhaust air (from the valves and the pilot
exhaust air) is also exhausted via these common channels.
Further components for pressure supply are also available,
e.g. in order to supply pressure zones.
The MPA-S valve terminal is equipped with current reduction.
The nominal current of the solenoid coils is then reduced
after the high-current phase (switching operation).
The current reduction offers the following advantages:
– The MPA-S valve terminal has a lower energy
consumption
– The power unit for the voltage supply to the MPA-S valve
terminal can be designed more economically depending
on the individual case
– The solenoid coils have less power loss and produce less
waste heat

1. Summary of components
1-4 Festo P.BE-MPA-EN en 1108e
1.2 Overviewofvariants
1.2.1 Electrical variants
MPA-S valve terminal
with CPX terminal
This variant of the MPA-S valve terminal is available in the
following grades:
MPA-S valve terminal with CPX terminal Number of valve positions 1)
Load voltage supply for the valves via ...
–CPXterminal
2)
– CPX terminal and electric supply plate (MPA) 3)
MPA1
4, 8, 12 ... 32
4, 8, 12 ... 64
MPA2
2, 4, 6 ... 16
2, 4, 6 ... 32
1) Two solenoid coils can be controlled per valve position.
2) A max. of 64 solenoid coils can be supplied.
3) A max. of 128 solenoid coils can be supplied.
Tab. 1/1: Number of valve locations of the MPA-S valve terminal with CPX terminal
Fig. 1/1: MPA-S valve terminal with CPX terminal
