Festo VTSA Series Operating and installation instructions

Description
Pneumatics
538923
1312 h
[8025774]
Valve terminal VTSA/VTSA-F
VTSA…

Contents and general safety instructions
I
Festo P.BE-VTSA-44-EN en 1312h English
Original de.......................................
Version en 1312h..................................
Designation P.BE-VTSA-44-EN........................
Order no. 538923..................................
© (Festo AG & Co., 73726 Esslingen, Germany, 2013)
Internet: http://www.festo.com
E-Mail: [e-mail]
Reproduction, distribution or sale of this document or
communication of its contents to others without express
authorization is prohibited. Offenders will be liable for
damages. All rights reserved in the event that a patent,
utility model or design patent is registered.

Contents and general safety instructions
II
Festo P.BE-VTSA-44-EN en 1312h English
CAGE CLAMP
®
is a registered trademark of the respective owner in certain
countries.

Contents and general safety instructions
III
Festo P.BE-VTSA-44-EN en 1312h English
Ta b l e o f c o n t e n t s
Intended use VII..........................................................
Range of application and certifications VII.....................................
Target group VIII..........................................................
Service VIII...............................................................
Notesonthisdescription IX................................................
Important user information X..............................................
1. Overview of components 1-1........................................
1.1 The VTSA/VTSA-F valve terminal 1-4...................................
1.2 Components, width 18 ... 52 mm 1-8...................................
1.2.1 Main and additional supply 1-10...............................
1.2.2 Valves 1-11.................................................
1.2.3 Manifold sub-bases 1-14......................................
1.2.4 Pilot control 1-15............................................
1.2.5 Pressure zone separation 1-18.................................
1.2.6 Vertical stacking 1-19........................................
1.2.7 Pressure regulator plates 1-23.................................
1.2.8 Components for protective functions 1-30........................
1.2.9 Vacuum block VABF-S4-1-V2B1 1-34............................
1.2.10 Pilot air switching function (manifold sub-base VABF-S4-…-S) 1-35....
1.3 Components, width 65 mm 1-36.......................................
1.3.1 Valves 1-37.................................................
1.3.2 Manifold sub-bases 1-38......................................
1.3.3 Pressure zones 1-39.........................................
1.3.4 Vertical stacking 1-39........................................
1.4 Connection and control elements of the pneu. components,
width 18 ... 52 mm 1-41..............................................
1.5 Connection, display and control elements of the pneumatic components,
width 65 mm 1-45...................................................

Contents and general safety instructions
IV
Festo P.BE-VTSA-44-EN en 1312h English
1.6 Electrical components 1-47...........................................
1.6.1 VTSA/VTSA-F valve terminal with fieldbus 1-47...................
1.6.2 VTSA/VTSA-F valve terminal with multi-pin plug 1-49..............
1.7 Connection and display components of the electrical components 1-52.......
2. Assembly 2-1.....................................................
2.1 General instructions on mounting and dismantling 2-4....................
2.2 Mounting variants 2-5..............................................
2.3 Mounting/dismantling the optional inscription label holder,
width 18 ... 52 mm 2-6..............................................
2.4 Mounting/dismantling the optional manual override cover caps,
width 18 ... 52 mm 2-7..............................................
3. Installation 3-1...................................................
3.1 Compressed air preparation 3-4......................................
3.1.1 Operation with unlubricated compressed air 3-4.................
3.1.2 Operation with lubricated compressed air 3-5....................
3.2 General notes on connecting the tubing 3-8.............................
3.2.1 Installing the tubing 3-9.....................................
3.3 Connecting the VTSA/VTSA-F valve terminal 3-13.........................
3.4 Pilot control, width 18 ... 52 mm 3-13...................................
3.4.1 Venting pilot exhaust air 3-13..................................
3.4.2 Pilot air supply 3-15..........................................
3.5 Pilot control, width 65 mm 3-20........................................
3.5.1 Pilot air supply 3-20..........................................
3.6 Pressure zone separation, width 18 ... 52 mm 3-23........................
3.7 Pressure zone separation, width 65 mm 3-26.............................
3.8 Reversibly operated VTSA/VTSA-F valve terminal 3-27.....................
3.8.1 Operating the VTSA/VTSA-F valve terminal with reversible valves 3-28
3.8.2 Operating the VTSA/VTSA-F valve terminal with reversible
pressure regulators 3-29......................................
3.8.3 Setting the pressure regulator 3-30.............................
3.9 Vacuum / low-pressure operation: 3-35.................................
3.10 Connecting the pneumatic lines 3-37...................................

Contents and general safety instructions
V
Festo P.BE-VTSA-44-EN en 1312h English
3.11 Connecting the electric cables 3-47.....................................
3.12 Address assignment of the valves 3-51..................................
4. Commissioning 4-1................................................
4.1 General instructions 4-4.............................................
4.1.1 Prior to commissioning 4-4...................................
4.1.2 Pressure build-up in the overall supply 4-4......................
4.2 Manual override (MO) 4-6...........................................
4.2.1 Manual override, width 18 ... 52mm 4-7.........................
4.2.2 Manual override, width 65 mm 4-8.............................
4.3 Checking the valves and the valve/actuator combination 4-10...............
4.4 LED display of the valves 4-15.........................................
4.4.1 Valves, width 18 ... 52 mm 4-15................................
4.4.2 Valves, widths 65 mm 4-17....................................
4.5 Fault finding 4-18...................................................
4.5.1 Impairments of function 4-18..................................
4.5.2 Operating states of the pneumatic system 4-19...................
5. Conversion and maintenance 5-1.....................................
5.1 General preventive action 5-4........................................
5.2 Service and maintenance measures to be executed regularly 5-5...........
5.3 Dismantling the valve terminal 5-6....................................
5.4 Replacing the solenoid coil fuse, width 65 mm 5-8.......................
5.5 Replacing valve terminal components 5-10..............................
5.5.1 Replacing valves or cover plates, width 18 ... 52 mm 5-10...........
5.5.2 Replacing the cover plate with a valve, width 65 mm 5-12...........
5.5.3 Replacing/adding components for vertical stacking,
width 18 ... 52 mm 5-14.......................................
5.5.4 Replacing/adding components for vertical stacking,
widths 65 mm 5-19..........................................
5.5.5 Replacing the exhaust plate or exhaust port cover,
widths 18 …52 mm 5-20......................................
5.5.6 Replacing the manifold sub-base, pneumatic supply plate
or right end plate, widths 18 … 52 mm 5-20.......................
5.5.7 Replacing the manifold sub-base or right end plate, size 65 mm 5-24.

Contents and general safety instructions
VI
Festo P.BE-VTSA-44-EN en 1312h English
5.6 Converting the VTSA/VTSA-F valve terminal 5-31.........................
5.6.1 Conversion, pilot exhaust air via port (12), widths 18 … 52 mm 5-31..
5.6.2 Conversion, internal or external pilot air supply,
width 18 ... 52 mm 5-33.......................................
5.6.3 Conversion, internal or external pilot air supply, widths 65 mm 5-34..
5.6.4 Conversion, VTSA/VTSA-F valve terminal with two or more
pressure zones, width 18 ...52 mm 5-36.........................
5.6.5 Conversion, valve terminal with 2 pressure zones,
widths 65 mm 5-39..........................................
5.6.6 Adding valve positions, widths 18 … 52 mm 5-40..................
5.6.7 Adding valve positions, widths 65 mm 5-41.......................
5.6.8 Adding a soft-start valve 5-43..................................
A. Technical appendix A-1.............................................
A.1 Technical data A-3..................................................
A.2 Accessories A-26....................................................
B. Supplementary component overview B-1..............................
B.1 Overview of valve position components B-3.............................
B.2 Separating the VTSA/VTSA-F valve terminal from the CPX terminal B-14.......
C. Index C-1.........................................................

Contents and general safety instructions
VII
Festo P.BE-VTSA-44-EN en 1312h English
Intended use
The VTSA/VTSA-F valve terminals described in this manual
are intended for fitting into a machine or automated system.
The user must at all times observe the safety instructions
specified in this manual, as well as the instructions concern-
ing the intended use of the relevant VTSA/VTSA-F valve ter-
minal. The VTSA/VTSA-F valve terminals may only be used as
follows:
– as intended for switching of gaseous media
(Appendix A “Technical data”) in an industrial
environment
– in original status without unauthorised modifications.
Only the conversions or modifications described in the
documentation supplied with the product are permitted
– in excellent technical condition.
If used together with additional commercially available com-
ponents, such as actuators, the specified limits for pressures,
temperatures, electrical data, torques etc. must be observed.
Observe the corresponding regulations of the trade associ-
ations, German Technical Control Board (TÜV), VDE stipula-
tions or relevant national regulations.
Range of application and certifications
The product fulfils the requirements of EU directives and is
marked with the CE marking.
Standards and test values, which the product must comply
with and fulfill, can be found in the section “Technical data”.
The product-relevant EU directives can be found in the declar-
ation of conformity.

Contents and general safety instructions
VIII
Festo P.BE-VTSA-44-EN en 1312h English
Certain configurations of the product have been certified by
Underwriters Laboratories Inc. (UL) for the USA and Canada.
These configurations bear the following mark:
UL Recognized Component Mark for Canada and the United
States.
Note
Observe the following if the UL requirements are to be
complied with in your application:
– Rules for complying with the UL certification can be
found in the separate UL-specific special documentation.
The relevant technical data listed there also apply here.
– The technical data in this documentation may show val-
ues deviating from this.
Target group
This manual is directed exclusively toward technicians trained
in control and automation technology.
Service
Please consult your local Festo repair service if you have any
technical problems.

Contents and general safety instructions
IX
Festo P.BE-VTSA-44-EN en 1312h English
Notesonthisdescription
This description contains specific information on mounting,
installing, commissioning, servicing and converting the
VTSA/VTSA-F valve terminal. It includes only the description
of the pneumatic components and refers to the following
valve terminal variants:
– Valve terminal with CPX terminal:
Information on CPX modules can be found in the manual
for the relevant module. An overview is provided in the
system description of your CPX terminal, in the “Descrip-
tionsoftheCPXterminal”table.
– All valve terminals with multi-pin node (Sub-D, cage
clamp, M23 round plug, IC):
Information about the electric/electronic components is
included in the documentation supplied with the product.
– Valve terminal with AS-interface:
Information about the electric/electronic components is
included in the documentation supplied with the product.

Contents and general safety instructions
X
Festo P.BE-VTSA-44-EN en 1312h English
Important user information
Danger categories
This description includes instructions on the possible dangers
which can occur if the product is used incorrectly. These in-
structions are marked with a signal word (Warning, Caution,
etc.), printed on a shaded background and marked addition-
ally with a pictogram. A distinction is made between the fol-
lowing danger warnings:
Warning
... means that failure to observe this instruction may result
in serious personal injury or material damage.
Caution
... means that failure to observe this instruction may result
in personal injury or material damage.
Note
... means that failure to observe this instruction may result
in material damage.
In addition, the following pictogram marks passages in the
text which describe activities with electrostatically sensitive
devices:
Electrostatically sensitive devices: Incorrect handling may
cause damage to devices.

Contents and general safety instructions
XI
Festo P.BE-VTSA-44-EN en 1312h English
Marking of special information
The following pictograms mark passages in the text which
contain special information.
Pictograms
Information:
Recommendations, tips and references to other information
sources.
Accessories:
Information about necessary or useful accessories for the
product from Festo.
Environment:
Information about environmentally friendly use of products
from Festo.
Text designations
• Bullets denote activities that may be carried out in any
desired order.
1. Numerals denote activities that must be carried out in the
sequence specified.
– Arrowheads indicate general lists.

Contents and general safety instructions
XII
Festo P.BE-VTSA-44-EN en 1312h English
The following product-specific terms and abbreviations are
usedinthisdescription:
Term/abbreviation Meaning
90° connection plate – Reversing unit (90°)
– With work connections (2) and (4)
The 90°-connection plate is attached to the connection side of the
manifold sub-base.
Basic components – Collective term for the manifold sub-base, 90°-connection plate,
pneumatic air supply plate or end plate
Blanking plate – Cover for a non-assigned valve position on the manifold sub-base
Component – Collective term for the exhaust plate, exhaust port cover, vertical
pressure supply plate, pressure regulator plate, flow control plate,
soft-start valve, directional control valve or cover plate
CPX modules – Common term for the various modules which can be incorporated
into a CPX terminal
CPX terminal – modular terminal
End plate – outermost right-hand plate of the VTSA/VTSA-F valve terminal with
holes for wall mounting
– outermost left-hand plate of the CPX terminal with holes for wall
mounting
Exhaust plate – Cover of the pneumatic supply plate
– With separate exhaust connections (3) and (5)
Exhaust port cover – Cover of the pneumatic supply plate
– Common exhaust port (3/5)
Intermediate solenoid
plate
– Plate with solenoid coils, air ducts and electric plug connectors to
ISO 5599/2
I/O module – Input/output module
Manifold sub-base – Plate with electrical interlinking
– with two valve positions for 18 mm and 26 mm widths
– with one valve position for 42 mm (ISO 1), 52 mm (ISO 2) and
65 mm (ISO 3) widths
– Per valve position with working lines (2) and (4).
MO – Manual override

Contents and general safety instructions
XIII
Festo P.BE-VTSA-44-EN en 1312h English
Term/abbreviation Meaning
Multi-pin node
M23 round plug
– Interface with electric M23 round plug via which all solenoid coils
are connected centrally
Multi-pin node, cage clamp – Interface with terminal strip via which all solenoid coils are centrally
connected
Multi-pin node, Sub-D – Interface with electric Sub-D multi-pin plug connection via which all
solenoid coils are centrally connected
Multi-pin node IC – Interface with individual electric connections via which the solenoid
coils are individually connected
IC = Individual Connector
Multi-pin plug connection – Plug connector on the multi-pin node; available in four different
versions:
– Cage clamp
– Round plug M23
–Sub-D
–IC
Pneumatics interface – Interface between the modular electric peripherals of the CPX
terminal and the VTSA/VTSA-F pneumatics
Pneumatics module – Module consisting of manifold sub-base, 90°-connection plate,
valve (intermediate solenoid plate for valves 65 mm wide) or cover
plate, or components for vertical stacking
Pneumatic supply plate – Plate within the horizontal stacking for supplying pressure to a
pressure zone
Selector end plate – outermost right-hand plate of the VTSA/VTSA-F valve terminal with
coding cap (for selection of the pilot variant and disposal of pilot
exhaust air)
– with pneumatic ports (12) and (14)
Tubing connections – Connecting the supply lines (tubing) to the valve terminal
Valve – Solenoid valve with monostable, impulse or mid-position valve
Valve terminal
VTSA/VTSA-F
– Valve terminal VTSA/VTSA-F
– With CPX terminal
– AS-interface
– or with multi-pin node (cage clamp, M23 round plug, Sub-D or IC).

Contents and general safety instructions
XIV
Festo P.BE-VTSA-44-EN en 1312h English
Term/abbreviation Meaning
Vertical pressure shut-off
plate
– Plate on a valve position for isolating the valve pressure supply
Vertical pressure supply
plate
– Plate on a valve position for individual compressed air supply
Tab. 0/1: Product-specific terms and abbreviations

Overview of components
1-1 Festo P.BE-VTSA-44-EN en 1312h English
Chapter 1
Overview of components

1. Overview of components
1-2
Festo P.BE-VTSA-44-EN en 1312h English
Ta b l e o f c o n t e n t s
1. Overview of components 1-1........................................
1.1 The VTSA/VTSA-F valve terminal 1-4...................................
1.2 Components, width 18 ... 52 mm 1-8...................................
1.2.1 Main and additional supply 1-10...............................
1.2.2 Valves 1-11.................................................
1.2.3 Manifold sub-bases 1-14......................................
1.2.4 Pilot control 1-15............................................
1.2.5 Pressure zone separation 1-18.................................
1.2.6 Vertical stacking 1-19........................................
1.2.7 Pressure regulator plates 1-23.................................
1.2.8 Components for protective functions 1-30........................
1.2.9 Vacuum block VABF-S4-1-V2B1 1-34............................
1.2.10 Pilot air switching function (manifold sub-base VABF-S4-…-S) 1-35....
1.3 Components, width 65 mm 1-36.......................................
1.3.1 Valves 1-37.................................................
1.3.2 Manifold sub-bases 1-38......................................
1.3.3 Pressure zones 1-39.........................................
1.3.4 Vertical stacking 1-39........................................
1.4 Connection and control elements of the pneu. components,
width 18 ... 52 mm 1-41..............................................
1.5 Connection, display and control elements of the pneumatic components,
width 65 mm 1-45...................................................
1.6 Electrical components 1-47...........................................
1.6.1 VTSA/VTSA-F valve terminal with fieldbus 1-47...................
1.6.2 VTSA/VTSA-F valve terminal with multi-pin plug 1-49..............
1.7 Connection and display components of the electrical components 1-52.......

1. Overview of components
1-3
Festo P.BE-VTSA-44-EN en 1312h English
Contents of this chapter This chapter provides the following information on the
VTSA/VTSA-F valve terminal:
– the maximum number of valve positions
– the connection variants and components of the valve ter-
minal
– the labelling of the pneumatic components
– connection, display and control elements.
Additional information Information on the modules of the CPX terminal can be
found in the CPX system description.
Information about the Midi/Maxi electronics modules can be
found in the corresponding Midi/Maxi electronics descrip-
tions.
Information about the electronics of the VTSA/VTSA-F valve
terminal with multi-pin node can be found in the corres-
ponding package insert.
Information about the electronics of the VTSA/VTSA-F valve
terminal with AS-interface can be found in the correspond-
ing package insert.

1. Overview of components
1-4
Festo P.BE-VTSA-44-EN en 1312h English
1.1 The VTSA/VTSA-F valve terminal
Festo supports your automation tasks at machine level with
theVTSA/VTSA-Fvalveterminals.Themodularstructureof
the valve terminal enables you to optimally customise it to
your machine or system.
The valve terminal pneumatics establish the following con-
nection:
– common ducts for supply and exhaust air
– electric signals of all solenoid coils.
The working ports (2) and (4) are provided for each valve
position on the individual manifold sub-bases. The valves are
supplied with compressed air (operating pressure and pilot
pressure) via the common channels and connections in the
pneumatic supply plates. The exhaust air (from the valves
and the pilot exhaust) is also exhausted via these common
channels and connections.
Dependent on its width, the valve terminal can be supplemen-
ted by additional pneumatic supply plates, such as to supply
pressure zones.
The function range at each valve position can be extended by
means of additional vertical stacking components, e.g. ex-
haust air flow control or pressure regulation.
Versions The valve terminal is available in a VTSA and VTSA-F design.
The VTSA-F valve terminal provides the mounted valves with
a higher flow volume.
