GARO GLB****-B series Installation instructions

GARO Charger GLB .... -B
Basic - No Load Balancing Model
End User Instruction (EN)
K-B-18-03

15
TABLE OF CONTENTS
Index
Box Contents
GHL Variants
Assembly Instruction for Fitters
Mainboard Simplified Connection Diagram
Step-by-Step Installation
Setting The Charging Current
Troubleshooting
Technical Data
2
EN
GARO Wallbox
Assembly instructions/User Instructions (EN)
380175-3
Language labels
GHL Wallbox
Keys
Drill template
(see the back of the box)
Manual
Box Contents
2
3
5
6
7
11
13
14

Serienr/SSI D password endast w ifiversi on
D
A
E
C
B
H
G
F
(figure 1)
(figure 3)
(figure 2)
I
3 4
A. Front cover
B. Cover
C. Base box
D. Indication light
E. Key
F. Connectortype1or 2
G. Type2 socket
H. Personalprotectivecircuitbreaker,residual‐currentcircuitbreakerandenergy
meter,if required.
I. Serialno./SSID,password(Wi‐Fiversion only)
GARO Wallbox Charger GLB
with type 2 socket outlet
GLB
GARO Wallbox Charger GLB with
cable and connector, type 1 or 2

ENEN Assemblyinstructionsfor fitters Circuitdiagram
1. blue/brown
2. blue/red
3. blue/yellow
4. blue/green
5. white
6. red
FUSE 2AT
OCPP/Wi‐Finot
available in GHL
M
CP PP
Fuse/RCCBFB
ContactorFB
Contactor control
Line (L)
Neutral(N)
Protectiveearth (PE)
RFID not available
in GHL
RCCB
LN PE
LNPE
Type2 outlet
Type2 outlet
GK32
12345 6
Ext.chargecontrol
open=on, close=off
*)‐ seeinfo below
SW2
*Remotecontrolsignal
canbesetininverse
function.
Seedip‐switch SW1(4)
A1 A2
63 64
GKN11
A‐ E‐Meter
B+
Remote control
A‐
B+ DataLink
MaxchargingFactorydefault
current(A) 16A
SW1Factory default
SW3
SW3–Resetbutton,
Pressdown>3secto
resetWiFibacktodefault
AccessPointmode.N/A
in GHL
5 6
Assemblyinstructionsfor fitters
CongratulationsonselectingaGAROWallboxEV Charger andcontributingtoabetter
environment.TheGAROChargerisanACchargerenablingMode3chargingwhich
compliesfullywiththerequirementsofIEC61851‐1andIECTS 61439‐7.
TheproductcomplieswithIPCodeIP44,withaclosed front.
Itistobefittedtoawall,andallinstallationmustbecarriedoutbyanauthorisedfitterand
complywithlocalinstallation regulations.
Importantinformationfor fitters:
Thechargermustalwaysbeprotectedbyaresidual‐currentcircuitbreakerand fuse.
Thethree‐phasechargerisequippedwitharesidual‐currentcircuitbreakerandmustbefitted
withamax32Afuseinthesupplydistributionbox.Thesingle‐phasechargerisfittedwith
apersonalprotectivechargerwithamaximum125Afuse.
(figure 4)

(figure 5)
78
(figure 6)
1. Ensurethesupplycableisnot live.
2. Removethedrilltemplatefromthe packaging.
3. Attachthedrilltemplatetothewallwherethechargerwillbeinstalled.
Suitableheight(seeTechnicaldataonpage 45)
4. Drill/markinaccordancewiththeinstructionsonthedrill template.
5. Unlockthefrontcoverwiththekeyprovidedandslidethecover downwards.
6. Thefrontcoverhasabuilt‐instop‐position.Tomovepastthisposition,gripthe
undersideofthecoverandliftoutwardsgraduallywhilepulling downwards.
7. Loosenthesevenscrewsandcarefullyremovethecoverfromthebase box.
T20
Step-by-Step installation

(figure 9)
910
(figure 10)
15. Re‐installthefrontcoverbyfeedingitinfrom below.
16. Lockthefrontc ove rwiththe k ey.
17. Connectthepowerandensuretheindicationlightisconstantly green.
18. If,notrefertothesectionon: Troubleshooting.
19. Whenthegreenlightshinesconstantly,thechargerisreadyfor use.

(figure 11)
Settingthechargingcurrent–Switch 2
Dependingonthesizeofthefuse,overloadmayoccur,primarilyattheproperty'smeter
fuse.Thewallbox'schargingcurrentcanbereducedusingtheswitchesonthecircuit
board.Thesupplyvoltagemustbebrokenbeforethechargingcurrentis reduced.
1112
SW2‐4
On = Fixed cable
Off = Type 2 outlet
with locking actuator
Settingtheamperageformain fuses
Duringinstallation,theamperageoftheDIPswitchSW1(1‐2‐3)mustbeadjustedto
correspondwiththesizeandstrengthofthemainfuses.
TheDIPswitchSW2(1‐2‐3‐)whichcontrolsthecharger'smaximumpermittedcharging
currentshouldbesettotherecommendedcurrentvaluesoutlinedbelow.
Main fuse 16A 20A 25A 32A 40A 50A 63A
SW1(1‐2‐3) 16A 20A 25A 32A 40A 50A 63A
SW2(1‐2‐3) 13A 16A 20A 25A 32A 32A 32A
S W 2 S W 2 
(figure 14)
Setting The Charging Current
Always ensure SW 4
is in ON position

Standards/directives: IEC61851‐1andIECTS 61439‐7
Installation: onwallorGaroWallbox stand
Voltage rating: 230V/400 50Hz
Installation systems: TT,T NandIT systems
Charging type: Mode 3
IP classification: IP44
Mechanical impact IK08
resistance:
Application temperature: ‐250C–+400C
Storage temperature: ‐350C–+550C
Installation height: 0.5–1.5metresaboveground/landtoloweredgeof
charger.
W eight: around3 kgincluding socket
3.8–4.1kgincludingcableandconnector,single‐phase
5,4 kgincludingcableandconnector, three‐phase
Technical data
Specification
Troubleshooting
Indication
1314
Typeof fault Measure
Constantred light Theresidual‐currentor
personalprotectivecurrent
breaker
Reset.Refertosectionon
Resettingtheresidual‐current
orpersonalprotective current
has been tripped. breaker.
Constant yellow light Broken cable Check cable
Flashing yellow light Motorlocksocketnot in Contacta qualified
latched position. electrician
No indication Checksupply fuse
Ifthemeasureadviseddoesnothelp,contactaqualified fitter.
