GAUI GU-INS User manual

Assembly Instruotion
1.Dimensions：Main controller: 53.5 x 38.5 x 12mm GPS antenna: 42 x 34 x 15mm
Weight：Main controller: 27g (w/o cables ), GPS antenna: 23g (with cable)
2.Frequency: 300Hz output to ESC
3.Operating temperature: -20~80°C
4.Operating modes: Rate (manual) mode, Auto balance mode, GPS positioning mode.
5.Rate (manual) mode: Max angular velocity: 300 degree/sec.
6.Auto balance mode: Max tilt angle: 60 degree.
7.GPS positioning mode:
a.Hovering accuracy: Horizontal: ±2m, Vertical: ±0.5m
b.Max yaw angular velocity: 250 degree/sec
c.Max tilt angle: 45 degree.
d.Max horizontal speed: 10 m/s，36 km/hr
e.Max vertical speed: 8 m/s (horizontal posture)
8.GU-INS provides pitch and rolls output signals, can work with different types of camera mounts.
9.Fail-safe functions: Automatic Go-Home, Signal lost Go-Home, Low voltage protection.
10.Suitable wind condition: < 10 m/s
●Specifications：
GAUI

Assembly Instruotion ᐈձᇴ݃
೤
1.Dimensions：Main controller: 53.5 x 38.5 x 12mm GPS antenna: 42 x 34 x 15mm
Weight：Main controller: 27g (w/o cables ), GPS antenna: 23g (with cable)
2.Frequency: 300Hz output to ESC
3.Operating temperature: -20~80°C
4.Operating modes: Rate (manual) mode, Auto balance mode, GPS positioning mode.
5.Rate (manual) mode: Max angular velocity: 300 degree/sec.
6.Auto balance mode: Max tilt angle: 60 degree.
7.GPS positioning mode:
a.Hovering accuracy: Horizontal: ±2m, Vertical: ±0.5m
b.Max yaw angular velocity: 250 degree/sec
c.Max tilt angle: 45 degree.
d.Max horizontal speed: 10 m/s，36 km/hr
e.Max vertical speed: 8 m/s (horizontal posture)
8.GU-INS provides pitch and rolls output signals, can work with different types of camera mounts.
9.Fail-safe functions: Automatic Go-Home, Signal lost Go-Home, Low voltage protection.
10.Suitable wind condition: < 10 m/s
●Specifications：
GAUI
HV.JOTҐᡞ
٪Ꭻݿෞ
ϳ೾ၿഀ௦ጤ
Ρ೾ၿഀ௦ጤ
HQTقಜ
VTCഀ௦ጤ
ٻңᇴ݃
GU-INS main controller
Damper sponges
User manual Six channel connection cable
USB cable
GPS system
Two channel connection cable
Index
System Assembly
System Setting
System Tuning
Note
GPS Navigation
Go-Home Function
Low Voltage Protection
Camera Gimbal Calibration
Firmware Update
On Screen Display Interface(Option)
Content
ᐸဵᄈྲߓ
Index for LED Light Status P2
P3~5
P6~7
P8~10
P11~15
P16~17
P18~19
P20~23
P24~25
P26~27
P1

13.You can activate the fail safe function on your tansmitter, set AILE, ELEV, THRO, and RUDD stick to its
central position, and assign the F/S to activate “GPS positioning” and “HOME” function for further protection.
Note
1.This product is NOT a toy, please keep away from crowd and buildings while flying.
2.Do not use this product for illegal purposes, or shall be responsible for breaking the law .
3.For your safety, please remove the propellers before setup and calibration procedures.
4.The throttle calibration procedure is very importnat (P.6), it calibrates not only the signals of ESC, but
also central position of the transmitter. Therefore, do not move other sticks or switches except throttle
stick; if you change the transmitter, make sure you execute the throttle calibration procedures.
5.The calibration of magnetic north and due north needs to be done throughly (P.14), or the 500X will slant or
circle under GPS positioning mode..
6.Under GPS positioning mode, all movements of the 500X are based on the speed signals of GPS.
Therefore, if the GPS signal is bad or interfered, the 500X will become uncontrollable. If so, please
switch back to auto-balance mode.
7.Do not insert the GPS antenna indoor, the 500X will become uncontrollable due to bad signal reception.
(You can still apply altitude maintaining function under GPS positioning mode as long as you unplug the
GPS antenna.)
8.Fly the 500X in an open area, and keep away from buildings. The GPS signal might be interfered due to
signal refraction from buildings.
9.Under GPS positioning mode, please keep the 500X away from magnetic materials, such as hovering
above the iron plate, the magnetometer inside the GU-INS will be interfered and result in instable of
heading.
10.Keep the GU-INS away from magnetic materials (irons, screws, motor and magnet), those will interfere
the GU-INS. (The screws of GU-INS are made of copper.)
11.If the 500X can not make a 360 degree turn, it reprents that the magnetometer of GU-INS is interfered.
Please keep away from sources of interference or execute the calibration process. (Please visit GAUI
official website for detail information.)
14.You can download the latest firmware from the official website of GAUI.
12.When the wind is getting stronger, we suggest to take off and land with auto-balance mode. Under GPS
positioning mode, altitude maintaining function would be interfered by change of air pressure. Therefore,
it would be more dangerous while the 500X is close to the ground.
1

Solid---- Execute low voltage protection function.
Index for LED Light Status
1.SET:
2.GPS:
3.MODE:
4.SENSOR:
Off---- Normal
Flashes 3 times and turn off---- Setup is completed.
Off---- GPS system is not inserted.
Fast flashing---- Execute “HOME” function.
Slow flashing---- Searching GPS signals.
Solid---- GPS signal searching procedure is completed.
Slow flashing---- Manual mode.
Fast flashing---- Auto-balance mode.
Solid---- GPS positioning mode.
Fast RED flashing---- Low voltage protection function is activated.
Solid RED---- System error, please restart the system.
Green ---- System works fine.
Red ---- System error, please restart the system.
2
1 sec

System Assembly
1.Install the damper sponges to the corners under GU-INS.
*Please keep GU-INS away from magnetic
material.
2.Install the GU-INS to the center of the platform.
3

System Assembly
3.Insert the 2 and 6 channel connection cables to the GU-INS main controller.
4.Insert the plugs of ESCs (1~4) to the given sockets of GU-INS. (Notice the position and spinning
direction of the motors.)
*The main controller of GU-INS is aeolotropic.
The arrow on GU-INS represents the direction
of the main controller.
Nose Direction
4
White/Red/Black Red/Orange/Yellow
Green/Blue
(AIL) (E) (T) (R)
(H)
Red/ /Black
(B) (P CAM)
(MODE)

AILE
ELEV
THRO
RUDD
Futaba JR Hitech
Normal
Normal
Normal
Normal
Normal
Normal
Normal
Reverse
Reverse
Reverse
Reverse
Reverse
System Assembly
5.Insert the plugs of receiver to GU-INS as illustrated.
6.Create a model as “Airplane” in transmitter, confirm the “REV” setting as illustrated.
7.Assign “MODE” (green wire) to the 3-positions switch (A)
on the transmitter (as illustrated), “H” (blue wire) to the
2-positions switch (B) on the transmitter, and “P CAM” (black wire) to the side lever (C) of the transmitter.
A
B
C
5
White/Red/Black AILE
Red ELEV
Orange THRO
Yellow RUDD
Green FLAP(Mode)
Blue GEAR(Go Home)
Black AUX2(Camera Mount Pitch Axis)

System Setting
1.For your safety, before setup, please remove the propellers, and notice the LED lights on the GU-INS.
2.Turn on the transmitter, and move the
throttle stick to its top position.
3.Connect the battery to the 500X, the motors will come up
with corresponding tones, and the LED light of “MODE”
lights “ Red flashing”.
4.Then move the throttle stick to its lowest
position.
5.The motors will come up with corresponding tones, LED light
of “MODE” lights “Solid green”, and the calibration of ESCs
is completed.
6
MODE 1
MODE 1

System Setting
Manual mode
Auto-balance mode
GPS positioning mode
Off
“Home” function
6.Then confirm the LED light of “MODE” and “GPS” in each fly mode; pay attention to the functionality of each
switch position (as illustrated).
You can also connect 1~2 satellite receiver instead of standard receiver, 6 channel connection cable is
unnecessary while using satellite receiver. While setting the transmitter, please assign the functions
(Home, Mode, etc) to the 2 or 3 positions switch and levers, and confirm again how it works according
to the status of the LED lights.
Ex: channel assignment for
JR DSX7 and DSX9:
Home function
Fly mode
Camera gimbal
Insert the “Bind plug” to the “AIL” slot
before binding the transmitter
and GU-INS
(For your safety, please remove the propellers
before binding.)
7

System Tuning
1.Install the propellers, turn on the transmitter, and switch to
“Manual” mode.
2.Connect the battery to the 500X, after the
corresponding tones of ESCs, you are ready
for test flight.
3.Move the throttle stick gradually until the 500X slightly lift off.
4.Move the “ELE” stick upward to check and make sure the 500X tilts forward as illustrated.
8
MODE 1
MODE 1

System Tuning
5.Check and make sure the “AIL” movement follow your transmitter command.
6.Check and make sure the “RUD” movement follow your transmitter command.
7.After checking all movements of the 500X are correct, hover the 500X about 1m above the ground, if it
shakes or wags while hovering, decrease the “GAIN” value until it is stable.
The recommanded initial setting of GAIN and Z GAIN value
is about central position of the knob. (as illustrated)
9
MODE 1
MODE 1

System Tunning
8.Hover about 1.5m above the ground, calibrate the attitude of 500X with trimmers of the transmitter.
9.Press “SET” buttom when
calibration is completed.
10.“SET” LED light flashes three
times when calibration under
manual mode is completed.
11.Set all trims to neutral
after calibration.
12.Switch to “Auto-balance” mode, and
calibrate the attitude of 500X with
trimmers of the transmitter.
13.Press “SET” bottom when calibration is completed, then set
all trims to neutral after calibration. (GPS positioning mode
does not need to be calibrated.)
1.5m
10

GPS Navigation
2.Turn on the transmitter. 3.Connect the battery of the 500X, the LED light of “GPS”
will start to flash, and the GU-INS will start to search for
GPS signal.
1.Install the GPS system on top of the canopy with twin adhesive tape,
(The GPS system is not aeolotropic, the mark on top of it should be faced upward.)
insert the plug to the given socket (GPS) on the GU-INS.
11

GPS Navigation
4.When the GU-INS has found more than
five satellites, the LED light of “GPS” will turn
solid green. We recommand to wait one more
minute.
5.You can verify how many satellites are received by
pressing the buttom and count the number of LED
flashes(as illustrated).
6.Switch to “GPS positioning” mode, the LED light will
turn solid green (as illustrated).
7.The definition of throttle stick under “GPS
positioning” mode is as illustrated above.
8.To lift up, move the throttle stick upward slowly
over its central position. 9.Until the 500X has climbed to the altitude you want,
move the throttle stick back to central position.
Up
12
Down
Set
MODE 1
MODE 1

GPS Navigation
10.You can also take off with “Auto-balance” mode (turn
switch as indicated above), the MODE LED light will
turn into fast green flash.
11.Climb to the altitude you want, and switch
back to “GPS positioning” mode.
12.Move the throttle stick upward, and the 500X will start to climb.
13.Move the throttle stick back to neutral position, the 500X will maintain its altitude.
13
MODE 1
MODE 1
MODE 1

GPS Navigation
14.Move the throttle stick downward, the 500X will start to decend.
15.If the 500X heads to the left while you move the “ELE” stick forward, please adjust the “HEAD” knob
to the right, this is the calibration of magnetic north and due north of different area.
14
MODE 1
MODE 1

GPS Navigation
16.Z gain is used for adjusting the gain value of altitude, it may be affected by wind or air pressure, thus
we recommand to adjust it to central position (as illustrated).
17.The 500X can decend slowly to the ground
under GPS positioning mode.
18.The propellers would not stop until switched back
to “Auto-balance” or “Manual” mode.
19.You can also land by switching to “Auto-balance” or “Manual” mode in the air.
15
MODE 1
MODE 1
MODE 1

Go-Home Function
1.While just starting the GPS system, the “Home” position may be within a radius of 5m.
2.By increasing the numbers of satellites received
and wait for convergence of signal, the precision
may increase to be within a radius of 2m.
3.Then press “SET” buttom under GPS positioning
mode will make the “Home” position setting to be
.
more accurate. (LED light of “SET” flashes.)
4.When you move the 500X away to a new location, and would like to reset “Home” position,
just press “SET” bottom under GPS positioning mode to reset “Home” position.
16

Go-Home Function
5.When switching to “Home” function, the 500X will turn its head
toward “Home” location and start returning to “Home” position.
If its altitude is more than 10m, it will decend to 10m height after
arriving at “Home” position. If its altitude is below 10m, it will
maintain altitude and hover. You can still give orders like yaw or
decend while the 500X is returning to “Home” position.
6.If you would like to operate after returning to “Home” position,
remember to switch back to “Manual” or “Auto-balance” mode.
17
10m

Low Voltage Protection
2.If you connect the battery to the 500X first, then insert the plug, the low voltage protection
function will not be activated, but the voltage will be shown on the OSD.
3.No matter which kinds of batteries
you use (2~4S), insert the plug to
the second cell (positive pole) of
the balance plug.
4.Due to the variation in performance among different
batteries, you will be able to adjust the activated voltage
for low voltage protection function.
1.When you first insert the plug to the second cell (positive pole) of the balance plug of battery,
and then connect the battery to the 500X, the low voltage protection function will be activated.
(LED light of SET turn solid.)
18
HV
LV
