GEM R639 User manual

GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)
Motorized diaphragm valve
Operating instructions
EN
further information
webcode: GW-R639

All rights including copyrights or industrial property rights are expressly reserved.
Keep the document for future reference.
© GEMÜ Gebr. Müller Apparatebau GmbH & Co. KG
01.03.2021
www.gemu-group.com2 / 67GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)

Contents
1 General information .................................................. 4
1.1 Information ......................................................... 4
1.2 Symbols used ..................................................... 4
1.3 LED symbols ....................................................... 4
1.4 Definition of terms ............................................. 4
1.5 Warning notes .................................................... 4
2 Safety information .................................................... 5
3 Product description ................................................... 5
4 Correct use ............................................................... 6
5 Order data ................................................................. 7
6 Technical data .......................................................... 9
7 Dimensions ............................................................... 14
8 Manufacturer's information ....................................... 27
8.1 Delivery ............................................................... 27
8.2 Packaging ........................................................... 27
8.3 Transport ............................................................ 27
8.4 Storage ............................................................... 27
9 Installation in piping .................................................. 27
9.1 Preparing for installation ................................... 27
9.2 Installation position ........................................... 28
9.3 Installation with butt weld spigots .................... 28
9.4 Installation with threaded sockets .................... 28
9.5 Installation with union ends .............................. 29
9.6 Installation with solvent cement sockets ......... 29
9.7 Installation with flare connection ...................... 29
10 Electrical connection ................................................. 30
11 Specific data IO-Link (pin 6) ...................................... 32
11.1 Operation on IO-Link .......................................... 32
11.2 Process data ....................................................... 35
11.3 Parameter overview ........................................... 36
11.4 Parameter ........................................................... 40
11.5 Events ................................................................. 54
12 Operation .................................................................. 57
12.1 Initialization ........................................................ 57
12.2 Manual override .................................................. 57
13 Inspection and maintenance ...................................... 58
14 Troubleshooting ........................................................ 61
15 Removal from piping ................................................. 63
16 Disposal .................................................................... 63
17 Returns ..................................................................... 63
18 Declaration of Incorporation according to 2006/42/
EC (Machinery Directive) ........................................... 64
19 Declaration of conformity according to 2014/68/EU
(Pressure Equipment Directive) ................................. 65
20 Declaration of conformity according to 2014/30/EU
(EMC Directive) ......................................................... 66
GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)
www.gemu-group.com 3 / 67

www.gemu-group.com4 / 67GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)
1 General information
1 General information
1.1 Information
•The descriptions and instructions apply to the standard
versions. For special versions not described in this docu-
ment the basic information contained herein applies in
combination with any additional special documentation.
•Correct installation, operation, maintenance and repair
work ensure faultless operation of the product.
•Should there be any doubts or misunderstandings, the Ger-
man version is the authoritative document.
•Contact us at the address on the last page for staff training
information.
1.2 Symbols used
The following symbols are used in this document:
Symbol Meaning
Tasks to be performed
Response(s) to tasks
– Lists
1.3 LED symbols
The following LED symbols are used in the documentation:
Symbol LED conditions
Off
Lit (on)
Flashing
1.4 Definition of terms
Working medium
The medium that flows through the GEMÜ product.
Diaphragm size
Uniform seat size of GEMÜ diaphragm valves for different
nominal sizes.
1.5 Warning notes
Wherever possible, warning notes are organised according to
the following scheme:
SIGNAL WORD
Type and source of the danger
Possible
symbol for the
specific
danger
Possible consequences of non-observance.
Measures for avoiding danger.
Warning notes are always marked with a signal word and
sometimes also with a symbol for the specific danger.
The following signal words and danger levels are used:
DANGER
Imminent danger!
▶Non-observance can cause death or
severe injury.
WARNING
Potentially dangerous situation!
▶Non-observance can cause death or
severe injury.
CAUTION
Potentially dangerous situation!
▶Non-observance can cause moderate
to light injury.
NOTICE
Potentially dangerous situation!
▶Non-observance can cause damage to
property.
The following symbols for the specific dangers can be used
within a warning note:
Symbol Meaning
Danger of explosion
Corrosive chemicals!
Hot plant components!

www.gemu-group.com 5 / 67 GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)
2 Safety information
The safety information in this document refers only to an in-
dividual product. Potentially dangerous conditions can arise
in combination with other plant components, which need to
be considered on the basis of a risk analysis. The operator is
responsible for the production of the risk analysis and for
compliance with the resulting precautionary measures and
regional safety regulations.
The document contains fundamental safety information that
must be observed during commissioning, operation and
maintenance. Non-compliance with these instructions may
cause:
•Personal hazard due to electrical, mechanical and chemical
effects.
•Hazard to nearby equipment.
•Failure of important functions.
•Hazard to the environment due to the leakage of dangerous
materials.
The safety information does not take into account:
•Unexpected incidents and events, which may occur during
installation, operation and maintenance.
•Local safety regulations which must be adhered to by the
operator and by any additional installation personnel.
Prior to commissioning:
1. Transport and store the product correctly.
2. Do not paint the bolts and plastic parts of the product.
3. Carry out installation and commissioning using trained
personnel.
4. Provide adequate training for installation and operating
personnel.
5. Ensure that the contents of the document have been fully
understood by the responsible personnel.
6. Define the areas of responsibility.
7. Observe the safety data sheets.
8. Observe the safety regulations for the media used.
During operation:
9. Keep this document available at the place of use.
10. Observe the safety information.
11. Operate the product in accordance with this document.
12. Operate the product in accordance with the specifica-
tions.
13. Maintain the product correctly.
14. Do not carry out any maintenance work and repairs not
described in this document without consulting the manu-
facturer first.
In cases of uncertainty:
15. Consult the nearest GEMÜ sales office.
3 Product description
3.1 Construction
1
6
5
3
2
4
7
Item Name Materials
1 Optical position indic-
ator
PA 12
2 Manual override
3 Actuator top with LED
display
Polyamide, 50% glass
fibre
4 Actuator base Polyamide, 50% glass
fibre
5 Electrical connection
6 Diaphragm NBR, FPM, CR, EPDM,
PTFE/EPDM
7 Valve body PVC-U (grey), PP,
PVDF, PP-H(natural)
3 Product description

www.gemu-group.com6 / 67GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)
4 Correct use
3.2 LED displays
3.2.1 Status LEDs
LED Colour Function
Standard Inversed 1)
Power/fault green green Operating indica-
tion/
communication
status
red red
Open orange green Process valve in
OPEN position
Error red red Error
Closed green orange Process valve in
CLOSED position
1) Inversed representation of the OPEN and CLOSED LEDs, ad-
justable via IO-Link
3.2.2 LED conditions
Status
process
valve
Power/
fault
Open Error Closed
OPEN posi-
tion
CLOSED
position
Position
unknown
Initializa-
tion Open and Closed flash
alternately
LED conditions
lit (on) flashes off
3.3 Description
The GEMÜ R639 is a motorized 2/2-way diaphragm valve.
The eSyStep electric actuator is available as ON/OFF or with
integrated positioner. An integral optical and electrical posi-
tion indicator is standard. The self-locking actuator holds its
position in a stable manner when idle and in the event of
power supply failure.
3.4 Function
The product controls or regulates (depending on version) a
flowing medium by being closed or opened by a motorized
actuator.
The product is equipped as standard with a mechanical posi-
tion indicator as well as an electrical position and status in-
dicator.
4 Correct use
DANGER
Danger of explosion
▶Risk of death or severe injury.
●Do not use the product in potentially
explosive zones.
WARNING
Improper use of the product
▶Risk of severe injury or death.
▶Manufacturer liability and guarantee will be void.
●Only use the product in accordance with the operating
conditions specified in the contract documentation and
in this document.
The product is designed for installation in piping systems
and for controlling a working medium.
The product is not intended for use in potentially explosive
areas.
●Use the product in accordance with the technical data.

5 Order data
The order data provide an overview of standard configurations.
Please check the availability before ordering. Other configurations available on request.
Order codes
1 Type Code
Diaphragm valve, motorized,
eSyStep
R639
2 DN Code
DN 12 12
DN 15 15
DN 20 20
DN 25 25
DN 32 32
3 Body configuration Code
2/2-way body D
4 Connection type Code
Spigot
Spigot DIN 0
Spigot for IR butt welding 20
Spigot for IR butt welding, BCF 28
Imperial butt weld spigot 30
Union end
Union end with insert (socket) – DIN 7
Union end with insert (Rp threaded socket) - DIN 7R
Union end with inch insert - BS (socket) 33
Union end with inch insert – ASTM (socket) 3M
Union end with JIS insert (socket) 3T
Union end with insert (for IR butt welding) – DIN 78
Threaded socket
Threaded socket DIN ISO 228 1
Solvent cement socket
Solvent cement socket DIN 2
Flange
Flange EN 1092, PN 10, form B,
face-to-face dimension FTF EN 558 series 1, ISO
5752, basic series 1
4
Flange ANSI Class 125/150 RF,
face-to-face dimension FTF EN 558 series 1, ISO
5752, basic series 1,
length only for body configuration D
39
Flare
Flare connection with PVDF union nut 75
5 Valve body material Code
PVC-U, grey 1
ABS 4
PP, reinforced 5
PVDF 20
Inliner PP-H, grey,
outliner PP, reinforced
71
Inliner PVDF/outliner PP, reinforced 75
PP-H, natural N5
6 Diaphragm material Code
NBR 2
FKM 4
EPDM 29
PTFE/EPDM one-piece 54
PTFE/EPDM two-piece 5M
7 Voltage/Frequency Code
24 V DC C1
8 Control module Code
OPEN/CLOSE control, additional end position in-
dicators
AE
Open/Close control, additional end position indic-
ators,
configured for emergency power supply module
(NC)
A5
Open/Close control, additional end position indic-
ators,
configured for emergency power supply module
(NO)
A6
9 Actuator version Code
Actuator size 0
diaphragm size 10
0C
Actuator size 1 1A
10 Mounting plate Code
With mounting plate M
Without
Order example
Ordering option Code Description
1 Type R639 Diaphragm valve, motorized,
eSyStep
2 DN 15 DN 15
3 Body configuration D 2/2-way body
4 Connection type 7 Union end with insert (socket) - DIN
5 Order data
www.gemu-group.com 7 / 67 GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)

Ordering option Code Description
5 Valve body material 1 PVC-U, grey
6 Diaphragm material 29 EPDM
7 Voltage/Frequency C1 24 V DC
8 Control module AE OPEN/CLOSE control, additional end position indicators
9 Actuator version 0C Actuator size 0
diaphragm size 10
10 Mounting plate Without
5 Order data
www.gemu-group.com8 / 67GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)

6 Technical data
6.1 Medium
Working medium: Corrosive, inert, gaseous and liquid media which have no negative impact on the physical and
chemical properties of the body and diaphragm material.
6.2 Temperature
Media temperature: Valve body material Media temperature
PVC-U, grey (code 1) 10 — 60 °C
ABS (code 4) 10 — 60 °C
PP, reinforced (code 5) 5–80 °C
PVDF (code 20) -10 — 80 °C
Inliner PP-H grey / outliner PP, reinforced (code
71)
5–80 °C
Inliner PVDF / outliner PP, reinforced (code 75) -10 — 80 °C
PP-H, natural (code N5) 5–80 °C
Ambient temperature: Valve body material Ambient temperature
PVC-U, grey (code 1) 10 — 50 °C
ABS (code 4) -10 — 50 °C
PP, reinforced (code 5) 5 — 50 °C
PVDF (code 20) 0 — 50 °C
Inliner PP-H grey / outliner PP, reinforced (code
71)
5 — 50 °C
Inliner PVDF / outliner PP, reinforced (code 75) -5 — 50 °C
PP-H, natural (code N5) 5 — 50 °C
6.3 Pressure
Operating pressure: MG DN Actuator
version
Diaphragm materials
Elastomer PTFE
10 12 - 20 0C 0 - 6 0 - 6
20 15 - 25 1A 0 - 8 0 - 8
25 32 1A 0 - 8 0 - 8
MG = diaphragm size
All pressures are gauge pressures. Operating pressure values were determined with static operat-
ing pressure applied on one side of a closed valve. Sealing at the valve seat and atmospheric seal-
ing is ensured for the given values.
Information on operating pressures applied on both sides and for high purity media on request.
The operating pressures apply at room temperature. In case of deviating temperatures, observe
the pressure / temperature correlation.
Pressure rating: MG 10: PN 6
MG 20 – 25: PN 10
GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)
www.gemu-group.com 9 / 67
6 Technical data

Pressure/temperature
correlation:
Pressure/temperature correlation PN 6
Valve body
material
Temperature in °C (valve body)
Material Code -10 ±0 5 10 20 25 30 40 50 60 70 80
PVC-U 1 - - - 6.0 6.0 6.0 4.8 3.6 2.1 0.9 - -
ABS 4 6.0 6.0 6.0 6.0 6.0 6.0 4.8 3.6 2.4 1.2 - -
PP 5 - - 6.0 6.0 6.0 6.0 6.0 6.0 5.5 4.0 2.7 1.5
PP-H 71 - - 6.0 6.0 6.0 6.0 6.0 6.0 5.5 4.0 2.7 1.5
PVDF 20 6.0 6.0 6.0 6.0 6.0 6.0 5.4 4.8 4.3 3.8 3.2 2.8
PVDF 75 6.0 6.0 6.0 6.0 6.0 6.0 6.0 6.0 6.0 6.0 5.4 4.7
PP-nat-
ural
N5 - - 6.0 6.0 6.0 6.0 5.1 4.2 3.3 2.4 1.6 0.9
Pressure/temperature correlation PN 10
Valve body
material
Temperature in °C (valve body)
Material Code -10 ±0 5 10 20 25 30 40 50 60 70 80
PVC-U 1 - - - 10.0 10.0 10.0 8.0 6.0 3.5 1.5 - -
ABS 4 10.0 10.0 10.0 10.0 10.0 10.0 8.0 6.0 4.0 2.0 - -
PP 5 - - 10.0 10.0 10.0 10.0 8.5 7.0 5.5 4.0 2.7 1.5
PP-H 71 - - 10.0 10.0 10.0 10.0 8.5 7.0 5.5 4.0 2.7 1.5
PVDF 20 10.0 10.0 10.0 10.0 10.0 10.0 9.0 8.0 7.0 6.3 5.4 4.7
PVDF 75 10.0 10.0 10.0 10.0 10.0 10.0 9.0 8.0 7.1 6.3 5.4 4.7
PP-nat-
ural
N5 - - 10.0 10.0 10.0 10.0 8.5 7.0 5.5 4.0 2.7 1.5
The pressure rating (PN) depends on the connection code.
Data for extended temperature ranges on request. Please note that the ambient temperature and media tem-
perature generate a combined temperature at the valve body which must not exceed the above values.
Depending on the valve configuration, the maximum operating pressure of the pressure rating may be lower.
Observe the operating pressure table.
Leakage rate: Leakage rate A to P11/P12 EN 12266-1
Kv values: MG DN Kv values
10 12 2.8
15 3.5
20 3.5
20 15 6.0
20 10.0
25 12.0
25 32 20.0
MG = diaphragm size, Kv values in m³/h
Kv values determined acc.to DIN EN 60534 standard, inlet pressure 5 bar, Δp 1 bar, PVC-U valve body and soft
elastomer diaphragm. The Kv values for other product configurations (e.g. other diaphragm or body materials)
may differ. In general, all diaphragms are subject to the influences of pressure, temperature, the process and
their tightening torques. Therefore the Kv values may exceed the tolerance limits of the standard.
The Kv value curve (Kv value dependent on valve stroke) can vary depending on the diaphragm material and
duration of use.
www.gemu-group.com10 / 67GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)
6 Technical data

6.4 Product compliance
Pressure Equipment Dir-
ective:
2014/68/EU
Machinery Directive: 2006/42/EU
FDA*
* depending on version and/or operating parameters
EMC Directive: 2014/30/EU
Technical standards used:
Interference resistance DIN EN 61000-6-2
Interference emission EN 61800-3
Category C3
The product is intended for operation in indus-
trial environments.
6.5 Materials
Materials: Diaphragm material O-ring material
PTFE FKM
NBR EPDM
FKM FKM
EPDM EPDM
6.6 Mechanical data
Protection class: IP 65 acc. to EN 60529
Actuating speed: Max. 3 mm/s
Weight: Actuator
Actuator size 0 (code 0C) 0.95 kg
Actuator size 1 (code 1A) 1.88 kg
Body
Connection
types code
0, 30 20 7 33 78 7R 3M,
3T
1 2 4, 39 75
MG DN
10 12 - - - - - - - 0.08 0.06 - 0.08
15 - - 0.18 0.13 0.20 - - - - - 0.125
20 15 -----------
20 -----------
25 -----------
25 32 -----------
MG = diaphragm size, weight in kg
GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)
www.gemu-group.com 11 / 67
6 Technical data

6.7 Duty cycle and service life
Service life: At least 500,000 switching cycles at room temperature and permissible duty cycle.
Duty cycle: Control module Open/Close control (code AE, A5, A6)
Duty cycle with full valve lift and playing time 10 minutes.
0
10
20
30
40
50
60
70
80
90
100
0 10 20 30 40 50 60 70 80
Duty cycle [%]
Ambient temperature [°C]
Diaphragm valve DN 12 - 20 (code 0C)
Diaphragm valve DN 15 - 32 (code 1A)
NOTICE
▶The specified characteristics and values apply to the factory setting.
▶With reduced forces, higher duty cycles and/or higher ambient temperatures are possible. At higher force settings the duty
cycle and/or ambient temperature is reduced.
▶IO-Link: Index 0x90 - Subindex 2 - Force
www.gemu-group.com12 / 67GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)
6 Technical data

6.8 Electrical data
Supply voltage Uv: 24 V DC ± 10%
Rating: Actuator size 0 (code 0C) 20 W
Actuator size 1 (code 1A) 60 W
Operation: Stepper motor, self-locking
Reverse battery protec-
tion:
Yes
6.8.1 Digital input signals
Inputs: Function selectable via IO-Link (see table Overview of available functions – Input and output sig-
nals)
Input voltage: 24 V DC
Logic level "1": > 15.3 V DC
Logic level "0": < 5.8 V DC
Input current: typically < 0.5 mA
6.8.2 Digital output signals
Outputs: Function selectable via IO-Link (see table Overview of available functions – Input and output sig-
nals)
Type of contact: Push-Pull
Switching voltage: Power supply Uv
Switching current: ≤ 140 mA
Short-circuit proof: Yes
6.8.3 Communication
Interface: IO-Link
Function: Parameterization/process data
Transmission rate: 38400 baud
Frame type in Operate: 2.5 (eSyStep ON/OFF, code AE, A5, A6)
Min. cycle time: 2.3 ms (eSyStep ON/OFF, code AE, A5, A6)
Vendor-ID: 401
Device-ID: 1906701 (eSyStep ON/OFF, code AE, A5, A6)
Product-ID: eSyStep On/Off (code AE, A5, A6)
ISDU support: Yes
SIO operation: Yes
IO-Link specification: V1.1
IODD files can be downloaded via https://ioddfinder.io-link.com/ or www.gemu-group.com.
GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)
www.gemu-group.com 13 / 67
6 Technical data

7 Dimensions
7.1 Installation and actuator dimensions
7.1.1 Actuator version code 0C
B2
B1
A
A1
B
CT*
MG DN Actuator
version
A A1 A2 B B1 B2
10 12 - 20 0C 203.5 39.0 33.2 59.4 81.0 133.5
Dimensions in mm, MG = diaphragm size
* CT = A + H1 (see body dimensions)
www.gemu-group.com14 / 67GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)
7 Dimensions

7.1.2 Actuator version code 1A
B2
B1
A
A1
B
CT*
MG DN Actuator
version
A A1 A2 B B1 B2
20 15 1A 298.0 116.0 32.5 70.0 82.0 150.0
25 32 1A 306.0 124.0 32.5 70.0 82.0 150.0
Dimensions in mm, MG = diaphragm size
* CT = A + H1 (see body dimensions)
GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)
www.gemu-group.com 15 / 67
7 Dimensions

7.2 Body dimensions
7.2.1 Spigot DIN / inch (code 0, 30)
L
c
Ød
H1
H
Connection type spigot DIN (code 0) 1), body material PVC-U (code 1), inliner/outliner (code 71, 75) 2)
MG DN NPS c ød H H1 L
Material Material
1 71, 75 1 71, 75
20 15 1/2" 16.0 18.0 20.0 36.0 36.0 10.0 124.0
20 3/4" 19.0 19.0 25.0 38.0 38.0 12.0 144.0
25 1" 22.0 22.0 32.0 39.0 39.0 13.0 154.0
25 32 1¼" 32.0 32.0 40.0 41.0 41.0 15.0 174.0
Connection type spigot - inch (code 30) 1), body material ABS (code 4) 2)
MG DN NPS c ød H H1 L
20 15 1/2" 24.0 21.4 36.0 10.0 141.0
20 3/4" 27.0 26.7 38.0 12.0 144.0
25 1" 30.0 33.6 39.0 13.0 154.0
25 32 1¼" 33.0 42.2 41.0 15.0 174.0
Dimensions in mm
MG = diaphragm size
1) Connection type
Code 0: Spigot DIN
Code 30: Imperial butt weld spigot
2) Valve body material
Code 1: PVC-U, grey
Code 4: ABS
Code 71: Inliner PP-H, grey, outliner PP, reinforced
Code 75: Inliner PVDF/outliner PP, reinforced
www.gemu-group.com16 / 67GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)
7 Dimensions

7.2.2 Spigot IR (code 20)
L
c
Ød
H1
H
s
Connection type spigot IR (code 20) 1), body material inliner/outliner (code 71, 75) 2)
MG DN NPS c ød H H1 L s
Material
71 75
20 15 1/2" 33.0 20.0 36.0 10.0 154.0 1.9 1.9
20 3/4" 33.0 25.0 38.0 12.0 154.0 2.3 1.9
25 1" 33.0 32.0 39.0 13.0 154.0 2.9 2.4
25 32 1¼" 33.0 40.0 41.0 15.0 194.0 3.7 2.4
Dimensions in mm
MG = diaphragm size
1) Connection type
Code 20: Spigot for IR butt welding
2) Valve body material
Code 71: Inliner PP-H, grey, outliner PP, reinforced
Code 75: Inliner PVDF/outliner PP, reinforced
7.2.3 Spigot (code 28)
c1
L
ød
H1
H
c
3
s
Connection type spigot (code 28) 1), body material PVDF (code 20) 2)
MG DN NPS c c1 ød H H1 L s
10 15 1/2'' 31,0 37,0 20,0 41,0 16,0 134,0 1.9
Dimensions in mm
MG = diaphragm size
1) Connection type
Code 28: Spigot for IR butt welding, BCF
2) Valve body material
Code 20: PVDF
GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)
www.gemu-group.com 17 / 67
7 Dimensions

7.2.4 Union end DIN (code 7)
L1
H1
H
L2
R
ØD
Ød
Connection type union end DIN (code 7) 1), body material PVC-U (code 1), PP (code 5). PVDF (code 20), PP-H (code N5), dia-
phragm size 10 2)
MG DN NPS ød øD H H1 L1 L2 R
Material Material Material
1, 20 5, N5 1, 20 5, N5 1, 20 5, N5
10 15 1/2" 20.0 43.0 30.0 41.0 15.0 16.0 90.0 128.0 125.0 G 1
Connection type union end (code 7) 1), body material PVC (code 1), ABS (code 4), inliner/outliner (code 71, 75), diaphragm
sizes 20 – 40 2)
MG DN NPS ød øD H H1 L1 L2 R
Material
1 4 71 75
20 15 1/2" 20.0 43.0 36.0 10.0 108.0 146.0 150.0 143.0 146.0 G 1
20 3/4" 25.0 53.0 38.0 12.0 108.0 152.0 156.0 146.0 150.0 G 1¼
25 1" 32.0 60.0 39.0 13.0 116.0 166.0 170.0 158.0 162.0 G 1½
25 32 1¼" 40.0 74.0 41.0 15.0 134.0 192.0 196.0 181.0 184.0 G 2
Dimensions in mm
MG = diaphragm size
1) Connection type
Code 7: Union end with insert (socket) – DIN
2) Valve body material
Code 1: PVC-U, grey
Code 4: ABS
Code 5: PP, reinforced
Code 20: PVDF
Code 71: Inliner PP-H, grey, outliner PP, reinforced
Code 75: Inliner PVDF/outliner PP, reinforced
Code N5: PP-H, natural
www.gemu-group.com18 / 67GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)
7 Dimensions

7.2.5 Union end inch (code 33, 3M, 3T)
L1
H1
H
L2
R
ØD
Ød
Connection type union end inch (code 33, 3M, 3T) 1), body material PVC-U (code 1) 2), diaphragm size 10
MG DN NPS ød øD H H1 L1 L2 R
10 15 1/2'' 21.4 43.0 30.0 15.0 90.0 128.0 G1
Connection type union end inch (code 33, 3M, 3T) 1), body material PVC-U (code 1), diaphragm sizes 20 - 40 2)
MG DN NPS ød øD H H1 L1 L2 R
Connection type Connection type
33 3M 3T 33 3M 3T
20 15 1/2" 21.4 21.4 22.0 43.0 36.0 10.0 108.0 146.0 158.0 152.0 G 1
20 3/4" 26.8 26.7 26.0 53.0 38.0 12.0 108.0 152.0 164.0 152.0 G 1¼
25 1" 33.6 33.5 32.0 60.0 39.0 13.0 116.0 166.0 180.0 166.0 G 1½
25 32 1¼" 42.3 42.2 38.0 74.0 41.0 15.0 134.0 192.0 204.0 192.0 G 2
Connection type BS (code 33) 1), valve body material PVC-U (code 4) 2)
MG DN NPS ød øD H H1 L1 L2 R
20 15 1/2" 21.4 43.0 36.0 10.0 108.0 150.0 G 1
20 3/4" 26.8 53.0 38.0 12.0 108.0 156.0 G 1¼
25 1" 33.6 60.0 39.0 13.0 116.0 170.0 G 1½
25 32 1¼" 42.3 74.0 41.0 15.0 134.0 198.0 G 2
Dimensions in mm
MG = diaphragm size
1) Connection type
Code 33: Union end with inch insert - BS (socket)
Code 3M: Union end with inch insert – ASTM (socket)
Code 3T: Union end with JIS insert (socket)
2) Valve body material
Code 1: PVC-U, grey
Code 4: ABS
GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)
www.gemu-group.com 19 / 67
7 Dimensions

7.2.6 Union end DIN, IR butt welding (code 78)
ØD
Ød
L2
H
H1
R
L1
S
C
Connection type union end DIN, IR butt welding (code 78) 1), body materials PP (code 5), PVDF (code 20), PP-H (code N5) 2)
MG DN NPS c ød øD H H1 L1 L2 R s
Material Material
5 20, N5 5 20, N5
10 15 1/2" 36.0 20.0 42.0 30.0 41.0 15.0 16.0 90.0 196.0 G 1 1.9
Connection type union end DIN, IR butt welding (code 78) 1), body materials inliner/outliner (code 71, 75) 2)
MG DN NPS c ød øD H H1 L1 L2 R s
Material
71 75
20 15 1/2" 36.0 20.0 43.0 36.0 10.0 108.0 214.0 G 1 1.9 1.9
20 3/4" 37.0 25.0 53.0 38.0 12.0 108.0 220.0 G 1¼ 2.3 1.9
25 1" 39.0 32.0 60.0 39.0 13.0 116.0 234.0 G 1½ 2.9 2.4
25 32 1¼" 39.0 40.0 74.0 41.0 15.0 134.0 258.0 G 2 3.7 2.4
Dimensions in mm
MG = diaphragm size
1) Connection type
Code 78: Union end with insert (for IR butt welding) – DIN
2) Valve body material
Code 5: PP, reinforced
Code 20: PVDF
Code 71: Inliner PP-H, grey, outliner PP, reinforced
Code 75: Inliner PVDF/outliner PP, reinforced
Code N5: PP-H, natural
www.gemu-group.com20 / 67GEMÜ R639 eSyStep
OPEN / CLOSE (Code AE)
7 Dimensions
