GF JRG Coral force 8000 User manual

JRG Coral force 8000
JRG Coral force 11000
JRG Coral force 14000
JRG Coral force 3.5D
JRG Coral force 5D
Operating Manual EN
FailSafe
Rev.: 1113803-1
Coral force 14000

Seite 2 von 68 Rev.: 1113803-1

Seite 3 von 68 Rev.: 1113803-1
Contents
1Preface......................................................................................................................... 5
1.1 Safety Information .................................................................................................................5
1.2 Warranty................................................................................................................................6
1.3 Duty of Care of the Operator .................................................................................................6
1.4 Safety Information and Prerequisites for Installation ............................................................7
1.5 CE-Marking ............................................................................................................................9
2Product description.................................................................................................... 10
2.1 Intended Use........................................................................................................................10
2.2 Principle of Operation..........................................................................................................12
3Control and Monitoring Module ................................................................................. 14
4Scope of Delivery and Setting Up................................................................................ 18
5Technical Data............................................................................................................ 20
6Installation Options.................................................................................................... 21
7Filling and Bleeding the Unit....................................................................................... 22
7.1 Remove thermal insulation..................................................................................................22
7.2 Filling and bleeding ..............................................................................................................23
7.3 Fitting thermal insulation and thermometer .......................................................................26
7.4 Signal Contact for Building Management System (optional)................................................27
8Commissioning........................................................................................................... 28
8.1 Switch unit on ......................................................................................................................28
8.1.1 Initialisation and Settings - Automatic Hygiene Program ................................. 30
8.2 Set date and time.................................................................................................................34
8.3 Setting Device Parameters (OPTIONAL) ...............................................................................35
8.3.1 Linking to pumping system (OPTIONAL)........................................................... 36
8.3.2 Setting the time for thermal disinfection (TD) (OPTIONAL).............................. 37
8.3.3 Changing the Service Interval (OPTIONAL) ....................................................... 38
8.4 Initiating a Manual Thermal Disinfection (TD) .....................................................................39
9Operating States and Indications................................................................................ 40

Seite 4 von 68 Rev.: 1113803-1
9.1 Water Treatment (WT) ........................................................................................................41
9.2 Thermal Disinfection (TD) ....................................................................................................42
9.3 Backflush (RS) ......................................................................................................................43
9.4 Service Display .....................................................................................................................44
9.5 Fault Messages/Malfunctions ..............................................................................................45
9.6 Manual Decommissioning if Ball Valve is Defective .............................................................48
9.7 Errors E00 to E05 – Ball Valve Positioning............................................................................49
9.8 Error E06 – Heating time exceeded during TD .....................................................................51
9.9 Error E07 – Backflush failed .................................................................................................54
9.10 Error E08 – Backflush not possible, pumping system...........................................................55
9.11 Error - Date and time settings missing .................................................................................56
10 Maintenance and Service ........................................................................................... 57
10.1 Service Message...................................................................................................................57
10.2 Safety when Replacing the Catalyst Granulate ....................................................................58
10.3 Switch off and Unplug..........................................................................................................58
11 Behälter entleeren ..................................................................................................... 59
11.1 Remove Thermal Insulation .................................................................................................61
11.2 Emptying Out Granulate ......................................................................................................61
11.3 Replacing Filter Stars............................................................................................................62
11.4 Filling with New Catalysing and Filter Granulate..................................................................63
11.5 Commissioning the Unit.......................................................................................................65
11.6 Documentation ....................................................................................................................65
11.7 Resetting the Operating Hours Counter...............................................................................66
12 Service Set ................................................................................................................. 67

Seite 5 von 68 Rev.: 1113803-1
1Preface
These operating instructions contain all the important information you will need for proper
operation of the device described. Observing these instructions helps avoid dangers, reduce
repair costs and downtime, and increase the reliability and service life of the unit.
Always keep this operating manual available at the site of use.
For more information or if problems arise that are not covered in this manual, please contact
Georg Fischer JRG customer services directly.
Georg Fischer JRG AG customer services: [phone] [e-mail]
1.1 Safety Information
The symbols in these operating instructions have the following meaning:
Warning
This symbol indicates information that must be observed to avoid the
possibility of extensive property damage. Observe the safety
information strictly.
Note
This symbol indicates important information regarding use of the device.
Failure to follow this instruction may result in malfunctions.
Instruction
This symbol refers to a measure that must be adhered to under all
circumstances to ensure proper installation and commissioning.
Georg Fischer JRG accepts no liability where the user disregards the instructions marked on the
devices and/or contained in the operating manual.

Seite 6 von 68 Rev.: 1113803-1
1.2 Warranty
The warranty shall be honoured under our General Terms of Sale and Delivery only if:
•the device is installed by a qualified professional,
•the device is used as instructed in this operating manual,
•the device is properly deployed,
•repairs are carried out exclusively by authorised and qualified personnel,
•no unauthorised modifications are made to the device.
1.3 Duty of Care of the Operator
The JRG Coral force limescale conditioning system has been designed and built under careful
observance of harmonised standards and other technical specifications.
The system is thus state of the art and allows maximum safety during all operating conditions.
The safety of the system can, however, only be assured in practice if all necessary measures are
taken. It is the operator's duty of care to plan these measures and to monitor their
implementation.
In particular, the operator must ensure that
•the system is used only for its intended purpose ( see section K2.1 Intended Use',
page 10).
•the system is operated only in a defect-free, fully functional condition, and in
particular that the safety systems are checked regularly for correct functioning.
•the required personal protective equipment is provided to, and worn by, the
operating, maintenance and repair personnel.
•the operating manual is always available at the installation site of the device or
system, complete and in legible condition.
•only qualified and authorised personnel operate, maintain and repair the system.
•this staff receives regular training in all relevant aspects of occupational safety and
environmental protection and is familiar with the operating instructions and
particularly the safety information contained therein.
•all safety and warning notices attached to the equipment are left in place and are
legible.
•changes to the system are carried out exclusively by authorised personnel.

Seite 7 von 68 Rev.: 1113803-1
1.4 Safety Information and Prerequisites for Installation
Attention
•Use the device only in its proper working condition and for its intended use and in
full awareness of safety issues and potential hazards.
•Observe the installation and operating instructions.
•Ensure that any faults that may affect safety are rectified immediately by a
specialist.
•Installations and repairs not performed by authorised professionals, technical
modifications to the device not approved in writing by the manufacturer and/or
the use of non-original spare parts will void the warranty and the product liability
of the manufacturer.
•UIntended Use of the JRG Coral force Series:
oLimescale protection in apartment buildings, hotels, schools and other
public buildings and in commerce and industry.
oTo be installed only in the cold-water supply line of the potable water
installation.
oThe applicable (local) installation regulations, general guidelines and
standards for the supply of potable water and heated potable water
(TrinkwV (German Drinking Water Ordinance), DIN2000, DIN2001,
DIN50930, DIN1988, DVGW, ÖVGW- or SVGW standards) must be
observed and complied with when used in potable water installations.
•UJRG Coral force units are not suitable forU:
oTechnical systems for which partially softened or demineralised water
is stipulated by the manufacturer (JRG Coral force units are not water
softeners),
oProcess water whose composition does not meet the requirements of
the Drinking Water Ordinance (TVO, Trinkwasserverordnung),
oWater that is strongly undersaturated with respect to lime (aggressive
to lime) in the vicinity of the treatment unit,
•The unit must be connected to a correctly installed, earthed and fused three-phase
power socket (400 V/50 Hz).
•Insert the power plug only after assembly is complete.
•Do not expose the system to direct moisture. In particular, ensure that no water
drips onto it from above.
•Check regularly that the system is watertight and correctly functioning and observe
the prescribed inspection and maintenance intervals and the measures provided
for this purpose accurately.
•Before performing maintenance or repair work, ensure that access to the working
area of the limescale conditioner for unauthorised persons is blocked.

Seite 8 von 68 Rev.: 1113803-1
oAffix or position a sign indicating that maintenance or repair work is in
progress.
oUnplug and depressurise the unit and secure it against inadvertent
reactivation.
oBefore undertaking maintenance or repair work, ensure that all device
and system parts have cooled to room temperature.
•The device contains a flushing line, which must be run out to a drain. The user must
ensure the unobstructed outflow of drain water at all times. Caution: any pumping
units must be secured by appropriate measures against power failure.
Any other or additional use of this equipment is deemed to be NOT
FOR INTENDED PURPOSE.
The manufacturer/supplier assumes no liability for damage caused by
non-observance of these operating instructions or applicable
regulations or for damage caused by improper use. In such cases all
risk is borne by the user/operator.

Seite 9 von 68 Rev.: 1113803-1
1.5 CE-Marking
The manufacturer
Georg Fischer JRG AG
declares that the following products and models
JRG Coral force 8000
JRG Coral force 11000
JRG Coral force 14000
JRG Coral force 3.5D
JRG Coral force 5D
DIRECTIVE 2006/42/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL
dated 17 May 2006 on machinery and to amend Directive 95/16/EC (amended version)
DIRECTIVE 2006/95/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL
dated 12 December 2006 for adjustment of the Member States' legislation on electrical
equipment for use within certain voltage limits, and of DIRECTIVE 2004/108/EC OF THE
EUROPEAN PARLIAMENT AND OF THE COUNCIL
dated 15 December 2004 for adjustment of the Member States' legislation on electromagnetic
compatibility and for repealing Directive 89/336/EEC
Georg Fischer JRG AG
Hauptstrasse 130
CH-4450 Sissach
......................................................................
M. Huck (Geschäftsführer)

Seite 10 von 68 Rev.: 1113803-1
2Product description
2.1 Intended Use
The JRG Coral force 8000,
11000, 14000, 3.5D, 5D limescale conditioning
units are designed to provide long-term
reductions in limescale formation in potable
water installations and sanitary systems. The
biomineralisation process is based on a
principle that protects against limescale build-
up without the use of chemical additives or
electrolytic decomposition of water.
The units are designed solely to be installed in
the main potable water system inlet of
apartment buildings, hospitals, hotels, schools,
and other public buildings and of commercial
and industrial premises.
Unit selection and sizing should be carried out
according to Georg Fischer JRG’s planning
documents and design specifications.
JRG Coral force 14000
This unit is not suitable for:
•Technical systems for which full or partial desalination is required or
prescribed by the manufacturer.

Seite 11 von 68 Rev.: 1113803-1
Installation example with JRG Coral force 14000 in the main potable water system inlet, fitted
after the water meter and a domestic water station with filter, RV and pressure control valve.
Any other or additional use of this equipment is deemed to be NOT FOR
INTENDED PURPOSE.
The manufacturer/supplier assumes no liability for damage caused by non-
observance of these operating instructions or applicable regulations or for
damage caused by improper use. In such cases all risk is borne by the
user/operator.

Seite 12 von 68 Rev.: 1113803-1
2.2 Principle of Operation
JRG Coral force limescale conditioners function on the basis of patented WATERCRYST catalyser
technology. This leaves the valuable minerals in the potable water and does not alter its natural
composition.
The stainless steel tank (1) contains a loose bed of active, fine-grained polymer catalyst
granulate (2), above which are filter granules of lower specific weight (3) in polypropylene and
filter stars (4, 5) in the water inlet and outlet. These are made of food-safe, temperature-
resistant plastics and serve to keep the catalyst granulate (2) in the tank (1).
The water to be treated flows and swirls (A) through the catalyst granulate (2). Imitating natural
bio-mineralisation processes, tiny crystals of lime from the hardeners dissolved in the water are
deposited on the surface of the catalyst (B). These tiny lime crystals are then stripped from the
catalyst surface by the water being treated (C) and spread throughout the entire installation
system by water removal (D). The result is a protective deposit of tiny lime crystals that act
throughout the entire hot water system (the Udeposit effectU).
A
B und C
D
E
If lime is now precipitated within the system, it is separated out onto the lime crystals present in
the water (D). As the crystals grow, they do not attach themselves to any surface and are flushed
out of the installation as water is extracted.
There is consequently a significant reduction in limescale deposits on pipes and boiler walls,
heating registers and valves.
An electronic control and monitoring system ensures that the unit functions automatically and
correctly.

Seite 13 von 68 Rev.: 1113803-1
Regular thermal disinfection (TDI) is performed automatically to prevent harm to the unit being
caused by microbiological action. During this process the catalyst cartridge is isolated from the
drinking water supply by means of a valve, while a bypass in the valve ensures that the supply of
drinking water continues unaffected. The water in the stainless steel vessel is heated to 75°C
and left to act for 90 minutes before being flushed out.
JRG Coral force limescale conditioners leave the valuable minerals in the water
and do not cause softening. When water evaporates from tiles, fittings or
shower walls, the minerals are left on the surfaces; over time, residues build up.
You should therefore maintain and clean your bathroom and sanitary facilities
regularly. You can find important advice on the Georg fischer JRG homepage
(
U
www.gfps.com
U
) together with various useful tips and tricks.

Seite 14 von 68 Rev.: 1113803-1
3Control and Monitoring Module
The control and monitoring module is based on an industrial programmable logic controller
(PLC) and offers the following functions:
•Monitoring Functions
oGranulate change interval via operating hours counter
oTime interval for automatic thermal disinfection
oControl valve positions for thermal disinfection and backflushing
oHeating function for thermal disinfection
oTemperature in all operating phases
•Display Elements
oGreen and red lamps
oControl unit display
oAcoustic alarm
o2 potential-free signal contacts for building management system (BMS)
Limescale protection
Pumping system
•Operating hours counter
oDisplays current number of operating hours
oDisplay and alarm when service is required (granulate change every 5
years)
•Operating elements
oKey switch (B)
oAlarm off button (A)
oLOGO! cursor keys
oLOGO! ESC and OK keys
•Control elements
oCharging pump
oPt100 temperature sensor for temperature monitoring

Seite 15 von 68 Rev.: 1113803-1

Seite 16 von 68 Rev.: 1113803-1
The controller is operated via the 4 cursor keys (1), the OK button (2) and the ESC button (3),
which are positioned to the right of the display (4).
Nach dem Einstecken des Netzsteckers erscheint im Display der Steuerung das in der Abbildung
oben zu sehende Menü. (Anzeige bei Betrieb der Steuerung)
Status
OK ... operating without
malfunctions
Error! ... fault occurred or
maintenance/granulate change
required
Bh
Operating hours count since
initial commissioning or last
granulate change
T-ist
Current temperature in the
system.
Tag
Days on which thermal
disinfection takes place.
e.g.: M - - T - - -
Monday, Thursday
(Factory setting: Monday and
Thursday)
Zeit
Start time for thermal
disinfection
(Factory setting: 00:05)
L.TD
Past time since last thermal
desinfection
Anz.
Number of thermal desinfections
T-min
Minimum temperature during TD
T-aus
Maximum temperature during TD
Hyst
Heater control hysteresis (Hz + Hy
… 70+(-5)°C ) i.e. the heater keeps
the temperature between 70-
75°C.

Seite 17 von 68 Rev.: 1113803-1
ANZAHL
TD
Counts the number of thermal
disinfections successfully
completed.
LETZTE TD
Time in hours since the last
thermal disinfection successfully
completed.
Timeout
Pos
The maximum time available for
the ball valve drives to reach their
defined positions
TD-heiz
Maximum heating time for the
temperature to reach TD…78°C
TD-halt
TD temperature holding time
Holding temperature: when
Tcurr>=TD…78°C the holding time
TD-halt begins to run.
When the holding time runs out,
thermal disinfection is
completed. A rinsing cycle now
begins, to flush out the hot
water.
RS
Maximum rinsing time to reach
temperature Tcurr < T-WT-
MAX…35°C
T- MAX-
WT
Maximum cold water
temperature
T-IST
Current temperature within
limescale conditioner
DAUER
DER TD
Duration of the current or last
performed disinfection in
seconds
DAUER
DER RS
Duration of current or last
backflush in seconds
0->I
Number of resets
Letzte
Time since last reset
SOFTWARE
Software version

Seite 18 von 68 Rev.: 1113803-1
4Scope of Delivery and Setting Up
Units are supplied on a euro pallet, ready for installation.

Seite 19 von 68 Rev.: 1113803-1
Item
Component
Description
A
Filter stars
Filter stars in food-safe plastic
B
Isolating non-return valve
Stopcock with integral backflow inhibitor, complies
with EN 1717
C
Catalyst granulate
fine-grained, polymer catalyst granulate
D
Stainless steel vessel and
pipework
PN10 stainless steel vessel with maintenance flange
E
Filter granulate
Floating polypropylene filter granulate
for retention of catalyst granulate
F
Thermal insulation
EPS thermal insulation, thickness 90 mm
G
PT 100
Temperature controller, 50°C–200°C
H
Non-return valve
Backflow inhibitor, complies with EN 1717
I
Main ball valve with drive unit
2-way ball valve to switch between water treatment
and bypass mode (used during thermal disinfection
and backflushing)
J
Bleed valve
Allows air venting
K
Safety valve
10-bar safety valve
L
DN 15 ball valve with drive
2-way ball valve for backflushing
M
Controller
Control and monitoring unit based on Siemens LOGO
logic module
N
Charging pump
Charging pump for heating the vessel during thermal
disinfection
O
Screw-on heater unit
Threaded heater unit with overtemperature
protection, for heating the vessel during thermal
disinfection
P
Drain valve
Fill and drain valve for vessel

Seite 20 von 68 Rev.: 1113803-1
5Technical Data
Hydraulic
Coral force
8000 11000 14000 3.5D 5D
Residential units max. up to VDI
3807-T3
*)
WE 30 68 114 160 230
Short-term peak flow rate, Qs
[l/h]
7.900
10.100
11.800
12.500
13.500
Continuous flow rate
[l/h]
650
1.500
2.500
3.500
5.000
Nominal pressure
PN
10
Operating pressure (min. - max.)
[bar]
2-8
Pressure loss at peak flow
[bar]
0,3
0,17
0,4
0,3
0,3
Ambient temperature
[°C]
40
Water temperature
[°C]
30
Backflush flow rate (pressure-
dependent)
[l/min] 40 bei 6bar
Backflush flow volume
[l]
100
190
260
382
432
Electric
Coral force
8000 11000 14000 3.5D 5D
Power consumption in treatment
mode
[W] 5
TDI power consumption
[W]
2070
4570
4570
6070
6070
Mains supply
400V, 50HZ, 3P+N+PE
Plug type
CEE 16A 400V 3P+N+PE
Max. ambient temperature
°C
40
Protection class
1
Protection type
IP
54
*) The maximum number of residential units (RU) specified in the table refers, under VDI 3807-T3, to an
average occupancy of 2.2 persons per RU and an average water consumption of 100 litres/person/day. While
these statistical average values must be considered during planning and design of limescale protection
systems, in practice significant variations may occur depending on the occupants' usage behaviour and actual
occupancy rates.
In principle the layout of JRG Coral force limescale conditioner systems should
comply with Georg Fischer JRG’s planning recommendations.
The relevant documents and planning information can be found in our planner
documentation.
