Goldmedal 2016 User manual

Part No 53021
Model 2016, 2025,
2025BN, 2025ST
Staging Cabinets
Instruction Manual
Cincinnati, OH 45241-4807 USA

Staging Cabinet
2016, 2025
2
SAFETY PRECAUTIONS
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
DO NOT immerse any part of this equipment in water.
DO NOT use excessive water when cleaning.
Keep cord and plug off the ground and away from moisture.
Always unplug the equipment before cleaning or servicing.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle.
008_051514
DANGER
Improper installation, adjustment, alteration, service, or maintenance can
cause property damage, injury, or death. Any alterations to this equipment
will void the warranty and may cause a dangerous condition. This appliance
is not intended to be operated by means of an external timer or separate
remote-control system. NEVER make alterations to this equipment. Read the
Installation, Operating, and Maintenance Instructions thoroughly before
installing, servicing, or operating this equipment.
014_020416
WARNING
To avoid burns, DO NOT touch heated surfaces.
DO NOT place or leave objects in contact with heated surfaces.
009_092414
WARNING
ALWAYS wear safety glasses when servicing this equipment.
010_010914
WARNING
No user serviceable parts inside. Refer servicing to qualified service
personnel.
011_051514
WARNING
Read and understand operator’s manual and all other safety instructions
before using this equipment. To order copies of the operator’s manual go to
gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive,
Cincinnati, OH 45241 USA 1-(800)-543-0862
022_060215

Staging Cabinet
2016, 2025
3
WARNING
DO NOT allow direct contact of this equipment by the public when used in
food service locations. Only personnel trained and experienced in the
equipment operation may operate this equipment.
Carefully read all instructions before operation.
012_010914
WARNING
This machine is NOT to be operated by minors.
007_010914
Note: Improvements are always being made to Gold Medal’s equipment. This information
may not be the latest available for your purposes. It is critical that you call Gold Medal’s
Technical Service Department at 1-800-543-0862 for any questions about your machine
operations, replacement parts, or any service questions. (Gold Medal Products Co. does not
assume any liability for injury due to careless handling and/or reckless operation of this
equipment.)

Staging Cabinet
2016, 2025
4
Installation Instructions
Inspection of Shipment:
After unpacking, check thoroughly for any damage which may have occurred in transit. Claims should
be filed immediately with the transportation company. The warranty does not cover damage that occurs
in transit, or damage caused by abuse, or consequential damage due to the operation of this machine,
since it is beyond our control (reference warranty in back of manual).
Manual:
Read and understand the operator’s manual and all other safety instructions before using this
equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal
Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862.
Setup:
Your new Popcorn Warmer is completely assembled and tested at the factory.
Remove all packing material and tape before starting operation.
Electrical Requirements:
The following power supply must be provided:
2025 Series: 120 V~, 800 W, 60 Hz
2016: 120 V~, 680 W, 60 Hz
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
DO NOT immerse any part of this equipment in water.
DO NOT use excessive water when cleaning.
Keep cord and plug off the ground and away from moisture.
Always unplug the equipment before cleaning or servicing.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle.
008_051514
A certified electrician must furnish sufficient power for proper machine operation and install any supplied
receptacle. We recommend this equipment be on a dedicated and protected circuit. Failure to wire properly
will void the warranty and may result in damage to the machine. It is Gold Medal Products Co.’s
recommendation that this machine be plugged directly into a wall outlet. The use of extension cords is not
recommended due to safety concerns, and may cause sacrificed and/or reduced performance. Make sure
cord is located to prevent a trip hazard or unit upset.

Staging Cabinet
2016, 2025
5
Before You Plug In Machine
1. Make sure all machine switches are OFF before plugging equipment into receptacle.
2. Make sure wall outlet can accept the grounded plugs (where applicable) on the power supply
cord.
3. The wall outlet must have the proper polarity. If in doubt, have a competent electrician inspect
the outlet and correct if necessary.
4. DO NOT use a grounded to un-grounded receptacle adapter (where applicable).
5. Install unit in a level position.
CAUTION
If the supply cord is damaged, it must be replaced by Gold Medal Products Co.,
its service agent or similarly qualified persons in order to avoid a hazard.
039_080614

Staging Cabinet
2016, 2025
6
Operating Instructions – Controls and Their Functions
Warmer Toggle Switch:
This switch operates the warmer blower/warmer element assembly inside the machine to
warm your popcorn as well as the warming lamps and dome light (if equipped). Controls
warming temperature up to 190°F (87.7°C). The ON position turns the warmer and dome
light on.
*Caution – Maximum heat lamp wattage is 125 Watts.
Care and Cleaning
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
DO NOT immerse in water.
Always unplug the equipment before cleaning or servicing.
025_020314
WARNING
To avoid burns, DO NOT touch heated surfaces.
DO NOT place or leave objects in contact with heated surfaces.
009_092414
Good sanitation practice demands that all food preparation equipment be cleaned regularly (only use non-
toxic, food grade cleaners). A clean looking, well-kept machine is one of the best ways of advertising your
product.
Follow the directions below to clean and sanitize unit each day after use.
1. Turn machine OFF, unplug unit and allow it to cool before attempting to clean.
2. Clean all pans/accessories in order to sanitize them before each use.
3. Wipe stainless steel parts with a clean cloth and cleaner designed for stainless steel, such as
Gold Medal Watchdog Stainless Cleaner (Item No. 2088).
DO NOT use oven cleaners or abrasive materials as they will damage parts of machine.
4. Clean glass panels with glass cleaner. Gold Medal Watchdog Glass Cleaner (Item No. 2588) is
recommended.
Ammonia cleaners will damage plastic doors/panels. Use only non-ammonia cleaners, such as
Gold Medal Watchdog Glass Cleaner (Item No. 2588).

Staging Cabinet
2016, 2025
7
MAINTENANCE INSTRUCTIONS
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
DO NOT immerse any part of this equipment in water.
DO NOT use excessive water when cleaning.
Keep cord and plug off the ground and away from moisture.
Always unplug the equipment before cleaning or servicing.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle.
008_051514
DANGER
Improper installation, adjustment, alteration, service, or maintenance can
cause property damage, injury, or death. Any alterations to this equipment
will void the warranty and may cause a dangerous condition. This appliance
is not intended to be operated by means of an external timer or separate
remote-control system. NEVER make alterations to this equipment. Read the
Installation, Operating, and Maintenance Instructions thoroughly before
installing, servicing, or operating this equipment.
014_020416
WARNING
No user serviceable parts inside. Refer servicing to qualified service
personnel.
011_051514
CAUTION
THE FOLLOWING SECTIONS OF THIS MANUAL ARE INTENDED ONLY
FOR QUALIFIED SERVICE PERSONNEL WHO ARE FAMILIAR WITH
ELECTRICAL EQUIPMENT. THESE ARE NOT INTENDED FOR THE
OPERATOR.
027_010914

Staging Cabinet
2016, 2025
8
ORDERING SPARE PARTS
1. Identify the needed part by checking it against the photos, illustrations, and/or parts list.
2. When ordering, please include part number, part name, and quantity needed.
3. Please include your model name, serial number, and date of manufacture (located on the machine
nameplate) with your order.
4. Address all parts orders to:
Parts Department
Gold Medal Products Co.
10700 Medallion Drive
Cincinnati, Ohio 45241-4807
Or, place orders by phone or online:
[phone]
[phone]
Fax: [phone]
E-mail: [e-mail]:
Web Page: www.gmpopcorn.com

Staging Cabinet
2016, 2025
9
Cabinet Breakdown
Glide (4)
p/n 47328
Lead
-
In Cord
p/n 22038
Old Maid Pan
p/n 47336
Drop Panel
p/n 54015
Door
p/n 77058
(Knob
–
p/n 41013)
Lamp Holder
p/n 47047
60W
Flood Short Coated
P/N
41979S
(125 Watt Heat Lamp p/n 47161)
Dome
(2016 Pictured)
(2025) p/n 77001
(2025ST) p/n 41811
(2025BN) p/n
45006
(2016) p/n 77001
Toggle Switch
p/n 47218
Glass
:
Front
p/n 47133
Side (2)
p/n 47134
See Lighted Dome
on next page.
Conical Light Shield (2)
p/n 53077
LED Sign (2025BN)
p/n 45003

Staging Cabinet
2016, 2025
10
Lighted Sign Assembly – Molded Dome
Item Part Description Part Number
1
5/16
-
18 X 5/8 PH TR (fastens dome)
46638
2
5/16 FLAT WASH R (fastens dome)
74134
3
DOM SPAC R
54014
4
20” X 28” MOLD D DOM
77001
5
L D LIGHT ASS MBLY
77040
6
L D MOUNTING
55475
7
8
-
32 X 3/8 PH PAN (fastens L D strip)
55379
8
8
-
32 H X NUT (fastens L D Strip)
42227
9
L D STRIP COOL WHIT
55379
10
.500 IN SNAP BUSHING
47236
1
1
1/4
-
20 X 1/2 H X HD (fastens L D mount.)
14821
1
2
F ND R WASH R (fastens L D mount.)
82101
1
3
1/4
-
20 S RRAT D NUT (fastens L D mount.)
46311
1
4
MOLD D PLUG
47726
1
5
24VDC 20W POW R SUPPLY
55394
1
6
6
-
32 X 3/8 PHIL PAN
(fastens power supply)
39000
1
7
6
-
32 NUT (fastens power supply)
14221
LED Light Assembly
–
Front View
4
1 , 17
15
14
11, 12
13
LED Light Assembly – Rear View
9
7, 8
5
Complete
LED
Light Assembly
10
2
1
3
1
2003
