Great Little Trading Alba Regular L4470 User manual

1
Alba Regular - Tall Open Base Unit & Top Shelf
L4470
easy - medium - hard
Assembly Difculty
one-person job
A few important pointers before you start:
• Please read the instructions right through before you start, and check
that all the components have been included in the pack; we nd
separating all the hardware into piles makes it easier to be sure that
everything is present and correct.
• Make sure you have the right tools.Allen keys are provided if required,
but screw drivers and other tools are not. You’ll nd details of the tools
you need at the beginning of the instructions.
• Do not throw away any packing materials until assembly is complete,
just in case you accidentally discard smaller parts or hardware.
Thank you for shopping with GLTC, we hope you enjoy
having this product in your home.
We know assembling furniture, toys or accessories is not everyone’s
favourite way to spend their time, so we’ve tried to make assembling
this item as quick and painless as possible.
Hopefully our efforts will have been worthwhile and you’ll sail
through the whole process. But if it all feels a bit too much
like hard work, then we do have an assembly company we
can recommend: the Flatpack Construction Company offers a
nationwide service and can be contacted on 0843 289 4951 or
www.atpackconstruction.co.uk.
06/06/2019
V1

2
Safety Warnings:
• Please read these instructions carefully before assembly.
• Warning! Not suitable for children under 3 years due to small parts
which may become detached and present a choking hazard.
• Assembly by a competent adult is required.
• Unassembled product contain small parts which may pose a choking
hazard to young children.
• During assembly children should be kept away from the product due
to possible risk of injury.
• Assemble and use on a at and level surface.
• This product is heavy, we recommend that you build it where you are
planning to use it.
• This unit can only be used in conjunction with other Alba Regular
units. All stacked Alba furniture must start with a GLTC Alba base unit.
• It is recommended that the Alba range is only stacked 3 units high i.e.
1x toy box base + top shelf & 2x middle units OR 1x tall base unit &
1x middle unit.
• DO NOT use power tools in the assembly of this product as there is a
risk of over tightening and consequently splitting of the wood
• Do not over tighten hardware. Cam dowels should be inserted to
the collar. Back panel screws should be screwed until they naturally
tighten/stop. This is difcult to feel if power tools are being used.
• Do not use if any parts are missing or damaged as this may lead to
products being unstable.
• WARNING! FURNITURE TIPPING RISK. Serious or fatal crushing
injuries can occur from furniture tipping over. Ensure you secure this
furniture product to the wall before you use it, using the kit provided.
If you have not received an anti-tip kit with your product please
contact Customer Services.
• To avoid possible injury from tipping - DO NOT allow children to step
or climb on the product.
• Check all xtures and ttings regularly and tighten as necessary.
• Remove all packaging before allowing your child to use the product.
• Please retain for future reference.
Customer Service:
• If you nd that any components are missing or damaged, please do
not begin assembly and do not use the item. Please contact GLTC
Customer Services on 0344 848 6000 immediately.
• We do stock spare hardware packs at our warehouse, so we should be
able to send you a replacement pack immediately if required.
Product Care:
• Wipe clean using a soft damp cloth followed by a dry cloth.
• Do NOT use cleaning products which contain ammonia, solvents or
abrasive material.
• Do NOT expose the item to extremes of heat and humidity.
• Regularly check all fastenings, xtures and ttings to ensure that they
properly tightened.
Could we do better?
If there is anything you think could be improved in these instructions or in
the assembly of this product we’d be grateful if you could let us know; we’ll
pass any helpful hints and tips on to other customers via our website and
update the instructions.
All you need to do is drop us a line at [e-mail]
Thank you

3
A B
C D
E F
I
L
M
Component Check List Component Check List
#1 #2
#3 #4
G H
You will need
(not supplied)
Philips Head Screwdriver
#5
21x Cam Dowels
35mmL
28x Wooden Dowels
25mmL
21x Cam Locks 18x Domed Head Screws
14mmL
K
J
1x Top Shelf - Base 1x Top Shelf - Back Upstand
1x Top Shelf - LH Side Panel 1x Top Shelf - RH Side Panel
1x Top Panel 1x Vertical Divider
1x Mid Shelf Panel 1x Front Panel
1x Base Panel 1x RH Side Panel
1x LH Side Panel 1x Upper Back Panel
1x Lower Back Panel
1x Anti-Tip Kit

4
STEP 2:
Using a Phillips screwdriver, prepare the top shelf side panels by inserting 3x
cam dowels (#1) into the smaller holes of BOTH panels D & C.
Hardware for Step 2:
Hardware for Step 1:
STEP 1:
Build the Top Shelf rst.
Take panel A and position with the large drill holes on the oor. Insert 1x cam
dowel (#1) in the central hole shown using a Phillips screwdriver and push 2x
wooden dowels (#2) in the remaining holes.
Take panel B and push onto the dowels, making sure the large drill holes are
facing outwards. (this will ensure they are not seen once the unit is nished.)
Insert 1x cam lock (#3) into the central hole of Panel B and turn clockwise to
secure.
2x #2 Wooden Dowels
A
B
#2
#2
#1
#3
#1
#2
#3
1x #1 Cam Dowel
1x #3 Cam Lock
DC
#1
#1 #1
#1 #1
#1 #1
6x #1 Cam Dowels
IMPORTANT: Make sure that the
small drill holes on the edge of
panel A are next to the connection
to panel B - they will be needed at
a later step.
Using Cam Locks:
When inserting into the panel, ensure that each cam lock’s
arrow is pointing towards the drill hole on the side edge
of the panel & the dowel that it will be receiving.
When the panels are in the connected position, using a
screwdriver, turn the cam lock in a clockwise direction to
lock and secure.

5
STEP 4:
The top shelf is now ready for use.
STEP 3:
Insert 2x wooden dowels (#2) into the innermost holes on BOTH edges of
panel A. These will insert into the larger holes on panels C& D.
Attach the side panels and secure using 3x cam locks (#3) on BOTH sides.
NOTE: The shaped side of the side panels
to be facing up as shown.
C
D
A
B
#3
#3
#3
#3
#3
#3
#2
#2
#2
#2
#3
#2
Hardware for Step 3:
4x #2 Wooden Dowels
6x #3 Cam Locks
Using Cam Locks:
When inserting into the panel, ensure that each cam lock’s
arrow is pointing towards the drill hole on the side edge
of the panel & the dowel that it will be receiving.
When the panels are in the connected position, using a
screwdriver, turn the cam lock in a clockwise direction to
lock and secure.

6
STEP 5:
Please note, you are building this unit BACK down.
Take top panel E and position with the grooved edge on the oor and the
large drill holes towards panel F that you will join it to.
Insert 2x wooden dowels (#2) into the central holes and connect with panel F.
Insert 2x wooden dowels into the remaining edge of panel F and connect with
panel G.
Hardware for Step 5:
4x #2 Wooden Dowels
Hardware for Step 6:
2x #2 Wooden Dowels
STEP 6:
Take base panel I and insert 2x wooden dowels (#2) into the holes along the
top edge.
Join panel H to panel I using the wooden dowels.
Note: Large drill holes of panel H should be facing inwards (so they will not
be seen in the nished unit)
#2
#2
#2
#2
#2
E
F
G
#2
#2
#2
I
H
Note the positions of the panels.
Groove of panel E is on the oor and
the large drill holes of the large panels
are facing in the same direction - down
towards the base.
BACK
BASE
TOP
BACK
Note: Grooved edge on the oor

7
STEP 7:
Prepare the side panels J & K by inserting 7x cam dowels (#1) into the smaller
holes on EACH panel
STEP 8:
Insert 8x wooden dowels (#2) into the the remaining holes on panel J.
Attach side panel J to the parts already constructed. Note the positioning of
panel J - long edge with the groove on the oor.
First push the E/F/G panels onto side panel J. Insert 4x cam locks (#3) into
panels E & G and turn clockwise to secure. This will make the unit more stable.
Now join the H/I panels to side panel J and insert 3x cam locks to panels H & I.
Turn clockwise to secure. Don’t forget the cam lock on the inside on panel H.
#1
#1
#1
#1
#1
#1
#1
#1
#1 #1
#1
#1
#1 #1
#1
Hardware for Step 7:
14x #1 Cam Dowels
#3
x2
#2
#3
E
F
G
H
I
J
#2
Hardware for Step 8:
7x #3 Cam Locks
8x #2 Wooden Dowels
J
K
#2
#2
#2
#2
#2
#3
#2
#3
#3
#3
#3
#3

8
STEP 9:
Insert 8x wooden dowels (#2) into the remaining holes on panel K.
Attach the remaining side panel K to the unit. Note the positioning of panel
K - long edge with the groove on the oor.
Push into position on the unit as shown.
Insert 7x cam locks (#3) into the remaining drill holes on panels E, G, H & I
and turn clockwise to secure - again not forgetting the one inside the unit on
panel H.
STEP 10:
With the help of a second person, carefully turn the unit over onto its front
OR side.
Line up the back panels L & M with the pilot holes in the grooved edges and
x in place with 18x domed head screws (#4).
Please note the positioning of the panels, the larger panel M is to be in the
lower position.
Hardware for Step 10:
18x #4 Domed Head Screws
#3
#3
#3
#3
#3
#3
#2
#2
#2
#2
#2
x3
#3
#2
K
#2
#3
Hardware for Step 9:
7x #3 Cam Locks
8x #2 Wooden Dowels
#4
#4
#4
#4 #4
#4
#4
#4
#4
#4
#4
#4
#4
#4
#4
#4 #4
#4
#4
L
M

9Copyright© 2019 G.L.T.C. Ltd.All rights reserved.
Great Little Trading Company and GLTC are registered trade marks of G.L.T.C. Limited.
STEP 11:
Your Alba Tall Base Unit and Top Shelf are now fully built and ready to use with
an Alba REGULAR Shelf unit of your choice.
Before you use your units, we strongly advise that you attach the anti-tip kit
(included) to the top shelf to secure this product to the wall.
Please use the pilot holes on the back edge of the top shelf (highlighted) to
attach the anti-tip brackets using the hardware included with the kit.
Please refer to the instructions in the kit provided for further guidance.
Hardware for Step 11:
1x #5 Anti-Tip Kit
#5
#5
#5
