Guardian ATOM-X RETRACTABLE TYPE FALL ARRESTER User manual

ATOM-X
RETRACTABLE TYPE
FALL ARRESTER
Parts # ; ; ; ; ; ;
; ; D; ; ;
; ; ; 
Instruction Manual
Do not throw instructions away.
Read and understand instructions before
using this equipment.
C
18 Brugsanvisning Dansk
25 Gebrauchsanleitung Deutsch
32 Manuel d’instructions Français
39 Manuale di istruzioni Italiano
46 Bruksanvisning Svenska

2
English
EU Declaration of Conformity
The manufacturer:
Checkmate Lifting & Safety Ltd. t/a Guardian Fall
New Road, Sheerness,
Kent, ME12 1PZ,
United Kingdom
declares under its sole responsibility that the range of PPE described hereafter:
ATOM-X
Retractable Type Fall Arrester
10210, 10211, 10212, 10213, 10214, 10215
and is subject to the conformity assessment procedure to type (Module D) of the Regulation under
surveillance of Notified Body:
SGS Fimko Oy (0598)
Takomotie 8,
Fl-00380, Helsinki
Finland
Signed for and on behalf of: Checkmate Lifting & Safety Limited.
Name: Peter Upcott Place: Sheerness, Kent
Position: Interim Compliance Manager Date: 8 March 2022
Signature:
is in conformity with the provisions of Regulation (EU) 2016/425 and with the European harmonised
standard(s) EN 360:2002 and is identical to the PPE which is the subject of EU Type Examination
(Module B) under certificate number 0598/PPE/22/2486:
Issued by:
SGS Fimko Oy (0598)
Takomotie 8,
Fl-00380, Helsinki
Finland

3
UK Declaration of Conformity
The manufacturer:
Checkmate Lifting & Safety Ltd. t/a Guardian Fall
New Road, Sheerness,
Kent, ME12 1PZ,
United Kingdom
declares under its sole responsibility that the range of PPE described hereafter:
ATOM-X
Retractable Type Fall Arrester
10210, 10211, 10212, 10213, 10214, 10215
and is subject to the conformity assessment procedure to type (Module D) of the Regulation under
surveillance of Notified Body:
SGS United Kingdom Limited (0120)
Rossmore Business Park
Ellesmere Port,
South Wirral,
Cheshire, CH65 3EN
United Kingdom
Signed for and on behalf of: Checkmate Lifting & Safety Limited.
Name: Peter Upcott Place: Sheerness, Kent
Position: Interim Compliance Manager Date: 9 March 2022
Signature:
is in conformity with the provisions of Regulation 2016/425 on personal protective equipment as
brought into UK law as amended and with the UK designated standard(s) EN360:2002 is identical
to the PPE which is the subject of EU Type Examination (Module B) under certificate number 0120/
PPE/220210:
Issued by:
SGS United Kingdom Limited (0120)
Rossmore Business Park
Ellesmere Port,
South Wirral,
Cheshire, CH65 3EN
United Kingdom
English

4
EU Declaration of Conformity
The manufacturer:
Checkmate Lifting & Safety Ltd. t/a Guardian Fall
New Road, Sheerness,
Kent, ME12 1PZ,
United Kingdom
declares under its sole responsibility that the range of PPE described hereafter:
ATOM-XTREME
Retractable Type Fall Arrester
10216, 10217, 10218, 10219
and is subject to the conformity assessment procedure to type (Module D) of the Regulation under
surveillance of Notified Body:
SGS Fimko Oy (0598)
Takomotie 8,
Fl-00380, Helsinki
Finland
Signed for and on behalf of: Checkmate Lifting & Safety Limited.
Name: Peter Upcott Place: Sheerness, Kent
Position: Interim Compliance Manager Date: 8 March 2022
Signature:
is in conformity with the provisions of Regulation (EU) 2016/425 and with the European harmonised
standard(s) EN 360:2002 and is identical to the PPE which is the subject of EU Type Examination
(Module B) under certificate number 0598/PPE/22/2486:
Issued by:
SGS Fimko Oy (0598)
Takomotie 8,
Fl-00380, Helsinki
Finland
English

5
UK Declaration of Conformity
The manufacturer:
Checkmate Lifting & Safety Ltd. t/a Guardian Fall
New Road, Sheerness,
Kent, ME12 1PZ,
United Kingdom
declares under its sole responsibility that the range of PPE described hereafter:
ATOM-XTREME
Retractable Type Fall Arrester
10216, 10217, 10218, 10219
and is subject to the conformity assessment procedure to type (Module D) of the Regulation under
surveillance of Notified Body:
SGS United Kingdom Limited (0120)
Rossmore Business Park
Ellesmere Port,
South Wirral,
Cheshire, CH65 3EN
United Kingdom
Signed for and on behalf of: Checkmate Lifting & Safety Limited.
Name: Peter Upcott Place: Sheerness, Kent
Position: Interim Compliance Manager Date: 9 March 2022
Signature:
is in conformity with the provisions of Regulation 2016/425 on personal protective equipment as
brought into UK law as amended and with the UK designated standard(s) EN360:2002 is identical
to the PPE which is the subject of EU Type Examination (Module B) under certificate number 0120/
PPE/220210:
Issued by:
SGS United Kingdom Limited (0120)
Rossmore Business Park
Ellesmere Port,
South Wirral,
Cheshire, CH65 3EN
United Kingdom

6
EU Declaration of Conformity
The manufacturer:
Checkmate Lifting & Safety Ltd. t/a Guardian Fall
New Road, Sheerness,
Kent, ME12 1PZ,
United Kingdom
declares under its sole responsibility that the range of PPE described hereafter:
ATOM-X²
Retractable Type Fall Arrester
10220, 10221, 10222, 10223
and is subject to the conformity assessment procedure to type (Module D) of the Regulation under
surveillance of Notified Body:
SGS Fimko Oy (0598),
Takomotie 8,
Fl-00380, Helsinki
Finland
Signed for and on behalf of: Checkmate Lifting & Safety Limited.
Name: Peter Upcott Place: Sheerness, Kent
Position: Interim Compliance Manager Date: 8 March 2022
Signature:
is in conformity with the provisions of Regulation (EU) 2016/425 and with the European harmonised
standard(s) EN 360:2002 and is identical to the PPE which is the subject of EU Type Examination
(Module B) under certificate number 0598/PPE/22/2486:
Issued by:
SGS Fimko Oy (0598),
Takomotie 8,
Fl-00380, Helsinki
Finland

7
UK Declaration of Conformity
The manufacturer:
Checkmate Lifting & Safety Ltd. t/a Guardian Fall
New Road, Sheerness,
Kent, ME12 1PZ,
United Kingdom
declares under its sole responsibility that the range of PPE described hereafter:
ATOM-X²
Retractable Type Fall Arrester
10220, 10221, 10222, 10223
and is subject to the conformity assessment procedure to type (Module D) of the Regulation under
surveillance of Notified Body:
SGS United Kingdom Limited (0120)
Rossmore Business Park
Ellesmere Port,
South Wirral,
Cheshire, CH65 3EN
United Kingdom
Signed for and on behalf of: Checkmate Lifting & Safety Limited.
Name: Peter Upcott Place: Sheerness, Kent
Position: Interim Compliance Manager Date: 9 March 2022
Signature:
is in conformity with the provisions of Regulation 2016/425 on personal protective equipment as
brought into UK law as amended and with the UK designated standard(s) EN360:2002 is identical
to the PPE which is the subject of EU Type Examination (Module B) under certificate number 0120/
PPE/220210:
Issued by:
SGS United Kingdom Limited (0120)
Rossmore Business Park
Ellesmere Port,
South Wirral,
Cheshire, CH65 3EN
United Kingdom

8
English
Competent Person Definition
The job site safety supervisor, referred to in this manual as
the Competent Person (CP), must be a highly trained and
experienced person who is assigned by the employer to
be responsible for all elements of the fall safety program;
this includes, but is not limited to, program regulation,
management, and application. The CP must be proficient
in identifying existing and predictable fall hazards, and
must have the authority to stop work to eliminate hazards or
otherwise promote safe and compliant work practices.
Product Specific Applications
ATOM-X & ATOM-XTREME
May be used to support a MAXIMUM 1 in
a Personal Fall Arrest System (PFAS) for
use in Fall Arrest applications and will
reduce fall arrest forces to no greater than 6kN.
No free fall is permitted.
D-ring: Dorsal (rear), Sternal (chest)
ATOM-X²
May be used to support a MAXIMUM 1 in
a Personal Fall Arrest System (PFAS) for
use in Fall Arrest applications and will
reduce fall arrest forces to no greater than 6kN.
Applicable Safety Standards
Meets or exceeds:
EN360:2002
For All Product Applications
ATOM-X & ATOM-XTREME
Maximum User weight (including all
clothing, tools, and equipment) is 150kg.
ATOM-X²
Maximum User weight (including all
clothing, tools, and equipment) is 136kg.
(FF0-FF2*)
*See Diagram A on page 17
Anchorage point in PFAS must be rated to
withstand minimum 12kN load and be
EN 795:2012 or 1997+A1:2000 approved.
The job site Competent Person (CP) must
ensure that there are sufficiently strong and
accessible anchorage points in the working
environment. Anchorages should be overhead
when possible and the area beneath and around
them should be clear of obstruction and sharp
edges. Always attach to an anchorage that
is as close to the point of work and as high
above head as possible without restricting free
movement. The user should be aware at all
times of which attachment points to use; if not
immediate obvious they must seek confirmation
from the CP. Always ensure that the means of
attachment to the anchorage is secure before
beginning work.

9
Materials
PC/ABS, aluminium alloy, carbon
steel, nylon, PTFE and webbing
made with HMPE.
ATOM-X2
ATOM-X
Specifications and Materials
English
ATOM-XTREME
ATOM-XTREME
TIE-BACK
Maximum Arresting Force
6 kN

10
English
Part # Length Description
10210 1.8m ATOM-X Web RTFA with Aluminium Snap Hook
10211 1.8m ATOM-X Web RTFA with Aluminium Scaold Hook
10212 1.8m ATOM-X Web RTFA with Aluminium Snap Hook
10213 1.8m ATOM-X Web RTFA with Aluminium Scaold Hook
10214 1.8m Dual ATOM-X Web RTFA with Aluminium Snap Hook
10215 1.8m Dual ATOM-X Web RTFA with Aluminium Scaold Hook
10216 1.8m ATOM XTREME Web RTFA with Aluminium Snap Hook
10217 1.8m ATOM XTREME Web RTFA with Aluminium Scaold Hook
10217-D 1.8m Dual ATOM XTREME Web RTFA with Aluminium Scaold Hook
10218 1.8m ATOM XTREME Tie-Back Web RTFA with Steel Tie-Back Hook
10219 1.8m ATOM XTREME Tie-Back Dual Web RTFA with Steel Tie-Back Hook
10220 1.8m ATOM-X² Web RTFA with Aluminium Snap Hook
10221 1.8m ATOM-X² Web RTFA with Aluminium Scaold Hook
10222 1.8m Dual ATOM-X² Web RTFA with Aluminium Snap Hook
10223 1.8m Dual ATOM-X² Web RTFA with Aluminium Scaold Hook
