Haverland New XR Designer Manual

5
Instructions for installation
4 screws
Screw both
brackets rmly
into position
3
7
To ax the radiator rmly to the brackets:- screw COMPLETELY the 6 x 50mm screws in the upper part
of the brackets (Diagram 6).
Make sure that the radiator is rmly xed to the wall to avoid future risk, before connecting the plug into
a nearby power supply socket.
The two 6 x 50mm screws
supplied should be fully
screwed down to lock the
radiator onto the brackets.
Check that the radiator
is securely xed to the wall
to avoid any risk.
6
Place radiator
over lower
tang of the
bracket
4
5
Place over top
tang and lower
gently into
position
