Hearth & Home Technologies • LPK-OH Conversion Kit • 4095-905 Rev. B • 5/18
LPK-OH - LEGACY/PHOENIX NG to PROPANE
Gas Conversion Kit
Models:
LEGACY42-IFT
PHOENIX42-IFT
Installation
Instructions
Note: An arrow () found in the text signies change in
content.
Note: The LPK-OH kit is for a one time conversion only.
Discard unused parts.
Note: For gas models not listed, refer to the model’s installation instructions for proper conversion kit or contact your Hearth
& Home Technologies dealer. For the dealer nearest you, please visit www.heatilator.com.
1 Components
Table 1.1
Description
Dexen Valve Regulator Replacement Kit. Includes gas
regulator, conversion label and instructions
Main Burner Orice (Propane)
Pilot orice (.014 for Propane)
Installation instructions
Installer conversion label
WARNING:
This conversion kit shall be installed by a qualied service
agency in accordance with the manufacturer’s instructions
and all applicable code and requirements of the authority
having jurisdiction. If the information in these instructions
is not followed exactly, a re, explosion or production of
carbon monoxide may result causing property damage,
personal injury or loss of life. The qualied service agency
is responsible for the proper installation of this kit. The
installation is not proper and complete until the operation
of the converted appliance is checked as specied in the
manufacturer’s instructions supplied with the kit.
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during installa-
tion. Sheet metal edges are sharp.
LPK-OH

Hearth & Home Technologies • LPK-OH Conversion Kit • 4095-905 Rev. B • 5/18
2
Table 2.1
2 Orice Sizes for Conversions
A. Conversion - Orices
Required Tools
7/16 in. Open End Wrench
(2) 3/4 in. Open End Wrench
Safety Glasses
Manometer
#20 Tamper Proof Torx
Small Cabinet Screwdriver
Non-corrosive Leak-Check Solution
A. Turn off the Gas and Electrical Power
• To turn off the gas, locate the manual shutoff valve in
the control area in the bottom of the appliance. Turn the
manual shutoff valve so it is perpendicular to the gas line
(Figure 3.1).
• Shut off all electrical power to the appliance by turning
off the appropriate circuit breaker or removing the fuse
in the electrical panel.
OFF
Figure 3.1 Manual Shutoff Valve
3 Preparation
LPK-OH
(CONVERT TO PROPANE)
Threaded
Orice Size Model
.098 LEGACY42-IFT PHOENIX42-IFT
Note: Care must be taken when working on appliance to
avoid damage to logs, burner and hearth pieces.
• Remove the logs and grate, set aside.
• Remove (3) Front Hearth Refractory pieces. See
Figure 3.2.
Figure 3.2
B. Access the Control Area
Front Hearth Refractory
Grate Assembly

3
Hearth & Home Technologies • LPK-OH Conversion Kit • 4095-905 Rev. B • 5/18
Figure 3.3
• Remove (2) Side Hearth Refractory pieces. See
Figure 3.3.
• Remove left and right Side Hearth Refractory Brackets,
(3) screws each. See Figure 3.4.
• Remove (4) screws, (2) per side, securing Burner
Assembly to the base of the appliance. See Figure 3.5.
Figure 3.4
Side Hearth Refractories
Hearth Refractory Bracket
Figure 3.5
• Disconnect incoming exible gas line from gas valve.
• Remove orange and green wires from the valve.
• Slide Burner Assembly towards the front of the
appliance and stand upright. Make certain Burner
Assembly is stable and will not fall over.
Caution: Use care not to damage Burner Top or Refractory
when standing Burner Assembly upright.
• When Burner Assembly is standing upright, access to
components for conversion is possible. See Figure 3.6.
Valve
Orice
Pilot
Figure 3.6
• Go to Section 4 - Converting the Appliance.

Hearth & Home Technologies • LPK-OH Conversion Kit • 4095-905 Rev. B • 5/18
4
Note: Save the label that came with the Dexen
conversion kit for later placement.
The LEGACY42-IFT/PHOENIX42-IFT come equipped
with a Dexen PIP valve.(Figure 4.1) use only the Dexen
Valve Regulator Replacement Kit or Replacement Valve.
Figure 4.1 Dexen Intermittent Pilot Valve
4 Converting the Appliance
Note: Remove all components blocking your access
and set aside.
Follow the regulator replacement instructions that came
with the regulator replacement kit. After completion of
the regulator replacement instructions, return to these in-
structions.

5
Hearth & Home Technologies • LPK-OH Conversion Kit • 4095-905 Rev. B • 5/18
5 Replace the Pilot and Burner Orice
Fire Risk
• Orices must be replaced
Failure to replace the orices could result in
overheating the gas appliance and possibly
damaging your appliance and your home.
WARNING
A. Replace Pilot Orice
• Loosen the nut at the base of the pilot hood with a
7/16 in. wrench. See Figures 5.1 & 5.2.
• Turn the nut until it comes free of the pilot.
• Discard the pilot orice and replace it with the new
Propane pilot orice. Handle carefully. Do not drop.
• Tighten the nut with a 7/16 in. wrench. Tighten until
snug.
Figure 5.1 Pilot Location
PILOT
ORIFICE
PILOT TUBE
ASSEMBLY CHECK FOR
LEAKS
PILOT HOOD
(Used in assembly
with 2-sided hood).
Note: Appearance of
pilot may vary.
Figure 5.2
Pilot

Hearth & Home Technologies • LPK-OH Conversion Kit • 4095-905 Rev. B • 5/18
6
Burner Orices - Novus NDV & NBV
• Using (2) 3/4 in. wrenches, disconnect exible gas line
from threaded orice. See Figure 5.3.
• Using 3/4 in. wrench remove NG orice from burner
neck and discard orice. See Figure 5.3.
• Replace the existing orifice with the appropriate
propane orice and tighten.
• Remove the NG air shutter. When converting from
NG to propane, the air shutter must be removed. See
Figure 5.4.
• Reconnect the exible gas line to the new propane
threaded orice and tighten.
• All connections must be tightened and checked for
leaks with a commercially available, non-corrosive
leak check solution. Be sure to rinse off the solution
when done leak testing.
Figure 5.3 Burner Orice
Figure 5.4 Air Shutter (Before & After)
Note: Test ttings for leaks with the pilot lit and the burner off.
B. Replace Burner Orice(s)
Flexible Gas LIne
Burner Neck
Orifice
Natural Gas Propane

7
Hearth & Home Technologies • LPK-OH Conversion Kit • 4095-905 Rev. B • 5/18
6 Adjust the Air Shutter
• The LEGACY IFT/PHOENIX42-IFT require the air
shutter be removed when the appliance is converted
to burn propane. No futher air shutter adjustments
need to be made.

Hearth & Home Technologies • LPK-OH Conversion Kit • 4095-905 Rev. B • 5/18
8
7. Checking Your Conversion
A. Leak Test
Fire Risk
Explosion Risk
WARNING
• All connections must be checked and
leaks must eliminated.
Incomplete gas line connections could
cause a gas leak.
1. Loosen the Tap marked "OUT" with
a small Screwdriver.
Manometer
2. Attach manometer hose.
Dexen Valve
3. Light main burner
and check pressure.
Figure 7.1 Intermittent Pilot Manometer Adjustment
Inlet Gas Pressure
Verify the inlet gas supply pressure by connecting a ma-
nometer to the inlet side of the valve. If the inlet gas pres-
sure is incorrect, do not adjust without specic approv-
al and instruction from the gas supplier. Changing inlet
pressure may effect other appliances in the residence.
Manifold Gas Pressure
To measure the manifold pressure, loosen the manifold
pressure tap with a small athead screwdriver, and con-
nect a manometer to the 1/8 in. manifold pressure tap on
the side of the valve. See Figure 7.1. Ignite the appliance
and ensure the pressure is between 3.2 - 3.7 in. for NG
and 9.5 - 10.5 in. for Propane water column.
Shut off Appliance
Remove the manometer and tighten the manifold pres-
sure tap.
B. Checking the Pressure
Fire Risk!
Explosion Risk!
Asphyxiation Risk!
WARNING
• High pressure will damage valve. Low pressure
could cause explosion.
• Check all ttings and connections with a non-
corrosive commercially available leak-check
solution. DO NOT use open ame.
Turn on the gas and electricity.
Gas Leak Test
•All connections must be tightened and checked for leaks
with a commercially available, non-corrosive leak check
solution. Be sure to rinse off the solution when done leak
testing.
• If the solution indicates there is a leak, tighten and seal
the connection and then retest.
Leak Test Dexen Intermittent Pilot Ignition
Models
Turn on the appliance and test for leaks at the valve and
the burner orice using the method above.

9
Hearth & Home Technologies • LPK-OH Conversion Kit • 4095-905 Rev. B • 5/18
THIS CONTROL
HAS BEEN
CONVERTED
TO PROPANE
Figure 8.2 Dexen Conversion Label Placement
Figure 8.3 Dexen Conversion Label
Figure 8.1 Conversion Label
All labels must be lled out and/or installed by the individual
completing the conversion. This must be nished or the con-
version is not complete. See Figures 8.1-8.3.
•Fill out the installer conversion label (Figure 8.1). After lling
out the label, clean an area near the existing rating label
and attach.
• Attach the valve manufacturer conversion labels as
indicated in Figures 8.2 and 8.3
• Locate the lighting instruction card and attach the red
Propane or blue NG label (included with this conversion
kit) over the existing blue or red label.
8 Attaching Labels
Place
conversion
label here
THIS CONTROL
HAS BEEN
CONVERTED
TO NG
LPK-OH
THIS PLATE MUST BE AFFIXED AS CLOSE AS POSSIBLE TO THE EXISTING RATING PLATE.
THE FOLLOWING MUST BE COMPLETED BY THE INDIVIDUAL CONVERTING THIS APPLIANCE:
THIS APPLIANCE HAS BEEN CONVERTED TO __________FUEL, ORIFICE __________, MANIFOLD PRESSURE
_________, AND INPUT ___________, ON ____________ (date), WITH KIT # LPK-OH
BY (name&address of organization making this conversion)
WHO ACCEPTS THE RESPONSIBILITY FOR THE CORRECTNESS OF THIS CONVERSION.
4095-906A
