Hearth & Home SRV2380-070 User manual

1
Heatilator • SRV2380-070, SRV2381-070, SRV2382-070, SRV2383-070 Log Instructions • 2382-935 Rev. B • 9/17
Figure 4. Log #4 in Position
1
Log Set Assembly:
SRV2380-070 SRV2381-070 SRV2382-070 SRV2383-070
Models: NDV3630I-B, NDV3630IL-B, NDV3933I-B, NDV3933IL-B,
NDV4236I-B, NDV4236IL-B, NDV4236I-NVR, NDV4842I-B,
NDV4842IL-B, NBV3630I-B, NBV3933I-B, NBV4236I-B, NBV4842I-B
LOG PLACEMENT INSTRUCTIONS
See Table 1 for corresponding log set and individual logs for each size Novus model.
Figure 1. Log Set Shown as Shipped
Figure 3. Locations of Flat Spots for Log #4
2
1
23
CAUTION: Logs are fragile, handle with care.
FLAT SPOTS FOR LOG #4
LOG #4: Place Log #4 into position by setting the left end of Log #4 into the at spot on Log #2 and then resting the right
end, or nose, of Log #4 on the at spot on Log #1. Figure 3 shows locations of at spots. Figure 4 shows Log #4 installed.
4
SIZE 3630 3933 4236 4842
ASSEMBLY SRV2380-070 SRV2381-070 SRV2382-070 SRV2383-070
LOG 1 SRV2380-071 SRV2380-071 SRV2382-071 SRV2383-071
LOG 2 SRV2380-072 SRV2381-072 SRV2381-072 SRV2383-072
LOG 3 SRV2380-073 SRV2381-073 SRV2381-073 SRV2383-073
LOG 4 SRV2380-074 SRV2380-074 SRV2382-074 SRV2382-074
LOG 5 SRV2380-075 SRV2380-075 SRV2380-075 SRV2383-075
Table 1.
The log set is shipped from the factory with three logs already in place on the hearth pan. See Figure 1. In case of damage,
the log will need to be removed from the base pan. See Figure 2 for locations of fasteners for each log.
Figure 2. Log Fastener Locations on Base Pan
FASTENERS-LOG #1
FASTENERS-LOG #2 FASTENERS-LOG #3

2Heatilator • SRV2380-070, SRV2381-070, SRV2382-070, SRV2383-070 Log Instructions • 2382-935 Rev. B • 9/17
Log #5: Place Log #5 into position. The forked end of Log #5 is positioned toward the front of the appliance, with the two
slots on the back side resting on the bent lip of the hearth pan. See Figure 6. Slide Log #5 toward the right until it contacts
the log pin as shown in Figure 6.
4
5
1
23
LOG PIN
Figure 5. Log Pin Location Figure 6. Log #5 in Position
Figure 7. Log Set Installed
BENT LIP
