LOG PLACEMENT
INSTRUCTIONS
Carefully remove the logs from the packaging. CAUTION:
Logs are fragile! Before placing logs, remove shipping bracket
and tie straps from the burner and grate. Place the lava rock
on the bottom of the firebox. Evenly spread out the lava
rocks with your hand.
703-925B 8/05
LOG #1 (SRV703-701): Place log #1 between log tabs on the left side on the burner. The log should be
pushed forward until the groove in the log makes contact with the front log tab. The right side of the log should
contact the firebox.
LOG #2 (SRV703-702): Place log #2 flush with grate tines 3 and 4. On the front of log #2 there is a
location feature to help locate the log. Slide the log to the right until the location feature contacts the fourth grate tine.
Log Assembly: LOGS-AZTEC
Model: AZTEC
1
1
2
2
BURNER
TAB
GRATE
34
1 2 3 4 5 6 7 8
34
Shipping Bracket
TIE STRAPS

2
LOG #3 (SRV703-703): Place log #3 flush with grate tines 1 and 2. The right end of the log should
make contact with grate tine 2.
LOG #4 (SRV750-705): Place the top of log #4 in the groove in log #1. Place the base of the log into the
groove on log #3 such that the end of the log contacts grate tine 2.
LOG #5 (SRV703-704): Place the top part of log #5 on the flat spot of log #4. Slide the log back until it
makes contact with log #1.
3
3
4
4
5
5
2
2
2
1
1
GROOVES
FOR LOG #4
FLAT SPOT
FOR LOG #5
12
4

3
LOG #6 (SRV750-706): Place log #6 in the groove in log #3. Log #6 must be placed parallel to the burner
ports behind the log. CAUTION: If log #6 is not parallel to burner ports then sooting may occur. Do not place logs
directly on burner ports.
LOG #7 (SRV750-704): Place the top portion of log #7 into the groove on log #1 and place the bottom of
the log in the groove in log #2.
LOG #8 (SRV703-705): Place log #8 on the flat spot on log #2.
6
6
7
7
8
8
GROOVES
FOR LOG #7
FLAT SPOT
FOR LOG #8
3
2
1
2
