1Hearth & Home Technologies • MANOR, CHAPEL, ENSEMBLE, LOFT, FORGE, STUDIO, VENTURA Instructions • 2596-930 Rev. D • 3/23
Leave this manual with party responsible for use
and operation.
WARNING! Risk of Fire! Combustible materials MUST
NOT overlap or be placed under a surround.
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during instal-
lation. Sheet metal edges are sharp.
DANGER
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and must be installed for
the protection of children and other at-risk
individuals.
CAUTION! Do not install damaged components.
WARNING! Risk of Fire! DO NOT apply combustible
materials beyond the minimum clearances. Comply with
all minimum clearances to combustibles as specied.
Overlapping materials could ignite and will interfere with
proper operation of decorative fronts.
DECORATIVE FRONT
MANOR36, MANOR42, CHAPEL-6,CHAPEL-8
ENSEMBLE36, ENSEMBLE42, LOFT-6, LOFT-8,
FORGE-6, FORGE-8, STUDIO-6, STUDIO-8, VENTURA36, VENTURA42
- Installation Instructions for all available color choices -
Preparation
1. Remove contents from packaging. Refer to Table 1 for
Decorative Front dimension information.
Decorative Front Height Width
LOFT-6
CHAPEL-6
FORGE-6
MANOR36
ENSEMBLE36
STUDIO-6
VENTURA36
32-7/16 in. 39-5/16 in.
LOFT-8
CHAPEL-8
FORGE-8
MANOR42
ENSEMBLE42
STUDIO-8
VENTURA42
34-7/16 in. 46-5/16 in.
Table 1 Decorative Front Dimensions
Finishing Material/Method
These decorative fronts are designed to be installed as
Overlap Fit or Inside Fit.
Inside Fit Method:
When installing a decorative front using the Inside Fit
method, the factory-supplied nishing strips must be in-
stalled prior to installation of the nishing material. The
nishing strips ship with the appliance and are located in
the control cavity underneath the rebox. The nishing
strips must be removed before installing the decorative
front. Finishing strips will add the proper clearances for
the installation of the front.
Typically, the inside t method is only used when non-
combustible nish material greater than 1 inch is used
(such as cultured stone). This nish material is installed
adjacent to the decorative front sides and top. When in-
stalled, the back of the decorative front contacts the black
surround on the replace, thus the decorative front is “in-
side” the adjacent nish material. Refer to the appliance
Installation Manual for more detailed information.

2Hearth & Home Technologies • MANOR, CHAPEL, ENSEMBLE, LOFT, FORGE, STUDIO, VENTURA Instructions • 2596-930 Rev. D • 3/23
Cleaning Instructions for Decorative fronts
Use a microber cloth and Windex® Original Glass
Cleaner or 03M003 Stove Bright® Glass Cleaner to
clean the decorative front immediately after installation
to remove acids deposited by the installer or technician.
Spray the cleaner onto the microber cloth and carefully
wipe the entire surface. The decorative front should
be cleaned in this manner annually by the homeowner
to remove ngerprints or other contaminants. Once
oxidation of the paint pigment has occurred, cleaning will
not restore the original color.
SERVICE PARTS
Decorative Front Part Number Description
LOFT-6 SRV2581-040
Mesh
CHAPEL-6
FORGE-6
MANOR36
ENSEMBLE36
SRV2582-023
STUDIO-6
VENTURA36 SRV2582-021
LOFT-8 SRV2585-040
CHAPEL-8
FORGE-8
MANOR42
ENSEMBLE42
STUDIO-8
VENTURA42
SRV2586-023
STUDIO-8
VENTURA42 SRV2586-021
Please contact your Hearth & Home Technologies
dealer with any questions or concerns.
For the location of your nearest Hearth & Home Technologies
dealer,
please visit www.hearthnhome.com.
Hearth & Home Technologies
7571 215th Street West, Lakeville, MN 55044
www.hearthnhome.com
Figure 2 Hanging Tab and Hook Locations
(Loft Decorative Front Shown)
TABS
(TOP AND BOTTOM)
HOOKS
(TOP AND BOTTOM)
Installation
1. Verify that the nishing strips have been removed, if
previously installed.
2. The decorative front is installed by engaging top and
bottom hooks on the front with top and bottom tabs on
the appliance. See Figure 2. Align the bottom hooks
on the decorative front with the bottom tabs on the
appliance. Set the bottom hooks on the tabs and tilt
the front toward the appliance until it contacts the top
tabs. Once the decorative front contacts the top tabs,
lift up slightly and push decorative front toward appli-
ance until hooks and tabs are engaged.
Overlap Fit Method:
The factory-supplied nishing strips are not needed for
this method of nishing. Remove the nishing strips from
the control cavity of the appliance and discard.
Non-combustible nish material that is 1 inch or less
(such as marble or tile) is installed up to the replace
opening on the sides and top. When installed, the back of
the decorative front contacts the face of the nish mate-
rial. Refer to the appliance Installation Manual for more
detailed information.
