Heat & Glo 6000CMOD-IPI User manual

Heat & Glo • CMOD-36 and CMOD-42 Door Instructions • 2241-946 Rev. B • 11/141
CMOD-36-GY, CMOD-42-GY, CMOD-36-BK, CMOD-42-BK Doors
Models: 6000CMOD-IPI, 8000CMOD-IPI Door
- Installation Instructions -
Figure 2. Inner Door Installation
CAUTION! Do not install damaged components.
Leave this manual with party responsible for use
and operation.
WARNING! Risk of Fire! Combustible materials MUST
NOT overlap or be placed under a surround.
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during instal-
lation. Sheet metal edges are sharp.
DANGER
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
INSTALLATION
1. Install the shoulder bolts by threading the bolts into the
rivnuts. See Figure 1.
CONTENTS:
(1) Decorative Front
(4) Shoulder Bolts
Verify and remove contents from packaging before begin-
ning installation.
TOP
SHOULDER
BOLTS
BOTTOM SHOULDER
BOLTS
3. Attach the inner door to the appliance, mount the J-hooks
on the shoulder bolts. See Figure 2.
Figure 1. Shoulder Bolt installation
2. Bend the (4) handbend J-hooks on the back of the inner
door to 90° perpendicular to allow for easy hanging of
the door on the unit. Adjust handbend J-hooks if needed.
See Figure 2 for reference.
90° HARDBEND J-HOOK

Heat & Glo • CMOD-36 and CMOD-42 Door Instructions • 2241-946 Rev. B • 11/142
Please contact your Heat & Glo dealer with any
questions or concerns.
For the location of your nearest Heat & Glo dealer,
please visit www.heatnglo.com.
Heat & Glo, a brand of Hearth & Home Technologies
7571 215th Street West, Lakeville, MN 55044
www.heatnglo.com
Figure 3. Outer Door Attachment
4 Attach the outer door to the inner door, mount the four
J-Hooks on the slots. See Figure 3.
SERVICE PARTS
CMOD-36-GY CMOD-36-BK
Mesh 2172-042
CMOD-42-GY CMOD-42-BK
Mesh 2173-042
Cleaning Instructions for Doors
Use a microber cloth and Windex® Original Glass
Cleaner or 03M003 Stove Bright® Glass Cleaner to clean
the door immediately after installation to remove acids
deposited by the installer or technician. Spray the cleaner
onto the microber cloth and carefully wipe the entire
surface. The door should be cleaned in this manner
annually by the homeowner to remove ngerprints or
other contaminants. Once oxidation of the paint pigment
has occurred, cleaning will not restore the original color.
CMOD-36-GY, CMOD-36-BK CMOD-42-GY, CMOD-42-BK
Shoulder Bolt 319-835
