HEIDENHAIN ND 1300 User manual

English (en)
2/2010
ND 1300
QUADRA-CHEK
(QC 320)
Operating Instructions
Optical Edge Detection and
Crosshair Systems

QC-300 Series
User’s Guide
Optical Edge Detection Systems
QC-320, QC-321, QC-323, QC-324
QC-320E, QC-321E, QC-323E, QC-324E

QC-300 Series
Optical Edge Detection and Crosshair Systems
User’s Guide
Published by
Metronics, Inc.
30 Harvey Road
Bedford, New Hampshire 03110
www.Metronics.com
User’s Guide part number: 11A10569 Revision 2
Publishing date: December, 2007
Printed in United States of America
Copyright © 2007 by Metronics, Inc., Bedford, New Hampshire
QC-300 software version: 2.00
All information set forth in this document, all rights to such information, any and all inventions disclosed
herein and any patents that might be granted by employing the materials, methods, techniques or apparatus
described herein are the exclusive property of Metronics Inc., Bedford, New Hampshire.
Terms, conditions and features referenced in this document are subject to change without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted in any form or by
any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permis-
sion of Metronics, Inc.. Requests to Metronics, Inc. for permission should be addressed to the Technical
Services Department, Metronics, Inc., 30 Harvey Road, Bedford, New Hampshire 03110.
Limit of liability and disclaimer of warranty
While this guide was prepared with great care, Metronics makes no representations or warranties with
respect to the accuracy or completeness of the contents of this book and specifically disclaims any implied
warranties of merchantability or fitness for a particular purpose. The advice, methods and instructions
contained in this book might not be suitable for your situation. When in doubt regarding suitability, you
are encouraged to consult with a professional where appropriate. Metronics shall not be liable for any loss
of profit or any damages, including but not limited to special, incidental, consequential or other damages.
Trademarks
Metronics and QC-300 are registered trademarks of Metronics, Inc. and its subsidiaries in the United States
and other countries.

Conventions & Terms
QC-300 refers to any of the QC-300 series of instruments. System refers to the QC-300 and the measuring
devices connected to it.
Icons
This guide uses the following icons to highlight information:
WARNINGS
The raised hand icon warns of a situation or condition that can lead to personal injury
or death. Do not proceed until the warning is read and thoroughly understood.
DANGEROUS VOLTAGE
The lightning icon warns of the presence of an uninsulated dangerous voltage within
the product enclosure that might be of sufficient magnetude to cause serious shocks or
death. Do not open the enclosure unless you are a qualified service person approved
by Metronics, Inc., and never open the enclosure while power is connected.
CAUTIONS & IMPORTANT INFORMATION
The exclamation point icon indicates important information regarding equipment
operation or maintentance, or a situation or condition that can lead to equipment
malfunction or damage. Do not proceed until the information is read and thoroughly
understood.
NOTE
The note icon indicates additional or supplementary information about an activity or
concept.
Safety & Maintenance Considerations
General safety precautions must be followed when operating the system. Failure to observe these precau-
tions could result in damage to the equipment, or injury to personnel.
It is understood that safety rules within individual companies vary. If a conflict exists between the material
contained in this guide and the rules of a company using this system, the more stringent rules should take
precedence.
Safety information is also included on the next page and in Chapter 2: Installation.

WARNINGS
Disconnect the QC-300 from power before cleaning.
The QC-300 is equipped with a 3-wire power plug that includes a separate ground
connection. Always connect the power plug to a 3-wire grounded outlet. The use of
accessories that remove the third grounded connection such as a 2-wire power plug adapter create
a safety hazard and should not be permitted. If a 3-wire grounded outlet is not available, ask your
electrician to provide one.
DANGEROUS VOLTAGE
Do not open the enclosure unless you are a qualified service person approved by
Metronics, Inc., and never open the enclosure while power is connected. There are no
user-serviceable components or assemblies inside. Refer servicing to qualified service
personnel.
General Maintenance
Disconnect the QC-300 from power and seek the assistance of a qualified service technician if:
 • Thepowercordisfrayedordamagedorthepowerplugisdamaged
 • Liquidisspilledorsplashedontotheenclosure
 • TheQC-300hasbeendroppedortheexteriorhasbeendamaged
 • TheQC-300exhibitsdegradedperformanceorindicatesaneedforservicesomeotherway
Cleaning the enclosure
Use only a cloth dampened with water and a mild detergent for cleaning the exterior surfaces. Never use
abrasive cleaners, and never use strong detergents or solvents. Only dampen the cloth, do not use a cleaning
cloth that is dripping wet. Instructions for cleaning the touch screen are different and are given below.
Cleaning the touch screen
The touch screen should be cleaned as described below to prevent scratching or wearing the screen surface
and to prevent liquids from leaking into the enclosure.
Use only a soft, lint-free cloth dampened with water for cleaning the touch screen. Never use abrasive
cloths or paper towels. Never use abrasive cleaners, and never use detergents or solvents. Only dampen
the cloth, do not use a cleaning cloth that is dripping wet. Never spray the screen.
If the screen is badly soiled, the cloth can be dampened with a 50:50 mixture of isopropyl alcohol and
water. Remember, only dampen the cloth, do not use a cleaning cloth that is dripping wet, and never spray
the screen.

Contents 1
Contents
Chapter 1 Overview
Overview of the QC-300 features and functions ......................................... 1
Chapter 2 Installation
Unpacking the QC-300 ................................................................................ 5
Assembling the mounting stand................................................................... 6
Safety considerations ................................................................................... 6
Power cord and plug ............................................................................. 6
Electrical wiring and connections......................................................... 6
Locationandmounting ......................................................................... 7
Power surge suppressor ........................................................................ 7
Connecting axis encoders ............................................................................ 7
Connecting a printer..................................................................................... 8
Connecting a computer ................................................................................ 8
Connecting an optional footswitch .............................................................. 9
Connecting the optical edge detector inputs ................................................ 9
Connecting optional CNC outputs............................................................... 10
Warranty registration form .......................................................................... 11
Repackaging for shipment ........................................................................... 11
Chapter 3 User Interface
Introduction.................................................................................................. 13
Measurement functions................................................................................ 14
Selecting a measurement type .............................................................. 14
Accessing programming functions ....................................................... 15
Sending data to a computer from the Extra tab .................................... 16
CNC and other Extra tab functions....................................................... 18
Extra tab functions................................................................................ 18
Space menu insert.......................................................................... 18
Divider line menu insert ................................................................ 18
Data prompt function..................................................................... 18
Optical edge detector probe calibration (probe teach)................... 18
Joystick motor speed ..................................................................... 18
Axis lock........................................................................................ 18
Part following ................................................................................ 19
Stop motion ................................................................................... 19

Contents 2 QC-300 Series User’s Guide
Goto feature ................................................................................... 19
Multiple Extra tabs ............................................................................... 19
Command buttons and wide keys ................................................................ 20
Feature list.................................................................................................... 21
LCDScreenfunctions.................................................................................. 22
Number keys ................................................................................................ 23
System functions.......................................................................................... 24
Datum lock............................................................................................ 24
Undo ..................................................................................................... 24
Probe ..................................................................................................... 24
Magnification........................................................................................ 25
Unit of measure..................................................................................... 25
Setup ..................................................................................................... 26
Printing reports and sending data................................................................. 26
LCDON/OFFanddeletingfeaturedata...................................................... 27
Chapter 4 Quick Start Demonstration
Start recording a program ............................................................................ 30
Select a probe............................................................................................... 30
Create part skew and datum references ....................................................... 31
Measuring a part skew .......................................................................... 31
Create a datum zero point ..................................................................... 32
Probing a datum zero point................................................................... 32
Constructing a datum zero point........................................................... 33
Measure a feature......................................................................................... 35
Measuring a circle................................................................................. 35
Apply tolerances to a feature measurement ................................................. 37
Print a report ................................................................................................ 39
Stop program recording ............................................................................... 40
Running the program ................................................................................... 41
Chapter 5 Probes
Probes........................................................................................................... 44
Edge detector probes.................................................................................... 44
Automatic point entry ........................................................................... 44
Manual point entry................................................................................ 44
Crosshair probes ................................................................................... 44
Automatic point entry ........................................................................... 45
Manual point entry................................................................................ 45
Preparing to use probes................................................................................ 46
System and part condition .................................................................... 46

Contents 3
QC-300 Series User’s Guide
Selecting a magnification ..................................................................... 46
Lighting................................................................................................. 46
Calibration ............................................................................................ 47
Edge teach ..................................................................................... 47
Distance calibration ....................................................................... 47
Cross calibration ............................................................................ 47
Probing with edge detectors......................................................................... 48
Automatic point entry ........................................................................... 48
Manual point entry................................................................................ 49
Probing with crosshairs................................................................................ 50
Automatic point entry ........................................................................... 50
Manual point entry................................................................................ 50
Chapter 6 Measuring
Measurement activities ................................................................................ 52
The measurement process ............................................................................ 52
Establishing the measurement reference .............................................. 53
Levelingthepart(optional) ........................................................... 53
Skewing the part ............................................................................ 54
Creating a datum zero point .......................................................... 55
Probing a datum zero point .................................................... 55
Constructing a datum zero point ............................................ 56
Probing and measuring features................................................................... 58
Probing with Measure Magic................................................................ 58
Probing specific feature types............................................................... 59
Probing a single specific feature type............................................ 59
Probing multiple specific feature types ......................................... 59
Probing process..................................................................................... 60
Supported feature types ................................................................. 60
Backward/forwardannotation ....................................................... 61
Probing with crosshairs and optical edge detection.............................. 61
Probing specific feature types............................................................... 62
Probing points................................................................................ 62
Probing lines.................................................................................. 63
Probing arcs ................................................................................... 64
Probing slots .................................................................................. 66
Probing rectangles ......................................................................... 67
Probing distances........................................................................... 68
Probing angles ............................................................................... 69

Contents 4 QC-300 Series User’s Guide
Constructing features ................................................................................... 70
Point constructions................................................................................ 70
Point constructed from a point ...................................................... 70
Point constructed from a point and a line...................................... 70
Points constructed from an arc and a line...................................... 71
Points constructed from a line ....................................................... 72
Point constructed from two lines................................................... 73
Points constructed from a distance ............................................... 73
Point constructed from a distance and a point............................... 74
Point constructed from a circle...................................................... 74
Points constructed from a circle and a line.................................... 75
Points constructed from two circles .............................................. 76
Point constructed from a slot......................................................... 77
Point constructed from a rectangle ................................................ 77
Point constructed from an angle .................................................... 77
Point constructed from an arc........................................................ 78
Point constructed from multiple features ...................................... 78
Lineconstructions................................................................................. 79
Lineconstructedfromaline.......................................................... 79
Lineconstructedfromtwopoints.................................................. 79
Linesconstructedfromapointandaline ..................................... 80
Lineconstructedfromadistance................................................... 80
Linesconstructedfromapointandacircle................................... 81
Lineconstructedfromapointandaslot ....................................... 82
Lineconstructedfromapointandarectangle .............................. 82
Linesconstructedfromapointandanarc..................................... 83
Linesconstructedfromtwolines .................................................. 84
Lineconstructedfromalineandadistance .................................. 85
Linesconstructedfromalineandacircle..................................... 85
Linesconstructedfromalineandaslot........................................ 86
Linesconstructedfromalineandanarc....................................... 86
Lineconstructedfromalineandanangle..................................... 87
Linesconstructedfromalineandarectangle ............................... 87
Linesconstructedfromtwocircles................................................ 88
Linesconstructedfromacircleandanarc.................................... 89
Linesconstructedfromacircleandaslot ..................................... 90
Lineconstructedfromaslot .......................................................... 91
Lineconstructedfromtwoslots .................................................... 91
Linesconstructedfromarectangleandacircle ............................ 92
Linesconstructedfromaslotandanarc ....................................... 93
Linesconstructedfromarectangleandanarc .............................. 94
Linesconstructedfromaslotandarectangle ............................... 95

Contents 5
QC-300 Series User’s Guide
Linesconstructedbetweentworectangles .................................... 95
Lineconstructedfromarectangle ................................................. 97
Lineconstructedfrommultiplefeatures........................................ 97
Distance constructions .......................................................................... 98
Distance constructed from a distance ............................................ 98
Distances constructed from two points.......................................... 98
Distances constructed from a point and a line............................... 99
Distances constructed from a point and a rectangle ...................... 99
Distances constructed from a point and a circle............................ 100
Distance constructed from a point and a slot................................. 101
Distances constructed from a point and an arc.............................. 102
Distance constructed from a line ................................................... 103
Distance constructed from a line and a rectangle.......................... 103
Distances constructed from two lines............................................ 104
Distances constructed from a line and a circle .............................. 105
Distances constructed from a line and an arc ................................ 106
Distance constructed from a line and a slot................................... 107
Distance constructed from two distances ...................................... 107
Distances constructed from two circles......................................... 108
Distances constructed from a slot and a circle .............................. 109
Distances constructed from a rectangle and a circle...................... 109
Distances constructed from an arc and a circle ............................. 110
Distance constructed from two slots.............................................. 111
Distances constructed from a slot and an arc ................................ 111
Distances constructed from a rectangle and an arc........................ 112
Distances constructed from a slot and a rectangle......................... 112
Distances constructed between two rectangles.............................. 113
Distances constructed from two arcs............................................. 114
Circle constructions .............................................................................. 115
Circle constructed from a circle .................................................... 115
Circles constructed from two lines ................................................ 115
Circle constructed from a circle and a distance............................. 116
Circle constructed from two circles............................................... 116
Circle constructed from multiple features ..................................... 117
Arc constructions .................................................................................. 118
Arc constructed from an arc .......................................................... 118
Arc constructed from an arc and a distance................................... 118
Angle constructions .............................................................................. 119
Angle constructed from an angle................................................... 119
Angle constructed from two lines.................................................. 120

Contents 6 QC-300 Series User’s Guide
Creating features .......................................................................................... 121
Creating a point..................................................................................... 121
Creating a line....................................................................................... 122
Creating a circle.................................................................................... 122
Creating an arc...................................................................................... 123
Creating a slot ....................................................................................... 123
Creating a rectangle .............................................................................. 124
Chapter 7 Tolerancing
Applying tolerances to features ................................................................... 127
Selecting a feature................................................................................. 127
Displaying the tolerance screen ............................................................ 127
Selecting a tolerance type ..................................................................... 127
Selecting a specific tolerance................................................................ 128
Entering nominal, limit or tolerance values.......................................... 128
Omitting a tolerance category ....................................................... 129
Tolerance types..................................................................................... 130
Bidirectional .................................................................................. 130
Points...................................................................................... 130
Lines ....................................................................................... 130
Circles and arcs ...................................................................... 131
Slots and rectangles................................................................ 131
True position.................................................................................. 132
Points and lines....................................................................... 132
Circles and arcs ...................................................................... 132
MMC/LMC(Materialcondition) .................................................. 133
MMC Circles and arcs............................................................ 133
LMCCirclesandarcs............................................................. 134
Runout ........................................................................................... 135
Roundness...................................................................................... 135
Concentricity ................................................................................. 135
Straightness.................................................................................... 135
Parallelism ..................................................................................... 136
Perpendicularity............................................................................. 136
Angle ............................................................................................. 136
Width ............................................................................................. 137

Contents 7
QC-300 Series User’s Guide
Chapter 8 Programming
Creating programs........................................................................................ 139
Start program recording........................................................................ 140
Enter a program title (or user message)................................................ 141
Measure a skew and create a datum ..................................................... 142
Measure a feature (include a message)................................................. 142
Apply a tolerance.................................................................................. 143
Report results ........................................................................................ 143
Stop the program recording .................................................................. 144
Specifying part fixturing (CNC option)................................................ 145
None .............................................................................................. 145
Temporary ..................................................................................... 145
Permanent ...................................................................................... 145
Editing Programs .................................................................................. 146
Editing existing steps..................................................................... 146
Editing program settings ........................................................ 146
Editing tolerances ................................................................... 148
Editing user prompt messages................................................ 149
Inserting or appending new program steps.................................... 150
Running programs ................................................................................ 152
Saving and retrieving programs............................................................ 153
Saving programs ............................................................................ 153
Retrieving programs ...................................................................... 153
Deleting programs ................................................................................ 155
Chapter 9 Communication
Connecting to a computer ............................................................................ 157
Sending data to a computer................................................................... 158
Connecting a printer..................................................................................... 159
Printer format strings ............................................................................ 159
Report formats ...................................................................................... 159
Printing a report .................................................................................... 160
Printing feature measurement data ................................................ 160
Printing QC-300 system settings ................................................... 161
RS232 connector pin designations............................................................... 162
ASCII Code table......................................................................................... 162

Contents 8 QC-300 Series User’s Guide
Chapter 10 Setup
The Setup Menu........................................................................................... 164
Accessing and using the Setup Menu .................................................. 164
Entering the supervisor password.................................................. 165
Selecting items from the Setup Menu ........................................... 166
Selecting setup parameter choices................................................. 166
Entering and deleting setup data.................................................... 166
Storing a parameter and advancing to the next step ...................... 167
Leavingthesetupmenu................................................................. 167
Minimum setup requirements ...................................................................... 168
Setup screen descriptions............................................................................. 169
Languagescreen ................................................................................... 169
Specifying the displayed language ................................................ 169
Supervisor screen ........................................................................................ 170
Entering the supervisor password......................................................... 170
Keeping setup privileges until the power is cycled .............................. 170
Hiding setup parameters from unauthorized personnel ........................ 170
Limitingaccesstoprogramfunctions................................................... 170
Saving and loading settings .................................................................. 171
Encoders screen ........................................................................................... 172
Selecting an axis to configure............................................................... 172
Specifying encoder resolution .............................................................. 172
Specifying encoder type ....................................................................... 172
Selecting reference marks..................................................................... 173
None .............................................................................................. 173
Manual........................................................................................... 173
Single............................................................................................. 173
Absolute......................................................................................... 173
Setting a new machine zero reference .................................................. 174
Reversing the encoder count direction ................................................. 174
Enabling axis error messages................................................................ 174
Specifying slew limit ............................................................................ 174
Squareness screen ........................................................................................ 175
SLECscreen................................................................................................. 176
LECorSLEC,whichisrightformyapplication? .............................. 176
LEC(Linearerrorcorrection)............................................................... 176
SLEC(Segmentedlinearerrorcorrection) ........................................... 178
NLECScreen ........................................................................................ 181
.acf Files................................................................................................ 181
.acf file format ............................................................................. 181
Example 3 X 3 grid............................................................................... 181

Contents 9
QC-300 Series User’s Guide
Example .acf file................................................................................... 181
Calibrating from features...................................................................... 182
CalibratingNLECbyadjustingstationvalues ..................................... 184
CalibratingNLECwithexistingNLECcorrectiontextfile ................. 185
Magnifications screen .................................................................................. 186
Adding magnifications.......................................................................... 186
Deleting magnifications........................................................................ 186
Edge calibrations for routine measurements......................................... 187
Edge calibrations for difficult measurements ....................................... 187
Specifying an active edge detection zone for program playback ......... 188
Evaluating optical light levels .............................................................. 188
Calibrating crosshair and edge probe offset ......................................... 188
Performing parcentric calibrations ....................................................... 189
Measure screen............................................................................................. 191
Annotation ............................................................................................ 191
Minimum points required for a feature measurement .......................... 191
Lockingfeaturestotheiroriginaldatums............................................. 192
Specifying signed distances.................................................................. 192
Enabling and configuring point filtration ............................................. 192
Enabling point filtration ................................................................ 193
Specifying a filtration error limit................................................... 193
Specifying a filtration standard deviation range............................ 193
Specifying the minimum percentage of retained points ................ 193
Crosshair timeout delay ........................................................................ 194
Crosshair delay restart distance ............................................................ 194
Display screen.............................................................................................. 195
Display resolution................................................................................. 195
Default units of linear measure............................................................. 196
Radix for numeric displays................................................................... 196
Angular units of measure...................................................................... 196
Time formats......................................................................................... 196
Date formats.......................................................................................... 196
Display mode switching ....................................................................... 197
Configuring the Extra tab ..................................................................... 198
Extra tab functions................................................................................ 199
Space menu insert.......................................................................... 199
Divider line menu insert ................................................................ 199
Data prompt function..................................................................... 199
Optical edge detector probe calibration (probe teach)................... 199
Joystick motor speed ..................................................................... 199
Axis lock........................................................................................ 199
Part following ................................................................................ 199

Contents 10 QC-300 Series User’s Guide
Stop motion ................................................................................... 200
Goto feature ................................................................................... 200
Header screen............................................................................................... 201
Creating report headers......................................................................... 201
Print screen................................................................................................... 202
Specifying a data type........................................................................... 202
Specifying a data destination ................................................................ 202
Report Type .......................................................................................... 202
Linesperpage....................................................................................... 202
Specifying column separators............................................................... 203
Selecting a USB printer ........................................................................ 203
Ports screen .................................................................................................. 204
Baud rate............................................................................................... 204
Word length .......................................................................................... 204
Stop bits ................................................................................................ 204
Parity..................................................................................................... 204
EOC delay............................................................................................. 204
EOLdelay............................................................................................. 204
Clock screen................................................................................................. 205
Sound screen ................................................................................................ 206
Miscellaneous screen ................................................................................... 207
Return to DRO threshold ...................................................................... 207
Touchscreen calibration rows and columns.......................................... 207
Calibrating the touchscreen .................................................................. 208
Touch screen cursor.............................................................................. 208
Touch screen repeat delay .................................................................... 208
Touch zone size .................................................................................... 209
Screen brightness .................................................................................. 209
Showing the Extra tab........................................................................... 209
Buttons screen.............................................................................................. 210
Selecting button functions .................................................................... 210
Selecting button responses.................................................................... 211
Selecting button logic ........................................................................... 211
Joystick screen ............................................................................................. 212
Enabling joystick motion...................................................................... 212
Specifying a joystick deadband ............................................................ 212
Specifying axis direction ...................................................................... 212
Specifying normal and fine axis velocity ............................................. 212
Specifying linear and nonlinear joystick motion control...................... 213
Calibrating the Joystick range of motion.............................................. 213

Contents 11
QC-300 Series User’s Guide
Digital positioner screen .............................................................................. 214
Enabling digital positioner motion ....................................................... 214
Specifying axis direction ...................................................................... 214
Specifying normal and fine axis velocity ............................................. 214
Specifying axis acceleration ................................................................. 214
Specifying a digital positioner counter debounce................................. 214
Current value display............................................................................ 214
Probe path screen ......................................................................................... 215
Probing and non-probing velocities...................................................... 215
Approach and search distances............................................................. 216
Edge values screen................................................................................ 217
Debouncing edges................................................................................. 217
Viewing current edge detector values................................................... 217
Hardware screen........................................................................................... 218
Chapter 11 Problem Solving
Symptoms, probable causes and solutions................................................... 220
NoimageisvisibleontheLCDscreen ................................................ 220
ValuesdisplayedontheLCDscreenareincorrect............................... 220
Reports are not printed or are incomplete............................................. 222
Reports are printed incorrectly ............................................................. 222
Optical edge detection is not working properly.................................... 223
Data cannot be transmitted to a computer ............................................ 224
Getting help from your distributor............................................................... 224
Chapter 12 Reference Material
Product specifications .................................................................................. 225
Electrical ............................................................................................... 225
Environmental....................................................................................... 225
Dimensions ........................................................................................... 225
LCD ...................................................................................................... 225
ENC tests .............................................................................................. 225
Footswitch wiring ........................................................................................ 226
RS-232 connector wiring ............................................................................. 227
Tolerance definitions ................................................................................... 228
Concentricity tolerance......................................................................... 228
Reference Features................................................................................ 228
Leastsquaresbestfit............................................................................. 228
Maximum inscribed circle .................................................................... 228
Minimum superscribed circle ............................................................... 228
ISO (least radial distance)..................................................................... 228

Contents 12 QC-300 Series User’s Guide
Chapter 13 Product Options
Listofproductoptions................................................................................. 229

1
1Overview
Chapter 1:
Overview
The Quadra-Chek 300 series is a family of advanced digital readout systems for performing 2, 3 and 4 axis
measurements at very high levels of precision and accuracy. Dimensional inspection of components can be
made using comparator or toolmaker’s microscope systems as part of in-line production activities or final
quality inspection.
Feature points are entered using crosshairs or (optional) optical edge detection. Feature type can automati-
cally be determined by the system using Measure Magic. Levelandskewcompensationcanbeperformed
on misaligned parts prior to measurements to eliminate the need for time-consuming fixturing.
Sequences of key-presses used to perform measurements can be recorded and stored as programs. These
programs can be replayed later to perform complete measurement sequences. Sequences can be as simple as
measuring a line, or can be expanded to include skew adjustment, datuming, the measurement of multiple
features, tolerancing and printing reports of measurement results. Programs can include the CNC motion
control option to fully automate program execution, increase thoughput and simplify operator tasks.
The intuitive interface will be familiar to users of
the QC-200 and other Metronics digital readouts.
Operators will find the QC-300 easy to under-
stand and use thanks to the large color touch
screenLCDdisplay.
The color LCD displays alphanumeric
and graphic information for the current
measurement, part features and mea-
surement data clearly on one screen,
eliminating the need to page or scroll
for information.
Touch screen controls select the feature
to be measured, change operating and
display modes, zero axes, and configure
setup parameters. Touch screen controls change
to support measurement-specific functions displayed on
theLCDscreen.

2QC-300 Series User’s Guide
Frontpanelkeysenternumericdata,turntheLCDonoroffandsenddatatoaprinterorcomputer.Two
wide keys located over the LCD can quickly be pressed without looking at the front panel to initiate
frequently used functions programmed by the user. All front panel keys provide tactile sensory feedback,
and key-press operations can be configured to generate an audible sound.
Speaker and external speaker jack outputs are provided that can be adjusted for quiet or noisy environ-
ments. Ear phones can be plugged into the external speaker jack to facilitate silent operation in quiet
environments.
Wide keys
LCD ON/OFF
Command keys
Numeric keypad
Print/Send data
Touch screen
controls
Color touch
screen
