Hioki 3522-50 User manual

Instruction Manual
For...は専用機種。複数の場合は「/」で区切る。不要の場合はとる。
形名を入力。 複数の場合は「/」で区切る。
3522-50
品名を入力。
LCR HiTESTER
June 2011 Revised edition 7 3522C981-07 11-06H

Contents
Introduction i
Shipping Check ii
Safety iii
Points for Attention During Use v
Layout of This Manual vi
Chapter 1 Overview 1
1.1 Product Overview 1
1.2 Product Features 2
1.3 Names and Functions of Parts 3
Chapter 2 Before Starting Measurement 7
2.1 Connecting the Power Cord 7
2.2 Connecting the Test Leads 8
2.2.1 Establishing the Connections 8
2.3 Turning the Power On and Off 10
Chapter 3 Outline of Operation 11
3.1 About the Touch Panel 11
3.2 About the Screen 12
3.2.1 Control Screen Sequence 14
3.3 Basic Measurement 15
3.3.1 Basic Flow up to Testing of the Sample 15
3.3.2 Setting the Test Parameters to be Displayed (Cs, D) 16
3.3.3 Setting the Test Frequency 18
3.3.4 Setting the Constant Voltage Level 21
3.3.5 Setting Open Circuit Compensation 23
3.3.6 Setting Short Circuit Compensation 26
3.3.7 Starting Testing 28
Chapter 4 Detailed Description of Functions 29
4.1 Description of the Screens 29
4.1.1 The Initial Screen 30
4.1.2 The Menu Screen and Application Menu Screen 31
4.2 Setting the Parameters to be Displayed 32
4.2.1 Control Screen Sequence 32
4.2.2 Details of the Setting Process 32
4.2.3 Series Equivalent Circuit Mode and Parallel Equivalent
Circuit Mode 34

4.3 Setting the Test Frequency 35
4.3.1 Control Screen Sequence 35
4.3.2 Selecting the Input Method 36
4.3.3 Input Using the Ten Key Screen 37
4.3.4 Input Using the Digit Screen 38
4.4 Setting the Test Signal Level 39
4.4.1 Control Screen Sequence 39
4.4.2 Selecting the Level Type 40
4.4.3 Setting the Open Circuit Voltage (V) Level 42
4.4.4 Setting the Constant Voltage (CV) Level 43
4.4.5 Setting the Constant Current (CC) Level 44
4.5 Setting the Voltage/Current Limit 45
4.5.1 Control Screen Sequence 45
4.5.2 Details of the Setting Process 46
4.6 Setting the Ranging 48
4.6.1 Control Screen Sequence 48
4.6.2 Setting the Ranging 49
4.6.3 Setting AUTO Ranging 49
4.6.4 Setting the Ranging to HOLD 50
4.7 Open Circuit Compensation 52
4.7.1 Control Screen Sequence 52
4.7.2 Setting the Compensation Method 53
4.7.3 ALL Compensation 54
4.7.4 Spot Compensation 56
4.7.5 When an Error Message Appears and Compensation
Has Stopped 59
4.7.6 Clearing Compensation Data 59
4.8 Short Circuit Compensation 60
4.8.1 Control Screen Sequence 60
4.8.2 Setting the Compensation Method 61
4.8.3 ALL Compensation 63
4.8.4 Spot Compensation 65
4.8.5 When an Error Message Appears and
Compensation Has Stopped 68
4.8.6 Clearing Compensation Data 68
4.9 Open Circuit Compensation and Short Circuit
Compensation 69
4.10 Setting the Trigger 71
4.10.1 Control Screen Sequence 71
4.10.2 Details of the Setting Process 72

4.11 Setting the Trigger Delay 74
4.11.1 Control Screen Sequence 74
4.11.2 Details of the Setting Process 75
4.12 Setting Averaging 77
4.12.1 Control Screen Sequence 77
4.12.2 Details of the Setting Process 78
4.13 Setting the Testing Speed 80
4.13.1 Control Screen Sequence 80
4.13.2 Details of the Setting Process 81
4.14 Setting and Activating the Comparator 82
4.14.1 Control Screen Sequence 83
4.14.2 Setting the Comparator 83
4.14.3 Returning from Comparator Operation to Normal
Testing 86
4.14.4 Choosing How to Set the Upper and Lower Limit
Values 86
4.14.5 Setting the Upper or Lower Limit Value as
an Absolute Value (ABS) 88
4.14.6 Setting the Upper or Lower Limit Value as
a Percentage (%) Relative to a Standard Value 90
4.14.7 Displaying Measurement Values as Deviations from
the Reference value (Δ%) 93
4.15 Setting and Activating the Scaling 95
4.15.1 Control Screen Sequence 95
4.15.2 Setting Scaling 96
4.15.3 Canceling the Scaling Function 97
4.15.4 Setting the Compensation Coefficient (a, b) 98
4.16 Panel Save Function 100
4.16.1 Control Screen Sequence 100
4.16.2 Details of the Setting Process 101
4.17 Panel Load Function 104
4.17.1 Control Screen Sequence 104
4.17.2 Details of the Setting Process 105
4.18 Setting the Beep Sound 107
4.18.1 Control Screen Sequence 107
4.18.2 Details of the Setting Process 108
4.19 Enlarged Display of Measurement Values 109
4.19.1 Control Screen Sequence 109
4.19.2 Details of the Setting Process 110
4.20 System Reset 111
4.20.1 Control Screen Sequence 111
4.20.2 Details of the Setting Process 112

4.21 Continuous Test Function 114
4.21.1 Control Screen Sequence 114
4.21.2 Details of the Setting Process 115
4.22 External DC Bias Setting 118
4.22.1 Control Screen Sequence 118
4.22.2 Details of the Setting Process 119
4.23 Setting the Number of Displayed Digits 120
4.23.1 Control Screen Sequence 120
4.23.2 Details of the Setting Process 121
4.24 Setting for Display 122
4.24.1 Control Screen Sequence 122
4.24.2 Details of the Setting Process 123
4.25 Key Lock Function 124
4.25.1 Turning the Key Lock On and Off 124
Chapter 5 Applications 125
5.1 Example of Comparator Application 125
5.2 Testing High Impedance Elements 127
5.3 Testing an Element in a Circuit 128
5.4 External Interference 129
5.4.1 Countermeasures Against Interference from the
Power Supply Line 129
5.4.2 Countermeasures Against Noise from the Test
Cables 131
5.5 The EXT I/O Connector 132
5.5.1 Pinouts for the EXT I/O Connector 133
5.5.2 Signal Lines for the EXT I/O Connector 134
5.5.3 Circuit Construction and Connections for the EXT I/O
Connector 136
5.5.4 Electrical Characteristics of the Output Signals 137
5.6 Testing Using EXT I/O 138
5.6.1 Normal Testing 138
5.6.2 Continuous Testing From EXT I/O 140
5.7 Supplying DC Bias 145
5.7.1 How to Supply a DC Bias Voltage 145
5.7.2 How to Supply a DC Bias Current 147
5.8 The Residual Charge Protection Function 148
5.9 9442 PRINTER (option) 149
5.9.1 Preparation 149
5.9.2 Connection Method 151
5.9.3 Control Screen Sequence 152

5.9.4 Returning from Comparator Operation to Normal
Testing 153
5.9.5 Screen Copy Mode 154
5.9.6 Auto Print Mode 155
5.9.7 Manual Print Mode 155
Chapter 6 Maintenance, Adjustment, and Disposal 157
6.1 Maintenance and Servicing 157
6.2 How to Change the Power Supply Fuse and Change
the Power Supply Voltage 159
6.3 Shipping the Unit 161
6.4 Troubleshooting Checklist 162
6.5 Disposing of the Unit 163
Chapter 7 Specification and Options 165
7.1 General Specification 165
7.2 Testing Parameters and Calculation Equations 170
7.3 Time Taken for Testing 172
7.4 Options 176
7.5 Test Accuracy 179
Index INDEX 1

i
────────────────────────────────────────────────────
────────────────────────────────────────────────────
Introduction
Thank you for purchasing the HIOKI "3522-50 LCR HiTESTER." To obtain
maximum performance from the product, please read this manual first, and
keep it handy for future reference.
This manual contains information and points for attention which are
necessary for safe operation of the unit and for storing it safely in proper
operational condition.

ii
────────────────────────────────────────────────────
────────────────────────────────────────────────────
NOTE
Shipping Check
When you receive the product, inspect it carefully to ensure that no damage
occurred during shipping. In particular, check the accessories, panel
switches, and connectors. If damage is evident, or if it fails to operate
according to the specifications, contact your dealer or Hioki representative.
Check the 3522-50 unit and the supplied accessories
Main unit
3522-50 LCR HiTESTER
Supplied accessories
(1) User manual ... 1
(2) Grounded power cord ... 1
(3) Spare fuse for power supply (according to voltage specification) ... 1
100 V, 120 V setting: 250 V F1.0AL 20 mm×5mmdia.
220 V, 240 V setting: 250 V F0.5AL 20 mm×5mmdia.
No interface boards and no test cables are supplied with the unit as standard
equipment. You should order them separately, according to requirements.

iii
────────────────────────────────────────────────────
────────────────────────────────────────────────────
WARNING This product is designed to comply with IEC 61010 Safety Standards,
and has been thoroughly tested for safety prior to shipment. However,
mishandling during use could result in injury or death, as well as
damage to the product. Be certain that you understand the
instructions and precautions in the manual before use. We disclaim
any responsibility for accidents or injuries not resulting directly from
product defects.
Safety symbols
The symbol printed on the product indicates that the user
should refer to a corresponding topic in the manual (marked with
the symbol) before using the relevant function.
In the manual, the symbol indicates particularly important
information that the user should read before using the product.
Indicates a grounding terminal.
Indicates AC (Alternating Current).
Indicates a fuse.
Indicates the ON side of the power switch.
Indicates the OFF side of the power switch.
WARNING Indicates that incorrect operation presents a significant hazard that
could result in serious injury or death to the user.
CAUTION Indicates that incorrect operation presents a possibility of injury to
the user or damage to the product.
NOTE Advisory items related to performance or correct operation of the
product.
Safety
This manual contains information and warnings essential for safe operation
of the product and for maintaining it in safe operating condition. Before
using the product, be sure to carefully read the following safety notes.
The following symbols in this manual indicate the relative importance of
cautions and warnings.

iv
────────────────────────────────────────────────────
────────────────────────────────────────────────────
Measurement categories (Overvoltage categories)
This instrument complies with CAT I safety requirements.
To ensure safe operation of measurement instruments, IEC 61010 establishes
safety standards for various electrical environments, categorized as CAT I to
CAT IV, and called measurement categories.
CAT I Secondary electrical circuits connected to an AC electrical outlet
through a transformer or similar device.
CAT II Primary electrical circuits in equipment connected to an AC
electrical outlet by a power cord (portable tools, household
appliances, etc.)
CAT II covers directly measuring electrical outlet receptacles.
CAT III Primary electrical circuits of heavy equipment (fixed installations)
connected directly to the distribution panel, and feeders from the
distribution panel to outlets.
CAT IV The circuit from the service drop to the service entrance, and to
the power meter and primary overcurrent protection device
(distribution panel).
Using a measurement instrument in an environment designated with a
higher-numbered category than that for which the instrument is rated could
result in a severe accident, and must be carefully avoided.

v
────────────────────────────────────────────────────
────────────────────────────────────────────────────
WARNING Before turning the product on, make sure the source voltage
matches that indicated on the product's power connector.
Connection to an improper supply voltage may damage the product
and present an electrical hazard.
To avoid electric shock and ensure safe operation, connect the
power cable to a grounded (3-contact) outlet.
The 3522-50 contains certain interior components which are at very
high voltages. Never remove the cover of the unit, because to do so
is very dangerous.
CAUTION Various connectors are present on the outside of the 3522-50. Never
connect any cable to any of these connectors without first turning off the
power supply and removing the power cord. Moreover, check the
connections carefully in order to avoid any chance of setting up a short
circuit etc..
If anything unusual happens during operation of the unit, turn off the
power switch immediately and contact any HIOKI service facility for help,
advice and service.
This product should be installed and operated between 0 and 40 and
80% RH or less, and less than 2000 m height.
The unit should always be stored in a range of temperature and humidity
from -10 to 55 , 80% RH or less.
Do not store or use the product where it could be exposed to direct
sunlight, high temperature or humidity, or condensation. Under such
conditions, the product may be damaged and insulation may deteriorate
so that it no longer meets specifications.
To avoid damage to the product, protect it from vibration or shock during
transport and handling, and be especially careful to avoid dropping.
Do not use excessive force on the touch panel, and do not use sharp
objects that could damage the touch screen.
Before using the product, make sure that the insulation on the probes is
undamaged and that no bare conductors are improperly exposed. Using
the product in such conditions could cause an electric shock. Replace the
test leads and probes specified by Hioki.
Ventilation holes for heat radiation are provided on the side panels of the
product. Leave sufficient space around the ventilation holes and install
the product with the holes unobstructed. Installation of the product with
the ventilation holes obstructed may cause a malfunction or fire.
Points for Attention During Use
Follow these precautions to ensure safe operation and to obtain the full
benefits of the various functions.
About the guarantee
You should be aware that HIOKI cannot accept any responsibility directly or
indirectly if the unit has been incorporated in some other system, or if it is
resold to a third party.

vi
────────────────────────────────────────────────────
────────────────────────────────────────────────────
Layout of This Manual
Chapter 1 Overview
Describes the product generally, and lists the parts and functions.
Chapter 2 Before Starting Measurement
How to connect the power cord etc., and important precautions before
operation.
Chapter 3 Outline of Operation
Explains the touch panel and basic testing.
Chapter 4 Detailed Description of Functions
Detailed explanation of the functions.
Chapter 5 Detailed Description of Applications
Various testing applications.
Chapter 6 Maintenance, Adjustment, and Disposal
Chapter 7 Specification and Options
Index

1
────────────────────────────────────────────────────
1.1 Product Overview
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
Chapter 1
Overview
1.1 Product Overview
The HIOKI 3522-50 LCR HiTESTER is an impedance meter which uses a
touch panel as the user interface. This interactive touch panel enables
extremely easy operation. The test frequency can be set DC and from 1
mHz to 100 kHz at high resolution.
The values of a maximum of any four of the fourteen test parameters,
including not only impedance |Z| and phase angle θ, but also L, C, and R
etc., can be simultaneously displayed upon the screen.
Moreover, this widely applicable impedance meter can be set, not only to a
floating voltage setting, but also to a constant voltage setting or a constant
current setting.

2
────────────────────────────────────────────────────
1.2 Product Features
────────────────────────────────────────────────────
1.2 Product Features
Wide range of test frequencies
The test frequency can be selected from a wide range - DC, 1 mHz to 100
kHz - at high resolution. Frequency dependent assessment of electronic
components and materials, etc., is possible.
Constant voltage and constant current testing
Assessment of dependence upon voltage or current is possible.
Outstanding operability
All control operations are initiated via a touch panel on the display. All the
keys currently available for use are shown on the display, and can be
operated interactively.
Simultaneous display of four parameters
Up to four of the test parameters (such as L,C,R, etc.) can be displayed
simultaneously.
Interface
Using a computer, any required parameters can be captured
Changing settings without stopping measurement
Various background settings can be changed without stopping measurement
(when an internal trigger is set).

3
────────────────────────────────────────────────────
1.3 Names and Functions of Parts
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
Test terminals
Contrast adjustment knob
Power switch
Liquid crystal display
Front View
1.3 Names and Functions of Parts
Liquid crystal display
This is a 5-inch liquid crystal display fitted with a touch panel. It also
serves to provide input keys.
Power switch
Turns the power for the unit on and off.
Contrast adjustment knob
This knob adjusts the screen contrast. Turning it clockwise decreases the
contrast, and vice versa.
Test terminals
There are five test terminals:
HCUR The test signal is supplied to this terminal.
HPOT Detected voltage high terminal
LPOT Detected voltage low terminal
LCUR Test current detected terminal
GUARD Guard terminal
These test terminals are designed according to the safety standard;
Pollution Degree 2, Measurement category I.

4
────────────────────────────────────────────────────
1.3 Names and Functions of Parts
────────────────────────────────────────────────────
Power input socket
with voltage selector Optional equipment interface
Key lock switch
EXT I/O connector
Rear View
Power input socket (internally fused type) with voltage selector
Connect the supplied power cord here.
Optional equipment interface
Optional interface boards are connected here.
EXT I/O connector
For input of an external trigger signal and output of comparator results.
Compatible with sequencer connection.
Key lock switch
Puts the touch panel keys into the input-not-accepted state.

5
────────────────────────────────────────────────────
1.3 Names and Functions of Parts
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
Stand
Handle
Left View
CAUTION Do not apply strong downward pressure with the stand extended.
Damage to the stand will result.
Stand
Can be opened to tilt the unit upwards.
Handle
Used when carrying the unit.

6
────────────────────────────────────────────────────
1.3 Names and Functions of Parts
────────────────────────────────────────────────────
