HUROM H-200 Series User manual

※ 발주용 인쇄시 본 페이지(시방서) 삭제 후 진행
시방서
DESIGN SPECIFICATION
R&D2본부 디자인팀 자재명(자재번호 / 파일명 / 버전) : 작성일 :
❶ 사이즈
❷ 인쇄도수
❸ 지류
❹ 페이지
❺ 제본
❻ 후가공
1. 자재 사양
2. 기재 언어
3. 제작 및 수정일자
4. 수정사항
※ 발주용 인쇄 시 필히 본 페이지(시방서) 삭제 후 진행하세요. 본 파일은 시방과 인쇄파일을 포함합니다. 유관의 부서와 업체의 견적 / 사양 / 발주 인쇄 진행 / 품질검사 외에는 사용을 금합니다.
인쇄물 시방서 개정 : 19' 11
주민아 4DC010798 사용설명서 통합 H200 Serise 영문_V.01 2020. 01. 28
150 x 220 mm
표지- 1도 인쇄
내지- 1도 인쇄
M 메트지 100g
12페이지
중철
없음
영문
1. 2020.01.20-V.01
-문구추가p.3 <
DO NOT USE THE APPLIANCE
IF THE ROTATING SIEVE OR THE PROTECTING
COVER IS DAMAGED OR HAS VISIBLE CRACKS.
EXCLUSIVELY FOR HOUSEHOLD USED ONLY>
1. 해당없음
4DC010798 사용설명서 통합 H200 Serise 영문_V.01.indd 1 2020-01-28 오후 3:21:47

TM
4DC010798 사용설명서 통합 H200 Serise 영문_V.01.indd 1 2020-01-28 오후 3:21:47

02
01 You should read <Safety Precautions>
02 You should follow <Safety Precautions>
03 Precautions are classified as follows.
1. Safety Precautions
OUTLET WHILE THE JUICER IS RUNNING.
WHEN THE POWER CORD, WIRE IS BROKEN OR
DAMAGED OR THE PLUG-IN PART BECOMES LOOSE,
DO NOT OPERATE THE MACHINE. IF THE SUPPLY
CORD IS DAMAGED, IT MUST BE REPLACED BY THE
MANUFACTURER, IT'S SUERVICE AGENT OR SIMILARLY
QUALIFIED PERSONS IN ORDER TO AVOID A HAZARD.
DO NOT WET OR SPLASH WATER ON THE MAIN BODY.
Be careful not to let any liquids or other substances get into the
switch on the appliance.
DO NOT OPERATE THE POWER DIAL WITH WET HANDS.
FOR SAFETY, GROUND THE APPLIANCE. (MAKE SURE
TO USE THE OUTLET WITH GROUND CONNECTION.)
DO NOT GROUND TO GAS PIPE, PLASTIC WATER PIPE,
TELEPHONE LINE, AND SO FORTH. It could cause electric
shock, fire, malfunction or explosion.
NEVER DISASSEMBLE THE CHAMBER SET DURING
OPERATION NOR INSERT FINGERS, FOREIGN OBJECTS
SUCH AS FORKS, SPOONS, ETC. INTO HOPPER CHUTE OR
JUICE OUTLET.
APPLIANCESCANBEUSEDBYPERSONSWITHREDUCED
PHYSICAL, SENSORY OR MENTAL CAPABILITIES OR LACK
OF EXPERIENCE AND KNOWLEDGE IF THEY HAVE BEEN
GIVEN SUPERVISION OR INSTRUCTION CONCERNING
USE OF THE APPLI ANCE IN A SAFE WAY AND IF THEY
UNDERSTAND THE HAZARDS INVOLVED. CHIL DREN
SHALL NOT PLAY WITH THE APPLIANCE. CLEANING
AND USER MAINTENANCE SHALL NOT BE MADE BY
CHILDREN. THIS APPLIANCE SHALL NOT BE USED BY
CHILDREN. KEEP THE APPLIANCE OUT OF REACH OF
CHILDREN.
DO NOT USE THE PRODUCT WHILE WEARING OR
CARRYING ITEMS WITH MAG NETIC FORCE (E.G.,
MAGNETIC BRACELETS, ETC.). Placing objects with magnetic
force around the product may lead to malfunctions.
Caution Violating the labeling requirement, may
cause serious injury or damage to the appliance.
DO NOT RUN THE JUICER WHILE THE CHAMBER SET IS
NOT ASSEMBLED PROPERLY.
WHEN DETECTING A GAS LEAK, DO NOT INSERT THE
POWER CORD INTO THE OUTLET. OPEN THE WINDOW TO
VENTILATE FULLY AND IMMEDIATELY.
NEVER INSERT UTENSILS SUCH AS CHOPSTICKS OR
SPOONS INTO THE JUICE/PULP VENT.
IF THE SQUEEZING SCREW STOPS SPINNING DURING
NORMAL OPERATION, PRESS THE "REV" BUTTON AND
HOLD FOR 3 TO 5 SECONDS TO ACTIVATE REVERSE
ROTATION. AFTER REVERSE ROTATION STOPS
COMPLETELY, PRESS "ON" BUTTON AGAIN TO RESUME
NORMAL OPERATION. If the screw continues to stop during
the operation, the parts may be damaged or performance
may be impaired due to overheating in the motor. When such
a problem continues, stop using the product and contact our
Warning Violating the labeling requirement, may
cause serious injury or death.
DO NOT PLUG IN NOR UNPLUG WITH WET HANDS.
USE THE RIGHT VOLTAGE ONLY AS SPECIFIED ON THE
WARRANTY CARD AND THE PRODUCT SPECIFICATIONS.
FAILURE TO FOLLOW THIS INSTRUCTION MAY RESULT
IN ELECTRIC SHOCK, FIRE, OR PERFORMANCE
IMPAIRMENT. Connecting to a different voltage may shorten
the motor's lifespan or cause malfunction.
PLUG THE POWER CORD CORRECTLY AND FIT IT
TIGHTLY INTO A WALL SOCKET.
IFTHEPOWERCORDISDAMAGED,ITMUSTBEREPLACED
BY THE MANUFACTURER’S ITS SERVICE OR SIMILARLY
QUALIFIED PERSONS IN ORDER TO AVOID A HAZARD. If the
power cord is damaged, it may cause electric shock or fire.
NEVERDISASSEMBLECHAMBER SET PARTSORINSERT
ALIEN SUBSTANCES INTO THE JUICE OUTLET AND PULP
1. Read 'Safety Precautions' (p. 2~3) and use the
appliance properly.
2. After reading the manual, keep it in a convenient
location for future reference.
3. Do not use it abroad which has different power
supply and voltage.
4. Any quality improvements is subject to change
without notice.
Before Reading Manual
Instruction Manual [ Home use only / Warranty not included ] | H-200 Series
CONTENS
1. Precautions for Safe Use
2. Cautions During Operation
3. Power Switch /
4. Precautions for Strainers
5. How to Assemble
6. Plugging and Unplugging Silicone
7. How to operate
8. When the squeezing screw stops
during normal operation
9. How to disassemble and clean
10. Before requesting repair
P 02
P 03
P 04
P 06
P 07
P 08
P 09
P 10
P 11
4DC010798 사용설명서 통합 H200 Serise 영문_V.01.indd 2 2020-01-28 오후 3:21:48

03
local customer service center.
DURING THE OPERATION, DO NOT ATTEMPT TO MOVE
THE MAIN BODY, DISASSEMBLE THE CHAMBER SET OR
PARTS, OR TRY TO LOCK THEM. It may cause an injury or a
failure. If any action is needed, switch off and unplug the power
cord first.
MAKE SURE NO ALIEN SUBSTANCES GET INTO THE
HOPPER OTHER THAN INGREDIENTS WHEN USING THE
JUICER.
PLACE THE APPLIANCE ON A FLAT AND STABLE
SURFACE.
DO NOT OPERATE THE APPLIANCE FOR MORE THAN
30 MINUTES AT A TIME. It may cause a motor failure due
to overheating. Cool it down sufficiently about 5 minutes and
operate it again.
DO NOT ALLOW A SEVERE SHOCK TO THE APPLIANCE
NOR DROP IT.
IF THE APPLIANCE GIVES OFF AN UNPLEASANT SMELL,
EXCESSIVE HEATING, OR SMOKE, STOP USING THE
APPLIANCE IMMEDIATELY AND CONTACT THE LOCAL
CUSTOMER CARE CENTER. When using a new appliance, it
gives off a smell, which disappears naturally over time.
ALWAYS UNPLUG THE APPLIANCE AFTER USE. ALWAYS
DISCONNECT THE APPLI ANCE FROM THE POWER
SOURCE IF IT IS LEFT UNATTENDED AND BEFORE AS
SEMBLING, DISASSEMBLING OR CLEANING. WHEN
UNPLUGGING THE POWER CORD, MAKE SURE TO HOLD
THE POWER CORD BY ITS HEAD.
DONOTWASHTHEAPPLIANCEATAHIGHTEMPERATURE,
800C(1760F) OR HIGHER. DO NOT PUT THE APPLIANCE IN A
DISHWASHER, A DRYER OR A MICROWAVE ETC.
THE MACHINE WEIGHS ABOUT 6.5kg. WHEN YOU ARE
MOVING THE MACHINE, MAKE SURE YOU HOLD THE
MAIN BODY TIGHTLY WITH BOTH HANDS. When you hold
the machine by the chamber or the side of the main body, the
main body may fall and result in injury or malfunction.
DO NOT USE HOUSEHOLD PRODUCTS FOR COMMERCIAL
PURPOSE. Forcing a large amount of ingredients for extraction
may damage the parts. Please contact the Customer Service
Center for the advice on using the product for commercial
purposes.
DO NOT USE THE APPLIANCE IF THE ROTATING SIEVE OR
THE PROTECTING COVER IS DAMAGED OR HAS VISIBLE
CRACKS.
EXCLUSIVELY FOR HOUSEHOLD USED ONLY
Make sure to properly read the instructions for
preparing ingredients before inserting them.
- Poorly prepared ingredients may hinder the extraction
process and/or cause damage to the product.
Ingredients that need extra care
- When using soft ingredients alone, such as mangoes,
2. Cautions during Operation
bananas, or strawberries, the juice may pool inside the
chamber and not be extracted properly. Please add other
ingredients that are not too soft.
-For walnuts, peanuts, almonds, sunflower seeds, pine
nuts, beans, etc., insert only a small amount or use them
with other ingredients after steeping in water.
Ingredients that cannot be juiced
- Do not use unjuiceable ingredients such as sesame
seeds, coffee beans, tree barks, or Chinese peppers. Do
not insert mudfish, eel, shrimp, marsh snail, squid, etc.
- Do not use fruits soaked in alcohol, honey, or sugar
(e.g., grapes, raspberries, or mulberries) and herbal
ingredients (e.g., glasswort or rock pine enzymes).
- Do not use any ingredients that are unjuiceable in nature,
such as autumn olive, aloe, cactus, quince, banana, yam,
kudzu root, sugar cane, acorn, and dandelion.
- Do not use boiled ingredients such as boiled potato,
boiled sweet potato, and boiled bean. Do not use this
product for grinding grains.
- Do not use frozen ingredients for juicing.
We recommend that you consume the juice
immediately, if possible, and not refrigerate it over a
long period of time.
Do not use this product for grinding grains. (Failure
to follow this instruction may cause malfunction or
damage to the product.)
Do not re-squeeze pulp discharged through the pulp
outlet.
Do not idle the product before inserting ingredients.
Do not overload ingredients into the hopper above the
guided limit mark.
Do not use for more than 30 minutes in a continuously.
- It may cause a failure due to the overheating of the motor.
When using the appliance continuously, stop for 5 minutes
after every 30 minutes of use.
Never insert chopsticks or spoon into pulp outlet during
the operation.
- Inserting chopsticks and the like may cause damage to
parts and personal injury.
Do not press the ingredients with anything except the
pusher.
- It may stick to the screw and cause injury and failure.
Do not operate the power dial with a wet hand
- It can cause electric shock, short circuit, or fire. Do
not stain the power dial and its proximity with alien
substances.
Keep the juice cap open while juicing, and empty the
pulp container frequently when juicing several times or
in bulk.
- Juice or pulp may overflow the container. The juice can
flow backwards into the hopper if the juice cap is closed.
If you do not wash immediately after use, it may be
caked with pulp, which makes it difficult to disassemble
and wash or may become the cause of performance
degradation.
4DC010798 사용설명서 통합 H200 Serise 영문_V.01.indd 3 2020-01-28 오후 3:21:48

04
누름
정회전
역회전
작동스위치 정회전
역회전
4. Precautions for strainers
3. Power Switch
[ ] : Stop - Press it to stop the
operation of the product.
Press and hold the switch for the product operations.
[ ] : REV - Press when the
production halts while in use
due to material overload. ※ The
appliance works only when the
button is pressed, and it stops
when the button is released.
※When you prepare juicing ingredients, choose
your own proper ingredients if you have any food
allergy.
※Refer to the ingredient preparation guide and
choose the right strainer type accordingly.
※Please refer to the recipe book for how to use the
product and tips for different ingredients.
※Juicing ingredients should be cut small enough
for the hopper. When you want faster or large
juicing process, chop up ingredients a bit smaller.
For every 1 kg extraction, repeat the "disassemble
and rinse" cycle.
※Do not overload ingredients into the hopper
above the guided limit mark.
※Fine strainer for soft fruits may cause pooling in
the chamber.
※Coarse strainer for fibrous fruit vegetables may
cause thick juice extraction.
※Ingredients to avoid: Inserting the following
ingredients may cause product damage or
breakdown.
- Unjuiceable ingredients such as sesame seed, coffee
bean, Chinese pepper, tree bark, or pine leaf. Mudfish,
eel, shrimp, marsh snail, squid, etc.
- Do not use fruits soaked in alcohol, honey, or sugar
(e.g., grapes, raspberries, or mulberries) and herbal
ingredients (e.g., glasswort or rock pine enzymes).
- Any ingredients that are unjuiceable in nature such as
autumn olive, aloe, cactus, quince, banana, yam, kudzu
root, sugar cane, acorn, dandelion
- Boiled ingredients such as boiled potato, sweet potato,
bean, etc.
- Do not use this product for grinding grains.
- Frozen ingredients
※Please refer to <Precautions during Operation>.
(refer to 3P)
누름
정회전
역회전
작동스위치 정회전
역회전
정회전
역회전
정지상태
작동스위치 정회전
역회전
off(정지) 정지
정회전
역회전
정지상태
작동스위치 정회전
역회전
off(정지) 정지
[ ] : ON - Starts the motor and
makes juice.
4DC010798 사용설명서 통합 H200 Serise 영문_V.01.indd 4 2020-01-28 오후 3:21:49

05
4-1. Coarse strainer (orange) 4-2. Fine strainer (black)
• Use this strainer for juicing fibrous roots, stalks, or
leafy vegetables.
(Use the coarse strainer for general fruit vegetables.)
• Strainer mark: The strainer is black and has a
strainer mark [ B ] on its hook.
• As some ingredients need extra care in trimming,
please refer to the preparation guide below.
• When juicing several times or in bulk, cut ingredients
smaller pieces, repeat "extract, disassemble, and
clean" cycle, and empty out the pulp container
frequently.
•For even faster process, cut ingredients into
smaller pieces as well.
Root vegetables
Carrots, beets, ginger, yam, potatoes, garlic, etc.
Make sure to wash dirt and debris off the roots with
running water. Peel outer skins of fibrous ingredients
such as ginger, and cut long ingredients into sticks for
extraction.
Leaf • stalk vegetables
Celery, kale, cabbage, watercress, wheat sprout,
chives, etc.
Cut the ingredients into 3 cm or shorter pieces for
extraction. As leaf stalk vegetables are rough and
fibrous, they are not squeezed well, or the screw can
get tangled.
•Find a strainer for root, leaf, stalk vegetables
cause pooling in the chamber. Please use the coarse
strainer.
• Use it for extraction of general fruits and vegetables.
• Strainer mark: It is translucent orange and has
strainer mark [A] on its hook.
Citrus fruits
Grapefruit, orange, lemon, etc.
Peel outer skin and cut the fruits into small size for the
hopper chute. Remove all the hard, unchewable seeds or
pits before insertion.
Fruits with thick rind
Pineapple, dragon fruit, melon, watermelon,
pomegranate, etc.
Peel outer skin and cut the fruits into small size for the
hopper chute. Remove fruit seeds that are hard to chew
before insertion.
Fruits with hard seeds
Grape, apple, peach, persimmon, plum, cherry, pear,
Korean melon, etc.
Use flesh only after removing hard, unchewable hard part
of fruit, such as a peach pit. Hard seeds cause the product
to halt while in use and may damage the product
components. Remove apple seeds, if possible, as they can
be toxic when ground. For grapes, pluck each grape from
the bunch after rinse. Do not use too soft ingredients alone,
but instead insert them with other fruit vegetables.
Fruits of soft, juicy texture
One-Ingredient Extraction
(berries, cherry tomatoes, pineapples, etc.)
※After cleansing, cut the ingredients into small pieces for
the hopper hole. Remove stalk ends from the fruit
vegetables.
Mixture Extraction
(strawberry, kiwi, banana, tomato, mango, etc.)
※For dry and viscous ingredients, mix with other
ingredients for juicing. Remove the rind and stalk in
advance. Remove mango seeds.
J
4DC010798 사용설명서 통합 H200 Serise 영문_V.01.indd 5 2020-01-28 오후 3:21:49

06
5. How to Assemble
Make sure to align groove in the chamber(⑦-5) external strainer wing(⑤/⑥).
Assemble the inner strainer and squeezing screw onto the external strainer of chamber.
The settlement point of the inner strainer (④-1) and the wing of outer strainer (⑤-1 / ⑥-1) should
be aligned in place.
Place the hopper lid (①-3) vertically onto the hopper (②-1).
Align the guide mark (⑦-1) of the hopper [ ] with the guide mark (②-3) of the chamber [ ].
Turn the assembled hopper clockwise until its guide mark is aligned with the guide mark [
] on the chamber.
If the internal components are not assembled correctly, the hopper will not close properly.
Make sure the discharge cover (⑦-2) of the chamber is properly fastened with the loop.
1. Close the discharge cover and fasten it with the loop.
2. If the silicone parts are not plugged in place, or the lever is not fastened,
juice may leak or the lever may open during extraction.
Place the well-assembled chamber set onto the base.
01
02
03
04
05
06
07
⑤-1
/⑥-1
⑦-5
③
①-3
②-1
⑦-2
④-1
⑦-5
01 02 03
06
04
②-3
05 ①
⑦-1
4DC010798 사용설명서 통합 H200 Serise 영문_V.01.indd 6 2020-01-28 오후 3:21:51

07
6. Plugging and Unplugging Silicone
※Silicone packings are supposed to be replaced
every 6 to 12 months. You can purchase them
through our Customer Service Center.
01
02
03
(The juicer may leak if the product is not assembled
properly.)
Hold the silicone ring and pull it out smoothly.
After cleaning, plug the silicone ring upright into
the slot by fixing one end into place first.
Insert the rest and press down firmly.
Extraction Packing
Seal Packing
01
02
⑦-3
⑦-3
01
02
⑦-4
⑦-4
After cleaning, firmly insert with the round side
outward and the grid hollow facing upward.
Plug the silicone packings upright.
Juice Cap Packing
Hopper Packing
01
02
03
Grab onto one side and pull out.
After cleaning, plug the silicone rings upright
into the slot as if it is hanged one side first.
Press the rest of packing down along the slot
in place without any folded part.
⑦-6
⑦-8
Chamber Packing
②-4
4DC010798 사용설명서 통합 H200 Serise 영문_V.01.indd 7 2020-01-28 오후 3:21:52

08
7. How to operate
04
07
05
08
06
09
정회전
역회전
정지상태
작동스위치정회전
역회전
off(정지)정지
01 0302
누름정회전
역회전
작동스위치 정회전
역회전
누름
정회전
역회전
작동스위치 정회전
역회전
정회전
역회전
정지상태
작동스위치 정회전
역회전
off(정지) 정지
4DC010798 사용설명서 통합 H200 Serise 영문_V.01.indd 8 2020-01-28 오후 3:21:53

09
01 Press and hold [REV] button for 3 to 5
seconds and release the button 2 to 3 times.
[REV] button pushes the ingredients back up to
dislodge. Reverse rotation continues only when
the button is pressed while the screw stops
when the button is released.
02 After reverse rotation stops completely,
press the [ON] button to run operation.
When pressing the [ON/Extract] or [REV/
Reverse] button, make sure to press it after the
screw stops moving completely.
Precautions
If the juicer does not work after these steps,
unplug the appliance, and disassemble and
clean the parts before operating the juicer
again.
The motor will continue to spin after the
machine is turned off, but it will slow down and
come to a complete halt.
8. When the squeezing screw stops
during normal operation
01
02
01 Pull up the lever inside the hopper knob and open
the lid.
①Pull up the lever inside the hopper knob, and open
the lid. Overloading the product with ingredients may
damage the product.
02 Insert juicing ingredients below the limit mark of
the hopper.
①Use watery soft ingredients after mixing them with
others.
②When juicing in bulk, empty out the chamber and
the pulp container frequently.
03 Close the hopper lid, and keep the juice cap open.
①Before pressing the ON button, put the juice
container in place.
②The juice can flow backwards intothe hopper if the
juice cap is closed. If the juice doesn't empty even after
opening the juice cap, open the hopper lid and remove
the contents.
04 Press the [ON] button to start operation.
①"Clicking" sound upon starting is made when the
chamber set fits with the motor.
05 If you want to add more ingredients during
operation, use the add door on the top or open up the
hopper lid.
①Operation stops when the hopper lid is open.
②Do not use any other voltages other than the
designated one.
③When the screw spins and the ingredients are
not being ground, use the pusher to push down
ingredients.
06 Empty out the pulp container behind the base
frequently in order to prevent the back of the product
to become full with wastes.
07 Let the product run for another minute or so after
the last ingredient goes down through the hopper.
①It takes some time for the last piece to be extracted
as it is pressed down the product slowly.
②Run the appliance after the extraction to send out
residual pulp, and it will be easier to disassemble and
clean the hopper.
08 Once the extraction and release of residue is
done, switch off the juicer.
①The juicer stops 3 seconds after it is switched off.
09 Pour any juice left in the product by tilting the
chamber set forward.
①For thick juice like tomato juice, it is likely to pool in
the chamber set.
누름
정회전
역회전
작동스위치 정회전
역회전
누름
정회전
역회전
작동스위치 정회전
역회전
정회전
역회전
정지상태
작동스위치 정회전
역회전
off(정지) 정지
4DC010798 사용설명서 통합 H200 Serise 영문_V.01.indd 9 2020-01-28 오후 3:21:54

10
9. How to Disassemble and Clean
After the product stop operating completely,
unplug the power cord with your dry hands.
The motor is still slowing down after the
appliance is turned off, so wait about 3 seconds
before separating the chamber.
Separate the chamber set from the base. Turn
the hopper open and pull off the parts in order.
Wash the parts under running water with the
cleaning brush.
Wash the chamber with the pulp outlet cover
and the juice cap wide open.
Wipe the base with a dry towel or soft cloth.
For silicon rings, detach and wash them after
use. -There may be juice residues stuck in.
(Hopper ring, juice cap, extraction cap, sealing,
and chamber ring)
You can sterilize the parts by soaking them in
warm water with baking soda, citric acid, or
vinegar.
※Clean the appliance right after use. Otherwise, it
will be harder to disassemble parts and clean off dry
residue inside, and it may also cause performance
impairment. For long-term storage, clean the
appliance with the cleaning brush in advance.
Do not clean the product with boiling water or subject it
to high temperature.
Do not use abrasive cleaning tool like kitchen sink
cleaner, or stainless-steel sponge.
Do not use a dishwasher or dish dryer for the product.
After cleaning, completely air dry the appliance and
store it at a clean place.
※
01
02
03
04
05
06
4DC010798 사용설명서 통합 H200 Serise 영문_V.01.indd 10 2020-01-28 오후 3:21:56

11
Check the following before asking for repair. For follow-up service and any inquiry
you may have while using the product, please contact our Customer Center, or
homepage at http://www.globalhurom.com Check the manufacturer’s number or
the number under the barcode when requesting for follow-up service or parts.
10. Before
Requesting Repair
01. When the product starts
operation, it will make a
"clicking" sound.
02. The product won't operate
with the main body only.
03. Align the safety sensors.
04. The product does not work.
05. The product suddenly
stops running.
06. There are cracks on the
screw and scratch marks on
the upper part of the screw.
07. Juice leaks through the
pulp outlet immediately upon
inserting ingredients.
08. Juice flows back into the
hopper.
09. Juice leaks between the
hopper and the chamber, or
between the chamber and the
main body.
10. I can't open the hopper.
11. The chamber is vibrating
(during juicing).
12. Pulp outlet is covered, but
the pulp comes out.
This is the sound of when the motor and the squeezing screw are connected.
and not a sign of malfunction.
Make sure the chamber set and main body are assembled properly.
Ensure the product is unplugged before assembling or disassembling it.
Make sure they are assembled in accordance with the assembly guide.
Ensure the product is unplugged before assembling or disassembling it.
Check if the power cord is plugged properly.
The machine may not work after prolonged use (30 minutes or longer).
It will resume normal operation once the main body (motor) cools down.
Check if the hopper fits properly.
If the hopper is connected incorrectly, the product will not operate properly.
It will operate only when the lock symbol on the chamber is perfectly aligned
with the assembly guide on the hopper (②-3). Ensure the product is assembled
in accordance with the assembly guide. Refer to the assembly page 6 of the
instruction manual.
Is the hopper overloaded with juicing ingredients, or are the ingredients too big?
Refer to the manual page 9, and activate reverse rotation.
In addition to the straight molding marks on the top and sides of the screw, there
are curved marks that were created while it was being molded.
These marks are normal and they have no impact on your use of the screw.
A little juice may come out of the pulp outlet depending on the ingredient.
This is not a product defect but the result of the characteristics of the ingredient.
The leakage will stop once the product starts running. If the leakage persists,
contact our Customer Service Center.
Did you operate the product with the juice cap closed? Closure of the juice cap
may cause a back flow up to the hopper. If the flow gets clogged even after opening
the juice cap, open the hopper lid and empty out the inside.
Is the hopper silicone ring assembled correctly?
Juice will leak if the chamber silicone ring has been assembled upside down or
incompletely. Check if the silicon rings have been assembled correctly.
There may be excessive pulp remaining inside. If the remaining pulp is discharged
by turning on the machine, or the machine is rotated in reverse for 10 seconds two
or three times, the hopper will open smoothly.
Perhaps you put foreign or solid substances (hard seeds such as persimmon
seeds)? If you have put foreign or solid substances, attempting to run the product
in reverse direction may further damage the component. Thus, contact our
Customer Service Center and request after-sales support.
The product may wobble slightly due to the vibrations produced by the main
body's motor. It may vibrate depending on the ingredient's hardness or toughness.
This is not a malfunction but a normal sign as it is caused by the rotating screw.
The product may seem to vibrate more when juicing solid ingredients (e.g.,
carrots, potatoes, radishes, beets, or kohlrabies) than when juicing soft and
watery ingredients. (e.g., carrot. potato, radish, beet, kohlrabi, etc)
Even if the lever is closed, pulp may still come out naturally.
The velocity and amount of pulp discharge may differ according to the ingredients
used.
4DC010798 사용설명서 통합 H200 Serise 영문_V.01.indd 11 2020-01-28 오후 3:21:56

4DC010798_V.01
MADE IN KOREA
Copyright© All Rights Reserved by HUROM
TM
4DC010798 사용설명서 통합 H200 Serise 영문_V.01.indd 12 2020-01-28 오후 3:21:56
