HUROM HN Series User manual

HN-SERIES
Terms of parts How to assemble
Cautions during operation When auger stops during
operation
Disassembling and cleaning
the spinning brush
Assembling the juice cap
seal
Assembling the spinning
brush
Before requesting for
repair
Assembling the chamber
seal
Product Specifications /
Warranty
01 02
Precautions for safe use
03 05 06
07
10
08
11
09
12
Hurom Juicer Household Use (Warranty Included)
1. Read ‘Precautions for safe use’ (Page 6) and use the appliance properly.
2. After finish reading the manual, keep it in a convenient location for future reference.
3. Do not use it abroad which has different power supply and voltage.
4. Any quality improvements are subject to change without notice.

01
19
15
14
11
5
07
Pusher
Hopper
Auger
Fine Strainer
Coarse Strainer
Spinning Brush
Silicone Brush
Chamber
Pulp Outlet
Juice Outlet
Juice Cap
Base
Pulp Container
Juice Container Lid
Juice Container
Small Cleaning Brush
Cleaning Brush
Hopper Lid
Operating Switch
Power Cord
Chamber Set Stand
09
10
11
12
13
14
15
16
17
18
19
01
02
03
04
05
06
07
08
08-1
08-2
01
02
03
04
06
08
08-1
09
12
13
18
17
16
Terms of parts
Terms of parts
08-2
10
open
close

www.hurom.com | 02
How to assemble
OPEN
open
close
Place the chamber on the base.
Make sure to press the auger down into the strainer in
STEP 2. The hopper does not close properly when the
auger does not fit in completely.
Assemble the parts in the following order:
Chamber>Spinning Brush> Strainer. Make sure
chamber arrow [ ] aligns with strainer arrow [ ].
Align the chamber arrow [ ] with hopper arrow [
OPEN] and turn the hopper clockwise until it clicks so
that the hopper arrow [ CLOSE] aligned with cham-
ber arrow[ ].
The spinning brush can be assembled regardless
of the direction.
4
3
2
1
STEP
STEP
STEP
STEP

03
1. You should read <Precautions for safe use>
2. You should follow <Precautions for safe use>
3. Precautions are classified as follows.
Warning When violating the labeling requirement, it may cause serious injury or death.
Do not plug in nor unplug with wet hanDs. It may cause electric shock or injury.
Do not use other than 230V - 240V aC. It may cause electric shock, fire or abnormal performance.
If the voltage is different, it may shorten the life of the motor or cause a failure.
plug the power CorD CorreCtly anD push it tight in a wall soCket.
It may cause an electric shock or a fire.
iF the supply CorD is DaMageD, it Must Be replaCeD By the ManuFaCturer
its serViCe or siMilarly QualiFieD persons in orDer to aVoiD a haZarD.
If the power cord is damaged, it may cause electric shock or fire.
neVer alter the applianCe. also, Do not DisasseMBle or repair By your-
selF. Do not insert Fingers, Foreign suBstanCes or oBjeCts suCh as pins
into gaps or holes in the Base.
It may cause a fire, electric shock or failure. For any technical support, contact the authorized local Customer Care Center.
when the power CorD, wire was Broken or DaMageD or the plug-in part
BeCaMe loose, Do not operate it. It may cause electric shock, fire or injury.
Do not Moisten the Base or splash water on the Base.
Be careful not to let any liquids or other substances get into the switch on the appliance.
Do not operate the switCh with wet hanDs. It may cause an electric shock or fire.
For saFety, Must Do grounDing ConneCtion. also, Do not Do the grounD-
ing on gas pipe, plastiC water pipe, telephone wire, etC.
It could cause electric shock, fire, malfunction or explosion. Be sure to use the electrical outlet with ground connection.
neVer DisasseMBle the ChaMBer set During operation or insert Fingers,
Foreign oBjeCts suCh as Forks, spoons, etC. into hopper Chute or juiCe
outlet. It may cause injury, accident or failure.
applianCes Can Be useD By persons with reDuCeD physiCal, sensory or
Mental CapaBilities or laCk oF experienCe anD knowleDge iF they haVe
Been giVen superVision or instruCtion ConCerning use oF the applianCe in
a saFe way anD iF they unDerstanD the haZarDs inVolVeD. ChilDren shall
not play with the applianCe. Cleaning anD user MaintenanCe shall not Be
MaDe By ChilDren without superVision. this applianCe shall not Be useD
By ChilDren. keep the applianCe anD its CorD out oF reaCh oF ChilDren.
Precautions for safe use

www.hurom.com | 04
1. You should read <Precautions for safe use>
2. You should follow <Precautions for safe use>
3. Precautions are classified as follows.
Caution When violating the labeling requirement, it may cause serious injury or damage to the appliance.
Do not operate without loCking the hopper properly. It may cause an injury or a failure.
when DeteCting a gas leak, Do not insert the power CorD into its slot.
open the winDow to Ventilate Fully anD iMMeDiately. It may cause injury or failure.
neVer put a Finger, Fork or spoon, etC. into juiCe outlet. It may cause injury or failure.
iF auger rotation is stoppeD in norMal operation, press [reVerse/reV]
Button anD holD For 2~3 seConDs anD then aFter reVerse operation is
CoMpletely stoppeD, press [on] Button again. If such a stop event continues during the oper-
ation, the parts may be damaged and performance may be deteriorated due to overheating in a motor. When the problem
continues, immediately stop the appliance and contact the local Customer Care Center.
During the operation, Do not atteMpt to MoVe the Base, DisasseMBle the
ChaMBer set or parts anD try to loCk theM.
It may cause an injury or a failure. Any act of event needed, switch off first and unplug the power cord.
when using the applianCe, Be CareFul For a neCktie, long neCklaCe, sCarF,
etC. not to Be entangleD into hopper Chute. It may cause injury, failure or breakage.
plaCe the applianCe on a Flat anD staBle surFaCe. It may cause injury or failure.
Do not operate the applianCe For More than 30 Minutes at a tiMe.
It may cause a motor failure due to overheating. Cool it down sufficiently about 5 minutes and operate it again.
when plaCing ingreDients into the hopper Chute, only use the pusher
proViDeD. It may cause injury or failure.
Do not allow a seVere shoCk to the applianCe or Drop it. It may cause electric shock,
fire or damage.
iF the applianCe giVes oFF an unpleasant sMell or exCessiVe heating,
sMoke, stop using iMMeDiately anD ContaCt the loCal CustoMer Care
Center. When using a new appliance, it gives off a smell and the smell disappears naturally over time.
always unplug the applianCe aFter use. always DisConneCt the applianCe
FroM the supply iF it is leFt unattenDeD anD BeFore asseMBling, DisasseM-
Bling or Cleaning. when unplugging the power CorD, Make sure to holD
the power CorD. Pulling on the wire to unplug may cause electric shock or fire.
Do not wash at high teMperatures oF 800C(1760F) or higher. Do not put the
applianCe in a Dishwasher,a Dryer or a MiCrowaVe etC.
It may cause a failure or parts deformation.
the applianCe weighs aBout 6.2kg (13.6lB). when MoVing the applianCe, en-
sure to MoVe it holDing grips tightly at the Base BottoM with Both hanDs.
If attempting to hold chamber or the edge of the base, the base falls causing an injury or failure.

05
Frozen fruit or withered ingredients that have been stored in the refrigerator for a long time
may give us less extracted amount or may even be impossible.
Ingredients which needs caution
- Fruits with hard seeds such as persimmon, Japanese apricot, lemon, plum, peach etc. that are
hard to chew with our teeth should be pitted before extraction.
- For stalk vegetables with strong fiber such as water parsleys, celery etc. cut them into small size
about 3~4cm before putting them into the hopper chute.
- Do not put in sesame, coffee beans, bark of the tree, pepper, etc. which cannot be extracted.
- Do not put in fruits preserved in alcohol, sugar, honey, etc. (grapes, apricot, berries, etc) and
enzymes (glasswort, houseleek, etc.). It may cause damage or failure.
We recommend you to drink green vegetable juice and fruit juice immediately after ex-
traction rather than keeping them for long time.
You may use for crushing spice (garlic, red pepper), but not for grinding grain.
It may cause damage or failure.
Do not re-squeeze residues expelled through the pulp outlet.
Soft fruits can be re-squeezed.
Do not operate the appliance before putting in the ingredients.
Do not use the appliance for more than 30 minutes continuously.
- It may cause a failure due to overheating of the motor.
When using continuously, stop it and leave it 5 minutes of interval and then you may use it again.
Never insert finger, fork or spoon etc. into juice outlet during the operation.
- Inserting such as chopsticks etc. into Juice outlet during operation may stuck in the spinning
brush and may cause damage of parts.
Do not press the ingredients with anything except the pusher.
-It may stuck to the auger and cause injury and failure.
Do not operate the switch with wet hands.
- It may cause electric shock or fire. Do not put foreign objects near the switch.
Cautions during operation
Note

www.hurom.com | 06
Cautions during operation
Even after following the directions above
and still doesn’t work, please unplug the
power cord and disassemble chamber
set, and clean it. And try it again.
1
2
Note
[Rev] is the button to push back the
ingredients upward.
[Rev] only works while pressing the
button, and the rotation of the auger
stops If you release the button.
Press [Rev] button on the operat-
ing switch for 3~5 seconds and
stop it. Repeat this 2~3times.
Press [On] button to operate af-
ter reverse operation completely
stops.
When using [ON] or [Rev] button,
make sure that the auger stops com-
pletely.
When the auger stops during the operation
Open
<REV>
<ON>
In case of reversing during operation, press [Reverse] button short, then you press [Reverse]
button for operation.
From the feature of the product, even though you stop the operation, it doesn’t stop right away. It rotates
slowly then stops. If the rotation stops completely, you may press the button to any direction you want.
(Same as when pressing [On] during reverse operation)
Caution when using operation button
<ON>
<REV>
<STOP>

07
3
2Detach the silicone brush from the
spinning brush.
With the cleaning brush, wash inside
and outside of spinning brush under
running water.
As shown in the figure, hold the outer part of silicone brush
and pull it out gently in the direction of the arrow. Silicone
brush may be torn or damaged if it is pulled apart forcefully.
Clean the silicone brush in the same way under running
water.
Remove the spinning brush from
strainer.
1
Silicone brush
Cleaning brush
Spinning brush
Disassembling and cleaning the spinning brush

www.hurom.com | 08
As shown in the figure on left, position the
silicone brush so the ‘inner wing’ faces the
spinning brush.
See No. 1 above and let the longer part of inner wing
1face upward.
Hold the outer wing 2of silicone brush with your
thumb and index finger and insert the inner wing into
the groove of spinning brush.
Check the groove of the spinning brush and
the direction of silicone brush.
There are grooves to insert silicone brush in the spinning
brush.
Silicone brush has inner wing 1and outer wing 2.
As shown in the figure on left, position the silicone brush so
the ‘inner wing’ faces the spinning brush.
Pull the inner wing tightly into the
spinning brush.
Push the silicone brush in from the outside and pull
the ‘inner wing’ into the spinning brush with the other
hand. (See figure)
Pull the silicone brush tightly into the groove on the
spinning brush. The unit may be damaged if it is op-
erated without being properly and fully assembled.
Make sure the silicone brush is placed firmly into the
groove by holding the top and bottom part of the
‘outer wing’ and pulling it up and down in opposite
directions.
3
2
1
Brush
groove
Inner
wing
Outer wing
1
2
1
2
spinning brush silicone brush
Top
(longer part)
Bottom
(shorter part)
Assembling the spinning brush

09
Insert the chamber seal into the cham-
ber hole.
Turn over the chamber and settle the
chamber seal into place.
Insert the bottom of the chamber seal into the cham-
ber hole and press it down fully. Do not insert the
entire chamber seal. The upper part of the chamber
seal must stay above the chamber hole.
If the chamber seal at the bottom of the chamber is
not fully installed, set it into place properly with the
rotating pick on the end of the cleaning brush.
Hold the chamber seal by pinching it
between the thumb and index finger.
As shown to the left in the dotted circle, let the pro-
truding part on the chamber seal face upward when
you hold it by pinching it between the thumb and
index finger.
Chamber seal
3
2
1
ASSEMBLING THE CHAMBER SEAL

www.hurom.com | 10
Open the juice cap and fit the juice cap
seal on to the inner disk.
Arrange the seal for a complete fit.
Be careful not to drop the chamber.
If the seal is not placed correctly, it may cause juice
leakage.
Hold juice cap seal as shown on the left.
As shown on the left in the dotted circle, the opening
on the seal must be visible when you hold the seal.
Juice cap seal
3
2
1
ASSEMBLING THE JUICE CAP SEAL

11
Before requesting for repair
Please check the details below before contacting Technical Support for repair or service.
If you need additional information, please contact the local Customer Care Center or visit www.hurom.com.
When applying for after-sales service, please have the manufacturer’s serial number or bar code available.
The AppliAnce Does noT WorK.
Make sure the power cord is properly plugged in.
Check if the hopper is assembled properly. If the hopper has not been locked into place, the appliance will not operate for safety reasons.
Check if the appliance has been assembled according to the directions given in the manual.
Refer to the assembling instructions in the manual or consult with a local Customer Care Center for addi-
tional assistance.
The hopper Does noT open.
Is there lot of pulp left inside the chamber? Press [ON] button to expel excess pulp.
Have you placed any foreign substances or solid objects such as hard seeds in the juicer?
Press the [Reverse/REV] button to bring the foreign objects back up toward the hopper chute.
DO NOT attempt to open the hopper by force. If the issue is not resolved after following the above process,
contact the local Customer Care Center.
The AppliAnce sTops During norMAl operATion.
Have you put in heavy loads or large pieces of ingredients into the appliance?
Read page 12 of the manual and follow the guideline for using [Reverse/REV] button.
If the issue is not resolved after following the above process, contact the local Customer Care Center.
There Are Fine lines or scrATch MArKs on The proDucT.
These are molding marks resulting from the normal manufacturing process. This is a normal product and
there is no problem for use.
Juice leAKs oVer The bAse.
Is extraction seal inserted properly?
Juice could leak out when the extraction seal is loose or has not been inserted properly. Push the extraction seal all the way for a tight seal.
Juice is still leaking even with the extraction seal inserted correctly.
Overloading may be the problem. If the chamber is overloaded with ingredients, the extraction seal may be pushed out of position, allowing the juice to
leak out through the gap. Always juice small, manageable amount of ingredients at a time and avoid processing heavy loads.
The chAMber shAKes When squeezing.
Slight shaking may be caused by the motor.
Depending on the texture of the ingredient, there may be slight to more pronounced shaking of the appliance.
There is some level of shaking when the auger is rotating. This is a normal occurrence and not a malfunction.
Hard ingredients (e.g. carrot, potato, radish, beet, etc.) may cause more shaking than soft ingredients.

www.hurom.com | 12
Please check the details below before contacting Technical Support for repair or service.
If you need additional information, please contact the local Customer Care Center or visit www.hurom.com.
When applying for after-sales service, please have the manufacturer’s serial number or bar code available.
Product Specifications
Product Name
Model Name
Rated Voltage
Rated Frequency
Rated Power
Consumption
RPM
Hurom Slow Juicer
HN Series
230 V
50 Hz
150 W
70 rpm
Product name
Important: To better protect your purchase, fill out and mail this form to a local distributor where
you purchased the appliance and keep the original receipt.
This certifies that the Hurom Slow juicer is covered under warranty by to be free
from defects in material construction and workmanship.
Hurom provides warranty for ten (10) years for the motor and two (2) years for other parts from
the date of purchase by the original purchaser. Coverage is valid only with proof of purchase
from an Authorized Local Distributor. (No international warranty available)
This warranty does not apply to damages caused by accident, misuse, abuse, commercial
use, alteration, failure to follow operating instructions, or damage caused by parts or service
unauthorized by . Damages caused by transportation must be claimed with carrier.
disclaims all responsibilities for consequential damages from incidental losses
caused by use of this appliance.
For service and assistance with technical difficulty, please contact our local customer care
center.
Manufacturer’s serial number
Supplier
Address
Model name
Date of purchase
Customer name
Warranty
Cord Length
Motor
Fuse
Weight
Outward
Dimension
Rated
Operating Hour
1.4 m
Single-phase induction motor
250 V 5 A
6.8 kg (15 lb)
Width 238 mm
Length 185 mm
Height 411 mm
Less than 30 minutes
Manufacturer :
Hurom webpage : www.hurom.com

13
MEMO

www.hurom.com | 14
MEMO

www.hurom.com
Copyright© All Rights Reserved by HUROM
Fine strainer has tiny and fine holes which is good to make clean
juice.
Fine Strainer
Coarse strainer has larger holes so it is good to make thick juice
with flesh in it.
It is to make juice with soft fruits and thick juice like banana, strawberry, and
also useful for smoothie, latte, or soup.
Coarse Strainer
NMNENN140515A _V.03
Juice fruits like apple, pear, kiwi, oriental melon, etc. put them with
seeds and peels. However, apple seeds contain toxicity, so it better
to remove them.
Separate each grape from the cluster. Peel the pomegranate and use
flesh only.
Peel off the skin of watermelon, orange, grapefruit and cut them into
right size.
Fruits like mango, cherry, peach, or plum, etc. have hard seeds
which are hard to swallow. Those seeds might cause stoppage or
parts damage, so they must be removed before using it.
Put a handful of wheat or chives in not to be scattered.
Cut fibrous ingredients into small sized less than 3 cm.
Apple, pear, kiwi,
oriental melon
How to trim the ingredients!
Which one is better, Fine Strainer or Coarse Strainer?
Pomegranate,
grapes
Watermelon, orange,
grapefruit
Mango, cherry,
peach
Wheat, chives
Water parsleys,
angelica, celery, kale
* This is a reference about how to trim the ingredients, so if you have allergy please choose your own proper
ingredients which agrees with you.
* Please refer to the recipe book for the product usage of each ingredient.
