IHP RDV-CONTF-BLK User manual

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE 1
CONTEMPORARY FACE KITS
INSTALLATION INSTRUCTIONS FOR INSTALLING CONTEMPORARY FACE KITS
FOR USE WITH RAVENNA SERIES AND DRI3030 SERIES GAS FIREPLACE INSERTS
P/N 900411-00
REV. A, 02/2015
HEARTH PRODUCTS
KITS AND ACCESSORIES
KIT CONTENTS (See Figure 1)
1 ea. Face
1 ea. Instruction Sheet
ALL WARNINGS AND PRECAUTIONS IN THE INSTALLATION AND
OPERATION MANUAL PROVIDED WITH THE APPLIANCE APPLY TO
THESE INSTRUCTIONS.
TURN OFF THE APPLIANCE AND ALLOW IT TO COMPLETELY COOL
BEFORE PROCEEDING.
INSTALLATION INSTRUCTIONS
Installation of the surround assembly is required prior to installing the
Contemporary Face Kit. Install the surround assembly per instructions in
the installation and operation manual provided with the fireplace insert.
Step 1.Place the face on the surround hanging brackets as shown in
Figures 2 and 3 by placing the hooks on position (1). Each side
of the face has a bracket with two (2) hooks.
Figure 1
Contemporary Face Kits
Cat. No. Model Description
F2322 RDV-CONTF-BLK Contemporary Face - Black
F2323 RDV-CONTF-MNK Contemporary Face - Mink
TOOLS NEEDED
5/32” Allen Wrench
GENERAL INFORMATION
All of these parts may scratch and bend, great care should be used
in handling them.
If you encounter any problems, need clarification of these instructions
or are not qualified to properly install this kit, contact you local distribu-
tor or dealer.
Read this instruction sheet in its entirety before beginning the installation.
Figure 2
The face has two hooks on each side that slide over and hang on the
surround brackets at position (1) shown here. The face may slide slightly
from side to side to center the face on the glass.
uLocation where hooked brackets on face will hang
u
fire-parts.com
All manuals and user guides at all-guides.com

2
Printed in U.S.A. © 2015 Innovative Hearth Products
P/N 900411-00 REV. A 02/2015 1508 Elm Hill Pike, Suite 108 • Nashville, TN 37210
Figure 3 - Face Installation Figure 4 - Completed Installation
IHP reserves the right to make changes at any time, without notice, in design, materials,
specifications, and prices, and also to discontinue colors, styles, and products. Consult your
local distributor for fireplace code information.
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE
