Inmotion E-scooter air User manual

Before using your scooter, please read the instructions, and keep this manual for ready reference.

Original instructions

User Manual

E-Scooter Air

Contents

Safety Instructions

Product Function Diagram

Safety Alerts & Error Messages

Assembly

Folding and Carrying

First Ride

Charging

Learning to Ride

Security Tips

Speciﬁcations

Maintenance

Before Your Ride

Trademarks and Legal Notices

Warranty

Electric scooter is a recreational device rather than a transporter. But once you ride it into a public community, it will also act as a transporter. Like

any riding products, an electric scooter can and is intended to move and it is therefore, of course, possible to get into dangerous situations.

Please understand that you can reduce the risks by following all the instructions and warnings in this manual, but you cannot eliminate all the risks.

Remember that whenever you ride the scooter you risk injury or death from loss of control, collisions, and falls. The electric scooter is intended for

use on ﬂat pavement or level ground without bumps and obstacles. Be alert and slow down when entering unfamiliar areas.

Always wear a helmet when riding. Use an approved bicycle or scooter helmet that ﬁts properly with the chin strap in place, and provides protection

for the back of your head.A long-sleeved shirt, long pants, and athletic shoes are recommended. Never ride in higheels sandals, high-heeled shoes or

barefooted. Long hair or bangs that can aﬀect vision should be tied up to avoid accidents caused by hair blocking vision.

Do not attempt your ﬁrst ride in any area where you might encounter children, pedestrians, pets, vehicles, bicycles, or other obstacles and potential

hazards.

Respect the rights and property of others. Pass on the left whenever possible. When approaching a pedestrian from the front, stay to the right and

slow down. Be careful to avoid pedestrians, especially the old, children, the disabled, pregnant women. When approaching from behind, announce

yourself and slow down to walking speed when passing. Please obey local traﬃc laws and regulations if situation is diﬀerent.

In places without laws comply with the safety guidelines outlined in this manual. INMOTION Technologies Inc. will not be responsible for any property

damage, personal injury/death, accidents, or legal disputes caused by violations of the safety instructions.

Do not allow anyone to ride your scooter on his/her own unless they have carefully read this manual and followed the riding guide video. The safety of

new riders is your responsibility. Assist new riders until they are comfortable with the basic operation of the scooter. Make sure each new rider wears

a helmet and other protective gear.

Before each ride check for loose fasteners and damaged components. If the scooter makes abnormal sounds or signals an alarm, immediately stop

riding. Diagnose your scooter via the INMOTION App and contact after-sales service at [email protected].

Be alert! Scan both far ahead and in front of your scooter - your eyes are your best tool for safely avoiding obstacles and low traction surfaces

(including, but not limited to, wet ground, loose sand, loose gravel, and ice).

To reduce risk of injury, you must read and follow all “CAUTION" and “WARNING" notices in this manual. Do not ride at an unsafe speed. Under no

circumstance should you ride on roads with motor vehicles. The manufacturer recommends riders aged between 14-60 years old and weigned less

than 120kg. People who should not ride the scooter include:

i. Anyone under the inﬂuence of alcohol or drugs.

ii. Anyone who suﬀers from disease that puts them at risk if they engage in strenuous physical activity.

iii. Persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way and understand the hazards involved.

iv. Anyone who has problems with balance or with motor skills that would interfere with their ability to maintain balance.

v. Anyone who is severely overweighted (see Speciﬁcations).

1. Safety Instructions

•

vi. Pregnant women.

Vii. Riders under the age of 18 years old should ride under adult supervision.

Comply with local laws and regulations when riding this product. Do not ride where prohibited by local laws.

To ride safely, you must be able to clearly see what is in front of you and you must be clearly visible to others.

Do not ride your scooter in wet or icy weather, or on roads which are wet, muddy, icy, or that are slippery for any reason. Do not ride over obstacles

such as sand, loose gravel, or sticks. Wet, slick, bumpy, uneven or rough surfaces may impair traction and contribute to a loss of balance or traction

and could cause a fall.

Do not ride at night when visibility is limited.

Sudden acceleration ordeceleration could lead to wheel slip, collision or falls.

Do not ride faster than the speed limit.

Do not attempt to charge your scooter if it, the charger, or the power outlet is wet.

Only use the INMOTION supplied charger. Use only with FY-4202000 supply unit. Do not use a charger from any other diﬀerent product models.

Use only INMOTION approved parts and accessories. Do not modify your scooter. Modiﬁcations to your scooter could interfere with the operation of

the scooter, could result in serious injury and/or damage, and could void the limited warranty.

Children should not use scooter or play with scooter parts. Cleaning and maintenance shall not be done by children without supervision. The vehicle

vibration will cause the driver's body vibration while riding.

Please park on ﬂat pavement, such as on a slope, the scooter kickstand must be facing downhill to prevent capsizing. Please check whether the

scooter is parked stably to prevent it overturned.

Perform regular inspections of equipment and conduct regular cleaning on your scooter for better ride experience.

This scooter contains batteries that are not replaceable.

Use any battery charger other than the original.

detachable supply unit.

Any load attached to the handlebar will aﬀect the stability of the vehicle.

Braking distances may be extended in wet weather.

LPA and LWA: Do not exceed 70dB(A).

In any case, anticipate your trajectory and your speed while respecting the code of the road, the code of the sidewalk and the most vulnerable.

•

Please carefully check whether the items in the packing box are

complete and intact. If there is any part missing or damaged, please

contact dealer or email to manufacturer ([email protected])

Please retain the box and packaging materials at least 15 days in

case you need to ship your scooter in the future.

For energy

saving mode The max. speed is 15km/h, suitable for beginners

The max. speed is 25km/h, suitable for general riders

The max. speed is 25km/h, suitable for skilled riders

Shows the speed of the scooter in real time, the speed will

be shown as two short lines when the vehicle is locked

The battery level is indicated by 5 bars, the last bar ﬂashing

indicates a low-battery level

The icon lights up after the electric scooter has been

turned on, and it will go out after the vehicle is turned oﬀ

Cruise mode is activated automatically when the same

speed is maintained. Press the brake or the throttle to go

back to the manual mode.

The icon indicates that the scooter has detected an error.

Refer to the error code table to ﬁnd solutions

Press and hold the button for 2 seconds to turn the electric

scooter on/oﬀ. When the scooter is on, press the button to

turn the headlight on/oﬀ, and press twice to switch modes

Hold the brake and double press the Power button to enter

Pedestrian Mode, then double click the Power button again

to exit.

(Note: Riding speed can be adjusted in the App. The max.

speed limit is 6km/h.)

For dynamic

mode

For sports

mode

Speedometer

Battery level

Light icon

Cruise mode

Error

Pedestrian

mode

Power button

Power cable Extended air

valve Power adapter Handlebar Hex wrench

2. Product Function Diagram

Dashboard

Packing list

Dashboard

Power button

Throttle

Bell

Brake lever

Headlight

Stem

Folding

mechanism

Front fork

Front

mudguard

Front

wheel

Head unit clip

Handlebar

Charging port

Head unit mount

Taillight

Plate

Bracket

Rear wheel

Rear reﬂector

Footrest

Kick-stand

Front reﬂector

Air valve

Error

code Solution Components Scenario Beep alert

Error

Controller error Controller

Motor

Battery

Brake lever

Throttle

Dashboard

Controller

Motor

Hall error

Battery error

Battery low

voltage

Battery low

voltage

Long press to power

oﬀ

Enter cruise mode

Double click to

switch modes

Vehicle failure

Battery drops below

20%

Battery level below

20% when power on

Press to light on/oﬀ

2 beeps

1 beep

2 beeps

1 beep

Keep beeping

App setrings 1 beep

Keep beeping for 5

seconds

Keep beeping for 5

seconds

App connected/

disconnected

1 beep

Dashboard

communication

error

Controller

communication

error

Mos overheating

Motor overheating

Brake self-test

failure

Throttle power-on

self-test failure

Controller error, please restart the vehicle or

contact after-sales service for replacement

Motor error, contact after-sales service for

motor replacement

Battery error, contact after-sales service for

battery replacement

The throttle is unreleased. Release the brake

handlebar or check the condition of the throttle

The battery voltage is too high, please stop

using and contact after-sales service for

support

The brake handlebar is unreleased. Release

the brake handlebar or check condition of the

throttle

Please restart the vehicle or contact

after-sales service for replacement

Controller board overheating, stop riding and

wait for it to cool down

Controller board overheating, stop riding and

wait for it to cool down

Please restart the vehicle or contact

after-sales service for replacement

The battery voltage is low, please charge now

08 / / /

3. Safety Alerts & Error Messages

To avoid personal injury, please follow the instructions shown in the diagram for assembly operation and

inspection. Children are not allowed to conduct assembly operations.

Unfold the stem and fasten the folding

wrench. Make sure the Unlock key

springs up normally after fastening. Be

sure to buckle up properly.

For better riding experience, always check the tire pressure before each ride. Please inﬂate in time if the tires of the device are deﬂated. The ideal

pressure ranges between 2.5 and 3.5 bar.

Note: The range and riding experience are related to the tire pressures. When the tire pressure is within normal range, the higher the tire pressure is,

the longer the range will get. While the lower the tire pressure is, the better the riding experience will have especially on bumpy road. Choose proper tire

pressure according to speciﬁc usage scenarios.

Place the brake lever on the handlebar,

tighten it ﬁrmly with hex wrench to be

sure it won't loosen.

Install the handles on the stem and

ﬁrmly tighten it according to the correct

position and direction marked on the

label.

Unscrew the air valve caps of tire. Thread the valve extender completely

onto the valve stem and tighten it ﬁrmly.

Attach the air pump, then inﬂate the tire

to the proper pressure.

Valve cover

Inﬂating the tires

4. Assembly

Power oﬀ the scooter, hold the stem,

press the locking button and pull the

lever, bend the handlebar stem towards

the footrest.

Hold the stem and pull the folding ring,

attach the hook to the locking clip on the

side of the mudguard.

Carry the scooter by holding the handlebar

stem. Watch out for bumps!

5. Folding and Carrying

Press the locking button

Press down the folding ring

Stem

Wrench

There are safety risks when using scooters. Before the initial use, users must carefully read the safe driving guide through

the APP. For safety consideration, the new scooter is not activated, it will be restricted to ECO mode which has a speed

limit of 15km/h. You need to activate the scooter through the App to unlock full function.

6. First Ride

1. Download and install the App,

（QR code）

2. Power on the scooter, pair your scooter

with the INMOTION App. The scooter will

beep when the connection is successful.

3. Follow the App instructions to active

the scooter and learn how to ride safely.

You can now start to use your scooter.

7. Charging

Charger indicator light: Red (charging) Green (charged)

Charging port

Charging precautions

•

Do not charge if the charge port or power

cord is wet.

Use only with the original changer, do not

use battery packs of other models or

brands.

Do not charge or stop using the battery

immediately if it is damaged or ﬂooded.

Please close charging port cover tightly

when not in use or after charging.

Never charge indoors.

Do not charge the electric scooter in wet environment.

The best ambient temperature for charging is 0-45°C.

Keep out of reach of children and animals, keep away from ﬂammable materials while charging.

Do not store the electric scooter in environments with a temperature ranging from -20 to 45°C. Do not put the battery pack into the ﬁre. Doing so

may cause ﬁre, heat generation, leakage or bursting.

After each use, fully recharge the battery to extend its useful life. Completely draining the battery may permanently damage the battery.

Do not charge or use the battery if it smells, overheats or leaks.

Do not open the battery pack or insert anything into the charging port as it contains hazardous substances.

Please only use the original battery and adapter for your scooter.

Always comply with local environmental protection laws about battery recycling.

Open the rubber

cap

Inset the battery

charger plug

Remove the battery

charger and close

the rubber cap when

charing ﬁnished

Wear an approved helmet, elbow pads,

knee pads and other protective gear to

minimize any possible injury.

1. Check the power level indicator after

powering on. Charge the scooter if the

battery level is low.

2. Stand on the footrest with one

foot and push oﬀ with another foot

to start gliding.

3. Stand on the footrest with both feet,

press the throttle on the right hand.

Note: For your safety, the motor will not

engage until the scooter reaches 3 km/h.

4. Slow down by releasing the throttle and

hold the braking lever lightly (Do not brake

suddenly and watch out for the road

conditions!)

5. When the car stops or slides

slowly, put down one foot and get

oﬀ.

When hard braking, you risk serious injury due to loss of traction and falls. Maintain a moderate speed and look out for potential hazards.

8. Learning to Ride

Failure to follow these instructions could lead to serious injury.

Do not ride the scooter in

the rain.

Do not ride at high speed

when you get over speed

bumps, thresholds etc.,

please ride at low speed on

rough roads.

Do not press the throttle

when walking with the

scooter.

Avoid contacting

obstacles and watch

out for the road

conditions.

Watch your head when

passing through doorways.

Do not step on the rear

fender

Do not carry heavy objects

on the handlebar.

Do not ride the scooter

with only one foot or

one hand.

9. Security Tips

Do not ride on motorways,

public roads, or highways.

Do not rotate the handle

violently while driving at high

speed.

Do not touch the motor, it

may overheat after running.

Do not take your hands

oﬀ the handlebar while

riding.

Do not ride through puddles,

please go around at low

speed.

The scooter is for one rider

only. Do not carry any

passengers especially a child.

Do not ride when pregnant.

Do not ride up and down stairs or

jump over obstacles.

Do not use mobile phone

or wear earphones when

riding the scooter.

10. Speciﬁcations

Index

Basic specs

Rider

Machine parameters

Items

Model

Unfold dimensions (L x W x H)

Folded dimensions (L x W x H)

Net weight

Max. payload

Recommended age

Max. speed

Operating temperature

Storage temperature

IP rating

Charging time

44.3″×17.5″×20.5″ (1125×445×1200mm)

44.3″×17.5″×47.2″ (1125×445×520mm)

34.6lbs (15.7kg)

264.6lbs (120kg)

14-60

US Version: 19mph (30km/h)/EU Version: 16mph (25km/h)

Approx. 22miles (35km)

-10℃ - +40℃

-20℃ - +45℃

IP55

Approx. 4.5h

Value

Max. slope Approx. 18%

[2]

Typical range [1]

Battery

Motor parameters

Charger

Features

Max. charging voltage

Nominal capacity

Battery management system

Peak power

Nominal power

Input voltage

Output voltage

Output current

Front / Rear tire size

Tire pressure

Headlignt power

Brake light power

42V

270Wh

Over-heating, short circuit, over-current and over-charge

protection

720W

350W

AC100-240V 50/60HZ

DC42V

10 inch, inﬂatable inner and outer tire with lower rolling resistance

2.5-3.5 bar

2.0W

0.8W

[1] Typical range test is based on a 75.0 kg load at a 25°C temperature with tire pressure of 3.5 bar, riding 15 km/h at a constant speed on a ﬂat road

test. The atual range may vary depending on the speed, times of start and stop as well as ambient temperature, etc.

[2] Max. slope test is based on a 75.0 kg load at a 25°C temperature with tire pressure of 3.5 bar, riding at 15 km/h. The atual slope may vary

depending on the battery level, payload, tire pressure, etc.

11. Maintenance

•

Cleaning

Wipe the body of the electric scooter with a damp cloth. If stains persist, apply some toothpaste, brush with a toothbrush, then wipe with a damp

cloth.

Note

When cleaning the electric scooter, make sure that it is turned oﬀ, that the charging cable is disconnected, and the rubber cap is closed, as a water

leak may cause a damage to electronic components.

Do not clean the electric scooter with alcohol, petrol, kerosene or other corrosive and volatile chemical solvents, to avoid serious damage. Do not

wash the electric scooter with jets of high pressure water.

Storage

When the electric scooter is not in use, store it in a cool, dry place. Do not store it outdoors for extended periods of time.

Note

Excessive sunlight, overheating, and excessive cold accelerate tire ageing and jeopardize the life of both the electric scooter and the battery.

Warnings

Only use original batteries, as other models or brands may pose a safety risk.

Please do not exceedthe speciﬁedtemperaturefor battery storage or charging. (See speciﬁcations)

Do not touch the battery contacts. Do not dismantle or puncture the outer casing. Avoid contact between metal objects and battery terminals to

prevent short circuits, physical harm or death.

Do not throw the battery into a ﬁre as this could damage it, cause overheating or even a ﬁre.

Do not charge or stop using the battery if it is damaged or ﬂooded.

Do not attempt to remove the battery as you may damage the scooter.

Do not attempt to disassemble the battery to prevent ﬁre hazards. Usersare nownot allowed to repair spare parts and components come with the

scooter.

Do not ride when the ambient temperature is higher than the operating temperature of scooter (see Speciﬁcations) because low/high temperature will

limit the maximum power/torque. Doing so could cause personal injury or property damage due to slips or falls.

After each use, fully recharge the battery toextend its service life. Completely draining the battery may permanently damage the battery.

Improper disposal of used batteries seriously pollutes the environment. Follow local regulations regarding battery disposal. Follow battery disposal

regulations to protect the environment.

12. Before Your Ride

13. Trademarks and Legal Notices

Typically, a fully charged battery should retain power for 120-180 days. A low-power battery should retain power for 30–60 days. Remember to

recharge it every 60 days to protect it from any damage. Electronics inside the battery record the charge-discharge condition of the battery, damage

caused by over-charging or under-charging will not be covered by the limited warranty.

A well-maintained battery can perform well even after many miles of riding. When used at room temperature 22°C, the battery range and performance

is at its best; whereas using it at low temperatures can decrease range and performance. Battery range will recover when temperature rises.

INMOTIONis a registered trademark of INMOTION TechnologiesInc.; Android, Google Play are trademarks of Google Inc., App Store is a service mark

of Apple Inc., The respective owners reserve the rights of their trademarks referred to in this manual.

We have attempted to include descriptions and instructions for all the functions of the scooter at the time of printing. However, due to constant

improvement of product features and changes of design, your scooter may diﬀer slightly from the one shown in this document. The manufacturer

reserves the right to change the design and functionality of the scooter product and documentation without prior notice.

Manufacturer: INMOTION TECHNOLOGIES CO., LTD.

Address: 18F, B1, Nanshan iPark, No.1001 Xueyuan Ave., Nanshan District, Shenzhen, China. 518055

1. Read the product instructions carefully and do not attempt to ride the scooter if you cannot follow the instructions completely.

2. Please do not allow others to use your scooter without carefully reading this instruction or knowing how to use this product and safety precautions.

3. All parts of the scooter must be properly installed in accordance with the instructions. Improper installation may result in the risk of loss of control,

collision or fall. Before installation or maintenance, please power the scooter oﬀ, install the components with proper strength. Too loose or too tight

installation may cause damage or failure of the products.

4. Please purchase insurance in time after purchasing the product to minimize the risk.

5. Before each ride, please check all vehicle components are in place and securely fastened, the performance of wheels, the battery level, running

condition, etc., to ensure any parts including the handlebar, stem, tires, brakes, screw are not loose or damaged, and the vehicle is in good condition for

riding. Ifyou've noticed anythingunusual, please stop using immediately and contact after-sales service for technical support.

6. You are obligated to be aware of all laws, regulations and policies of scooter riding in your area and to strictly comply with the applicable laws,

regulations and policies.
