InMotion L8 User manual

INMOTION E-SCOOTER
INMOTION TECHNOLOGIES CO.,LTD
www.imscv.com
USER MANUALL8

1. Introduction
1.1. Overview
1.2. Related Documents and Materials
1.3. Signs and Words of Caution
2. Product Overview
2.1. Product Serial No.
2.2. Product Dimensions
2.3. Product Parameters
2.4. Product Structure
2.5. Packing Carton Check
2.6. Open L8
2.7. Display Screen
2.8. INMOTION APP
2.9. Pairing with INMOTION APP
2.10. Scooter Working Modes
3. Battery and Charger
3.1. Battery Specifications
3.2. Charging Method
3.3. Safety Prompt for Charging
3.4. Protection against Over-discharging
4. How to Use L8
3
3
3
3
4
4
4
5
6
7
7
9
10
10
11
12
12
12
13
13
14
Catalog
1

4.1. Riding L8
4.2. Precautions before driving
4.3. Operating steps of beginners
4.4. Body folding steps
4.5. Switch lamp and active power off
5. Precautions for Safe driving process
6. Care and Maintenance
6.1. Storage
6.2. Cleaning
6.3. Handling
6.4. Inflation and Replacement of the Interior and Exterior Tires
6.5. Handlebar loosening adjustment
7. Contact and Legal Information
7.1. Feedback of issues
7.2. Contact Us
7.3. Following the Local Laws
7.4. Version No.
8. Legal Statement
8.1 Statement about the Product
8.2 Personal Information Protection Statement
8.3 Intellectual Property Statement
9. Product Warranty
Product Warranty Card
Certificate of Quality
14
14
15
15
16
16
17
17
17
17
17
18
18
18
18
18
18
19
19
21
22
23
26
28
2

3
1. Introduction
1.1. Overview
For your driving safety，please read this manual carefully before using L8 and ensure to be able to drive L8 under the correct
guidance.
·Learning all the safety warnings and precautions listed in this manual that will be helpful for you to better control the L8.
· This manual is applicable to INMOTION E-scooter products manufactured by Shenzhen INMOTION Technology Co.,Ltd.
· If you have any questions or you cannot find the information you require from this manual, please contact in time the dealer
authorized by INMOTION or the after-sale service department of INMOTION Company.
1.2. Related Documents and Materials
The document in PDF format for "User Manual" of L8, INMOTION APP and other help files can be downloaded from the official web
site of Shenzhen INMOTION Technology Co., Ltd. : www.imscv.com.
1.3.Signs and Words of Caution
The following descriptions are applicable all through this manual, and the "Warnings" and "Notes" deserve your special attention.
Warns you about actions that may result in personal injury.
Identifies important points, helpful hints, special circumstances, or alternative methods.
WARNING!
NOTE:

2. Product Overview
L8 is a cool, highly efficient and economical personal travel tool. With its stylish and futuristic appearance, superb shock mitigation
design and powerful lithium battery, L8 is created to give you a wonderful riding experience.
2.1.Product Serial No.
A serial No. is a product's unique identity, used for quality tracking, after-sales service, insurance claiming, identification of a lost
product, etc. Make sure to keep a record of the serial No. and take care not to lose it. You can find the serial No. of the product at the
following positions: the outer packing, the warranty card, and the body of L8 (to be more specifically, it's located at structure of the Body
folding).
2.2. Product Dimensions
430mm
150mm
166mm
1105mm
1056mm
366mm
1100mm
4

2.3. Product Parameters
Product model
Factory default speed
Maximum speed
Endurance mileage
Max. gradient
Net weight
Max. Load capacity
Overall dimensions
Motor rated power
Max. motor power
Battery specifications
Charging requirements
Charging time
Tire types
Brake type
Optimal operating
temperture
Working temperature
Protection grade
Remarks
① You can set the maximum
cruising speed with mobile
telephone APP. The maximum
cruising speed is measured at the
temperature of 25℃ 、the payload
of 70 kg、full electric voltage and
flat pavement. The factors like
driving habit, environmental
temperature, road surface condition,
payload etc. will affect the
continuous travel mileage.
② The travelling range is measured
at the temperature of 25℃、
about15km/h、the payload of 75 kg
and flat pavement. The factors like
driving habit, environmental
temperature, road surface condition,
payload etc. will affect the
continuous travel mileage. Different
models will also make different
continuous travel mileages.
③Charging time varies with the
ambient temperature and the
battery capacity that may change in
the course of time.
5
L8
25 km/h
Approx. 30 km/h ①
Approx. 15 km ②
Approx. 15
Approx. 11.5 kg
100 kg
1056*430*1100mm
250W
500W
36V 4.4Ah lithium battery
100-240V AC 50~60Hz
Approx. 2.5 hours ③
8 inch solid tire for the front
wheel and 8 inch pneumatic
tire for the rear
Electronic brake and Foot brake
25℃
-10~40℃
IP54
L8F
25 km/h
Approx. 30 km/h ①
Approx. 35 km ②
Approx. 15
Approx. 12 kg
100 kg
1056*430*1100mm
250W
500W
36V 8.7Ah lithium battery
100-240V AC 50~60Hz
Approx. 5 hours ③
8 inch solid tire for the front
wheel and 8 inch pneumatic
tire for the rear
Electronic brake and Foot brake
25℃
-10~40℃
IP54

2.4. Product Structure
Floodlight
Decorative light
Handlebar quick spanner
Kickstand
Folding button
Folding quick spanner
Front decorative piece
Charging port
Display screen
Folding fixing part
Throttle button
Brake button
Handlebar rubber
Handlebar lamp
Handlebar
decorative piece
Decorative strip
Handlebar stem
Steering
decorative piece
Body
Tail
Rear fender & foot brake
Tail lamp cover
Rear wheel
Front fender
Front fork
Motor
6

2.5. Packing Carton Check
Before delivery, the INMOTION E-scooter package includes the following parts that shall be checked when unpacking, consult with
the local dealer or after-sale department of INMOTION in case of any missing.
·Scooter main body ×1 ·Charger ×1 ·User Manual ×1
Use of unauthorized parts and components or incorrectly installed parts and components may result in damage to L8 or even
personal injury. In order to ensure quality and safety, all parts of L8 will be subject to the approval of Shenzhen INMOTION Technology
Co., Ltd. and assured to be correctly mounted to L8.
Please do not try to stand on an L8 that is not correctly, effectively and completely installed.
Do not disassemble, refit L8 without permission, or it will cause irreparable damage of L8 and may result in personal injury.
2.6. Open L8
Step 1：Press the folding button,
Help handle the direction toward the left body,
Until you hear a click sound,
then press folding quick spanner.
1
2
3
WARNING!
7
Press the folding button
Press folding quick
spanner
Start the handlebar

Step 2：Open Handlebar quick spanner，then rotate the hand out to the side，Inserted into the middle，Pressing Handlebar quick
spanner.
Step 3：Hands holding the hand，you can use L8 normal through promote the body.
Open Handlebar quick spanner
Pressing Handlebar quick spanner
Rotate the hand out to the side
Inserted into the middle
4
5
6
7
8

2.7. Display Screen
The LED display screen is an interface that shows the operation status of the scooter：
Speed indicator
Only this grid of electricity flicker must be charged to use
Battery life indicator which consists of 5 bars
Bluetooth status indicator
9

2.8. INMOTION APP
The INMOTION APP is a mobile software specially designed by INMOTION for its users, and can be used to control the scooter,
make friends, publish messages, take part in INMOTION activities, purchase INMOTION accessories, etc. The English title of the L8
INMOTION APP is: INMOTION.
The INMOTION APP can be downloaded from the official website of INMOTION or related APP stores (for IOS, it's Apple App Store;
for Android OS, Google Play)
The INMOTION APP features the following functions：
·Scooter control: locking, unlocking.
· Scooter status indication: providing information including speed, range, battery life, etc.
·Scooter parameters setting: Light color, top speed, drive mode, etc.
·Fault detection: conducting detection and estimation on the health state of L8.
·After-sales service: exchanging with INMOTION's service personnel and working out solution to your problems in a timely manner.
·Firmware updating: checking the latest scooter firmware updates released and updating it via connection to network.
·For more details about the mobile client's functions, refer to tips and help information contained in the mobile client, or download and
read the instruction manual of the latest mobile APP from INMOTION's official website. In addition, new functions will be added to
INMOTION APP on an irregular basis.
2.9. Pairing with INMOTION APP
· Open the APP and L8，Search and choice for L8.
· Click connection and enter the initial password of 000000
· Appearance of on the scooter screen signifies a paring success
Download App
10

2.10. Scooter Working Modes
L8 features 3 working modes and here are some brief introductions to some important ones:
Accelerator mode
Locked mode
Error handling mode
Working mode
When L8 is parked normally and connected to your mobile phone, you can switch the scooter to the locked
mode by operating on your phone. In this mode, the throttle will cease to function. Only by operation via the
connected mobile phone, can the scooter be released from this mode.
This mode will be activated automatically when the system detects some error or warning, and in this case the
system will take control of the scooter and bring it to a stop, and the same time, L8 will be flashing red light
warning, After stop, Please put L8 for a period of time, reboot, if still can not be normal use, please contact
INMOTION service.
Accelerator press to achieve acceleration, the factory default for this mode, can be switched to other modes
via mobile phone APP
After L8 is off, still can keep the telephone APP related settings for the L8.
NOTE:
11
Description

3. Battery and Charger
3.1. Battery Specifications
Various battery parameters are described in the table below：
3.2. Charging Method
step 1: The position of the charging port is at the front of L8, Open the Charging cover, and make sure that the Charging interface
is dry.
step 2: Insert the charging port to the charging interface on the L8.
step 3: When the indicator of the charger is on in red color, it means it is charging; when the indicator turns to green from red, it
means that the battery is fully charged. Stop charging at this time, as long time of charging will affect the service life of the batteries.
Parameter
Battery type
Rated voltage
Charging voltage
Capacity
Battery weight
Dimensions
Working temperature
Charging temperature
Storage temperature
L8
Lithium batteries
36 V①
42 V
4.4Ah②
Approx. 1.2 kg
L*W*H：330*81*45 mm
-10℃~40℃
5℃~ 45℃
-20℃~45℃
L8F
Lithium batteries
36 V①
42 V
8.7Ah②
Approx. 1.7 kg
L*W*H：330*81*45 mm
-10℃~40℃
5℃~ 45℃
-20℃~45℃
Remarks
①The voltage here refers to the voltage with
moderate capacity of a lithium battery
②L8 is configured with 4.4Ah batteries, L8F is
configured with 8.7Ah batteries
12

3.3. Safety Prompt for Charging
Please charge the batteries every three month or after driving each time in order to extend the service life of the batteries to the
maximum extent. Please charge in the suitable temperature environment.
Failure to charge on time may lead to battery damages. As time goes by, the battery electric quantity will be gradually used up which
will finally lead to over-discharging.
Please use the battery, charger and cable supplied by the original manufacturers so as to avoid over-discharging risk.
Please ensure that the charger uses the designated cable and with correct connection.
Please ensure a well-ventilated environment.
Please ensure that it is used in a dry environment. Never allow the charger or cable to contact
with water, as this may cause an electric shock. Do not touch with wet hands, and in process of
charging, immediately pull out the power plug in occurrence of any failure.
Please make sure to pull out by the plug, do not pull out plug by the cable.
Please do not allow the charger or cable to contact sharp or hot object.
Make regular visual inspection of the charger and charger cable.
In case of any obvious damages found with the charger or cable, do not use the charger to
avoid further impairment but instead contact for replacement.
Please do not repair the batteries, charger or cable by oneself,
but instead, contact us for service in case of any problems.
3.4. Protection against Over-discharging
The INMOTION E-scooter system has a built-in smart over-discharging protection system which will actively cut off the power when
the scooter is in locking state or shutdown state and the electric quantity is too low. The scooter in an over-discharging protection state
need to be awakened via charging, if the scooter remains un-awakened after half hour's charging, please contact the authorized dealer
of the INMOTION Company or the INMOTION after-sale department. 13
Charging port
·
·
·
·
·
·
·
·
·
·
·

4. How to use L8
4.1. Riding L8
L8 is a high-tech traveling and commuting device. Driving without learning about the operating specifications will cause unpredict-
able injuries. This instruction is made for green hands, especially the beginners of L8, stating in details on how to correctly drive L8.
Matters needing attention in driving are also listed. Users shall read them carefully and drive L8 in accordance with the instructions.
4.2. Precautions before driving
During the driving and parking, L8 may produce wear and tear, which will reduce product performance. Thus before driving L8, the
following items must be checked:
· All parts of L8 shall be checked whether they are fixed securely and intact without damage.
· Folding mechanism is locked.
· Sufficient electric power.
· Good state of the type.
· Whether the handle is fixed; loosened bolts and screws shall be tightened.
· You shall find an open area with flat surface for driving, at least an area of 4m * 20m, indoor or outdoor.
· You shall learn about the surrounding driving environment sufficiently to guarantee that it is free from the disturbance of cars,
walkers, pet, bikes and other obstacles.
· A skillful assistant shall accompany you at side. The assistant needs to operate INMOTION E-scooter proficiently and know very
well about precautions and driving methods in this manual.
· Do not trial drive on slippery and wet field.
· Safety helmet and protecting articles against the possible injuries shall be put on.
· Moisture will cause the brake working slowly. After cleaning L8 body, dry the brake at a safe place by air.
· This product must not be used under severe weather conditions( like raining, snowing or icy).
· Before using this product under any circumstance, please confirm whether the brake can work normally nor not.
WARNING!
14

1
2
3
4
4.3. Operating steps of beginners
· Hold the handlebar with two hands, Promote L8 and the power on.
· When the power on, Front decorative lights and tail lights will be lit.
· Step on the pedal with one foot; look ahead, another foot shall be on the ground forwardly, applying initial velocity, after the initial
speed control level is activated, L8 can accelerate to travel forwardly upon starting accelerator handle.
· At that time, another foot also steps on the pedal. Two feet stand in staggered way front and back. Stands upright naturally and two
eyes look ahead horizontally, like standing on the ground. Keep the balance of body.
· Lightly press the accelerator handle for acceleration. The degree of acceleration depends on holding degree on accelerator. Beginners
shall lightly hold the accelerator handle and accelerate slowly.
· Rotate the handle can control L8 in direction. Due to the length of L8, you should pay attention not to swerve within the narrow
space.
· While Scooter needs to decelerate or stop during the driving process, press fingers on brake button until scooter decelerates or
stops.
· At the same time can also be used after stepping on the rear fender, also can make L8 slow down or stop.
· After starting the brake, APO (Automatic Power Off) of the right handle accelerator becomes invalid.
· When not using L8, parking for 1 minutes can be automatically shut down.
4.4. Body folding steps
· 1 : Open the Folding quick spanner.
· 2 : Forward nudge handlebar.
· 3 : Press the Folding button
（As far as possible with the second step at the same time）.
· 4 : Walking down the folding handlebar until a click sound.
· 5 : Folding can be completed.
15

4.5. Switch lamp and active power off
5. Precautions for Safe driving process
L8 is a personal traveling and commuting tool. Strict inspection has been implemented on the technology and production. If the
users do not use it in accordance with the safety warnings regulated in this manual, driving risks may occur. Anywhere or any time,
falling, out of control or bumping, including violence of the driving manual specifications, may cause injuries, even death. To reduce risks
and avoid injuries, users must read this manual carefully and watch the related safety video and abide by the following precautions.
Please wear helmets and protection equipment while riding and driving.
Please do not drive on the slopes over 15° gradient. Do not sharply accelerate or decelerate on slopes.
Protect yourself from obstacles and slipping on road surface. Do not drive on the grass and cobbled road.
Depth of driving into water shall not be more than 30mm.
Forbid riding a Scooter to go up or down steps.
Forbid driving on motor vehicle road.
Forbid soaking in water.
L8 is the transportation tool for only one person, prohibiting driving and riding by several persons at a time.
Beginners who are older than 45 years old or younger than 18 years old shall drive accompanied by others for assistance.
Make sure that the battery has enough power and tire pressures(5.0bar) are normal.
Before mastering the driving skills proficiently, do not try to drive at a fast rate. Please accelerate slowly.
In the case of parking and the power is on,
Both press brake button and throttle button
to turn off the power supply.
In the case of parking and the power is on,
Long press the brake button for 3 seconds,
can turn on or off the lights
16
·
·
·
·
·
·
·
·
·
·
·

6. Care and Maintenance
6.1. Storage
Unreasonable storage will cause inside lithium battery life shorter and other hidden dangers. L8 shall be placed at indoor dry places
with suitable humidity and temperature.
Avoid parking the electric scooter at sun-bathing places (even the trunk of your car) in that the temperature of the body and the
battery from sunbathing may rise as high as 50℃, The battery function and product lifespan may be damaged.
When L8 is not used, the battery will discharge automatically. The battery power shall be monitored within three months and
charged in time to guarantee battery fully charge. Avoid the irrevocable losses from long-time storage of battery without electricity
(deep discharge of battery)
In winter, battery may lose the electricity power due to low temperature.
L8 shall be charged fully before placing for a long time.
6.2. Cleaning
Before cleaning, L8 shall be turned down. Charging wire shall be pulled up and the charging port shall be closed. During the rinsing
process, water shall not flow into the battery-charging port.
Use soapy water, clean water or soft cloth to rub the outer cover of L8. Prohibit using high pressure water gun to swash L8.
The waterproof and waterproof level of L8 shall be IP65 that is, spilling resistant and dust resistant. Thus, it is not allowed to dip L8
in water, which may cause L8 permanent damage.
6.3. Handing
Battery and electricity devices shall not be treated as general domestic rubbish. Since you have made contributions to environmental
protection by driving L8, in order to further avoid unwanted pollution.
Please handle your electric Scooter and all the related components (battery) through authorization processing facilities.
Please abide by the updated guidance notes. Please consult dealers or contact after-sale departments if you have any questions.
6.4. Inflation and Replacement of the Interior and Exterior Tires
If the tire pressure is insufficient, please fill in time to ensure the normal tire pressure.
If you get a flat tire or are in need of new tires, please contact an INMOTION authorized distributors or the INMOTION service
department.
·
·
·
·
·
·
·
·
·
·
·
·
·
17

7. Contact and Legal Information
7.1. Feedback of issues
If you yourself or any other people you know have any questions or improvement advice when using L8, please feel free to contact
us, and we will heed each and every of your question and advice, and do all we can to provide you with the best service.
7.2. Contact Us
ShenZhen INMOTION Technologies Co., Ltd.
Address: Shenzhen city Nanshan District Xueyuan Road No. 1001 Nanshan ZhiYuan B1 building 18 floor
Tel: [phone] or 0086-755-26906865
Email: [e-mail]
7.3. Following the Local Laws
L8 may serve as a smart and convenient travel tool, but it still can't replace other existing transportation means, thus do not try to
ride L8 on public transportation roads. In some countries and regions, L8 is barred from public transportation roads. For detailed
information, contact the related local authority, or you can also make contact with the authorized agent or the after-sales department of
INMOTION.
7.4. Version No.
Version 1.1
18
6.5. Handle loosening adjustment
If you find the right and left side of the handle is loose,
please use M4 six angle wrench Lock the two screws on the lower
position of the quick release wrench.
