IPC CT45 B User manual

This guide is intended for quick consultation only and does not replace the user and maintenance manual.
Before using the machine, read the user and maintenance manual contained in the machine’s packaging thoroughly and strictly follow all the
instructions.
PREPARATION & OPERATION
CT45 B Quick guide
1
6
2 3
9
5
7 8
PLDC02099
ON
AUTO
ECO
ECO
CHEM
H
2
O
+
> 3”

REPLACING THE SQUEEGEE BLADES
ATTACHING/REMOVING THE BRUSH
Attaching the brush:
• rest the brush on the oor in front of the machine. Raise the front of the machine by levering on the handle, then lower it onto the brush, centring it with the brush cover. Action the drive lever repeatedly until the brush
engages..
Removing the brush:
• Raise the front of the machine by levering on the handle, then operate the brush lever repeatedly. After operating the lever a few times, the brush is released and falls to the ground.
DAILY MAINTENANCE
Clean the dirty
water tank.
Check the dirty water tank oat
is undamaged and clean and
moves freely on the pin.
Check that the
detergent outlet lter
is clean.
Check that the brush is clean.
Replace if necessary.
Check that the
squeegee is clean
and the blades are not
worn.
Open the clip (Ref. 1).
Remove the two blade retainers (Ref. 2) by pushing them outwards then extracting them.
Remove the blade.
Reuse the same blade by reversing the edge in contact with the oor until all four edges are worn out, or replace with a new blade, tting it onto the
screws on the body of the squeegee.
Reposition the two blade pressing devices by centering the wider part of the slots on the squeegee body fastening pins, then push the blade pressing
devices inwards.
Close the hook again.
Replace the squeegee on its support, following the instructions described previously.
PLDC02099
BATTERY
CHARGER ON
BOARD
1
2
