Ironwood DTS User manual

0522
DTS
DELUXE
TYPING STAND
IMPORTANT!
Assembly may require the assistance of
another person.
Before you begin assembly:
READ THE DIRECTIONS all the way through one
time. This will speed up the process and help you
understand the sequence of steps.
COUNT THE PARTS AND HARDWARE before
assembly. This ensures you have received all
necessary parts before you begin.
TOOLS: You may need a Phillips head screwdriver,
a medium slotted screwdriver or a plastic mallet. To
protect your new furniture from damage during
assembly, it is recommended to work on a carpeted
surface.
CAUTION: On assemblies requiring glue, make
sure the unit is assembled correctly before gluing.
Once this unit is assembled with glue, the
manufacturer will not be responsible for damaged
parts. Keep a damp cloth or sponge handy to wipe
off excess glue.
To care for this furniture, simply wipe with a cloth
dampened with glass cleaner containing ammonia-D.
In the event any parts are missing from
this package, send your name, address,
telephone number, and a description of
the missing part(s) to: PARTS, Box 1420,
Missoula, MT 59806 or call:
1-800-769-5693 or FAX [phone].

PARTS DIAGRAM
Right Side 05850341 1 ea.
A
B
C
DEFG
H
A
B
C
DEFG
H
Worksurface 05850101 1 ea.
Left Side Panel 05850141 1 ea.
AB
C
D
EFG
H
AB
C
DEF
G
H
AB
C
DE
F
G
H
AB
C
D
E
FG
H
AB
C
DEFG
H
Paper Rack Side 05850116 2 ea.
1/4" black
shelves 4 ea.
Back 05850152 1 ea.
Paper Rack
Bottom 05850119 1 ea.
Paper Rack Top 05850118 1 ea.

H3 Rafix Cam 909909 9 ea.
H1 Rafix Bolt 909925 15 ea.
H8 Washer Head
Screw 920201 2 ea.
HARDWARE
H9 Label Holders H3402 4 ea. H10 Shelf Pins H1021 16 ea.
H2 Rafix Flush
Cam 909911 8 ea.
ASSEMBLE DISASSEMBLE
Using the Rafix System:
Insert the Rafix Cams into the
appropriate holes. The flat edge of
the cam should be facing the edge
of the panel.
Slide Rafix Cams of the panel to be
attached onto the corresponding posts.
Using a #3 Phillips screwdriver, turn the
rotating portion of the Rafix Cam a 1/2
turn clockwise to secure. IMPORTANT!
Do not exceed 1/2 turn when tightening
cams. Turn 1/2 turn counterclockwise
to disassemble and remove panel.
When screwing post
into hole, Do Not
over tighten. Screw
post down until
bottom face of post
flange just touches
board surface.
Flat
edges
must be
aligned
H6 Caster
Locking Caster
H1192 2 ea.
2 ea.
H7 Caster Screw 4ea.

#1
C
H1
H1
Screw four Rafix Bolts (H1) into the pre-drilled holes of the Worksurface
(C) where indicated.
.
H1
#2
AB
H1
H2
H1
 Screw two Rafix Bolts (H1)
into pre-drilled holes of
each Side (A and B) where
indicated.
 Insert two Rafix Cams (H3)
facing out into each Side (A
and B) as shown.
#3 Place Casters (H6) over hold of bottom of A and B
and insert caster screw to secure.
NOTE: The locking Casters should be installed
toward the front of the unit.
A/B
Bottom
H7

D
A
H2
H2
HOLES
Insert four (H2) into the Back (D) as shown. Position
the Back onto the Left Side (A) as shown.
NOTE: Note the hole orientation on Back (D).
Rotate Minifix Cams clockwise to lock in place.
#4 H2
#5
B
D
A
Position the Right Side (B) onto the Back (D) as
shown.
Rotate cams to lock in place
#7 Insert 4 rafix cams (H3) into Paper Rack Top (F)
and 5 rafix cams into Paper Rack Bottom(G)
C
Turn the unit upright. Position the Cams and Dowels of the
Worksurface (C) into the Rafix Cams of the unit as shown.
Rotate Cams (H3) to lock in place.
#6
AB
C
DE
F
G
H
AB
C
DEF
G
H
H3

Take Paper Rack Side (E) and place 4 rafix
bolts (H1) in designated holes. Position
Side panel and insert bolts into rafix cams
of (F) and (G). Turn cams to secure.
#8
E
F
G
E
H8
Select either a left or right-hand Paper Rack placement.
Attach Paper Rack unit to the underside of the
Worksurface (C) using two Washerhead Screws (H8) in
the pre-drilled holes as shown. Turn cam of Paper Rack
Bottom (G) to secure in palce
#9
H8
AB
C
D
E
FG
H
H1

#10 Insert eight Shelf Pins into the pre-drilled holes
in both Paper Rack sides as shown.
Assembly of the Deluxe Typing Stand is now complete.
#11 Put label holders on shelves. Insert shelves to
sit on shelf pins
