Ironwood MBW User manual

03/07
MBW
Modular Break Room
Wardrobe
IMPORTANT!
Assembly may require the assistance of
another person.
Before you begin assembly:
READ THE DIRECTIONS all the way through one
time. This will speed up the process and help you
understand the sequence of steps.
COUNT THE PARTS AND HARDWARE before
assembly. This ensures you have received all
necessary parts before you begin.
TOOLS: You may need a Phillips head screwdriver,
a medium slotted screwdriver or a plastic mallet. To
protect your new furniture from damage during
assembly, it is recommended to work on a
carpeted surface.
CAUTION: On assemblies requiring glue, make
sure the unit is assembled correctly before gluing.
Once this unit is assembled with glue, the
manufacturer will not be responsible for damaged
parts. Keep a damp cloth or sponge handy to wipe
off excess glue.
To care for this furniture, simply wipe with a cloth
dampened with glass cleaner containing ammonia-D.
In the event any parts are missing from
this package, send your name, address,
telephone number, and a description of
the missing part(s) to: PARTS, Box 1420,
Missoula, MT 59806 or call:
1-800-769-5693 or FAX [phone].

A
B
PARTS DIAGRAM
C
G
H
F
D
Left Back - A
Right Back - B 1 ea.
Shelf 1 ea.
Left Side Panel - D
Right Side Panel - F 1 ea.
Top - G
Bottom - H 2 ea.
K
J
E2
E1
Left Door - J
Right Door - K 1 ea.
Divider 1 ea.
HARDWARE
H5 Swivel Casters 402640 2 ea.
H7 1/4-20
Nyloc Nut 904420 16 ea.
H4 Locking Casters 402650 2 ea.
H2 Wood Dowel 195000 32 ea.
H3 Minifix Bolt 909834 50 ea.
H1 Minifix Cam 909810 50 ea.
H6 1/4-20 x 1-1/4
Philip PH Bolt 902205 16 ea.

H8 Flush HingeArm 400200 6 ea. H9 Flush Hinge
Plate 400201 6 ea.
H17 Grommet H1480 1 ea.
H10 Hooded Door
Pull H0820 2 ea.
H18 Plastic Vent H4300 2 ea.
H14 #8 x 1 FH
Quad-Z Screw H2060 5 ea.
H12 12” x 12” Mirror H1380 1 ea.
H13 Mirror Clips H1370 5 ea.
H15 Coat Rod 18”-
30” H1291 1 ea.
H16 #6 x 3/4 PH-Z
Screw H2002 4 ea.
H11 #8 x 1-1/4” Phil
Truss Screw” 920201 4 ea.
H21 #6 x 5/8"
Panhead Screw 901216 2 ea. H19 SP-101
Catch Plate 452340 1 ea.
H22 #8 x 5/8"
Panhead Screw 988056 4 ea.
H20 SP-257
Stop Plate 452330 1 ea.
LOCKSET 250-HP
H23 Lock & Key Set
452310
452320
452350
1 ea.
1 ea.
1 ea.

ASSEMBLED DISASSEMBLED
Using the Minifix System:
Insert the Minifix Cams into the
appropriate holes with the arrow
facing outwards as shown.
Using the #2 Phillips screwdriver,
rotate the Cam Devices a half turn
clockwise until snug.
To disassemble, turn the Cam
Devices counter-clockwise and
remove panels.
When screwing post into hole, Do
Not over tighten. Screw post down
until bottom face of post flange just
touches board surface.
Place the Left Back Panel (A), the Right Back Panel (B) and the Shelf (C) on a clean,
carpeted surface with the pre-drilled holes facing up. If a carpeted surface is not
available, use the foam or cardboard packing material that shipped with this unit.
Insert 32 Minifix Cams (H1) into the pre-drilled holes as shown. Be sure that the arrow
on the Cams is facing toward the outside edge of the panel.
Using a Phillips screwdriver, install two Minifix Bolts (H3) into the pre-drilled holes in the
Right Back Panel (B) as shown.
#1
AB
C
H1
H1 H3 H1
H1
H1
H1
H1
H1
H1 H3

Insert 6 Minifix Cams (H1) into the pre-
drilled holes in the Left Panel (D) and
6 Minifix Cams into pre-drilled holes
in the Right Panel (F)
#2a
F
D
H1
H1
H1
H1
#2b
F
D
H2
H2
Insert 6 Wood Dowels (H2) into the pre-
drilled holes in the Left Panel (D) and the
Right Panel (F) as shown.
H2
#2c
F
D
H3
H3
Using a Phillips screwdriver, install 11 Minifix
Bolts (H3) into the pre-drilled holes of the
Side Panels (D & F) as shown.
H3
H1
#2d
F
D
H9
H9
Install Hinge Plates (H9) using the screws
that are packed with the Hinge Set.
H9 F/D
H9

NOTE: Before installing the dowels and
bolts into the E1 side, turn the Divider over
and prop it up on a flat, raised surface so
that the bolts and dowels in the E2 side do not
press into floor.
#3a
Install 2 Wood Dowels (H2) and 5 Minifix Bolts
(H3) into the E1 side of the Divider (E) as shown.
Install six Minifix Cams (H1) into the pre-
drilled holes in the E2 side of the Divider.
THE E2 SIDE OF DIVIDER CONNECTS TO
THE RIGHT BACK PANEL (B).
Install four Wood Dowels (H2) and six Minifix
Bolts (H3) into the E2 side of the Divider (E)
as shown.
E1
H2
E1
H3
#4 Set the Shelf (C) onto the Back Panel (B)
as shown, guiding the Bolts and Dowels
into the Cams of the Shelf. Using a Phillips
screwdriver, rotate both Cams clockwise to
secure the Shelf to the Back Panel.
C
B
H1
Attach the Left Side Panel (D) to
the Left Back Panel (A) by seating
the Bolts and Dowels of the Side
Panel into the pre-drilled holes of
the Back Panel. Rotate all 4 Cams
clockwise to secure the assembly.
DA
H1
#5
E2
H1 H1
H2
E2
H3
#3b

#6 Attach the Divider (E) to the Left Back
Panel (A) by seating the Bolts and
Dowels of the Side Panel into the pre-
drilled holes of the Back Panel. Rotate
all 4 Cams clockwise to secure the
assembly.
NOTE: The E1 Side of the Divider
must be facing in toward the Left
Panel. This side of the Divider has 2
pre-drilled holes for screws that will
mount the coat rod between the Left
Panel (D) and the Divider (E).
D
E1
H1
#8
D
E
F
H1
H1
Attach the Right Side Panel (F) to the Back (B)-Shelf
(C2) part of the unit, securing the Cams and Bolts as
instructed above.
#7
D
E
C
B
H1
H1 H1
Slide the Right Back Panel (B)-Shelf (C2) assembly to the
assembled portion of Step 7. Make sure the Minifix Bolts of
the Divider (E2 side) are seated into the Cams of the Shelf
(C2)-Back (B) unit. Using a screwdriver, rotate all six cams
clockwise to secure the assembly.

#9
#10
G
H3
H3
H2
H2
H2
H2
Install 13 Minifix Bolts (H3) and 10 Wood Dowels (H2)
into the Top (G) as shown.
DEF
G
Attach the Top (G) to the assembly,
securing Cams and Bolts to the Back
Panels (A & B), the Right and Left
Sides (D & F) and the Divider (E) as
shown.
D
H15
Install the Clothing Rod (H15) into the space between the
Left Side (D) and the Divider (E). Use four #6 PH-Z Screws
(H16) screwed into the pre-drilled holes.
H15
#11
H16

#13
#12
H
H3
H2
H3
H2
H2
H2
H3
H3
Install 13 Minifix Bolts (H3) and 10 Wood
Dowels (H2) into the Bottom (H) as shown.
H
FRONT
H7
H7
H7
H7
H6
H6
H6
H6
Install the two Locking Casters (H4) to the
front of the Bottom (H) using eight Panhead
Bolts (H6) and eight Nyloc Nuts (H7) as
shown.
Install the two Swivel Casters (H5) to the
back of the Bottom (H) using eight Panhead
Bolts (H6) and eight Nyloc Nuts (H7) as
shown.
Attach the Bottom (H) to
the assembly, securing all
13 Cams and Bolts as
shown.
H1
H1
H1
D
F
H
H1
H1
#14

#15a #15b
J
H8 H8 H8
Press three Hinges (H8) into the pre-drilled holes
in each Door Panel (J & K) as shown. Tap them
securely in place using a plastic mallet.
Install the Mirror (H12) to the Left Door (J).
Secure the MIrror with five Mirror Clips
(H13) screwed into the pre-drilled holes
using five Quad-Z Screws (H14) as shown.
H8
J
H14
H13
H12
K
J
With the assistance of another person, put the cabinet upright. The assistance of another person
will be needed to install the Doors (J & K) to the cabinet.
#16
HOOK
PRESS DOWN FIRMLY
SNAP INTO PLACE
Attach the hinges (H8) on the Doors to the
hinge plates (H9) on the Side Panels by
catching the hook on the bottom of the hinge
into the lip of the hinge plate, then pressing the
whole hinge down upon the plate until it snaps
into place.

#18
H10
H11
K
Attach a Catch Plate (H19) to the Top as
shown below, using two #8x5/8" Panhead
Screws (H22).
#17 Install Door Pulls (H10) to each Door using four
Phillips Truss Screws (H11).
H11 H10
H12
H20
H22
H22
H20
H22
H19
Attach a Stop Plate (H20) to the
Divider as shown using two #8x5/8"
Panhead Screws (H22).
H23
H21
Position the Lock (H23) onto the inner side of the Right Door (K) oriented as shown. Secure
the Lock in place using two #6x5/8" Panhead Screws (H21) into the pre-drilled holes of the
Right Door. Press the trim ring of the lock over the keyhole portion of the lock on the opposite
side of the Right Door as shown.
#19
J
K
H19
H23

#20
Push the Plastic Vents (H18) into the two
rectangular openings on the Right Back
Panel (B).
Insert the Grommet (H17) into the round
opening in the Right Back Panel (B).
H17
H18
H17 H18
Your Ironwood Mobile Break Room Wardrobe
Cabinet is fully assembled and ready for use.
