Ironwood GLACIER LPC User manual

LPC
LECTERN
PROJECTOR CART
09/07
IMPORTANT!
Assembly may require the assistance of
another person.
Before you begin assembly:
READ THE DIRECTIONS all the way through one
time. This will speed up the process and help you
understand the sequence of steps.
COUNT THE PARTS AND HARDWARE before
assembly. This ensures you have received all
necessary parts before you begin.
TOOLS: You may need a Phillips head screwdriver,
a medium slotted screwdriver or a plastic mallet. To
protect your new furniture from damage during
assembly, it is recommended to work on a
carpeted surface.
CAUTION: On assemblies requiring glue, make
sure the unit is assembled correctly before gluing.
Once this unit is assembled with glue, the
manufacturer will not be responsible for damaged
parts. Keep a damp cloth or sponge handy to wipe
off excess glue.
To care for this furniture, simply wipe with a cloth
dampened with glass cleaner containing ammonia-D.
In the event any parts are missing from
this package, send your name, address,
telephone number, and a description of
the missing part(s) to: PARTS, Box 1420,
Missoula, MT 59806 or call:
1-800-769-5693 or FAX [phone].
BY

AB
C
F
D
PARTS DIAGRAM
Back 01050352 1 ea.
Top 01050301 1 ea.
Left Side - A
Right Side - B
01050342
01050343 1 ea.
Shelf 01050327 1 ea.
E
Bottom 01050311 1 ea.

ASSEMBLED DISASSEMBLED
Using the Minifix System:
Insert the Minifix Cams into the
appropriate holes with the arrow
facing outwards as shown.
Using the #2 Phillips screwdriver,
rotate the Cam Devices a half turn
clockwise until snug.
To disassemble, turn the Cam
Devices counter-clockwise and
remove panels.
When screwing post into hole, Do
Not over tighten. Screw post down
until bottom face of post flange just
touches board surface.
H4 Swivel Caster 402640 2 ea.
H5 Locking Caster 402650 2 ea.
H1 Wood Dowels 195000 16 ea.
H3 Minifix Cam 909810 18 ea.
H2 Minifix Bolt 909834 18 ea.
H9 Tab-V Plastic
Housing 909930 4 ea.
H6 Panhead Screw 902205 16 ea.
H8 Tab-V Shelf Clip 909932 4 ea.
H7 Flange Lock Nut H2380 16 ea.
H10 Grommet H1480 1 ea.
HARDWARE

Push eight Wood Dowels (H1) into the pre-
drilled holes in the Side Panels (A & B) as
shown.
Screw eight Minifix Bolts (H2) into the pre-
drilled holes in the Side Panels (A & B) as
shown.
#1a
AB
H1 H2 H2
H1
H2
H1
H1
H1
H2
Insert four Minifix Cams (H3) into the pre-drilled holes in the
Side Panels (A & B) as shown. Be sure that the arrows on the
cams are pointing out toward the near edge of the panel.
#1b
AB
H3
H3

H3
Insert seven Minifix Cams (H3) into the pre-
drilled holes in the Top Panel (C) as shown. Be
sure the arrows on the cams are pointing out.
#2
Insert seven Minifix Cams (H3) into the pre-
drilled holes in the Back Panel (D) as shown. Be
sure the arrows on the cams are pointing out.
#3a
Insert two Wood Dowels (H1) into the pre-
drilled holes in the Back Panel (D) as shown.
Screw three Minifix Bolts (H2) into the pre-
drilled holes in the Back Panel as shown.
#3b
D
H3 H3
D
H1
H2
C
H3 H3
#4
H3
H3
D
C
Place the Top Panel (C) so that the Minifix
Cams (H3) are seated onto the
corresponding Minifix Bolts (H2) on the
Back Panel (D) as shown. Turn the Cams
clockwise to secure the two panels together.

#5
With the assistance of another person, place
the Top-Back assembly onto the Left Side Panel
(A), seating the Minifix Cams (H3) of the panels
onto the corresponding Minifix Bolts (H2) in the
Side Panel as shown. Turn the four Cams
clockwise to secure the assembly.
H3 H3
D
C
A
Place the Right Side Panel (B) onto the
assembly, seating the Minifix Bolts into the
corresponding Cams (H3) of the Top (C) and
the Back (D). Turn the four Cams clockwise
to secure.
#6
A
B
C
D
H3 H3
#7
E
H2
H1
H1 H1
Place the Bottom Panel (E) with the
“inside” set of holes facing up. Push
six Wood Dowels (H1) into the pre-
drilled holes as shown.
Screw seven Minifix Bolts (H2) into
the pre-drilled holes as shown.

Install the four Casters to the Bottom.
Position the two Locking Casters (H5) at
the front of the unit, and the two Swivel Casters
(H4) at the back of the unit.
Attach the Casters in place by screwing 16
Panhead Screws (H6) into the pre-drilled holes
from the inside.
Tighten the Flange Lock Nuts (H7) from the
Caster Wheel side to secure the Caster plates to
the assembly as shown.
With the assistance of another person,
set the assembly with the Top (C) down.
Place the Bottom Panel (E) on the
assembly, seating the Bolts into the
corresponding Cams in the Side (A & B)
and Back (D) Panels. Turn all seven
cams clockwise to secure.
#8
E
H3 H3
H3
H6
LOCKING
CASTERS
FRONT
H7
F
#9
With the assistance of another person,
turn the unit upright. Determine the
height for the Shelf (F). Push four Tab-
V Shelf Pins (H8) into the pre-drilled
holes at the chosen height.
#10
Side A/B
H8

A
LIGNED
FLAT
EDGE
#11
#12
F
Install four Tab-V Plastic Housings
(H9) into the Shelf (F). Using a plastic
mallet, tap the plastic housings into
the pre-drilled holes. Make sure that
the flat edge faces outwards and is
flush with the surface.
IMPORTANT! The flat edge
of the plastic housing must
be aligned with the shelf
edge. Plastic Housings
cannot be repositioned once
installed.
Slide the Shelf (F) into place over the
Shelf Pins (H8) and push down until
fully seated.
Turn the rotating portion (Cam) 1/2 turn
to lock in place.
To remove, simply turn the Cam counter
clockwise 1/2 turn and lift the shelf off
of the Shelf Pins.

#13
The Projector Cart is now fully assembled and ready for use.
The Projector Cart may also be used with the “Teacher’s Cart Lectern (TCL) as shown below.
Insert the Round Grommet (H10) into the hole on the top.
H10
