jbc HA245A-5B User manual

HA245/HA470
Automatic General/Heavy Duty
Soldering Set for Robot
INSTRUCTION MANUAL

Work Place Examples
HA Automatic Soldering Set for Robot
HM Soldering Set for Robot
Automatic Soldering Tool for Robot .... 1 unit
According purchased reference included either
Ref. TRA245-B or
Ref. TRA470-B
Manual ........................................................ 1 unit
Ref. 0027874
TRA includes:
This manual corresponds to the following references:
- HA245A-5B works with R245 cartridges
- HA470A-5B works with R470 cartridges
Packing List
Manual ............................ 1 unit
Ref. 0027871
2

SFR includes:
Allen Key 1,5 mm ........ 1 unit
Ref. 0741610
Reel Support .............. 1 unit
Ref. 0024561
Solder Feeder for
Robot .............................. 1 unit
Ref. SFR-B
Communications
Cable 3 m........................ 1 unit
Ref. 0024563
Spanner 10 mm ........... 1 unit
Ref. 0017631
Allen Key 2,5 mm ........ 1 unit
R ef . 0 0125 74
Screws
DIN 912 M4x65 .......... 2 units
Ref. 0024552
Screws
DIN 912 M4x20 .......... 2 units
Ref. 0921890
Manual ............................ 1 unit
Ref. 0027875
Insulator ........................ 1 unit
Ref. 0024588
Allen Key 3 mm ......... 1 unit
Ref. 0013609
Screws
DIN 7991 M4x10 .......... 1 unit
Ref. 0490180
www.jbctools.com
3

UCR includes:
Manual ........................................................................................................................................................ 1 unit
Ref. 0027876
Tool Cable 3m .............. 1 unit
Ref. 0027924
Communications
Cable 3m ........................ 1 unit
Ref. 0024563
Control Unit for Robot ........................................................................................................................... 1 unit
According purchased reference included either
Ref. UCR245-5A or
Ref. UCR470-5A
Power Cord 1.5m ........ 1 unit
Ref. 0023714 (230 V)
4

Cartridge Exchanger for Robot ............ 1 unit
According purchased reference included either
Ref. CS2R245-B or
Ref. CS2R470-B
Screw ........................................................... 2unit
DIN 912 M6x20
Ref. 0842925
Washer ........................................................ 2unit
DIN 125 Ø6.4 mm INOX
Ref. 0919480
Manual .................................................................................................................................................................. 1 unit
Ref. 0027877
CSR includes:
Upper Center Jig ...................................... 1 unit
Ref. 0023652 for CS2R245-B
Ref. 0023625 for CS2R470-B
Lower Center Jig ...................................... 1 unit
Ref. 0029067 for CS2R245-B
Ref. 0029055 for CS2R470-B
www.jbctools.com
5
