SIMPLIFIED CHART DISPLAY
NDC-2000

●Displays vector charts such as S-57 and C-MAP, and raster chart as ARCS.
●Safe navigation ensured by the crossing alarm function for safety contours,
dangerous area and the guard ring function (not available for ARCS).
●ARPA and AIS information can also be displayed in overlay in a chart.
●Ease of operation supported by high-speed drawing and processing.
●Heavy duty design to realize high-reliability operation for maritime use
(in compliance with IEC-60945 ver. 4).
●The dedicated LCD display with high visibility and the keyboard with
superior operability are optionally available.
LCDDisplayNWZ-147-ACS※
※TheLCDdisplayandthekeyboardareoptions.
NDC-2000MainUnit
KeyboardNCE-7721C※

NDC-2000Model
100/110/220/230VAC±10% 50/60Hz±5%Powersupply
100Wmax.60WinaveragePowerconsumption
−15℃to＋55℃Operatingtemperature
Environmental
conditions 93%at40℃Operatinghumidity
−25℃to＋70℃Storagetemperature
AnalogRGB × 1（D-Sub15pin）
SXGA:1280 × 1024pixels（60Hz）
VIDEOoutput
External
input/output
Ethernet10/100base-T× 1portLAN
2portUSB
2portPS/2
RX:4port,TX:3port.IEC-61162-1
BuiltinDVD-R
Media Builtin3.5"FDD
Vectorchart:ENC,C-MAPEd2/Ed3*
Rasterchart:ARCS
Displayablecharts
Chartdisplay
functions Motionmode:TM/RM
Presentationmode:North-Up/Course-Up/Rotation（Settingdirectionup）
Displaymodes
1/1,000to1/75,000,000Chartscale
0.125to120nmRange
Routeediting,alternativerouteeditingandsafetycheckonplannedrouteRouteplanningfunctions
Monitoringofownship'sposition,safetydepthcontourcrossing,approachto
obstacle/exclusionarea,off-route,waypointarrival,off-courseanddrifting
Navigationmonitoringfunctions
60targetsmax.OthershipsdisplayonARPA
200targetsmax.OthershipsdisplayonAIS
CorrespondingAutopilot:YDK,TOKIMEC
*NotcorrespondingTCS
Automaticnavigationfunction
Multi-view,scrolling,semi-automaticchartupdate,
datarecording(90daysmax.),printingofscreen/route/logbook
Otherfunctions
7ZPNA4011（English）Instructionmanual
Accessories 7ZPNA0506（English）Extramanual
NWZ-147-ACSDedicatedLCDdisplay
Options
NCE-7721CDedicatedkeyboard
NCT-4106NSKunit
BQD-2888（IEC-61162-1transmit/receiveport × 4port）Serialinterfaceextensionunit
PCP-ACK-595US-PS2-R/5EZKT00022PCkeyboard
ST-45UPI/5EZLY00003Trackball
MPXP33436C-MAPEd3upgradekit
*C-MAPEd3isoption.

2-R3
φ1 4
6
1010
74.5
156.713
169.7
118.5
144.5
150
35337
372
112.5
340
20.3 20.3 （122）
RearView
299.4
PrintedinJapan2007.10 1-1.5D
2007.10
Mass:12kg
For further information, contact:
Since 1915
Main Office: Nittochi Nishi-Shinjuku bldg.
10-1, Nishi-Shinjuku 6-chome
Shinjuku-ku, Tokyo 160-8328, Japan
Telephone: [phone]
Facsimile: [phone]
Overseas Branches : Seattle, Amsterdam, Athens
Liaison Offices : Taipei, Manila, Jakarta, Singapore,
Hanoi, Shanghai, New York
26EM
，
●
Specifications may be subject to change without notice.
