Keys Fitness KF-HCL User manual

Half Cage lat attaCHment
Owner’s Manual
Read all precautions and
instructions in this manual before
using this equipment.
KF-HCL
215-00099
10/06 Rev A

2
Important Safety Information 3
Before You Start 4
Assembly 5-9
Parts List 10
Exploded View 11
Warranty Information 12
Table of Contents

3
Prior to assembly, remove components from the box and verify that all the listed parts
were supplied.
Before using this unit or starting any exercise program, consult your physician.
This is especially important for persons over the age of 35 and/or persons with pre-
existing health problems. Keys Fitness Products LP assumes no responsibility for
personal injury or property damage sustained by or through the use of this prod-
uct.
It is the owner’s responsibility to ensure that all users of this unit have read the
Owner’s Manual and are familiar with safety information and precautions.
SAFETY INFORMATION WARNING!
SAFETY PRECAUTIONS
• This unit should only be used on a level surface and is intended for indoor use
only. Keys Fitness recommends an equipment mat be placed under the unit to
protect the floor or carpet and for easier cleaning.
• Wear comfortable, good-quality walking or running shoes and appropriate cloth-
ing. Do not use this unit with bare feet, sandals, socks or stockings!
• Always examine your unit before using to ensure all parts are in working order.
• Do not leave children unsupervised near or on the unit.
• Service to your unit should only be performed by an authorized service represen-
tative, unless authorized and/or instructed by a Keys Fitness technician. Failure
to follow these instructions will void the warranty.
Important Safety Information
NOTE: Hand tighten bolts and nylon nuts until machine is fully
assembled.

4
THANK YOU for making this unit a part of your exercise program.
Keys Fitness assures the very best in value, appearance, durability
and biomechanics.
This manual will guide you through the assembly process. If at any
time you are having trouble with the assembly or use of this product, then
please contact us at our Keys Fitness Helpline. We have trained service techni-
cians on site to take care of you, our valued customer.
KEYS FITNESS SERIES
MODEL: KF-HCL
QUESTIONS?
CALL
1-888-340-0482
Monday-Friday
8:30-5:30 Central Time
When calling please have the following product information available:
REGISTRATION CARD
To avoid unnecessary delays in warranty parts and to insure that a permanent
record of your purchase is on file with our company, be sure to send in the war-
ranty registration card or register on-line at www.keysfitness.com within 10 days
of purchase.
Before You Start

Assembly
5

STEP 1
Connect Lower Support (1), Footbrace (8) and Pulley Bracket
(9) to Half Cage using:
3 x (19) Bolt M10x70
8 x (20) Washer 10
5 x (21) Nylon Lock Nut M10
2 x (27) Bolt M10x95
6
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Assembly

STEP 2
Assemble weight carriage structure using:
2 x (6) Guide Rod
1 x (4) Slide Weight Support
4 x (11) Plastic Sleeve
2 x (12) Bumper for Weight
1 x (2) Weight Base (Not Labeled)
2 x (20) Washer 10
2 x (25) Bolt M10x20
Note: Bolts (25) will need to be tightened before moving to
STEP 3.
Secure Weight Base (2) to Half Cage using:
1 x (2) Lower Support 2 x (21) Nylon Lock Nut
2 x (28) Bolt M10x95 4 x (20) Washer 10
7
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Assembly

STEP 3
Connect Top Frame (4) to Half Cage and Guide Rods (7) using:
2 x (22) Bolt M12x80 2 x (25) Bolt M10x20
4 x (23) Washer M10 2 x (20) Washer 10
2 x (24) Nylon Lock Nut M12
Place High Pulley Cable (34) into positions using:
5 x (14) Big Pulley 4 x (21) Nylon Lock Nut
6 x (18) Big Pulley Spacer 2 x (26) Bolt M10x50
10 x (20) Washer 10 2 x (13) Plate for Pulley
3 x (19) Bolt M10x70
Place Low Pulley Cable (35) into positions using:
4 x (14) Big Pulley 4 x (21) Nylon Lock Nut
1 x (18) Pulley Bracket 2 x (19) Bolt M10x70
4 x (26) Bolt M10x50 8 x (20) Washer 10
8
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Assembly

STEP 4
Connect all attachments using:
2 x (30) Pear Hook
1 x (15) Long Bar
1 x (8) Footbrace
1 x (32) U Pin
1 x (10) Chain
1 x (5) Short Bar
5 x (17) Plug
9
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Assembly

KF-HCL Parts List Rev B
Ref # Part # Description Qty
A KF-HC-REF ****Reference Only***** 1
1 223-00922 LOWER SUPPORT, KF-HCL 1
2 223-00923 WEIGHT BASE, KF-HCL 1
3 223-00924 TOP FRAME, KF-HCL 1
4 223-00055 SLIDE WEIGHT SUPPORT 1
5 223-00092 LAT BAR KPS-GYM 1
6 223-00056 GUIDE ROD KPS-HCL 2
7 210-00123 SPRING CLIP 2
8 219-00366 FOOT BRACE, KPS-HCL 1
9 219-00012 PULLEY BRACKET KPS-HCL 1
10 229-00111 CHAIN, KPS-HCL 1
11 206-00188 PLASTIC SLEEVE, 44.5X25 4
12 206-00026 WEIGHT BUMPER KPS 2
13 219-00006 PULLEY PLATE, KPS 2
14 223-00228 BIG PULLEY 4.5" 9
15 223-00099 SHORT BAR 1
16 206-00016 ROUND PLUG 48 2
17 206-00394 PLUG, 50.8X76.2 KF SERIES 5
18 202-00385 BIG PULLEY SPACER, KPS-HCL 6
19 202-00650 ALLEN BOLT, M10X70 5
20 202-00223 WASHER, 11X23X2 34
21 202-00091 NYLON NUT, M10 15
22 202-00651 ALLEN BOLT, M12X80 2
23 202-00222 WASHER, 13X26X2 KPSFI #32 4
24 202-00092 NYLON NUT, M12 2
25 202-00644 ALLEN BOLT, M10X20 4
26 202-00125 ALLEN BOLT M10*50 6
27 202-00652 ALLEN BOLT, M10X100 2
28 202-00653 ALLEN BOLT, M10X95 2
29 206-00103 LAT BAR GRIP - KPS 4
30 210-00032 PEAR HOOK 3
31 219-00326 SPRING COLLAR PLASTIC GRIPS 4
32 210-00146 U PIN, KPS-HCL, KPS-LEGA, KPS-OB 1
33 202-00048 JAM NUT 1/2" 1
33 202-00048 JAM NUT 1/2" 1
34 229-00014 HIGH PULLEY CABLE KPS-HCL 1
35 229-00013 LOW PULLEY CABLE KPS-HCL 1
10
Parts List
