KI Enlite ENRC Series User manual

Assembly Instructions
Enlite Tables
March 2017

Enlite Tables
Assembly Instructions
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
1
TOOLS REQUIRED
lTorque adjustable screw gun
or screw driver
lPhillips #2
lPhillips #3
l3/4”open end wrench
lTorx #25
l1/8”drill bit
1. Identify the table to be
assembled and verify the
style and orientation of the
table legs (Figure 1).

2
Enlite Tables
Assembly Instructions
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
STANDARD HEIGHT TABLES
Note: See page 3 for ADA
wheel chair height tables.
1. Carefully place table top upside
down on a soft protective
surface.
2. Line up bases with pre-drilled
holes (Figures 3 & 4).
Note: The longer side of the
attachment plate always faces
towards the center of the table.
3. For “T” & “Y” legs, secure
legs to table top using eight or
ten #12 x 3/4” Phillips
pan head screws per leg
(Figures 3 & 4).
Note: Screws are not required
in the holes closest to the the
leg tubes (Detail A).
For Post leg (Boomerang &
Scale-up tables), secure leg
to table top using ten #12 x 3/4”
Phillips pan head screws per
leg (Figure 4).
4. Screw casters or optional
glides into threaded leg tubes.
(Figures 3 & 4).
Note: For “T” & “Y” legs,
locking casters should be
installed on user’s side of table
(Figures 3, 4 & Detail B). For
Post legs, use non-locking
casters only (Figure 4).
5. Tighten casters using 3/4”open
wrench. Turn optional gliders
until about 1/2”of telescoping
shroud material remains visible.

Enlite Tables
Assembly Instructions
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
3
ADA WHEELCHAIR HEIGHT
TABLES
Important: Not all of the required
base attachment pilot holes are
pre-drilled in the table top. It is
important that pilot holes be drilled
for the remaining mounting screws
to avoid damage to the table top
(Detail C). ADA table bases must be
secured with ten screws each.
1. Carefully place table top upside
down on a soft protective
surface.
2. Line up the attachment holes
at the outer corners of the
bases with the pre-drilled holes
(Figure 5).
Note: Depending on the table,
there will be six or seven pilot
holes aligned with the base
attachment holes.
3. Secure bases to the table
top using #12 x 3/4”
Phillips pan head screws
(Figures 5 & 6).
4. Drill
1/8"diameter pilot holes
5/8"deep into three or four
available attachment points to
complete ADA leg attachment
(Detail C).
5. Install #12 x 3/4” Phillips
pan head screws into holes
drilled in step 4.
Note: There should be five
screws on each side of leg.
For Post leg (Boomerang
& Scale-up tables), secure
leg to table top using ten
#12 x 3/4” Phillips pan head
screws per leg (Figure 6).
6. Screw casters or optional
glides into threaded leg tubes.
(Figures 5 & 6).
Note: Locking casters should
be installed on user’s side of
table (Figure 5 & Detail B).
For Post legs, use non-locking
casters only (Figure 6).
7. Tighten casters using 3/4”open
wrench. Turn optional gliders
until about 1/2”of telescoping
shroud material remains
visible.

4
Enlite Tables
Assembly Instructions
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
ACCESSORIES
Clear Plastic Vertical Leg Wire
Manager
Clear plastic vertical leg wire
managers come in pairs and may
be assembled onto different legs or
onto each upright on one leg.
1. Press one end of the wire
manager over one of the leg
uprights. Then, complete
snapping on the wire manager
by working it over the upright to
the other end (Figure 7).
An optional, more permanent
installation requires attaching
the leg wire manager to the leg
with #8 Torx screws. Proceed to
steps 2 & 3.
2. Drill a 1/8”diameter hole through
the wall between two “barrels”
of the wire manager. Locate the
hole using the groove in the
wire manager’s shared wall and
at a distance from the end of the
manager for the desired height
up the leg tube (Detail D).
3. Secure the wire manager to the
pre-drilled leg tube hole
using a #8 Torx screw
(Figure 8).

Enlite Tables
Assembly Instructions
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
5
Leg End Panel
End panels are pre-installed on
the legs at the factory but may be
ordered separately.
1. From the middle of the table,
insert narrow end of panel
between the leg tubes
(Figure 9).
2. Line up the five holes in the
end panel with the mounting
holes in the leg tubes.
3. Secure the end panel in place
using five #25 Torx screws.
4. Repeat for other leg.

6
Enlite Tables
Assembly Instructions
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Power/Data Module
(PowerUp®)
Tables may be ordered with one or
two power/data modules. Theses
tables come equipped with the clear
vertical leg wire managers.
1. After completing table
assembly, and with the table
right side up, insert the
power/data module cord
through the hole in the work
surface (from above) and press
the power/data module into the
hole (Figure 10).
2. Secure the power/data module
to the table top with two spacer
clips and #8 Phillips head
screws (two screws per clip)
(Figure 11).
3. Route the module cord and/or
optional data lines to the clear
vertical wire managers at one or
both table legs (Figure 12).

Enlite Tables
Assembly Instructions
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
7
Power/Data Module
(PowerUp®) continued
4. To open module, push down
lightly on the lid dimple and
release. To close module,
push lid down until slightly
recessed in module body and
release (Figure 13).
5. Select the appropriate data
plate for the phone/data
jack to be used (see chart)
and carefully remove from
injection-molded tree (Figure
14). Jacks are sold by
separate companies and not
supplied with the module.
6. Depending on style of jack,
it may be necessary to route
phone/data cord through
module grommet opening
and data plate to install. Wire
jack appropriately and snap
into data plate. Snap data
plate assembly into module
grommet opening as shown
(Figure 15).
7. The PowerUp module may
be removed without tools
by squeezing the front and
rear snaps located under the
worksurface while pulling up
on a module (Figure 15).
Data Plate
Letter Opening Size Phone/Data Jack
A None Blank
B .635 x .730 Blank
C .670 x 9.29 Panduit “CJ”
D .585 x .780
Panduit “KJ” and “KJA”, amp CAT-3 and CAT-5,
Hubbel “HD5”, Otronics “OR-6295003-T568B”
and “OR-6295004-T568A”, Krone, Leviton
“41108-RE5”
E .680 x .710 ATT & T

8
Enlite Tables
Assembly Instructions
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Care and Maintenance
KI Enlite tables require minimal
maintanence. The high pressure
laminates used on the
continuous tables also require
minimum maintenance.
To clean laminate, use a mild
solution of water and detergent.
Pine-Sol and warm water works
very well. Wipe clean with a dry
cloth. As a last resort, stubborn dirt
or grease may be removed with a
lacquer thinner or other solvents.
Some stains such as grape juice
may be removed by wetting the
table surface and sprinkling lightly
with baking soda, then wipe clean
with a damp cloth. As always,
thoroughly dry the surface with a
dry cloth. Never use a harsh
abrasive such as Comet cleanser,
scrub pads, etc., to clean the
surface. To maintain a bright
attractive surface, occasionally
apply a coating of wax (the same
you would use on your home
furniture) to the table top.
Gouges and abrasions in the vinyl
“Bull Nose” edging can be removed
with “000” steel wool. Apply a light
coating of vinyl floor wax to restore
the sheen. Mop and Glo works well.
Never use a water hose to clean a
table. In the event a table becomes
wet, as soon as possible thoroughly
dry both sides of the top with a dry
cloth. Excessive moisture will cause
the particleboard core to swell the
top and bottom, exposing the core
behind the molding. The top will
appear to grow in thickness.
Do not use these products:
lSolvent based cleaners such as
mineral oil, mineral spirits or
turpentine.
lCitrus cleaners (all contain
high levels of citric acids that
penetrate plastics).
lOrange oil based cleaners (all
contain citric acid).
lHeavy-duty cleaners such as
Fantastic, 409 and other
aggressive industrial cleaners
that are designed for bathrooms
and kitchens.
lPowdered cleaners such as Ajax
or Bon-Ami.
lProper care and careful use is
the best method of maintaining
the finish of the product.

Enlite Tables
Assembly Instructions
9
