Kramer VP-796 User manual

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 1
VP-796
Operating Instructions

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 2
This manual explains how to operate your VP-796 Presentation Scaler-Switcher.
If you have any queries relating to this or any other product supplied by Kramer please visit our
web site www.kramerelectronics.com.
All trademarks acknowledged
Kramer operates a policy of continued product improvement, therefore specifications are subject to
change without notice as products are updated or revised.
E&OE.

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 3
Contents
SAFETY WARNING 5
INTRODUCTION 6
1.1. General Introduction 6
1.2. Packing List 7
QUICK SET-UP FLOW CHART 8
2.1. Basic Switcher Set-Up 8
VP SYSTEM DESCRIPTION 9
3.1. Product Overview 10
3.2. Product Specification 10
3.2.1. Power Supply Requirement 10
3.2.2. Video Inputs 10
3.2.3. Component Video Inputs 10
3.2.4. Computer (SVGA) Inputs VESA formats 11
3.2.5. HDMI & DVI Inputs 11
3.2.6. DP Input 11
3.2.7. HDBT Input 11
3.2.8. Audio Output 12
3.2.9. Display Output 13
UNIT CONTROL 16
4.1. LCD Panel Control 16
4.2. Web Browser Control 19
4.3. Introduction 24
4.4. Main Menu 26
4.5. Input 26
4.6. Output 26
4.6.1. Display Type 26
4.6.2. Gamm/Color/Crush 28
4.6.3. Output Config 29
4.7. Colour 29
4.7.1. Black-Level Offset 29
4.7.2. Black-Level 29
4.7.3. Contrast 30
4.7.4. Saturation 30
4.7.5. Hue 30
4.7.6. RGB values 30
4.7.7. Colour Temp 30
4.7.8. Input Gamma 30
4.8. Geometry 30
4.8.1. Picture Format 30
4.8.2. Overscan 31
4.8.3. Pan Tilt Zoom 31
4.9. Enhancement 32
4.9.1. Sharpness 32
4.9.2. Detail 32
4.10. System 33
4.10.1. User 33
4.10.2. Names/Profiles 33
4.10.3. Input Config 33
4.10.4. Menu Settings 35
4.10.5. Network Settings 35
4.10.6. Security Settings 36
4.10.7. Factory Defaults 36
4.11. Status 36
FIRMWARE UPDATE 37
5.1. Introduction 37
5.2. Updating Firmware 37
ENVIRONMENTAL AND EMC 38
6.1. Recommended Operating Conditions 38

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 4
6.2. Storage 38
6.3. CE and FCC Compliance 38
6.4. PAT Testing 38

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 5
SAFETY WARNING
1. THERE ARE NO USER SERVICEABLE PARTS WITHIN THE UNIT. REMOVAL OF THE TOP COVER
WILL EXPOSE DANGEROUS VOLTAGES. DO NOT OPERATE THE UNIT WITHOUT THE TOP COVER
INSTALLED.
2. ENSURE THAT ALL ELECTRICAL CONNECTIONS (INCLUDING THE MAINS PLUG AND ANY
EXTENSION LEADS) ARE PROPERLY MADE AND COMPLY WITH ELECTRICAL SAFETY
REGULATIONS.
3. ENSURE THAT THE INTEGRITY OF THE EQUIPMENT ISOLATION BARRIER IS MAINTAINED WHEN
CONNECTING TO OTHER EQUIPMENT. THIS MEANS THAT ONLY LOW VOLTAGE ISOLATED
CIRCUITS MAY BE CONNECTED TO THE SIGNAL INPUTS AND OUTPUTS. IF ANY DOUBT EXISTS
CONSULT QUALIFIED SERVICE PERSONNEL.
4. TO PREVENT SHOCK OR FIRE HAZARD DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR
MOISTURE. IF SUCH EXPOSURE OCCURS, REMOVE THE PLUG FROM THE MAINS OUTLET AND
HAVE THE EXPOSED UNIT CHECKED BY QUALIFIED SERVICE PERSONNEL.
5. DO NOT CONTINUE TO OPERATE THE EQUIPMENT IF YOU HAVE ANY DOUBT ABOUT IT
WORKING NORMALLY, OR IF IT IS DAMAGED IN ANY WAY. WITHDRAW THE MAINS PLUG FROM
THE MAINS OUTLET AND CONSULT QUALIFIED SERVICE PERSONNEL.
6. DO NOT REMOVE ANY FIXED COVERS UNLESS YOU ARE QUALIFIED TO DO SO AND EVEN THEN
WITHDRAW THE MAINS PLUG FROM THE MAINS OUTLET BEFORE YOU START.
7. THIS EQUIPMENT CONTAINS NO USER SERVICEABLE PARTS. REFER ALL SERVICING AND
MAINTENANCE TO QUALIFIED SERVICE PERSONNEL.
8. TO AVOID EXPLOSION, DO NOT OPERATE THIS EQUIPMENT IN AN EXPLOSIVE ATMOSPHERE

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 6
INTRODUCTION
1.1.
General Introduction
VP-796 features excellent image processing algorithms for the very best scaling, and market leading
HD & SD per-pixel multiple Iow-angle motion-adaptive de-interlacing and automatic film 3:2 and 2:2
pull-down correction, significantly outperforming the capabilities of benchmark competitor products.
The unit can be operated as a seamless switcher with extremely fast switching transitions.
VP-796 uses a very flexible high performance video input front end including true component video
support in analogue YPbPr and RGBS formats as well as composite (CVBS) inputs. A very high
performance video decoder is utilised with 4x oversampling and 3D Y/C separation for outstanding
video image clarity.
HDMI, DVI, HDBT and Display Port video with HDCP encryption is also supported, as are computer
graphics inputs in SVGA analogue and HDMI/DVI digital formats.
The output format can be set to I/O Lock mode where it locks the output frame rate to the input frame
rate dynamically without frame rate conversion so as to reduce system latency, or it can be set to a
fixed output frame rate, e.g. for driving basic screens which are not 50Hz-compatible. The output format
can also be set to lock to an externally provided synchronization signal on various models (see model
matrix).
Outputs are available in HDMI/DVI digital and HDBaseT formats on various models which are useable
simultaneously.
Please note that if an HDCP encrypted signal is connected to the DP, HDMI or DVI input, the HDMI and
DVI output signals will be similarly HDCP encrypted. HDCP capability can be switched off by the units,
so that a source may be forced to output non content protected material unencrypted.
VP-796 supports Pan, Tilt and Zoom to select a ‘region of interest’ portion of the input image, fill the
screen and pan/tilt within it.
System control is via a menu system through the inbuilt TCP/IP web server or via the built in LCD panel
and jog dial. Additionally a free API manual is published on our website of the LAN remote control port.

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 7
1.2.
Packing List
VP-796 is supplied with the following:
1) 3 pin plug IEC mains cable
2) CD (w/ documentation)

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 8
QUICK SET-UP FLOW CHART
2.1.
Basic Switcher Set-Up
Connect Power
Connect Sources (Blue Ray Player, Set Top Box, PC, etc.)
Use input connectors from different groups for ultra-fast switching, groups are identified by
input channel keys with identical color.
Press the Test button so the unit displays an image regardless of the state of the sources
connected.
Press the Menu/Select button to activate the menu system. Scroll through the menu system
with the jog wheel. Turn the wheel to the left to climb down the menu system, and to the
right to climb up the menu. The jog wheel has a push function. Pushing the jog wheel has
the same effect as pressing the Menu/Select button.
Scroll to the menu item Output with the jog wheel. Input TESTPAT
The menu will look like this with the Output menu item marked >Output >
by an arrow. Color >
Geometry >
Connect the display device (Monitor, LED Wall, Projector, etc.)
to one of the output connectors DVI/HDMI 1, HDMI 2 or HDBaseT.
Start

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 9
The Display Type sub menu allows changing the default >O/P Mode 1920x1080p
output mode of 1080p at 60Hz. Press the menu button and a Frame Rate 60 Hz
list of output modes is shown. I/O Lock Off
Frame Rates >
This is a list box. The currently selected mode and the nearest O/P Mode
neighbors are shown. Use the jog wheel to scroll to the desired 1920x1080i
output mode and press the menu button to select it. Let us >1920x1080p
assume the unit was set to UHD resolution. 2048x1080p
The Display Type menu will show up again and the newly >O/P Mode 3840x2160p
chosen mode is active. Frame Rate 60 Hz
I/O Lock Off
Frame Rates >
Press the Esc (Escape) button on the keyboard three times to In: SMPTE
successively get the menu tree up again. Finally the following TESTPAT
status screen will be displayed. Out:3840x2160p 60Hz
Now press an input channel key on the keyboard to switch to Free Run
a connected source, e.g. HDMI 1.
Let us assume the input is 1080p 59.94Hz from e.g. a BD In: 1920x1080p 59Hz
player. The status menu changes to the following screen. HDMI 1
An image should be seen on the display connected. Out:3840x2160p 60Hz
Free Run
Enter the Display Type sub menu by pressing the menu button. >Display Type >
(Note: Since the first item of a sub menu is selected when Gamma/Color/Crush >
first entered the jog wheel does not need to be used to select Output Config >
the Display Type menu item.) Exit >
Press the menu button to enter the Output menu. >Display Type >
The menu will now look like this. Gamma/Color/Crush >
Output Config >
Exit >
Finished

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 10
VP SYSTEM DESCRIPTION
3.1.
Product Overview
The unit designed to accept the following input signals:
Model
VP-796
VP-797
VP-798
2x 3G-SDI/HD-SDI/SDI
(Serial Digital Interface) via BNC



Display Port
via DP connector



2x HDMI (4k)
via HDMI connector



HDBaseT
Via RJ45 connector



DVI via DVI-U
(supporting a digital and a YPbPr input)



VGA analogue via 15HDD



Composite Video
via BNC



HDMI (1080p deep color)
via HDMI connector



3.2.
Product Specification
This section provides technical details for all possible inputs.
3.2.1.
Power Supply Requirement
100V-264VAC 50/60Hz connected via a standard IEC connector located on the rear panel.
3.2.2.
Video Inputs
Composite via BNC connector
Signal formats Composite (CVBS)
Standards NTSC, PAL, SECAM
Composite (CVBS) input level 1V p-p nominal incl. sync
Input Impedance 75 Ohms
3.2.3.
Component Video Inputs
Via DVI-U connector and appropriate adapter cable
YPbPr (YUV), YPbPrS and RGsB component video, menu selectable.
Signal formats 484i (480i) and 576i (SD), 480p, 576p (ED), 720p, 1080i at 50, 59.94 and 60Hz and
1080p at 23.98, 24, 25, 29.97 and 30Hz.
Please note this input does not support Computer SVGA signals which should be connected via the
Computer SVGA input, The SVGA input supports the separate H & V syncs.

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 11
3.2.4.
Computer (SVGA) Inputs VESA formats
Signal formats: DOS, VGA –WUXGA up to 165MHz pixel clock
RGB video level 0.7V - 1.0V
RGB input impedance 75 Ohms
Sync format Separate H & V sync at TTL/5V levels.
3.2.5.
HDMI & DVI Inputs
HDMI with or without HDCP, 36-bit video compatible.
DVI-D input with or without HDCP
Signal formats - video
SD: 625i (576i) and 525i (480i) in double-rate formats; ED: 480p, 576p; HD: 1280x720p, 1920x1080i,
1920x1080psf; 1920x1080p 23.97, 24, 25, 29.94, 30, 50, 59.94 & 60Hz; 2048x1080p 23.97, 24, 25,
29.94, 30, 50, 59.94 & 60Hz.
The 4k capable HDMI 1 and HDMI 2 inputs also support: 3840x2160p & 4096x2160p 23.97, 24, 25,
29.94, 30, 50, 59.94 & 60Hz (50, 59.94 & 60Hz supported in YUV 4:2:0 colour space format),
Signal formats –computer
Common VESA graphics formats from VGA to 4k up to 297 MHz (HDMI 1 and HDMI 2) and 225 MHz
(HDMI 3) pixel clock
Note: As of now HDMI1/2 and HDBT inputs support RGB and YUV 4:2:0 colour space formats. Signals
with YUV 4:4:4 and YUV 4:2:2 colour space formats need to be connected to the HDMI3 or DVI input.
Note: Graphics formats with odd numbered horizontal active pixels, e.g. 1365x768 are currently not
supported.
3.2.6.
DP Input
Display Port without HDCP, 36-bit video compatible.
Signal formats as HDMI 1 and HDMI 2.
3.2.7.
HDBT Input
Uncompressed HD video over RJ45 connector and max.100m CAT5e cable (or better)
CAT5e/CAT6 for 100m and signals with less than 225MHz Pixel Clock
CAT6a/CAT7 for 100m and signals up to 297MHz Pixel Clock
Signal formats as HDMI 1 and HDMI 2.

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 12
3.2.8.
Audio Output
Audio is embedded in HDMI video streams and brought into the unit through the respective input
channels. The audio is passed through the system and re-embedded into the HDMI output signals.
Also, the unit features a S/PDIF coaxial digital audio output connector for monitoring audio of the HDMI
channel.
When HDMI is selected as the input channel the HDMI EDID is read by a video source such as a Blue
Ray Player. The unit allows the source to provide the formats shown under output formats for HDMI in
the below table.
All formats are re-embedded into the HDMI output data stream, those which are not allowed on SPDIF
output are muted on the individual channels.
Output Channel
Output Format
HDMI
PCM up to 8ch, up to 24Bit, up to 192kHz sampling rate
(incl. 32kHz,44.1kHz,48kHz,96kHz,192kHz)
Dolby Digital (AC3) up to 5.1 channels, up to 640kBit/sec bit stream rate
MPEG2 up to 8ch, up to 112kBit/sec bit stream rate
DTS up to 6.1 channels, up to 1536kBit/sec bit stream rate
SPDIF
PCM up to 2ch, up to 24Bit, up to 96kHz sampling rate
(incl. 32kHz,44.1kHz,48kHz,96kHz)
Dolby Digital (AC3) up to 5.1 channels
DTS up to 6.1 channels

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 13
3.2.9.
Display Output
Three output channels are provided which are useable simultaneously. That is an HDMI, a DVI-I output
connector for DVI/HDMI connectivity and an RJ45 connector for HDBaseT connectivity.
When the input signal has HDCP encryption, the DVI-D, HDMI and HDBaseT output connectors will
carry a similarly HDCP encrypted signal.
When an HDCP encrypted signal is input, but the display device does not support HDCP, the
output image will turn black and a message indicating HDCP Signal will come up to the LCD
menu screen to indicate this.
There is a DVI-D and HDMI output. Both conform to normal VESA standards for connectors and pin
outs for these signal types.
The DVI-D connector will support HDMI with 36-bit video and audio formats when connected to a
suitable HDMI receiver. The colour depth of the HDMI signal is determined by the set-up of the unit and
the capabilities of the monitor.
4096x2160 currently is supported at 23.97/24Hz/29.97/30/50. 4096x2160 at 59.94/60 is not supported.
Note: The processor’s HDCP compliance can be turned off. This is of importance particularly
when using a MAC computer as the source. A MAC will encrypt its output signal if a compliant
device is seen attached to its output regardless of copy protection requirements to the content.
By turning off the unit processor’s compliance the MAC will see a non-compliant device and
therefore will not encrypt its output. When HDCP compliance is turned off encrypted sources
will not be displayed.
Note: The DVI/HDMI1 output of HDBaseT enabled products works fine with most displays at 4k.
However, this cannot be guaranteed. There may be occasional short video drop outs which
immediately recover. The frequentness depends on the display input electrical circuitry, the
input format measurement of the display and the quality of the cable being used.

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 14
The following output modes can be set up:
(HFP/VFP: horizontal/vertical front porch, HBP/VBP: horizontal/vertical front porch, HS/VS:
horizontal/vertical sync, HTot/VTot: horizontal/vertical total pixels)
Hor Pix
Ver Pix
HTot
HFP
HS
HBP
VTot
VFP
VS
VBP
Hor Freq
Ver Freq
Pix Clock
Specification
640
480
800
16
96
48
525
10
2
33
31.47
59.94
25.175
VESA DMT
640
480
800
16
96
48
629
62
2
85
31.46
50.02
25.170
proprietary
640
480
800
16
96
48
629
62
2
85
30.19
48.00
24.154
proprietary
800
600
1056
40
128
88
628
1
4
23
37.88
60.31
40.000
VESA DMT
800
600
1056
40
128
88
628
1
4
23
31.40
50.00
33.158
VESA 60 - CLK wind down
800
600
1056
40
128
88
628
1
4
23
30.14
48.00
31.832
proprietary
1024
768
1344
24
136
160
806
3
6
29
48.36
60.00
65.000
VESA DMT
1024
768
1312
40
104
144
793
3
4
18
39.63
49.98
52.000
VESA CVT 001M3
1024
768
1312
40
104
144
793
3
4
18
38.11
48.06
50.000
proprietary
1280
768
1664
64
128
192
798
3
7
20
47.78
59.87
79.500
VESA CVT 001M9/VESA DMT
1280
768
1648
56
128
184
793
3
7
15
39.59
49.93
65.250
VESA CVT001M9
1280
768
1648
56
128
184
793
3
7
15
38.06
48.00
62.730
proprietary
1280
800
1680
72
128
200
831
3
6
22
49.70
59.81
83.500
VESA CVT 001MA/VESA DMT
1280
800
1680
72
128
200
831
3
6
22
41.55
50.00
69.804
propietary
1280
800
1680
72
128
200
831
3
6
22
39.89
48.00
67.012
propietary
1280
1024
1688
48
112
248
1066
1
3
38
63.98
60.02
108.000
VESA DMT
1280
1024
1688
48
112
248
1066
1
3
38
53.32
50.02
90.000
VESA 60 - CLK wind down
1280
1024
1688
48
112
248
1066
1
3
38
51.17
48.00
86.370
proprietary
1360
768
1792
64
112
256
795
3
6
18
47.71
60.02
85.500
VESA AddDMT
1360
768
1744
56
136
192
793
3
5
17
39.56
49.89
69.000
VESA CVT 001M9
1360
768
1688
48
112
248
1066
1
3
38
51.17
48.00
86.370
proprietary
1366
768
1792
26
100
300
795
4
3
20
47.70
60.00
85.478
proprietary
1366
768
1792
26
100
300
795
4
3
20
39.75
50.00
71.232
proprietary
1400
1050
1864
88
144
232
1089
3
4
32
65.31
59.98
121.750
VESA CVT 001M3/VESA DMT
1400
1050
1864
88
144
232
1089
3
4
32
54.43
49.98
101.458
VESA 60 - CLK wind down
1400
1050
1864
88
144
232
1089
3
4
32
52.27
48.00
97.435
proprietary
1440
900
1904
80
152
232
934
3
6
25
55.93
59.89
106.500
CVT 1.30MA/VESA DMT
1440
900
1872
72
144
216
929
3
6
20
46.34
49.88
86.750
VESA CVT 001MA
1600
1200
2160
64
192
304
1250
1
3
46
75.00
60.00
162.000
VESA DMT
1600
1200
2128
96
168
264
1238
3
4
31
61.80
49.92
131.500
VESA CVT 002M3
1600
1200
2128
96
168
264
1238
3
4
31
59.42
48.00
126.450
proprietary
1680
1050
2240
104
176
280
1089
3
6
30
65.29
59.95
146.250
VESA CVT 002MA
1680
1050
2208
88
176
264
1083
3
6
24
54.12
49.97
119.500
VESA CVT 002MA
1680
1050
2208
88
176
264
1083
3
6
24
51.98
48.00
114.780
proprietary
1920
1200
2080
48
32
80
1235
3
6
26
74.04
59.95
154.000
VESA CVT 002MA-R/VESA DMT
1920
1200
2080
48
32
80
1129
3
6
20
61.42
49.97
127.750
VESA CVT calculated
1920
1200
2080
48
32
80
1235
3
6
26
29.64
24.00
61.650
proprietary
1920
1200
2080
48
32
80
1129
3
6
20
59.28
48.00
123.300
proprietary
720
480
858
19
62
57
525
27
3
15
31.47
59.94
13.500
EIA/CEA-861-B Format 6
720
576
864
12
63
69
625
27
3
19
31.25
50.00
13.500
EIA/CEA-861-B Format 24
720
576
864
12
63
69
625
28
3
18
30.00
48.00
12.960
proprietary
720
480
858
16
62
60
525
9
6
30
31.47
59.94
27.000
EIA/CEA-861-B Format 2
720
576
864
12
64
68
625
5
5
39
31.25
50.00
27.000
EIA/CEA-861-B Format 17
720
576
864
12
64
68
625
5
5
39
30.00
48.00
25.920
proprietary
1280
720
1650
110
40
220
750
5
5
20
44.95
59.94
74.176
EIA/CEA-861-B Format 4
1280
720
1980
440
40
220
750
5
5
20
37.50
50.00
74.250
EIA/CEA-861-B Format 19
1280
720
4125
2585
40
220
750
5
5
20
17.98
23.98
74.176
SMPTE 296M-1997 Format 8
1280
720
2063
483
40
260
750
5
5
20
35.97
47.96
74.176
proprietary
1920
1080
2200
88
44
148
1125
25
5
15
67.43
59.94
74.176
EIA/CEA-861-B Format 5
1920
1080
2640
528
44
148
1125
25
5
15
56.25
50.00
74.250
EIA/CEA-861-B Format 20
1920
1080
2750
638
44
148
1125
25
5
15
53.95
47.95
74.176
SMPTE 274-1998 Format 11
1920
1080
2750
638
44
148
1125
25
5
15
53.95
47.95
74.176
SMPTE 274-1998 Format 10
1920
1080
2200
88
44
148
1125
4
5
36
67.43
59.94
148.352
EIA/CEA-861-B Format 16
1920
1080
2640
528
44
148
1125
4
5
36
56.25
50.00
148.500
EIA/CEA-861-B Format 31
1920
1080
2750
638
44
148
1125
4
5
36
26.97
23.98
74.176
EIA/CEA-861-B Format 32
1920
1080
2640
440
88
192
1125
3
5
37
53.95
47.95
142.418
proprietary

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 15
Hor Pix
Ver Pix
HTot
HFP
HS
HBP
VTot
VFP
VS
VBP
Hor Freq
Ver Freq
Pix Clock
Specification
2048
1080
2750
510
148
44
1125
4
36
5
27.000
24.00
74.250
proprietary
2048
1080
2200
24
84
44
1125
4
36
5
33.716
29.97
74.176
proprietary
2048
1080
2750
510
148
44
1125
4
36
5
54.000
48.00
148.500
proprietary
2048
1080
2640
464
84
44
1125
4
36
5
56.250
50.00
148.500
proprietary
2048
1080
2200
24
84
44
1125
4
36
5
67.432
59.94
148.351
proprietary
2048
1080
2200
24
84
44
1125
4
36
5
67.500
60.00
148.500
proprietary
2560
1080
3750
998
44
148
1100
4
5
11
26.400
24.00
99.000
EIA/CEA-861-F VIC=86
2560
1080
3200
448
44
148
1125
4
5
36
28.125
25.00
90.000
EIA/CEA-861-F VIC=87
2560
1080
3520
768
44
148
1125
4
5
36
33.750
30.00
118.800
EIA/CEA-861-F VIC=88
2560
1080
3300
548
44
148
1125
4
5
36
56.250
50.00
185.625
EIA/CEA-861-F VIC=89
2560
1080
3000
248
44
148
1100
4
5
11
66.000
60.00
198.000
EIA/CEA-861-F VIC=90
2560
1440
2640
8
32
40
1474
20
8
6
73.626
49.950
194.374
VESA CVT 004M-R
2560
1440
2640
8
32
40
1481
27
8
6
88.771
59.940
234.356
VESA CVT 004M-R
2560
1600
2640
8
32
40
1638
24
8
6
81.818
49.950
216.000
VESA CVT 004M-R
2560
1600
2640
8
32
40
1646
32
8
6
98.661
59.940
260.466
VESA CVT 004M-R
3840
2160
5500
1276
88
296
2250
8
10
72
54.000
24.00
297.000
EIA/CEA-861-F VIC=93
3840
2160
5280
1056
88
296
2250
8
10
72
56.250
25.00
297.000
EIA/CEA-861-F VIC=94
3840
2160
4400
176
88
296
2250
8
10
72
67.500
30.00
297.000
EIA/CEA-861-F VIC=95
4096
2160
5500
1020
88
296
2250
8
10
72
54.000
24.00
297.000
EIA/CEA-861-F VIC=98
4096
2160
5280
968
88
128
2250
8
10
72
56.250
25.00
297.000
EIA/CEA-861-F VIC=99
4096
2160
4400
88
88
128
2250
8
10
72
67.500
30.00
297.000
EIA/CEA-861-F VIC=100
4096
2160
5280
968
88
128
2250
8
10
72
112.500
50.00
297.000
EIA/CEA-861-F (VIC=101) 4:2:0
4096
2160
4400
88
88
128
2250
8
10
72
135.000
60.00
297.000
EIA/CEA-861-F (VIC=102) 4:2:0

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 16
UNIT CONTROL
4.1.
LCD Panel Control
VP-796 has a front panel LCD to control the unit. The menu structure is also available through a web
browser allowing control from a PC. When pressing the Menu/Sel key the start screen will be replaced
by the main menu. Navigation through the menu system is by means of the jog wheel and the Menu/Sel
button. To exit a submenu press the Esc key.
1st Level
>Input HDMI 1
Output >
Color >
Geometry >
Enhancement >
System >
Status >
Exit >
2nd Level
3rd Level
4th Level
5th Level
>Display Type >
Gamma/Color/Crush >
Output Config >
Exit >
>O/P Mode 720p
Frame Rate 60 Hz
I/O Lock Off
Frame Rates >
Genlock Offsets >
Exit >
>50 Hz Yes
48 Hz No
30/29.97 Hz Yes
24/23.98 Hz Yes
Exit >
>Native Color 6500K
Output Gamma 2.2
Black Crush 0
Exit >
>Display DVI
HDCP On
DVI Colspace RGB
DVI Range Default
Exit >
>BL-Offset 7.5 IRE
Black-Level 0
Contrast 0
Saturation 0
Hue 0
RGB Values >
Color Temp 6500K
Input Gamma 2.2
Exit >
>Red Bias 0
Red Gain 0
Green Bias 0
Green Gain 0
Blue Bias 0
Blue Gain 0
Exit >
>Pict.Format Std.
Overscan 1
PTZ >
Exit >
>PTZ Enable On
PTZ Settin Use Glob
Pan 0.0
Tilt 0.0
Zoom H 100.0
Aspect Lock Off
Zoom V 100.0
PTZ Reset
Exit >
>Sharpness 0
Detail 1
Exit >

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 17
>User USER 1
Names/Profiles >
Input Config >
Menu Settings >
Network Settings >
Security Settings >
Factory Defaults>
Exit >
>Unit name
Input Name >
User name >
Exit >
>Display Port
HDMI 1
HDMI 2
HDBaseT
DVI
VGA
RGB/YPbPr
CVBS
HDMI 3
Exit >
>User 1 USER 1
User 2 USER 2
User 2 USER 2
User 2 USER 2
Exit >
>Analog Inputs >
Digital Inputs >
Test Pattern Setup>
Input Enable >
Switching Freeze
Exit >
>VGA Setup >
RGB/YPbPr Setup >
CVBS Setup >
Exit >
>Auto setup
Clock 1764
Phase 15
H-Position 0
V-Position 0
Color Space RGB
Range Full
Reset Mode
EDID 1920x1080p59.9
Exit >
>Phase 0
H-Position 0
V-Position 0
Color Space RGB
Reset Mode
Exit >
>CCS On
Exit >
>DP Config >
HDMI1 Config >
HDMI2 Config >
HDBT Config >
DVI Config >
HDMI3 Config >
HDMI Audio Full
Exit >
>DP Colspace Auto
DP Range Auto
Deep Color Yes
EDID In 1920x1080p
Exit >
>HDMI Colspace Auto
HDMI Range Auto
Deep Color Off
EDID 1920x1080p59.9
HDCP On
Exit >

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 18
>DVI Colspace Auto
DVI Range Auto
Deep Color Off
EDID 1920x1080p59.9
HDCP On
Exit >
>HDMI Colspace Auto
HDMI Range Auto
Deep Color Off
EDID 1920x1080p59.9
HDCP On
Exit >
>Audio Map Stereo12
Exit >
>Test Pat. Moving
Test Tone Off
Exit >
>Language English
Keypad Lock Off
MenuTime 15 sec
LCD Backlight 10
Jog Push Enable On
Web Colors Dark
Exit >
>Address Type DHCP
[IP N/A ]
[Net N/A ]
[Gateway N/A ]
DHCP Addr.obtained
IP 192.168.251.005
NM 255.255.255.000
GW 000.000.000.000
M 9C-5E-73-00-39-AA
Exit >
>FTP Password
WWW Password

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 19
4.2.
Web Browser Control
The unit can be remotely controlled from a PC (or tablet, or smartphone, …). No extra software needs
to be installed on the PC. The PC web browser is used as the graphical user interface for all control
items. To connect to the unit the TCP/IP address of the unit has to be entered into the address list box
of the web browser in the following format http://xxx.xxx.xxx.xxx. The TCP/IP address assigned to the
unit can be found in the System/Network Settings menu.
The Network Settings menu of the unit allows to configure the unit’s TCP/IP address. Under Address
Type a static or DHCP leased address can be chosen. The factory default of the unit is DHCP. The
static address and Netmask needs to be entered manually.
The Network Settings menu has a section with information on the DHCP Status and IP address
assigned to the board, as well as the fixed MAC Address programmed into the board. The DHCP status
is Off when static assignment is used or it displays an address when DHCP has leased an address
accordingly or it is None assigned if the lease was not successful.
Note: When changing from DHCP to Static mode or vice versa it is strongly recommended that the unit
is powered down after such a change, then powered back up, so that it is properly recognised by other
devices on the network.
Kramer provides a DiscoveryTool.exe Windows application to identify Kramer boxes in the network.
http://www.calibreuk.com/downloads/LEDView/DiscoveryTool_V1.0.exe
Clicking on the link of the recognized box will open a browser and make a connection to the
corresponding box. The box identifier is made up of “PV7” in followed by the MAC address. The MAC
address of the box can be found in the System/Network Settings menu.
Note: This is for use on a network not on a single wire connection.
Once the address has been entered into the web browser starts to load pages from the unit mirroring
the menu system. All menu items are shown as their respective buttons, sliders and list boxes and can
be accessed and altered with the PC mouse or corresponding navigational key presses.
To control the unit through a network start a Web Browser and enter the TCP/IP address of the unit in
the address field of the browser. The web server will ask for a user name and password which are:
User Name: user
Password: user
A “Loading… Please Wait.” message will appear in the browser window and the web server of the unit
will mirror the menu into the browser.

©KRAMER ELECTRONICS LTD. Issue 1.10 16th of December 2015 20
The main page will be displayed. The Unit ID above the menu is composed of the board identifier PV7
followed by the MAC address. Also the firmware version number and information on the input mode is
shown.
Under the information pane the available input channels are shown and can be activated directly.
Below the input channel buttons the menu system is shown.
