1. - Dear Owner
FC244/D/-FF/D-FF
3
KN329CGB_A
Mower conditioner
1. Dear Owner
In buying a Kuhn machine you have chosen wisely. Into it have gone years of thought, research and
improvement. You will find, as have thousands of owners all over the world, that you have the best that
engineering skill and actual field testing can produce. You have purchased a dependable machine, but only
through proper care and operation can you expect to receive the performance and long service built into it.
This manual contains all the necessary information for you to receive full efficiency from your machine. The
performance you get from this machine is largely dependent on how well you read and understand this
manual and apply this knowledge. Please DO NOT ASSUME YOU KNOW HOW TO OPERATE AND
MAINTAIN YOUR MACHINE before reading this manual carefully. KEEP THIS MANUAL AVAILABLE FOR
REFERENCE. Pass it on to the next owner if you re-sell the machine.
Your KUHN dealer can offer a complete line of genuine KUHN service parts. These parts are manufactured
and carefully inspected in the same factory that builds the machine to assure high quality and accurate
fitting of any necessary replacements.
About improvements
We are continually striving to improve our products. We therefore reserve the right to make improvements
or changes when it becomes practical to do so, without incurring any obligations to make changes or
additions to the equipment sold previously.
Wear parts
Wearing parts fitted on our machines have been tested in very different situations to optimize their service
life. Nevertheless, the service life depends highly on theconditions of use (products tohandle,soil,weather
conditions, etc...).
Document illustrations
The illustrations in this manual may be based on one type of machine only. However, all instructions apply
to all machines covered in this manual.
Copyright 2019 KUHN

FC244/D/-FF/D-FF
42. - Contents
KN329CGB_A
Mower conditioner
2. Contents
1. Dear Owner .....................................................................................................................3
2. Contents..........................................................................................................................4
3. Identification of the machine.........................................................................................8
3.1 Front view ........................................................................................................................................ 8
3.2 Rear view.........................................................................................................................................8
3.3 Identification of the machine............................................................................................................9
3.3.1 Location of the plates .........................................................................................................9
3.3.2 Description..........................................................................................................................9
3.4 Optional equipment.........................................................................................................................11
4. Safety.............................................................................................................................12
4.1 Description of symbols used in this document............................................................................... 12
4.2 Safety instructions ......................................................................................................................... 13
4.2.1 Introduction....................................................................................................................... 13
4.2.2 Read and follow the safety instructions............................................................................ 13
4.2.3 Precautions to be taken before carrying out any operations on the machine................... 14
4.2.4 Precautions to take before using the machine ................................................................. 14
4.2.5 Precautions when driving ................................................................................................. 15
4.2.6 Precautions when driving on public roads........................................................................16
4.2.7 Maximum speed...............................................................................................................20
4.2.8 Precautions when coupling...............................................................................................20
4.2.9 Hydraulic circuit................................................................................................................21
4.2.10 PTO shaft.......................................................................................................................... 22
4.2.11 Precautions during manoeuvres....................................................................................... 24
4.2.12 Remote controlled components........................................................................................ 24
4.2.13 Hydro-pneumatic accumulator.......................................................................................... 24
4.2.14 Safety decals.................................................................................................................... 25
4.2.15 Waste disposal ................................................................................................................. 25
4.2.16 Precautions for maintenance and repair work.................................................................. 26
4.2.17 Projection of stones and foreign objects........................................................................... 27
4.2.18 Precautions for machine use............................................................................................ 28
4.2.19 Burn hazard...................................................................................................................... 28
4.2.20 Precautions to take before using the parking stands........................................................ 29

2. - Contents
FC244/D/-FF/D-FF
5
KN329CGB_A
Mower conditioner
4.3 Location and description of safety decals on the machine............................................................ 30
4.3.1 Location of safety decals..................................................................................................30
4.3.2 Description of safety decals ............................................................................................. 31
4.4 Road safety equipment and recommendations............................................................................. 35
4.4.1 Specific instructions.......................................................................................................... 36
4.5 Likely critical failures...................................................................................................................... 36
4.6 Incorrect use of the machine by the user ...................................................................................... 37
4.7 Limit state criteria........................................................................................................................... 37
5. Machine specifications................................................................................................ 38
5.1 Description and glossary ............................................................................................................... 38
5.1.1 Designated use of the machine........................................................................................ 39
5.2 Technical specifications................................................................................................................. 40
5.2.1 Designated parameters.................................................................................................... 40
5.3 Required equipment...................................................................................................................... 41
5.3.1 Cutter bar ......................................................................................................................... 41
5.3.2 Hydraulic adjustment........................................................................................................ 42
5.4 Sound levels.................................................................................................................................. 42
6. Putting into service...................................................................................................... 43
6.1 Description of control elements ..................................................................................................... 43
6.2 Coupling and uncoupling............................................................................................................... 46
6.2.1 Description of coupling elements ..................................................................................... 46
6.2.2 Preparing the tractor......................................................................................................... 47
6.2.3 Preparing the machine..................................................................................................... 49
6.2.4 Coupling the machine.......................................................................................................52
6.2.5 Hydraulic connections......................................................................................................54
6.2.6 Electrical connections....................................................................................................... 54
6.2.7 Primary PTO shaft............................................................................................................ 55
6.2.8 Intermediate PTO shaft .................................................................................................... 56
6.2.9 Adjusting the machine......................................................................................................58
6.2.10 Uncoupling the machine................................................................................................... 59
7. Instructions for transport............................................................................................ 61
7.1 Putting the machine into transport position ................................................................................... 61
7.2 Conformity with the road regulations............................................................................................. 62
7.3 Machine transport using transport means ..................................................................................... 63

FC244/D/-FF/D-FF
62. - Contents
KN329CGB_A
Mower conditioner
-
8. Instructions for work....................................................................................................64
8.1 Putting the machine into work position ..........................................................................................64
8.2 Adjustments in working position.....................................................................................................66
8.2.1 Cutting height ...................................................................................................................66
8.2.2 Ground pressure...............................................................................................................67
8.2.3 Finger conditioning rotor speed........................................................................................ 71
8.2.4 Conditioning intensity .......................................................................................................76
8.2.5 Swathing and wide spreading...........................................................................................80
8.3 Machine use .................................................................................................................................. 83
8.3.1 Drive speed ......................................................................................................................83
9. Optional equipment......................................................................................................84
9.1 Raised skid shoes.......................................................................................................................... 84
9.2 Side deflector with high cone disk .................................................................................................84
9.3 Lateral signalling equipment (for France) ......................................................................................85
9.4 4-belt drive (Equipment delivered depending on country) ............................................................. 85
9.4.1 Start-up.............................................................................................................................85
9.4.2 Instructions for work .........................................................................................................87
9.5 Flow limiter.....................................................................................................................................90
9.6 Female coupler..............................................................................................................................90
9.7 USA signalling equipment.............................................................................................................. 91
9.7.1 Coupling and uncoupling.................................................................................................. 91
9.8 Chain stroke limiter........................................................................................................................ 92
10. Maintenance and storage ............................................................................................94
10.1 Frequency chart.............................................................................................................................94
10.2 Cleaning the machine.................................................................................................................... 95
10.3 Lubrication .....................................................................................................................................96
10.3.1 PTO shaft.......................................................................................................................... 96
10.3.2 Oil change ........................................................................................................................ 98
10.3.3 Lubrication......................................................................................................................102
10.3.4 Greasing.........................................................................................................................102

2. - Contents
FC244/D/-FF/D-FF
7
KN329CGB_A
Mower conditioner
-10.4 Maintenance................................................................................................................................ 105
10.4.1 Hydro-pneumatic accumulator ....................................................................................... 105
10.4.2 Transport stop ................................................................................................................ 107
10.4.3 Belt tension..................................................................................................................... 108
10.4.4 Replacing the belts......................................................................................................... 109
10.4.5 Checking cutterbar oil level.............................................................................................111
10.4.6 Inspection of knives and securing elements....................................................................112
10.4.7 Outer and inner cones.................................................................................................... 129
10.4.8 Intermediate PTO shaft .................................................................................................. 129
10.5 Storage........................................................................................................................................ 133
10.5.1 At the end of each season.............................................................................................. 133
10.5.2 At the start of each season............................................................................................. 134
10.5.3 Storage........................................................................................................................... 136
10.6 Dismantling and scrapping of the machine.................................................................................. 136
11. Troubleshooting guide.............................................................................................. 137
12. Appendix.....................................................................................................................143
12.1 Calculating the load on an axle ................................................................................................... 143
13. Limited Warranty........................................................................................................ 151

FC244/D/-FF/D-FF
83. - Identification of the machine
KN329CGB_A
Mower conditioner
3. Identification of the machine
3.1 Front view
3.2 Rear view

3. - Identification of the machine
FC244/D/-FF/D-FF
9
KN329CGB_A
Mower conditioner
3.3 Identification of the machine
- Do not remove the manufacturer,
homologation and marking plates attached
to the machine.
3.3.1 Location of the plates
- Please write below the type and serial number of
the machine:
• Serial Number:
- This information is to be given to the Kuhn
authorized dealer for any spare parts order or
warranty claim.
3.3.2 Description
Model identification plate
1: Manufacturer name and address
3: Brand
4: KUHN logo
5: Description of the machine
7: Model
9a: Machine serial number
9b: Barcode (Machine serial number)
12: Weight empty (Minimum/Maximum)
18: Data matrix
19: Plate reference
27: Place of manufacture
28: Manufactured by... for...
34: Special operation
9: Serial Nr. 34: Ex
5: Machine
7: Model
09993000
3: Brand
kg
kg
12: Unladen Mass min/Max
3: 商 Brand
9: 机架号 Serial Nr. 34: Ex
5: 机器描述 Machine
7: 型号 Model
kg
12: 卸重量最小/最大Unladen Mass min/max kg
1
34
18
19
3
9a
5
7
12
28
27
9b
4

FC244/D/-FF/D-FF
10 3. - Identification of the machine
KN329CGB_A
Mower conditioner
Certification plate (CE)
For machines aimed at countries which are
members of the European Union (EC marking).
4: KUHN logo
7: Model
9: Machine serial number
19: Plate reference
23: Logo CE
24: Manufacturing year
26: Model year
54: Data matrix
Certification plate (EAC)
For machines aimed at countries member of the
Eurasian customs union (EAC marking).
4: KUHN logo
7: Model
9: Machine serial number
19: Plate reference
23: Logo EAC
25: Manufacturing year
26: Model year
54: Data matrix
Importer plate (BRASIL)
For machines to be sent to Brazil.
1: Manufacturer name and address
4: KUHN logo
7: Model
9: Machine serial number
19: Plate reference
24: Manufacturing year
54: Data matrix
24: Year of Construction
26: Model Year
7: Model
9: Serial Nr.
23
54
4
19
7
9
24
26
25: Month-Year of Construction
26: Model Year
7: Model
9: Serial Nr.
23
54
4
26
25
7
9
19
24: Year of Construction
19
54 4
1
24
97

3. - Identification of the machine
FC244/D/-FF/D-FF
11
KN329CGB_A
Mower conditioner
3.4 Optional equipment
- Tick box corresponding to the equipment fitted on
your machine:
Raised skid shoes 120 mm (4.7’’).
Side deflector with high cone disk (Knife attachment per bolt and nut).
Side deflector with high cone disk (Fast fit knives).
Lateral signalling equipment (for France).
4-belt drive (Equipment delivered depending on country).
Shut off valve.
Female coupler.
USA signalling equipment.
Chain stroke limiter.

FC244/D/-FF/D-FF
12 4. - Safety
KN329CGB_A
Mower conditioner
4. Safety
4.1 Description of symbols used in
this document
This symbol indicates a potentially hazardous
situation that if not avoided, could result in serious
bodily injury.
This symbol is used to identify special instructions or
procedures which, if not followed strictly, could result
in machinery damage.
This symbol is used to communicate technical
information of particular interest.

4. - Safety
FC244/D/-FF/D-FF
13
KN329CGB_A
Mower conditioner
4.2 Safety instructions
4.2.2 Read and follow the safety instructions
4.2.1 Introduction
The machine must only be operated, maintained and repaired by competent persons who are familiar with
machines' specifications and operation and aware of safety regulations for preventing accidents.
The operator must imperatively respect safety instructions in this manual and in the warnings posted on the
machine. The operator is also obliged to respect current legislation concerning accident prevention, work
safety and public traffic circulation.
Designated use of the machine also means following operation, maintenance and repair recommendations
given by the manufacturer, and using only genuine spare parts, equipment and accessories, as
recommended by the manufacturer.
The manufacturer is not held liable for any damage resulting from machine applications other than those
specified by the manufacturer. Any use other than the designated operation is at the risk and responsibility
of the operator.
The manufacturer is not held liable for any damage or accident resulting from machine modifications carried
out by the operator himself or by a third party without previous written agreement from the manufacturer.
- Before using the machine, carefully read all the
safety instructions in this manual and the warnings
placed on the machine.
- Before starting work, the operator must be familiar
with all machine controls, handling devices and
their functions. It is too late to learn once work has
been started!
- Never let anyone operate the machine who is not
trained to do so.
- Should you have any difficulties in understanding
any parts of this manual, please contact your
KUHN dealer.

FC244/D/-FF/D-FF
14 4. - Safety
KN329CGB_A
Mower conditioner
4.2.4 Precautions to take before using the
machine
4.2.3 Precautions to be taken before carrying
out any operations on the machine
- Before leaving the tractor or before adjusting,
maintaining or repairing the machine, disengage
the PTO drive, turn off the engine, remove ignition
key and wait until all moving parts have come to a
complete stop and apply park brake.
- Do not wear loose clothing which could become
caught up in moving parts.
- Wear the appropriate protective clothing for the
work in hand (gloves, shoes, goggles, helmet, ear
defenders, etc.).
- Ensure that all operating controls (ropes, cables,
rods, etc) are placed so as they cannot be operated
unintentionally and cause damage or injury.
- Before operating the machine, check tightness of
nuts and bolts, particularly on fixing elements
(tines, forks, blades, knives, etc). Retighten if
necessary.
- Before operating the machine, ensure that all the
safety guards are firmly in place and in good
condition. Immediately replace any worn or
damaged guard.

4. - Safety
FC244/D/-FF/D-FF
15
KN329CGB_A
Mower conditioner
4.2.5 Precautions when driving
- Tractor handling, stability, performance and
braking efficiency are all affected by weight
distribution, trailed or mounted implements,
additional ballast and driving conditions. It is
therefore of great importance that the operator
exercises caution in every given situation.
- Groundspeed must be adapted to ground
conditions as well as to roads and paths. Always
avoid abrupt changes of direction.
- Be particularly cautious when turning corners,
paying attention to machine overhang, length,
height and weight.
- Never use a narrow track tractor on very uneven or
steeply sloping ground.
- Never leave the tractor seat while the machine is
operating.
- Carrying people or animals on the machine when
working or in transport is strictly forbidden.

FC244/D/-FF/D-FF
16 4. - Safety
KN329CGB_A
Mower conditioner
4.2.6 Precautions when driving on public
roads
Dimensions
Depending on the dimensions of the machine,
contact the relevant authorities to ensure that it can
be legally transported on public roads.
If the machine is over the maximum legal size,
follow the local regulations forspecial transportation
of oversize equipment.
Transport position
Before transporting the machine on public roads,
place the machine into its transport position,
according to the instructions in this manual.
Lights and indicators
Before transporting the machine on public roads,
ensure that all legally required lightings and
signallings are in place.
Ensure that lightings and signallings are clean and in
good working order. Replace any missing or broken
equipment.
Always obey current regulations for driving
on roads.

4. - Safety
FC244/D/-FF/D-FF
17
KN329CGB_A
Mower conditioner
Gross weight and weight per axle
Description of symbols
The drawings are not legally binding, their only aim is to illustrate the method to use.
Prior to driving on public roads, check that all criteria are met to be in conformity with the
countrie's regulations:
• When coupling a tool to the front and/or rear 3-point lift linkage, the maximum authorized
payload must not be exceeded.
• When coupling tools to the front and/or rear 3-point lift linkages, the maximum load on
tractor's tires must not be exceeded.
• The load on the tractor front axle must always represent 20 % of the tractor unladen weight.
For machines with hoppers or tanks:
- If the total unit weight exceeds the tractor Gross Combined Weight Rating in accordance with
the countrie's legislation, empty the hopper to travel on public roads.
- In any case, we recommend to travel on public roads with empty hoppers and tanks.
Description Units Description
T kg Tractor unladen weight
PTAC kg Gross Combined Weight Rating
T1 kg Unladen load on tractor front axle
T2 kg Empty load on tractor rear axle
t kg Axle loads (Tractor + machine)
t1 kg Load on front axle (Tractor + machine)
t2 kg Load on rear axle (Tractor + machine)
t1 max kg Maximum load authorized on the tractor front axle according to the tires
t2 max kg Maximum load authorized on the tractor rear axle according to the tires
M1 kg Total weight of front tool or front ballast

FC244/D/-FF/D-FF
18 4. - Safety
KN329CGB_A
Mower conditioner
How to proceed:
Stage 1:
Stage 2:
To measure:
- Tractor tare (T).
T = _____kg
- Couple the machine to the tractor.
To measure:
- Load on front axle (t1):
• Tractor + machine (transport position).
To do:
- If the front axle load (t1) is below 20% of the tractor
tare (T), add ballast weights (M1) to exceed the
minimum load on the front axle.
Example:
• (T) = 7500 kg (16535 lb)
• The front axle load must be of minimum 1500 kg
(3300 lb).(20% of T).
• (t1) = 700 kg (1545 lb).
• 700 kg (1545 lb) < 1500 kg (3300 lb).
• Add ballast weights until the minimum front axle
load is exceeded.
• Repeat checking procedure.
t1 = _____kg
t1 < 20% T
t1 < 20% T
t1
t1 ≥
20% T
20% T

4. - Safety
FC244/D/-FF/D-FF
19
KN329CGB_A
Mower conditioner
Stage 3:
Stage 4:
To measure:
- Total weight (t):
• Tractor + machine (transport position).
• Ballast weights.
Checking:
- To go to the next stage:
• Check in the tractor's operator's manual that the
value measured is below the tractor's Gross
Combined Weight Rating.
To do:
- If t < PTAC go to the next stage.
- If the total unit weight exceeds the tractor Gross
Combined Weight Rating in accordance with the
countrie's legislation, empty the hopper to travel on
public roads.
- Repeat checking procedure.
Example:
• (t) = 10000 kg (24250 lb)
• PTAC = 13000 kg.
• t < PTAC: Go to the next stage.
kgkg
t = _____kg
To measure:
- Load on rear axle (t2):
• Tractor + machine (transport position).
• Ballast weights.
Checking:
- Check in the tractor's operator's manual that the
value measured is below the maximum allowed
tractor rear axle load.
- Check that tyre and rim specifiations are in
conformity with the requirements of the tractor
manufacturer.
Example:
• Load on rear axle (t2) = 8500 kg (18740 lb)
• Check in the tractor's operator's manual that the
value measured is below the maximum allowed
tractor rear axle load.
• Check that tyre and rim specifiations are in
conformity with the requirements of the tractor
manufacturer.
kgkg
t2 = _____kg
t2 > t2 maxt2 > t2 max
t2t2 ≤t2 maxt2 max

FC244/D/-FF/D-FF
20 4. - Safety
KN329CGB_A
Mower conditioner
4.2.7 Maximum speed
Always keep to the legal speed limit for driving a
tractor-machine assembly on public roads.
4.2.8 Precautions when coupling
- Before attaching the machine, make sure that it
cannot accidentally start moving (chock the
wheels) and that the parking stand is in the right
position.
- The machine must only be attached to the hitch
points provided for this purpose.
- Do not stand between the machine lower hitching
points or between the tractor lower hitching points
during coupling maneuvers.
- Never stand between the tractor and the machine
when operating the three point linkage.
- Do not stand between the machine and the tractor
or on the machine without having first applied the
tractor parking brake and placed the gearbox in the
neutral position.
