LEGRAND 5739 34 User manual

Part. U3499A - 11/08-01 PC
User manual
5739 34
5739 35
Burglar-alarm unit

Contents
Introduction1. 5
The Burglar-alarm Unit■6
The keypad
■7
Navigation keys✔7
The display
■7
Initial page✔7
In case of an alarm✔7
Edit menu
✔7
What is the display showing?
■8
Operation 12. 1
Enabling - disabling the burglar alarm 1■2
With user code 1✔2
With transponder key 1✔2
Rapid enabling 1✔3
Activation scenarios 1
■3
Activating - deactivating the zones 1■4
With user code 1✔4
With transponder key 1✔5
From the zone menu 1✔5
Stopping the siren sound 1■6
With user code 1✔6
With transponder key 1✔6
What type of alarm occurred? 1
■7
Enabling the automations 1■8
Enabling keys and numeric codes 1■9
Enabling the remote control 2
■0
Editing 23. 1
The Unit menu 2■2
Accessing the edit menu 2
■2
Setting the date and hour 2
■3
Sound signalling 2
■4
Memorizing the Jolly number 2
■5
Making your own list of telephone numbers 2■6
Setting up the calls 2
■7
Editing vocal messages 2■9
Changing the user code 3■1
Changing the numeric codes 3
■2
Remote use 34. 3
Answering a call from the Unit 3■4
Querying the Unit 3
■4
Controlling your home from a distance 3■5
3

Introduction
1
The Burglar-alarm Uni■t
The keypa
■d
Navigation key✔s
The displa■y
Initial pag✔e
In case of an alar✔m
Edit men✔u
What is the display showing■?

1 - Introduction
123
56
987
0
4
OK
P
The Burglar-alarm Unit■
The Burglar Alarm guards the safety of your house; the system is split
into zones that can be activated separately; for example, at night, you
can have protection only in the day zone or only around your house, so
you can move around freely even when the system is on. You can save up
to 16 activation scenarios and use them as needed.
In case of an alarm, the Telephone dialling device (communicator) warns
you with a message, allowing you to have direct control on what is
happening in your house even when you’re not there.
You can check the status of the Unit and system from a xed or mobile
phone, listen to what is happening at home from a distance or send a
vocal message, which will be emitted through the Unit loudspeaker or,
if connected, through the sound system.
The combination of roller shutter movement devices and lights turning
on lets you program the roller shutters to go up in case of an alarm in
order to confuse the burglar.
You can control the functions in your house (lights, roller shutters, etc.)
remotely with just a telephone call.
The Unit can also communicate with surveillance rms by means of a
special protocol, further increasing the protection of your property (to
set this service consult your installer).
1 - Graphic display
2 - Navigation keys
3 - Alphanumeric keypad
4 - Microphone
5 - Transponder keys reader
6 - Loudspeaker
6
1
5
3
4
2
6

1 - Introduction
The keypad■
Navigation keys✔
Scroll keys
allow you to scroll the list of items
in the menu
Selection keys
allow you to select the functions,
which in some menus, may appe-
ar in the last line
OK - Key for entering the selection
or data
CLEAR - Key for cancelling the
selection and for returning to the
previous page – if it is held down,
you can escape from the program-
ming menu
The display■
Edit menu✔
In case of an alarm✔
Initial page✔
01
: Entrance 1
02
: Perimeter 2
03
: Night 3
Exclude
1 2 3 4 –– –– –– ––
1 2 3 4 –– –– –– ––
16 / 11 / 08 08 : 11
System zones
(max. 8 zones)
Technical indications
Alarm signal zone
Functions
Active zones
Disabled zone
Date and
hour
ON/OFF indication
7

1 - Introduction
System on, intrusion alarm signal and
PSTN telephone call in progress
System off, Unit battery damaged
or dead
System o, no power
What is the display showing?■
System on,
e.g.: zone activation as in scenario 2
System off, general alarm signal,
tamptest with system switched OFF
or a dead radio device battery
System o,
e.g.: zones 1, 2, 3, 4 active
1 2 3 4 –– –– –– ––
16 / 11 / 08 08 : 12
1 2 3 4 –– –– –– –– 1 2 3 4 –– –– –– ––
1 2 3 4 –– –– –– ––
s c e n a r i o 2
16 / 11 / 08 08 : 12
1 2 3 4 –– –– –– ––
8

1 - Introduction
System o, Burglar-alarm (antitheft)
battery dead or damaged and tech-
nical alarm signal
System o, telephone calls disabled
(Important Unit functions are
disabled; disable only if extremely
necessary)
System off, one or more sensors
disabled (Important Unit functions
are disabled; disable only if extremely
necessary)
1 2 3 4 –– –– –– ––
16 / 11 / 08 08 : 13
1 2 3 4 –– –– –– ––
16 / 11 / 08 08 : 13
1 2 3 4 –– –– –– ––
9

1 - Introduction
10

Operation
2
Enabling - disabling the burglar alar■m
With user cod✔e
With transponder ke✔y
Rapid enablin✔g
Activation scenarios■
Activating - deactivating the zone
■s
With user cod✔e
With transponder ke✔y
From the zone men✔u
Stopping the siren soun■d
With user cod✔e
With transponder ke✔y
What type of alarm occurred■?
Enabling the automation
■s
Enabling keys and numeric code
■s
Enabling the remote contro
■l

2 - Operation
When the burglar alarm (antitheft) is
disabled, an open lock appears in the
middle of the display
The display will show a closed lock;
if the sound system is enabled, you
will hear an “enabled” vocal message;
execute the same operation to disable
the burglar alarm
Press the key
Type in the user code (basic 00000)
or an enabled numeric code; typing
an incorrect code, after the third
attempt the keypad blocks for about
1 minute
Enabling - disabling the burglar alarm■
With user code✔
When the burglar alarm (antitheft) is
disabled, an open lock appears in the
middle of the display
To enable the burglar alarm (anti-
theft), press the or key on the
Unit keypad and then bring the key
(less than one centimeter) near the
reader for 2 seconds
The display will show a closed lock;
if the sound system is enabled, you
will hear an “enabled” vocal message;
execute the same operation to disable
the burglar alarm
With transponder key✔
123
56
987
0
4
P
123
56
987
0
4
12
1 2 3 4 –– –– –– ––
17 / 11 / 08 15 : 37
1 2 3 4 –– –– –– ––
17 / 11 / 08 15 : 38
1 2 3 4 –– –– –– ––
17 / 11 / 08 15 : 39
1 2 3 4 –– –– –– ––
17 / 11 / 08 15 : 39

2 - Operation
When the burglar alarm (antitheft) is
disabled, an open lock appears in the
middle of the display
Keep the key pressed for 3 seconds
for the rapid enabling
The display will show a closed lock;
if the sound system is enabled, you will
hear an “enabled” vocal message
Rapid enabling✔
Use the keys to select the sce-
nario you want
After the confirmation only the
zones included in the scenario will
be activated.
To create or modify scenarios consult
the installation manual
Activation scenarios■
The Unit can save up to 16 activation scenarios and you can select the
one you want as follows:
Confirm the selection using the
user code, a transponder key or a
numeric code
3 seconds
123
56
987
0
4
13
1 2 3 4 –– –– –– ––
17 / 11 / 08 15 : 40
1 2 3 4 –– –– –– ––
17 / 11 / 08 15 : 40
1 2 3 4 –– –– –– ––
17 / 11 / 08 15 : 41
1 2 3 4 –– –– –– ––
17 / 11 / 08 15 : 41

2 - Operation
You can deactivate (reactivate) one or more zones at any time. This
will allow you to personalise the burglar-alarm operation according to
your needs.
For instance, if you want to have protection even if you’re not at home,
you can deactivate the infrared detector zones, leaving the outer zones
(entrance door and windows) active. This will allow you to move around
freely inside your house without making any alarms go on and without
giving up safety.
The zones in which your burglar alarm is split into appear in the rst
line of the display.
The active zones are shown in a dark box
the following example shows the system made up of 4 zones, all active;
zone 3 is deactivated.
Activating - deactivating the zones■
The zones (max. 8) of the system are
all active (e.g. 1-2-3-4)
Press the corresponding key on the
Unit keypad to deactivate zone 3
The Unit confirms the operations
with the vocal message “executed”;
the display shows zone 3 without the
dark box (deactivated)
Press the key
Type in the user code (basic 00000) or
an enabled numeric code
With user code✔
1 2 3 4 –– –– –– ––
17 / 11 / 08 15 : 43
1 2 34 –– –– –– ––
17 / 11 / 08 15 : 44
123
56
987
0
4
14

2 - Operation
Press the corresponding key on the
Unit keypad to deactivate zone 3
The Unit conrms the operations with
the vocal message “executed”; the
display shows zone 3 without the dark
box (deactivated)
Conrm the operation by bringing a
transponder near the reader within
5 seconds
The zones (max 8) of the system are all
active (e.g. 1-2-3-4)
With transponder key✔
After accessing the edit menu (next
section)
Hold down the key to escape
from menu
Press to access the burglar-alarm
(antitheft) menu
Press to access the zone menu
Press to enter
From the zone menu✔
Select the zone you want to activate
or deactivate with the keys
(e.g. 3)
P
123
56
987
0
4
1 2 3 4 –– –– –– ––
17 / 11 / 08 15 : 44
1 2 34 –– –– –– ––
17 / 11 / 08 15 : 45
1 2 34 –– –– –– ––
17 / 11 / 08 15 : 46
SELECT
Antitheft
Communicator
Scenarios
Zones
Devices
Event memory
01
: Entrance 1
02
: Perimeter 2
03
: Night 3
Exclude
15

2 - Operation
Stopping the siren sound■
If the alarm goes on while you’re there, you can stop the siren as
follows:
Make sure there are no trespassers
in the house
The siren stops; the Unit answers with
the vocal message “disabled”
Press the key
Type in the user code (basic 00000)
With user code✔
With transponder key✔
Press the or key on the Unit
keypad and then bring the key (less
than one centimeter) near the reader
for 2 seconds
Make sure there are no trespassers
in the house
The siren stops; the Unit answers
with the vocal message “disabled”
1 2 3 4 –– –– –– –– 1 2 3 4 –– –– –– ––
1 2 3 4 –– –– –– –– 1 2 3 4 –– –– –– ––
123
56
987
0
4
P
123
56
987
0
4
16

2 - Operation
To learn more, press the key
The display provides the following
information:
- detector and its name (living room
window)
- type of alarm (intrusion)
- burglar-alarm (antitheft) status
when the alarm goes on (ON-
inserted)
The alarm signal is cancelled from
the display the next time you turn
on the burglar alarm (antitheft), but
it remains memorised in the “Event
memory”, which can be consulted
by selecting “Event memory” in the
Burglar-alarm (antitheft) menu.
The Unit has detected an alarm ...
What type of alarm occurred?■
When an alarm signal is displayed, you can nd out what type it is (intru-
sion, technical, etc.) and which detector has detected it; a name has been
given to each detector (kitchen window, entrance, etc.) by the installer for
easier identication. Press just one key to get this information.
To learn more, press the key
The display provides the following
information:
- device name (remote assistance)
- type of alarm (technical start)
- burglar-alarm (antitheft) status
when the alarm goes on (OFF-
disconnected)
The Unit has detected a technical
alarm
By pressing the key, a page appe-
ars, which lets you reset a single alarm
or execute a total reset
In case of a technical alarm (its symbol appears), you can nd out which
device has produced the alarm and reset it as well.
P
123
56
987
0
4
1 2 3 4 –– –– –– ––1 2 3 4 –– –– –– ––
51 AI device
peripheral 1
Intrusion alarm
inserted
42 receiver
remote assistance
Start technical
Disconnected
press:
* reset single
reset total
17

2 - Operation
Accessing the edit menu
Enabling the automations■
The burglar-alarm unit can be programmed so that an automation is
linked to a particular event. For example the lights come on when the
unit registers an intrusion alarm.
Press to access the Burglar-alarm
(antitheft) menu
In this menu you can enable or
disable the automations program-
med by the installer.
Select Automations with the
keys
Press to access
Press to enter
With the keys enable the automa-
tion which you intend to enable or disable;
if the automation selected is enabled the
wording Disable will appear in the last line
of the display and vice versa
The selected zone is enabled; the
identication number is shown by a
black square
Keep the key pressed to return to
the initial page
NEXT
SELECT
Antitheft
Communicator
Scenarios
Zones
Devices
Event memory
Devices
Event memory
Date and hour
Automations
01
: automation 1
02
: automation 2
03
: automation 3
Disable
01
: automation 1
02
: automation 2
03
: automation 3
Enable
01
: automation 1
02
: automation 2
03
: automation 3
Disable
18

2 - Operation
NEXT
Enabling keys and numeric codes■
You can enable or disable remote controls, transponder keys and
numeric codes as you require.
Accessing the edit menu
Press to access the Burglar-alarm
(antitheft) menu
Select Settings with the keys
Press to access
Press to enter
Select Code/Keys with the
keys
The key has been enabled; the iden-
tication number is shown by a black
square.
Keep the key pressed to return to
the initial page
With the keys select the key
whose state you intend to change.
If the key selected is enabled the wor-
ding Disable will appear in the last line
of the display and vice versa
SELECT
Antitheft
Communicator
Scenarios
Zones
Devices
Event memory
Event memory
Date and hour
Automations
Settings
User code
Codes/keys
Contrast
Select
User code
Codes/keys
Contrast
Select
01
: key No. 1
02
: key No. 2
03
: key No. 3
Enable
01
: key No. 1
02
: key No. 2
03
: key No. 3
Disable
19

2 - Operation
Access the edit menu and select Te -
lephone Dialling device (Commu-
nicator)
Enabling the remote control■
You can enable/disable your unit for remote assistance or remote mana-
gement of the alarms via telephone line.
Consult your installer before modifying the settings of this menu.
Remote assistance
If this setting is enabled the unit allows the entry of remote assistance
calls from units which use the Contact ID protocol.
Remote management
allows management of the alarms via telephone line; the setting has
the following options:
ON: the user and the surveillance unit can perform the remote management.
Manager: only the surveillance unit can perform the remote management
User: only the user can perform the remote management
OFF: the remote management is disabled
Press to access the menu
Select Tel. functions with the
keys
Press to access
Press to enter
Select Remote control with the
keys
The indications for the settings and
their meaning can be found below.
When the setting is finished keep
the key pressed to return to the
initial page
NEXT
SELECT
Antitheft
Communicator
Index book
Set calls
Vocal messages
Tel. functions
Remote control
Sound spread
Select
Teleassistance
Telecontrol AI
OFF
20
