Montageanleitung
EDK84AYCO
.R/y
Ä.R/yä
EtherNet/IP

E84AYCEO
Kommunikationsmodul
Communication module
Module de communication
Módulo de comunicación
Modulo di comunicazione
Mounting Instructions
Instructions de montage
Instrucciones para el montaje
Istruzioni per il montaggio
L−force Communication


2
EDK84AYCO DE/EN/FR/ES/IT 2.0
0
V
Lesen Sie zuerst diese Anleitung und die Dokumentationen auf der im Lieferumfang
des Grundgerätes enthaltenen CD−ROM, bevor Sie mit den Arbeiten beginnen!
Beachten Sie die enthaltenen Sicherheitshinweise.
Please read these instructions and the documentation on the CD−ROM supplied
together with the basic device before you start working!
Observe the safety instructions given therein.
Avant de commencer les opérations, lisez tout d’abord le présent manuel d’utilisation
ainsi que la documentation présente sur le cédérom comprise dans la livraison de
l’appareil de base !
Respectez les consignes de sécurité indiquées.
Antes de empezar con los trabajos, lea detenidamente estas instrucciones y la
documentación que se encuentra en el CD−ROM suministrado junto con el equipo
básico.
Observe las instrucciones de seguridad correspondientes.
Prima di utilizzare l’apparecchiatura, leggere le istruzioni contenute nel presente
manuale e la documentazione sul CD−ROM fornito in dotazione con il modulo asse.
Osservare le note di sicurezza.


3
EDK84AYCO DE/EN/FR/ES/IT 2.0
Stop!
Das Kommunikationsmodul enthält elektronische Bauteile, die durch elektrostatische
Entladung beschädigt oder zerstört werden können.
Treffen Sie vor dem Berühren des Moduls geeignete Maßnahmen zum Schutz der
Bauteile.
Stop!
The communication module contains electronic components that may be damaged or
destroyed through electrostatic discharge.
Take appropriate measures to protect the components before touching the
communication module.
Stop !
Le module de communication contient des composants électroniques qui peuvent être
endommagés ou détruits par les décharges électrostatiques.
Avant d’entrer en contact avec le module, prenez les mesures appropriées pour
assurer la protection des composants.
¡Alto!
El módulo de comunicación contiene piezas electrónicas que pueden resultar dañadas
o destruidas por descargas electroestáticas.
Antes de entrar en contacto con el módulo, tome las medidas necesarias para proteger
las piezas.
Stop!
Il modulo di comunicazione contiene componenti elettronici che possono essere
danneggiati o distrutti da scariche elettrostatiche.
Prima di toccare il modulo, si raccomanda di prendere tutte le misure necessarie per
proteggere i componenti.


4
EDK84AYCO DE/EN/FR/ES/IT 2.0

E84YCEO001
10.25, 0.37 kW

5
EDK84AYCO DE/EN/FR/ES/IT 2.0
1

0.25, 0.37 kW
E84YCPM002D
E84YCPM002E
10.55 ... x kW

6
EDK84AYCO DE/EN/FR/ES/IT 2.0
0.55 ... x kW
E84YCPM002A
E84YCPM002B
X258 − X259/X260 − LED 2

7
EDK84AYCO DE/EN/FR/ES/IT 2.0
2
X258 − X259/X260 − LED
E84YCEO003
X258
Terminal Signal
+ DC 24 V (20.4 V − 0 %  28.8 V + 0 %)
I = 140 mA
− Ground
X258 Rigid Flexible
10 mm 0.2 ... 1.5 mm2(AWG 24 ... 16) 0.2 ... 1.5 mm2(AWG 24 ... 16)
X259 / X260
Pin Signal Cable
1 Tx +
2Tx −
3Rx +
4 ˘
5 ˘
6Rx −
7 ˘ S/FTP (Screened Foiled Twisted Pair, ISO/IEC 11801 / EN 50173), CAT 5e
8 ˘
IP address 3

8
EDK84AYCO DE/EN/FR/ES/IT 2.0
3
IP address
E84YCEO004
Switch IPADR
0
x16
0
x1
ÞC13005 (IP Config. Control)
0 1 Þ1 (C13000/4 (IP Address))
... ... ...
15 14 Þ254 (C13000/4 (IP Address))
15 15 ÞReset IP−Configuration:
lC13000 (IP Address)
lC13001 (Subnetwork Mask)
lC13002 (Gateway Address)
lC13005 (IP Config. Control)
lC13006 (Multicast IP Start Address)
lC13017 (Ethernet Config. Control)
lC13018 (Multicast Config. Allocation Control)
lC13021 (Quality of Service − VLAN−Tagging)
lC13846 (Address Conflict Detection)
[mm] 4

9
EDK84AYCO DE/EN/FR/ES/IT 2.0
4
[mm]
E84YCEO005
a b c c1
[mm] [mm] [mm] [mm]
E84AYCEO 67 50 57 8
