Lockly LATCH EDITION SECURE PGD628 User manual

LATCH EDITION
INSTALLATION
GUIDE
SECURE

Go to LOCKLY.com/installation to watch a video
version of this installation guide.
Download the BILT app in the Apple or Google Play
store for step-by-step interactive 3-D walk-through
installation instructions.
OROR

Reference installation parts overview foldout on back page
Welcome!
This guide will walk you through step-by-step how to
install and get your LOCKLY
®
Secure up and running.
Installation generally takes less than 30 minutes. If
you have any questions please reference our online
support at: LOCKLY.com/support or call (669)
500-8835 for help.

3
Preparation
Phillips Screwdriver
To complete the installation you will need:
Flathead Screwdriver Tape measure or ruler
Pliers
（Optional）
Screwdriver with drill bits
Drilling is not required to install the lock, and is optional. However if you are installing
your lock on a brand new door, a drill is required if there are no holes prepared for
lock installation.

4
Preparation
1 " - 2"
(35mm - 50mm)
2 "
54mm
1"
25mm
Backset
2" (60mm)
or 2 " (70mm)
IMPORTANT NOTICE
*
Measure and confirm your door is
between
1 " - 2" ( 35mm - 50mm).
Measure and confirm the hole in the
door is
2 " (54mm).
Measure and confirm that the backset
is between
2 " (60mm) to
2 " (70mm).
Measure and confirm that hole in the
door edge is 1” (25mm).
*You are not requiredto drill an extrahole on your door. We have provided double
sided Adhesive tape for you to help stabilize the lock during installation. Only drill ahole
if you wish to have added stability. Please refer to the provided template for drilling if
needed.
Remove existing door hardware, latch or deadbolts before installing the new lock.
Use provided template to bore new holes if needed.
1
2
3
4

5
INSTALLING THE LOCKSET
Step 1
Measure the distance between center of front door hole to the edge of your door
and select the correct lockset. Select F1 if 2-3/8"(60mm)or F2 if 2-3/4"(70mm).
2-3/4"
(70mm)
2-3/8"
(60mm)
F 1 F 2
8
"
m
Facing the door exterior, install the lockset according to the opening direction of your door.
In-swing Door Out-swing Door
G
G
G
G
OR
Secure lockset with provided Gscrews.

6
CHANGING HANDLE FOR RIGHT OR LEFT SWING DOORS
Step 2
R
The lock ships set for right swing doors. Skip STEP 2 if your door is a right swing door.
See steps below to change door handle orientation for a left swing door.
Determine right swing or left swing door
While facing the door from the inside, if hinges are on the right side you have the right swinging
door. If hinges on the left side you have a left swinging door.
Changing the Exterior Handle Orientation
(Right handle)
Insert key and rotate lock
face so that the two white
dots align as shown.
Use the provided pin insert Rto
push the metal pin located at
the 3 o’clock of the the base
handle, then the other pin at
9 o’clock position. Remove the
handle once the pins are
compressed.
Rotate the handle 180o
to the other side of the lock.
Using your fingers, press the
two pins located on the left
and right side of the the lock
to insert the handle back
onto the lock.
12 3

7
CHANGING HANDLE FOR RIGHT OR LEFT SWING DOORS
Step 2 continued
Confirm that your installation was
complete by checking if the pins
are flush against the handle, and
has popped out. Adjust the handle
accordingly to make sure the pins
are fully decompressed and sits
flush against the surface.
Check that your handle works
smoothly by giving it a turn up
and down.
Twist key back to horizontal position. The key can
be taken out once it goes back to the horizontal
position.
45
6

8
Remove the screw by turning counter
clockwise and rotate the handle 180° in
the direction of the arrow as shown.
Make sure the screw hole is aligned with
the marker as illustrated.
Changing the Interior Handle Orientation
Securely screw clockwise as shown
to complete your handle orientation
change.
CHANGING HANDLE FOR RIGHT OR LEFT SWING DOORS
Step 2 continued
12

9
PREPARING LOCK FOR INSTALLATION
Step 3
2
D
3
If you drilledahole in Preparation, use SlottedBarrel Extension Uand securely tighten with aflat head
screwdriver by turning it clockwise onto the lock. If you did not drill ahole in Preparation, you can leave
this pole removed.
1
Install Spindle Cwith
the holes side into the
base of the lock and
align the holes locate
in the 3 o’clock and
9 o’clock position.
Insert locking pin D
in to the hole as
shown above.
Carefully bend the end
of the locking pin Dwith
a needle nose pliers.
Failure tobend the locking
pin and turn the handle
freely without obstruction
will result tomalfunction.
4Peel paper layer OFF the
Adhesive tape and
prepare for installation.

10
INSTALLING THE LOCK (EXTERIOR)
Step 4
Exterior
Install the exterior lock as shown
to the left by aligning the lock
straight and passing the cable and
attached rods through the lockset.
Align the lock straight and press
hard (if you use the Adhesive tape
in step 3.4) to secure the top of the
lock.
Pass the Spindle Cthrough
the center of the lockset, and
the round rods through the sides
in their respective holes. The cable
should run underneath the lockset.
1
2
3

11
INSTALLING THE LOCK (INTERIOR)
Step 5
Interior
Positioning rods slide
through these holes.
Install the side with the black
plastic seal against the door.
Insert Positioning Rods Vinto
the holes to the left and
right of the Spindle C.
The holes are located at the 3
o’clock and 9 o’clock positions.
Interior Mounting Plate LK will go
against the interior side of your door.
Remove the paper layer off of the
Adhesive Tape and align the
positioning rods on the bottom of
the plate to the corresponding left
and right holes.
V
Mounting Plate LK
1
2

12
INSTALLING THE LOCK (INTERIOR)
Step 5 continued
* If you have drilled a hole on the
top in Preparation, please secure
the hole with screw M1 or M2
depending on your door thickness.
Skip this if no hole was drilled in
Preparation.
P M 5 X 2 5 m m
P M 5 X 3 5 m m
LK
O
3
x
Pull the cable from the lock
exterior through the rectangular
hole underneath the positioning
rods and spindle.
Secure the hole above the
spindle with screws O.
Remove the position rods V
and replace them with
screws OTighten clockwise until
the mounting plate is secure.
Screw O
*Secure top with M1 or M2
Screw O
M1
M2
3
4

13
INSTALLING THE LOCK (INTERIOR)
Step 5 continued
Align the square rod to the lock interior and attach
the Interior lock to the Interior mounting plate.
While you are doing so, gently push some
of the excess cable through the rectangular
hole into the door.
Place the remaining cable against
the interior side of the lock interior
so the lock interior sits securely
onto the mounting plate.
5
6
X
Y
Plug Xcable that is coming through the door into the lock
interior Y. Match red side of the plug with red on socket -
insert tightly.
NOTE: If you need to disconnect the cable,
make sure to press the snap tab to release the
plug before carefully pulling it out. Do not force,
as this may result in damaging the lock.
Make sure the cable is away and
not tangling with the square rod C

14
INSTALLING THE LOCK (INTERIOR)
Step 5 continued
+
+
-
-
P (3X)
Once the lock interior is flush against the
mounting plate, secure the lock to the
plate by screwing clockwise using
provided screws P.
Insert 4 AA batteries into the lock by
aligning the positive +and negative -
orientation markings on the batteries to
the battery chamber.
Secure the battery cover by sliding the
cover over the lock and turning the screw
clockwise on top until tight.
7
8

15
INSTALLING THE DOOR STRIKE
Step 6
（2X）
DOOR STRIKE INSTALLATION
Close your door to see if your lock closes securely with your existing door strike. If the lock closes
securely, you may keep the existing door strike without removing the old hardware. However, it’s
recommended that you use our door strike.
F
H
G
Make sure the slanted side of Latchbolt ( F1 / F2 ) is closing against
the slanted part of Strike Plate Hbefore fixing it on to door frame.

16
DOWNLOAD THE LOCKLY
®APP
Step 7
Congratulations! You have completed the LOCKLY Secure physical lock installation. To complete
your setup, download the LOCKLY app from the iOS or Google Play app Store and follow
on-screen instructions.
Scan or visit
LOCKLY.com/app

17
Smart Home Ready
Always In The Know
Lock, unlock, and monitor your smart lock remotely, whenever,
wherever. The 2.4 GHz ( 802.11 b/g/n) Wi-Fi enabled hub connects
seamlessly to your smart lock and app, and provides live updates
whenever you need them including live access history without
connecting via Bluetooth to the lock.
Connected.
Wireless Door Sensors
No more worries wondering if your door was shut when you locked
your door. Included is a set of wireless door sensors that can
provide accurate information on the status of your door. Whether
it's securely shut or still open.
You can add live status monitoring and voice control capabilities to your LOCKLY®Smart Lock with
Amazon Alexa or Google Assistant via installing the Secure Link (PGH200) Wi-Fi Hub and Door
Sensors (Sold Separately)
Know it’s Closed.
SECURE LINK
Amazon Alexa or Google Assistant
Configure your voice commands in your Alexa or Google Assistant
app to work with your smart lock. Give commands like “Is my front
door locked?” or “Lock my front door”
Smart Home Integration
Get one now to enable the above features.
https://LOCKLY.com/hub

FCC Warning：
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
FCC Radiation Exposure Statement
The Secure Link Wi-Fi Hub complies with FCC radiation exposure limits set forth for an uncontrolled environment. It should
be installed and operated with minimum distance 20cm between the radiator & your body.
IC WARNING
This device contains licence-exempt transmitter(s) that comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation,
Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre
le fonctionnement.
IC Radiation Exposure Statement
This equipment meets the exemption from the routine evaluation limits in section 2.5 of RSS-102. It should be installed and
operated with a minimum distance of 20cm between the radiator and any part of your body.
Cet équipement est conforme à l'exemption des limites d'évaluation habituelle de la section 2.5 de la norme RSS-102. Il
doit être installé et utilisé à une distance minimale de 20 cm entre le radiateur et toute partie de votre corps.
WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to
cause cancer. For more information go to www.P65Wamings.ca.gov.

INSTALLATION OVERVIEW & PARTS LIST
Exterior
T
O
3x
G
4x
P
3x
D
S
L K
N
Q
F
H
M
C
B
U
A
Adhesive
PM5x 25MM Screw, Door thickness 1-19/50"~1-69/100"(35~43mm)
BatteryCover
BM4 × 8MM Screw
Interior Assembly
Mounting Plate
Interior Adhesive
Strike Plate
KA4x 20MM Screw
Locking Pin
Spindle
SlottedBarrel
Extension
Exterior Adhesive
Exterior Assembly
F1 Latchbolt F2 Latchbolt
Keys
Latch
PM5 Screw
BM4 x 32MM Screw
PM5x 35MM Screw, Door thickness1-69/100"~1-97/100"(43~50mm)
M 1
M 2
*NOTE: You can either use the exterior adhesive(T)or slottedbarrelextension (U) to stabilize the
exterior part. Slottedbarrelextension (U) requires drilling an extrahole. Use provided Template
for drilling instructions if needed.
2-3/4"
(70mm)
2-3/8"
(60mm)
Measure distance between the center of the hole to the edge of door:
Use F1 if 2-3/8"(60mm)or F2 if 2-3/4"(70mm)
R
Clamping Tool
For changing
handle orientation
W
2x
Positioning Rod
For installing mounting
plate (LK)
Activation Card
This lock can be installed for both right swing and left swing doors. The lock ships ready for a right swing
door installation. If you wish to change the orientation of the lock for a Left Swing door, follow instructions
on Installation Guide (Step 2) or the BILT App (Step 10).
LOCKLY.COM|HOTLINE: [phone]| EMAIL: [email protected]
AUTHENTIC LOCKLY PRODUCT | DESIGNE D IN USA | CA RD I S PRINTED WITH A SPECIFIC PATT ERN
SECURE ADDITIONAL DOORS AT A DISCOUNT: HTTP://WWW.LOCKLY.COM/MORE
ACC20200402
LOCK SERIAL
ACTIVATION CODE
PGDxxxxxxxxxx
xxxxxxxxSCAN & SAVE
