Lockly LATCH EDITION SECURE PLUS User manual

USER MANUAL
LATCH EDITION
SECURE PLUS
with Fingerprint and RFID Card
PGD628FC
ERP机型：PL3572FCQ-GL-SMT00010A-V1
Designed：曹显贵
7540C
Date：2022-07-07
描述:
说明书:PL 3572FCQ/PGD628FNC,SMT000,REV. A(UMPGD62820220707）,196x196mm,
封底、面:128g双粉卡双面过哑油,双面单黑，内页:80g书纸,双面印单黑，16页32面装
订本，
RoHS2.0,REACH,Prop65，POPs，PAHs
ERP P/N：
REV：1.0
KC

Section 1 - Product Highlights
Section 2 - Product Overview
Section 3 - Using Your Smart Lock
3.1 Configuring Access
3.2 Adding a Fingerprint
3.3 Fingerprint Scanning Directions
3.4 Fingerprint Scanning Tips & Troubleshoot
3.5 Adding an RFID card
3.6 Adding Secure Link
1.1 Product Features
Section 5 - Advanced Features
Section 7 - Important Notes
Section 8 - Maintenance and Cleaning
Section 9 - Safety Precautions
9.1 Safety Precautions
1
2
3
4
5
6
5
7
8
9
10
12
13
14
14
15
16
17
19
18
18
20
22
24
25
23
23
26
27
27
28
2.1 Product Overview - Exterior
2.2 Product Overview - Interior
2.3 Understanding Your New Lock
2.4 Reset Button
2.5 Keypad Display Switch
2.6 Rebooting Your Lock
2.7 Low Battery
2.8 Changing The Battery
4.4 Unlocking using RFID
4.5 Locking/Unlocking using Physical Key
4.6
Locking/Unlocking using Voice Assistants
4.7 Safe Mode
4.8 Rain Mode
4.9 Shine Mode
4.10 Welcome Mode
Section 4 - Locking and Unlocking
5.1 Offline Access Code™(OAC)
5.2 Sub-Admin Access
7.1 Important Notes
Section 6 - Re-keying
25
6.1 Re-keying
8.1 Cleaning
8.2 Calibrating the Lock
Table of Contents
TABLE OF CONTENTS
For additional support, visit http://Lockly.com/help or
email [email protected]
4.1 Unlocking using Access Codes
4.2 Unlocking using Fingerprint
4.3 Locking/Unlocking using App

1.1 Product Features
1SECTION 1.1
Patented Hack-Proof PIN Genie Keypad
Digits are randomly displayed on the key pad ensuring access codes to be undetectable to intruders
after repeated use. Numbers are randomly distributed across 4 buttons, with 3 numbers in each button.
Users can press any button showing their number. Location of the numbers are always different every
time someone uses the keypad, making it hard for prying eyes to guess the correct code.
Multiple Access Codes & Monitoring
Store up to 18 Access Codes for family, friends and guests, as well as monitor entry and exit records.
Advanced 3D Fingerprint Recognition
Biometric Fingerprint Recognition protocol allows up to 99 registered fingerprints to be used and accepts
only actual fingerprints - preventing lifted prints from being used.
Live Monitoring and Voice Control
Through your smartphone, monitor door access from anywhere in the world and securely control who
comes and goes. You can also control your Lockly smart lock using your voice with Amazon Alexa or
Google Assistant-enabled devices.
Complete Privacy
The exterior displayed keypad can be locked and switched off using the simple ON/OFF toggle from
the inside panel. The owner can prevent others trying to input the passcode from the outside and entering
the home.
Offline Access Code™(OAC)
The offline access code can allow owners to issue access codes, set the allowed access duration, all
without Lockly ever connecting to the internet, so in case of power outage, you can still magically and
remotely issue Access Codes without any connection to the web.
Auto-Lock
Users no longer have to worry about forgetting to lock the door. With Auto Lock enabled, Lockly will
automatically auto-lock the door based on your customized timing set between 5-300 seconds.
Backup Keys and 9V Battery Socket
The door can be opened with physical backup keys. There is also a 9V battery connection socket for
emergency power backup to access the keypad in case your smart lock runs out of battery.

2.1 Product Overview - Exterior
2SECTION 2.1
Key Hole Cover
9V Battery Backup Socket
Key Hole
Touchscreen
Keypad Buttons
Battery Indicator
Welcome/Safe Mode
OK Button
Bluetooth Indicator
Handle
Fingerprint Sensor
Reboot
RFID Card Reader

Inside Handle
ResetButton
Program Button
Beep Alert
Battery
Compartment Cover
Battery Compartment
4 x AA Alkaline
Batteries(Included)
Keypad Display Switch
Low Battery Indicator/
Door Lock Button
Battery Compartment Screw
SECTION 2.2 3
2.2 Product Overview - Interior

2.3 Understanding Your New Lock
After the installation of your new Lockly, understanding some key functions of operating your smart
lock is important. The following guides will walk you through resetting a lock, adding/ deleting Access
Codes, adding/deleting fingerprints, adding/deleting RFID cards, configuring your Offline Access Code™
(OAC) and other features of your lock.
To access these features, you will need the Lockly app and a registered account. You may visit the link
below to download the app if you haven't done so.
For any questions you can always visit http://Lockly.com/help for assistance.
Scan or visit Lockly.com/app
4 SECTION 2.3

SECTION 2.4~2.5 5
2.4 Reset Button
In order to restore the Lockly Secure to factory default settings, you must have your “Activation Code”
available. The Activation Code can be found on the Activation Code Card that came with your smart
lock.
After you have the Activation Code ready, push the reset button on the back panel of the Lockly Secure
to perform your reset. See below to see which Reset Process applies for you. Once the smart lock has
been reset, all the data previously stored will be deleted.
2.5 Keypad Display Switch
The exterior keypad screen can be locked and
turned off by using the ON/OFF switch at the back
panel (interior) of the smart lock. When it is switched
off, people who are outside cannot enter any
access codes to unlock the door.
If Paired with App If Never Paired
Press Reset Button for
three (3) seconds
Press Reset Button
for one (1) second
and till you hear a
short beep.
Open the Lockly
smartphone app to
add your lock using
the Activation Code
Reset Button

6
2.6 Rebooting Your Lock
Reboot Button
NOTICE
Reboot Lockly in case of dead battery or malfunction. No settings
will be changed and all Access Codes will still be stored within Lockly.
SECTION 2.6
Press and release the reboot button when you want to reboot the lock. Your Lockly will beep once after
reboot. Only reboot when necessary.
To reboot, find the reboot button located on the bottom of the exterior side of Lockly lock. The reboot
button is located in the middle of the two 9V battery backup sockets.
You will need something small such as a paperclip, to press the reboot button. Insert the paperclip and
press down firmly and let go. Your screen should restart and the lock should reboot automatically.

7SECTION 2.7
9V Battery
-
+
2.7 Low Battery
When the battery is in seriously low condition, Lockly will make continuous beeping sounds in addition
to the flashing low battery icon on the touch screen. You should replace batteries immediately to
avoid your smart lock from shutting down.
When your smart lock low-battery warning alert finally dies, you will have 3 chances to unlock your smart
lock either by a password, APP or fingerprint. If the unlock was successful, the low-battery warning alert
will be on for 1 minute. After which, the smart lock will go to dead-battery mode and will lock auto lock
in 5 seconds and the screen will display a low-battery icon.
Dead Battery
Condition Indicator Solution
Low Battery
Battery Icon on the display
keypad will light up to indicate
low battery.
Replace batteries immediately to
avoid battery failure. Lockly Secure
can still operate up to 300 cycles
in low battery condition.
When there is no display
and sounds; and screen is
non-functional.
Replace batteries immediately.
Supplied physical backup keys
can be used to unlock the door.
Alternatively, use a 9V battery as
shown below to temporarily
activate the lock.
Your Lockly will automatically detect battery polarity.
So hold your 9V battery lead in place against bottom
of the Lockly to temporarily activate the screen to
enter your Access Code. Be sure to hold the 9V
battery against the contact points located at the
bottom of the lock until you have successfully unlocked
your door with your Access Code. Once unlocked,
batteries should be replaced immediately.

8SECTION 2.8
2.8 Changing The Battery
12AA 1.5V X 4
3
+
+
-
+
-
-
+
-
Screw
Under normal use, the Lockly battery will last up to a year. Please check battery levels regularly and
change your batteries when the low battery notification is issued. For best practice, always use new
batteries by a major brand.
Open the battery compartment cover and insert four (4) new AA alkaline batteries as shown. Be sure
to unscrew the screw located on the top of the cover first by unscrewing counterclockwise before
sliding the cover up.
- Make sure the batteries are oriented correctly by matching the orientation displayed.
- Replacing the batteries do not reset stored Access Codes.
- To see a list of recommended brands, please visit http://Lockly.com/battery
NOTICE
Whenever batteries are replaced, reconnecting the smart lock to your smartphone
App is required.
If you have not yet downloaded the app, visit: Lockly.com/app

SECTION 3.1 9
3.1 Configuring Access
The Default Access Code is
NOTICE 1 2 3 4 5 6
Your new Lockly Access Code can be any combination of 6 to 8 digits. Once a new Access Code is
entered, the Default Access Code of 123456 would be deleted. A maximum of 16 sets of Access Codes
can be stored for use at any given time. To add more than 16 sets of Access Codes, you must delete
an existing Access Code before adding a new code.
There are a total of five (5) buttons on the keypad as shown in the
example image to the left. The numbers in each button may differ
than what is shown on your device than what is displayed here.
To enter your required digit, just simply press the circle where your
number is shown. You do not need to press the actual number as
anywhere within the circle will suffice.
The button on the bottom is the OK button. You will be pressing
this button when you are done entering your Access Code.
OK Button
IMPORTANT: Pairing your lock to your smart phone is required to manage your access
codes, fingerprints and RFID cards. To pair you lock, you need to download the Lockly
app and the Activation Code Card, then follow on-screen instructions.
There are different types of Access Codes that can be generated using the Lockly App. Each type of
access code have different levels of permission you can select for your guests, tenants, deliveries, helpers,
etc., Get the latest updates on access codes, visit: www.support.lockly.com/faq/accesscodes/

10 SECTION 3.2
3.2 Adding a Fingerprint
Fingerprint Pattern with
Cross Intersection Lines
Concentric or Parallel Pattern
with no Cross Intersection Lines
Fingerprint with Scars or
Worn Out Ridges
OK Not OK Not OK
We are using an advanced biometric sensor, providing the most secure fingerprint authentication. For
security reasons, Lockly will only accept fingerprint patterns that consist of cross intersection points.
Patterns with no cross intersection points will not be acceptable.
Please check your fingers before registration to make sure the finger you want to register will be
acceptable by our system. Otherwise, use an alternative finger to ensure successful registration.
The following examples show which types of fingerprint patterns will be acceptable. It is highly
recommended to enroll at least one finger from each hand in case the hand you are using is
unavailable, such as, in instances like if you are holding items in that hand or have sustained an injury.
Your smart lock can register up to ninety-nine (99) fingerprints. Please read the following sections
if you want to add or delete fingerprints. We recommend using your app to add fingerprints,
however, the following section can show you how to add and remove fingerprints if you did not
pair your lock with a smart phone.
NOTICE
Please make sure your fingers are clean from dirt and oils before scanning
your fingerprint. Make sure the sensor is also clean by taking a soft cloth and
wiping the surface.

SECTION 3.2 11
3.2 Adding a Fingerprint (Continued)
OK Button
PASS will be displayed on the keyboard and automatically returns to number keypad. If you did not
successfully register your fingerprint, FAIL will show on the keypad. If FAIL is displayed, return to the
previous menu and rescan your finger.
Once you’re in Fingerprint Registration Mode you will see two numbers
displayed on keypad. The top number is your Fingerprint Registration
number, in this example to the left, “1”. The bottom number will always
start with a “6”.
You must successfully scan your fingerprint six (6) times for it to properly
register. Every time you scan your fingerprint, the number on the bottom
will change, starting from 6 - then 5, 4, 3, 2, 1, until the fingerprint is
successfully registered.

12 SECTION 3.3
3.3 Fingerprint Scanning Directions
The fingerprint sensor equipped in your smart lock is loaded with powerful fingerprint algorithms to extract
only metadata from fingers, even in poor conditions. Placing your finger on the sensor correctly helps
consistency in fingerprint recognition. The following directions and tips will guide you on how to scan
an optimal fingerprint image.
Sensor
Core
Position your finger on the
center of the sensor
Top View
SideView
OK
OK
Correct
Incorrect

13SECTION 3.4
3.4 Fingerprint Scanning Tips & Troubleshoot
Tips for Fingerprint Enrollment and Recognition
• Place your finger to completely cover the sensor with maximum contact surface.
• Position the center of your finger (core) to the center of the sensor.
• Hold your finger still for more than a second until you hear a beep.
• Scan a finger that is clean and free from dirt.
• Children ages 12 and under are not recommended to use fingerprint access due to the constant
changes of their fingers during growth.
• Elderly with fading fingerprints may have difficulty in recognition.
• If your finger has a cut, scar, or cracked skin due to dryness, try another finger.
Troubleshooting Fingerprints
In case of poor fingerprint conditions
• If wet - wipe excess moisture from finger before scanning
• If dirty - wipe stains and dirt off from finger before scanning
• Make sure the sensor is clean from dirt or smudges - wipe sensor with soft cloth regularly
For more troubleshooting help, visit http://Lockly.com/help

14 SECTION 3.5 ~ 3.6
3.6 Adding Secure Link
Lockly Secure Link¹adds live status monitoring and voice control capabilities to your Lockly Smart
Lock. If you purchased a Secure Pro model, the Secure Link is included in your package. For all other
Lockly products, the Secure Link can be purchased and added anytime.
To set up the Lockly Secure smart lock with Secure Link Wi-Fi Hub and Door Sensors, launch the Lockly
App on your iOS or Android™device. From the main menu drop down located on the upper left of
the screen, select “Add a New Device” then select “Secure Link Wi-Fi Hub” . Follow the in-app
instructions to set up your Secure Link.
To activate voice commands, you will need Amazon Alexa or Hey Google. Make sure you enable
the Lockly Action on Google or the Amazon Alexa Skill before you can configure your voice to perform
voice commands.
¹Included in Secure Pro and sold separately for other models.
Visit the link below to purchase:
https://Lockly.com/hub
3.5 Adding an RFID card
Once you’re in RFID Registration Mode,
the screen will display the RFID card
series number when adding.
Place the RFID card to the
screen where the RFID card
sensor is embedded.
PASS will show on the
keypad once card is
registered successfully.

SECTION 4.1 15
4.1 Unlocking using Access Codes
Slide your hand across the screen to activate the keypad.
Enter your 6 to 8 digit Access Code followed by the OK
button. Press OK anytime to reset if you entered the
wrong digit.
If the Access Code entered is correct, the door will unlock.
If the Access Code entered is incorrect, Lockly will beep twice.
Three consecutive wrong attempts will put Lockly in “Safe Mode”. (See Section 4.7)
Lock your Lockly by pressing the OK Button or by brushing your hand across the screen anytime when
the door is closed. The smart lock will also auto-lock after unlocking based on your set auto-lock settings.
You may toggle between two types of keypad displays
to enter your Access Code. The fixed digit version and
the PIN Genie version (Recommended). Press and hold
the OK Button for 3 seconds to toggle back and forth
between the two keypads.
(Sample display shown only)
Hold OK (3 sec)
PIN Genie Fixed Digit
Lockly Smart Lock can be unlocked using multiple ways - via your stored Access Code, registered
fingerprint, smartphone with Bluetooth, the physical key supplied with your lock, or voice (Secure Pro
only or Secure Plus with Secure Link Wi-Fi Hub installed)
OK Button

16 SECTION 4.2
4.2 Unlocking Lockly using Fingerprints
Place a registered finger to the fingerprint scanner
located on the exterior side of the lock to the right.
To register a fingerprint, please see Section 3.6.
If your fingerprint is registered and acknowledged,
you will hear a “beep” sound and a Green LED will
light up on the fingerprint scanner. You can then
push down the handle and open the door.
If you see a Red LED, it means your fingerprint is not
recognized. Try again or use another registered
fingerprint.
For best fingerprint scanning practices, see Section
3.7.
OK Button
Locking
Unlocking
To lock your smart lock, press the OK Button anytime
or brush your hand across the screen when the lock
is unlocked.

17
4.3 Locking/Unlocking using App
You must have the Lockly iOS or Android™app installed in order to lock and unlock with smartphone
and connect with your Amazon Alexa or Google Assistant-enabled devices. Please download the
app by visiting the link below or search “Lockly” from the correct app store.
SECTION 4.3
Scan or visit
Lockly.com/app

4.5 Locking/Unlocking using Physical Key
Exterior View
To unlock your lock using the phys-
ical key (included), open the key
cover by sliding the cover on
either clockwise or counterclock-
wise to reveal the keyhole.
Insert key and turn clockwise (right
swing door) or counterclockwise
(left swing door) to unlock the
door.
18 SECTION 4.4 ~ 4.5
4.4 Unlocking using RFID
Light up the screen by
touching the keypad.
Place your RFID card
closer to the panel.
Push down the handle
and open the door
after it chimed.
